Page 1: User Manual
DIGITAL COLOR CAMERA user manual imagine Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsungsecurity.com the possibilities SCC-B2333(P) SCC-B2033P... -
Page 2: Safety Information
fi re or electric shock. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifi cations or attempted repair.) 2 –... - Page 3 When cleaning, do not spray water directly onto parts of the product. Doing so may cause fi re or electric shock. CAUTION Do not drop objects on the product or apply strong shock to it. Keep away from a location subject to excessive vibrationor magnetic interference.
-
Page 4: Important Safety Instructions
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifi... -
Page 5: Table Of Contents
Introduction Features PRODUCT & ACCESSORIES Part Names and Functions Installation Connecting the Auto Iris Lens Connector Mounting the lens Connecting cables and checking operation How to use OSD Menu Using Icons in the Menu Main Menu Camera Setup Intelligence Privacy Zone Setup Other Set Communication System Information... -
Page 6: Introduction
Introduction FEATURES ❖ High Resolution • This camera has realized high resolution of 600 lines using the top-notch full digital image processing and special algorithm technologies. ❖ Intelligent Motion Detection & Tracking • This is an intelligent function that automatically detects a motion of an object. You can set a virtual fence so it sounds an alert if an object passes / enters /exits the virtual fence or virtual area. -
Page 7: Product & Accessories
PRODUCT & ACCESSORIES ❖ Product & Accessories • Main Product • Accessories C Mount Adapter Camera Holder(Mount) Introduction Camera User’s Manual Auto Iris Lens Connector English –... -
Page 8: Part Names And Functions
Introduction PART NAMES AND FUNCTIONS ❖ Side View Auto Iris Lens Connector Auto Iris Lens Control Cable • Auto Iris Lens Connector This groove is used for screwing the mount adapter, a part of the bracket where the camera will be installed. •... - Page 9 Introduction ❖ Rear Panel <AC24/DC12V (B2333(P))> <AC220V~240V(SCC-B2033P)> English –...
- Page 10 Introduction Input/Output Connector This connector has input and output ports for RS-485 control signals, DAY/NIGHT switching, and alarm output signals. Function ALARM OUT SHUTTER (S0) SHUTTER (S1) SHUTTER (S2) 5V OUT DAY/NIGHT IN RS-485 DATA- RS-485 DATA+ SETUP Switch This switch is used to set the function or property. When this switch is pressed for at least 2 seconds, the MAIN MENU appears.
-
Page 11: Installation
CONNECTING THE AUTO IRIS LENS CONNECTOR Connect each uncovered shutter control cables to the Auto Iris Lens Connector as the following DC Control Video Control Type Type Damp(-) Power (+12V) Damp(+) Not applicable Drive(+) Video Signal Drive(-) Note : You can switch a control type of the lens in the menu. -
Page 12: Connecting Cables And Checking Operation
Installation CONNECTING CABLES AND CHECKING OPERATION Connect one end of the BNC cable to the VIDEO OUT Port on the rear of the camera. Connect another end of the BNC cable to the VIDEO IN Port on the monitor. Video In Terminal of Monitor Rear Surface 1 . -
Page 13: How To Use Osd Menu
How to use OSD Menu USING ICONS IN THE MENU • (EXIT) Exits the menu setting. Before you exits the menu setting, select SAVE to save your settings, or select QUIT to cancel. • (RET) Returns to the previous menu. •... -
Page 14: Profi Le
How to use OSD Menu PROFILE PROFILE STANDARD BACKLIGHT DAY/NIGHT GAMING CUSTOM In the PROFILE menu, you can confi gure the following camera settings at once. CAMERA SET Menu STANDARD Previous Sub-menus Menu IRIS LENS LEVEL BACKLIGHT MOTION (F.FAST)--- SHUTTER SENS-UP DAY/ NIGHT... - Page 15 How to use OSD Menu CAMERA SET Menu STANDARD Previous Sub-menus Menu WHITE MODE ATW2 BLUE NIGHT User setting BRIGHTNESS allowed MODE User setting allowed User setting BLUE allowed DETAIL ❖ It will be set automatically so you can easily check the traffi c conditions. ❖...
-
Page 16: Camera Setup
How to use OSD Menu CAMERA SETUP CAMERA SET CAMERA ID IRIS MOTION (F.FAST)--- SHUTTER SENS-UP AUTO X4 FLICKERLESS (OFF)--- DAY/NIGHT WHITE BAL DIGITAL ZOOM DETAIL V-SYNC AGC COLOR SUP REVERSE POSI/NEGA Setup the general functions of zoom camera module. Use the switch to select a menu item. - Page 17 How to use OSD Menu The LEVEL menu is used to adjust the overall brightness, where “+” will increase the brightness and “–” will decrease it. If you set the BACKLIGHT option to BLC, you will see a menu where you can set the BLC area.
- Page 18 How to use OSD Menu AGC FIX LEVEL [01] If you press the SETUP switch with a FIX sub menu selected, you will see the appropriate screen. As a fi xed value of the AGC gain is used in FIX mode, you can select one of the 16 detailed levels from VERY LOW to VERY HIGH before fi...
- Page 19 How to use OSD Menu 1/2000 1/4000 1/10K Note : If IRIS mode is set to ELC, the SHUTTER menu will be – deactivated as you adjust the brightness using the electronic shutter. If the SENS-UP function is set to AUTO, only items of –...
- Page 20 How to use OSD Menu • AUTO The camera will automatically switch between DAY and NIGHT mode, according to the lighting condition. If you press the SETUP switch with an AUTO- based sub menu selected, you will see the appropriate screen. AUTO BURST DAY NIGHT...
- Page 21 How to use OSD Menu • NIGHT Use the NIGHT mode if you want to set the white balance differently according to the ambient luminance. If the NIGHT mode is set to OFF, the white balance will always operate as set in DAY mode; if not to OFF, the camera will switch to as set in DAY/NIGHT mode according to the brightness.
-
Page 22: Intelligence
How to use OSD Menu ❖ V-SYNC [INT, LINE] Select the vertical sync mode for INT or LINE. If you select INT, the camera will use the internal synchronization. If selecting LINE, the camera will use the external power source frequency for the synchronization. You can adjust the LL-PHASE. - Page 23 How to use OSD Menu FENCE LINE AREA You can set the position and detection direction of the LINE, and the size and position of the AREA. - How to set the line LINE PIXEL LEVEL <POINT> DIRECTION If you press the SETUP switch with the LINE option set to ON, you can specify the position and detection direction of the line.
-
Page 24: Privacy Zone Setup
How to use OSD Menu ❖ MASK AREA [1~4] Specify a detection exception area to mask. Select a mask number and specify the size and position. MASK AREA <SIZE> <LOCATION> ❖ DISPLAY [ON, OFF] With the DISPLAY option set to ON, a motion or a set ADVANCED function will be displayed on the screen, if detected. -
Page 25: Other Set
How to use OSD Menu - How to set the point You can set each position of the 4 points. If you press the SETUP switch in <POINT>, you will see the points available in the PRIVACY ZONE. Each time you press the SETUP switch, the points available will move. -
Page 26: Communication
How to use OSD Menu COMMUNICATION COMMUNICATION RS-485 PROTOCOL SAMSUNG BAUD RATE ADDRESS The COMMUNICATION menu is used to confi gure the settings regarding RS-485 communications. Use the rear panel of the camera to connect to RS-485. [Camera I/O Connector]... - Page 27 How to use OSD Menu ❖ Initial Confi guration Table • Camera Confi guration CAMERA ID IRIS VERY HIGH MOTION SHUTTER SENS-UP FLICKERLESS DAY/NIGHT DIGITAL ZOOM DETAIL AGC COLOR SUP REVERSE POSI/NEGA V-SYNC (F.FAST) AUTO x4 (OFF) AUTO English –...
-
Page 28: Specifi Cations
Specifi cations SPECIFICATIONS Items Camera Type Image Pixels System Scanning Line Frame Scanning Horizontal Frequency Vertical Frequency Min. Scene Illumination Number of Privacy Zone Motion Detection eXtended Dynamic Range(XDR) High Speed Shutter Functions White Balance Digital Noise Reduction(DNR) Digital Image Stabilization(DIS) Intelligent Video 28 –... - Page 29 Items Sub-items Horizontal Resolution Vertical Video Output S/N Ratio S/N Ratio Lens Drive Type Lens Mount Type Input Alarm Output Coaxitron (Data On Coax cable) Remote Control RS-485 Operating Temperature Environmental Conditions Humidity Power Requirement Power Power Consumption (With DC Lens) LED Indicator Dimensions (WxHxD)
- Page 30 512 times 512 times Day/Night D-Zoom Flickerless Sens-Up Line Lock Camera ID Etc. Function Horizontal Vertical SCC-B2333P / SCC-B2033P 1/3” Super-HAD IT CCD 795 x 596 752 x 582 Interlace 625 lines 25frame/1sec 15,625 Hz 15,625 Hz 50 Hz 50 Hz Min.
- Page 31 In switching the DAY/NIGHT fi lter : SCC-B2333P :2.8W SCC-B2033P : 3.4W SCC-B2333P : 64(W) x 58(H) x 109.2(D) mm SCC-B2033P : 64(W) x 58(H) x 129.2(D) mm Package 173(W) x 99(H) x 115(D) mm SCC-B2333P : Approx. 305g SCC-B2033P : Approx. 395g SCC-B2333P : Approx.
- Page 32 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
