Fulham FireHorse FHEX26 General Installation Manuallines

When using electrical equipment, including this emergency exit product, basic safety
precautions should be followed at all times, including but not limited to the following:
PLEASE READ CAREFULLY AND FOLLOW ALL INSTRUCTIONS FOR YOUR SAFETY
1. All service shall be performed by qualified service personnel. This product must be installed and
maintained in accordance with the applicable installation codes by a person familiar with the construction
operation of the product and the hazards involved.
2. This product must be installed in accordance with the applicable installation codes and ordinances.
3. Before wiring to power supply, turn off electricity at fuse or circuit breaker.
4. Disconnect A.C. power and unplug battery before servicing.
5. Consult your local building code for approved wiring and installation.
6. May be used outdoors under cover. (-10°C - 50°C / 14°F - 122°F).
7. Do not let power supply cord touch hot surfaces.
8. Do not mount near gas or electric heater.
9. Equipment should be mounted in locations and at heights where it will not readily be subjected to
tampering by unauthorized personnel.
10. The use of accessory equipment not recommended by manufacturer may cause an unsafe condition.
11. Do not use this equipment for other than intended use.
12. The AC voltage rating of this equipment is specified on the product label. Do not connect equipment
to any other voltage.
WALL MOUNT INSTALLATION
1. Use flat head screwdriver to loosen the screws on the lens.
2. Remove lens from sign, set aside.
3. Remove EXIT stencil from housing, set aside.
4. Drill or knock out appropriate knockouts on back plate to fit junction box mounting points.
5. Drill or knock out center hole in back plate for EXIT supply wire leads.
6. Remove backing from self adhesive junction box gasket and adhere to back plate.
7. Route EXIT input wires through center hole of the back plate and make wiring connection.
For 120V, use black and white wires and for 277V, use red and white wires.
8. Secure back plate to junction box (hardware not included).
9. Remove proper chevron(s) as required. When removing chevrons it may be helpful to
remove the color diffuser panel to allow easier access to the chevrons. If removing color
diffuser panel it is importsnt to remember to reinstall the diffuser panel once chevron(s)
have been removed.
10. Connect battery to lamp board (battery back up models only).
11. Secure face plate(s) to the housing.
12. Secure lens to face plate and securely torque screws.
13. Apply continuous AC power and press 'TEST" button to check operation.
Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: 1-323-779-2980 Fax.: 1-323-754-9060.
Specifications subject to change without notice.
GENERAL INSTALLATION GUIDELINES
FOR WET LOCATION EXIT FIXTURE
(FHEX26/FHEC34)
SAVE THESE INSTRUCTIONS
