7. Using the NASH

At activation, the NASH spends a little time to ensure that all supplies reach their nominal
levels, during which the model name is displayed.
After the activation delay is expired, some general operational information is shown on the
NASH display: the selected source, MM stage gain (not for line inputs) and the high pass
filter setting (not for line inputs).

7.1. Source selection

The NASH is provided with various inputs, therefore it is possible to connect different
sources and select which one to listen to.
To select a source, press the encoder shortly. The name of the current source will start
flashing on the display. Rotate the encoder until the desired source is displayed. Then,
press the encoder again to confirm: the new source will be selected.
Should the user change his/her mind and keep the current source, it is sufficient to push
the button to the left of the front panel (item 1 Fig. 1) or avoid doing anything else: After a
few seconds the NASH will automatically return in its "idle" status without changing the
source setting.
Sources can also be selected using the remote control, by the IN- and IN+ keys.

7.2. Menu Navigation

The NASH allows for configuring various parameters, some of which (the ones less
frequently changed) are grouped in a menu which can be navigated by both the front
panel's controls and the dedicated keys on the remote control.
To access the menu, keep the encoder pressed for at least two seconds or push the
"MENU" key on the remote control.
It is possible to scroll the various menu items with successive short pushes of the encoder
or with the "arrow up" and "arrow down" keys on the remote control.
