OWNER'S MANUAL AND INSTALLATION
SAFETY WARNING....................................................................................2
SETTING UP THE REFRIGERATOR ........................................................4
MAJOR FEATURES.....................................................................................4
CONTROL PANEL .......................................................................................5
DIGITAL PANEL ..........................................................................................7
TEMPERATURE CONTROL ......................................................................8
ICE AND COLD WATER DISPENSER .......................................................8
USING THE WATER DISPENSER(optional).......................................................9
SHELVES AND BINS ...................................................................................11
FOOD STORAGE GUIDE ........................................................................12
REMOVING FREEZER ACCESSORIES..................................................16
REMOVING REFRIGERATOR ACCESSORIES.....................................16
CLEANING ACCESSORIES......................................................................17
CHANGING THE INTERIOR LIGHT.........................................................18
WATER FILTER..........................................................................................19
DOORS.......................................................................................................19
INSTALLATION INSTRUCTIONS
INSTALLATION OF THE REFRIGERATOR ............................................20
REMOVING THE FRONT LEG COVER .........................................21
REMOVING THE REFRIGERATOR DOORS ......................................... 22
REATTACHING THE REFRIGERATOR DOORS....................................24
CHECKING THE WATER DISPENSER LINE ..........................................29
INSTALLAING THE WATER DISPENSER LINE......................................30
TROUBLESHOOTING...............................................................................35
Register your product at www.samsung.com/global/register
SIDE BY SIDE
REFRIGERATOR
CONTENTS
Drawer GUIDE.............................................................14
(optional) ............................................................16
DA99-00494B REV ( 1.3 )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS23FESW and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung RS23FESW

Summary of Contents for Samsung RS23FESW

  • Page 1: Table Of Contents

    REMOVING THE REFRIGERATOR DOORS ... 22 REATTACHING THE REFRIGERATOR DOORS...24 ADJUSTING THE CLEARANCE BETWEEN THE DOORS...27 CHECKING THE WATER DISPENSER LINE ...29 INSTALLAING THE WATER DISPENSER LINE...30 TROUBLESHOOTING...35 Register your product at www.samsung.com/global/register SIDE BY SIDE REFRIGERATOR CONTENTS Drawer GUIDE...14 (optional) ...16...

  • Page 2: Operating Instructions

    • The refrigerator only use ice makers which made by samsung Electronics for the refrigerator. • The incorporated ice-makers are to be installed only by the manufacture or its service agent.
  • Page 3 If the refrigerator is not to be used for a long period of time, pull out the power plug. • Deterioration in the insulation may cause fire.

  • Page 4: Setting Up The Refrigerator

    SETTING UP THE REFRIGERATOR Once you have performed the following steps, your refrigerator should be fully operational. If not, check the power supply and electricity source. If you have any questions, contact your SAMSUNG service center. Place the refigerator in an appropriate location with reasonable clearance between the wall and the refigerator.

  • Page 5: Control Panel

    FRIDGE TEMP. BUTTON To set the fridge temperature, press the but- ton repeatedly to change the set tempera- ture in sequence between 7°C and 1°C. POWER COOL BUTTON Speeds up the cooling process in the refrigerator...
  • Page 6 CONTROL PANEL Basic Model (With CoolSelect Zone) Cool Select zone Dispenser Model (With CoolSelect Zone) Cool Select zone...

  • Page 7: Digital Panel

    • This light is on when you press the Power Cool button. Power Cool Press the button to quickly return the refrigerator to the set temperature. • Press the button again to cancel the Power Cool mode. • This light indicates the recyclable deodorizer is in operation.

  • Page 8: Temperature Control

    • When ice cream is stored above -15°C in freezer, it may melt. • The temperature of the freezer or the refrigerator rises from frequent openings, when sweeping and from warm food. This may cause the digital display to blink . The digital display will stop WARNING blinking when the freezer and refrigerator return to the normal temperature.

  • Page 9: Filling The Water Tank

    USING THE WATER DISPENSER (OPTION) With the water dispenser, you can obtain chilled water easily without opening the refrigerator door. In addi- tion, you can save electricity by reducing the number of times the door is opened by more than 30%.
  • Page 10 INSTALLING A REGULAR BOTTLE Press the fixing lever, lift the exclusive water tank upwards, then remove it. Remove the water supply device from the exclusive water tank, then set the inner groove of the water supply device in a regular spring water bottle and fix it in position by turning it.

  • Page 11: Shelves And Bins

    SHELVES AND BINS FREEZER Basic model REFRIGERATOR Door Bin Light Shelf Twist ice maker Ice tray Drawer Front leg cover Model with ice and water dispenser Dairy compartment Lights Wine Self(Optional) Water tank Door Bin Beverage Station Foldable Shelf(optional) Deodorizer (optional)

  • Page 12: Food Storage Guide

    FOOD STORAGE GUIDE FROZEN FOOD STORAGE IN FREEZER Tempered Glass Shelf • Can be used to store all types of frozen food. Door Bin • Can be used for small packages of frozen food. Plastics Drawer • Can be used to store meat and dry foods. Stored food should be wrapped securely using foil or other suitable wrapping materials or containers.
  • Page 13 • Place your wine bottle on the shelf to maintain their taste. • If you have a long vacation planned, you must empty the refrigerator and turn it off. Wipe excess moisture from the inside and leave the doors open. Otherwise, odor and mold may develop.

  • Page 14: Coolselect Zone

    • “Chill” temperature helps keep meat or fish fresh longer. Cool • When “Cool” is chosen, the temperature will be the same as the set temperature of the refrigerator. The digital panel shows the same temperature as that of the display panel.

  • Page 15: Quick Cool" Button

    CoolSelect Zone Drawer GUIDE “Quick Cool” button • You can use the Quick Cool feature with the CoolSelect Zone • “Quick Cool” allows 1~3 canned beverages to cool within 60 min. • To cancel this option, press the “Quick Cool” button again. CoolSelect Zone returns to the previous temperature.

  • Page 16: Removing The Freezer Accessories

    In addition, this saves energy. • Before removing the freezer and refrigerator accessories, please move the stored foods to other space. • The door of the Beverage Station should never be removed. WARNING The Beverage Station cannot function if its door is missing.

  • Page 17: Cleaning The Accessories

    Rubber door seals • If the rubber door seals are dirty, the door will not close properly and the refrigerator and freezer will be unable to function efficiently. Clean them with a mild detergent and damp cloth. Then wipe them with a dry cloth.

  • Page 18: Changing The Interior Light

    Before changing the interior light, unplug the appliance from the power supply. If you experi- ence difficulty when changing the light, contact your service centre. WARNING INTERIOR LIGHT IN THE FREEZER (BASIC MODEL ONLY) / REFRIGERATOR Place a flat screwdriver under the light cover hooks and push in the direction of the arrow.

  • Page 19: Water Filter

    • You can not use the water and ice dispenser without a water filter cartridge because of the water line block at the water supply. Ordering replacement filters • To order more water filter cartridges, contact your authorized Samsung dealer. DOORS The refrigerator doors have a special door opening and closing feature to make sure that the doors close all the way and are securely sealed.

  • Page 20: Installation Of The Refrigerator

    Allow sufficient space to install the refrigerator on a flat surface. • If your refrigerator is not level, the internal cooling system may not work correctly. 1 Cm When you install the refrigerator, it is recommended that the clearance be maintained as much as specified above. NOTE If the space is not allowed, maintain at least 5cm clearance to the back wall.

  • Page 21: Removing The Front Leg Cover

    REMOVING THE FRONT LEG COVER Removing the Front Leg Cover (Optional) Open the freezer and refrigerator doors, and then take off the front leg cover assembly by turning the three screws counter-clockwise. Separating the water supply line from the refrigerator (Optional) 1) Remove the screw from clamp ( ).

  • Page 22: Removing The Refrigerator Doors

    REMOVING THE REFRIGERATOR DOORS • Lift the door straight up. • Be careful not to pinch the water tubing and wire harness on the door. NOTE • Place doors on a protected surface. Removing the Freezer Door 1) With the door closed, remove the upper hinge cover (➀) using a screwdriver, and then disconnect the wires (➁).

  • Page 23: Removing The Refrigerator Door

    4) Remove the lower hinge (➈) from the bracket lifting the door (➇). lower hinge (➉) by lifting the lower hinge (➈) in the direction of the arrow. • After disassembling the freezer / refrigerator door, move it to the appropriate location. you must reassemble it. NOTE...

  • Page 24: Reattaching The Refrigerator Doors

    REATTACHING THE REFRIGERATOR DOORS Reattaching the Freezer Door 1) Reattach the lower hinge (➀) using screwdriver. 3) Insert the upper hinge shaft (➃) into the hole (➄). After levelling the upper hinge hole (➅) with the hole of the cabinet (➆). Fasten bolts (➇) and screw (➈) in a clockwise direction.

  • Page 25: Reattaching The Refrigerator Door

    (➇). Fasten hinge screws (➈) and screw (➉) in the clockwise direc-tion. 4) Connect the wires. 2) Place the hole in the refrigerator door (➂) over the lower hinge (➃). 5) Put the front part of the upper hinge cover ( )
  • Page 26 REATTACHING THE REFRIGERATOR DOORS Reattaching the Water Tube (Optional) 1) While pressing the front face of coupler (➁), insert the water line (➀) in the coupler. 2) Tighten the screw on the clamp ( ). Reattaching the Front Leg Cover (Optional) Put on the front leg cover by turning the three screws clockwise, as shown in the figure.

  • Page 27: Adjusting The Clearance Between The Doors

    ADJUSTING THE CLEARANCE BETWEEN THE DOORS Please level the refrigerator first. The doors will be uneven if the refrigerator is not level. Case 1) Freezer door is lower than that of the refrigerator Case 2) Freezer door is higher than that of the refrigerator Do not make small adjustment by turning the control lever, Please refer to the next page.

  • Page 28: Making Small Adjustments Between Doors

    ADJUST THE CLEARANCE BETWEEN THE DOORS Making small adjustments between doors. Adjustment part ➂ WRENCH ➀ NUT ➁ BOLT ➂ WRENCH ➁ BOLT ➂ WRENCH ➀ NUT ➁ BOLT Please open the doors and adjust the doors as follows: 1) Release the nut (①) on the lower hinge until the upper end of the bolt (➁).

  • Page 29: Checking The Water Dispenser Line

    3) If the refrigerator is installed in an area with low water pressure (below 1.4kgf/cm a booster pump to compensate for the low pressure. 4) Ensure the water storage tank inside the refrigerator is preperly filled initially. Push the water dis penser lever until the water runs from the outlet.

  • Page 30: Installaing The Water Dispenser Line

    - Locate the nearest cold drinking water line. - Follow the instructions in the ice maker installation kit. Connect the water line to the refrigerator - Slip the compression nut and plastic ferrule through the plastic tube.

  • Page 31: Installing The Water Dispenser Line

    - Reattach the compressor cover of the refrigerator. Secure the water line. - Using clip ”A”, fix the water line to the wall (the back of refrigerator). - When the water line is secure, make sure whether the water line is not excessively bent, pinched or squashed.

  • Page 32: Connect To The Water Supply Line

    INSTALLING THE WATER DISPENSER LINE For Exterior model Connect to the water supply line Connect the water pipe with coupler and tap. - Close the main water tap. - Connect coupler “A” to the tap. - Every join should be protected with sealing tape. WARRANTY INFORMATION This water line installation is not covered by the refriger-ator or ice maker manufacturer's warranty.
  • Page 33 Connect the water line to the refrigerator. - Remove the compressor cover of the refrigerator. - Connect the water line to the valve, as shown in the fig-ure. - When connected, check if there is any leakage.
  • Page 34 3) Additional flushing may be required in some households. 4) Open the refrigerator door and check if water leaks around the water filter. • A newly-installed water filter cartridge may cause water to briefly spurt from the dispenser.

  • Page 35: Troubleshooting

    • Is the refrigerator in direct sunlight or located near a heat source? • Is the back of the refrigerator too close to the wall? The food in the refrigerator is frozen • Is the temperature control on the display panel set to the correct temperature? Try seting it to a warmer temperature.

  • Page 36: Ambient Room Temperature Limits

    Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Ambient Temperature...
