- Page 2 To avoid injuries or damage to property, please read the following precautions carefully and use the product accordingly. The images here are for reference only, and are not applicable in all cases (or countries). Failure to follow the instructions marked with this symbol may cause personal injury or even fatality. Failure to follow the instructions marked with this symbol may cause personal injury or damage to the product or property.
- Page 3 Always unplug the unit by holding the power plug. Pulling the power cable may damage the inside of it. There is a danger of fire. Unplug the power plug before cleaning the product. There is a danger of electric shock or fire. Do not let water or any liquid come into contact with the adapter.
- Page 4 When installing the product in a cabinet or on a shelf, make sure the front end of the base does not protrude. Dropping the product may damage it or cause injury. Keep the power cord away from heaters. The coating of the power cord may melt and cause electric shock or fire. Do not install the product in locations exposed to oil, smoke, moisture or water (rainwater), or in a vehicle.
- Page 5 Do not drop the product while carrying it. Doing so may cause damage or injury. Keep the product out of children’s reach. If the product falls it may cause harm to children. Install on a flat and stable location as the front part is heavy. Power Related Installation Related Do not insert any metal such as chopsticks, wires, gimlets, or inflammable objects...
- Page 6 If the product emits smoke, unusual noise, or there is a burning smell,disconnect the power plug immediately, and contact a Service There is a danger of electric shock or fire. If the power plug pin or jack is exposed to dust, water or alien substances, clean it thoroughly.
- Page 7 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Europe only (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household waste at the end of its working life.
- Page 8 Product Features The SP-P310 is a custom made projector designed for important marketing activities and presentations of the active business person! This Portable Projector SP-P310ME provides high mobility and ease of use. Product Features Your Projector Product Views Battery (sold separately) High Mobility Design - Small Size.
-
Page 9: Source Button
1. Power Button To turn it on Press the Power button. The Power LED will light up and the power is turned on. To turn it off Press the Power button until the Power LED is turned off. 2. Menu Button Press to display the OSD menu. - Page 10 Quick Installation Guide Adapter Lens Cover Use only the adapter supplied with the product. To purchase an additional adapter, contact your dealer or nearby service center. Optional Accessories Battery The following parts are sold separately. To purchase optional module, contact your dealer or nearby service center.
- Page 11 Product Features Your Battery 1. Locking hole Locks the battery to the projector. 2. Power Terminal Connect the power cord here to charge the battery. 3. Battery Latch The battery latch is used to hold the battery in place when connected to the main body. 4.
- Page 12 LED lights up red. This displays the remaining battery power in a percentage. To check the remaining battery power, press the PUSH button at the bottom right of the battery pack. The remaining battery life is indicated with the blue lamp and the blue lamp turns off after about five (5) seconds.
- Page 13 Hold the back of the projector and lift it up while sliding the latch on the back of the battery to the left ( 3. Battery Use Time Operating time : Up to 2.5 hours when fully charged Charge time : About 3 hours when charging separately from the projector 4.
- Page 14 Using a non-designated battery may damage the projector. Avoid heat or impact to the battery. Avoid strong force/impact to the battery, such as dropping or throwing the battery. Avoid exposing the battery to high temperatures such as a sauna. This may generate heat or cause fire or the battery to explode.
- Page 15 Environment Class B Noise Maximum 25 dB (by Samsung Reference) This Class B equipment is designed for home and office use. The equipment has been registered regarding EMI for residential use. It may be used in all areas. Class A is for office use. Class A is for business while class B emits less electromagnetic waves than class A.
- Page 16 XGA, 1024 x 768 60.241 The DMD Panel used in Samsung Projectors consists of several hundred thousand micro mirrors. As with other visual display elements, the DMD Panel may include a few bad pixels. Samsung and the DMD Panel manufacturer have a rigid, bad pixel identification and limitation procedure in place and products will not exceed the maximum number of bad pixels set by our standards.
- Page 17 Basic Settings Connecting the Power Installing the Projector Install the projector so that the beam from the projector is perpendicular to the screen. Place the projector so that the lens is at the center of the screen. If the screen is not vertically installed, the picture on the screen may not be a rectangle. Do not install the screen in bright surroundings.
- Page 18 Screen Size and Projection Distance Distance mm x mm 1.64 25.5 x 19.1 3.28 50.8 x 38.1 1.64 5.38 83.3 x 62.5 6.56 101.6 x 76.2 9.18 127.0 x 95.3 Basic Settings Connecting the Power Connect the adapter to the power port( Connect the power cord to the adapter and connect it to a wall outlet.
- Page 19 Basic Settings Connecting the Power Connect the [PC/COMPOSITE] port on the side of the projector to the Monitor OUT port [D-Sub] of your PC using a PC/Composite cable. When all the connections above have been connected, turn the projector and the PC on. Using the Projector Selecting the external input source.
- Page 20 Connect a PC/Composite cable to the [PC/COMPOSITE] port on the side of the projector and then connect the [COMPOSITE Input (Yellow)] connector of the PC/Composite cable to the VIDEO OUT (Yellow) port of the AV device using a video cable. When all the connections above have been completed, turn the projector and video devices on.
- Page 21 1. Power Button To turn it on : Press the Power button. The Power LED will light up and the power is turned on. To turn it off : Press the Power button until the Power LED is turned off. 2.
- Page 22 * Click the Play( )/Stop( ) button in the table below to view the video file. Screen Description Play/Stop Adjustment Source List Select an input signal connected to the projector. 1) Composite 2) PC You can select an input signal connecting to the projector by pressing the SOURCE button.
- Page 23 Screen Adjustment Picture Mode You can select a preset screen mode or make your own custom settings. 1) Dynamic Select to set a sharper visual quality than the standard screen. 2) Standard Select to watch a sharper picture when the surrounding illumination is bright. 3) Movie Select to view a picture that is comfortable for viewing and to save power consumption when the room is dark.
- Page 24 Screen Adjustment Install To support various Installation positions of the projector, horizontally and vertically. Reversed images as well as negative images are supported. 1) Front-Floor : Normal Image 2) Front-Ceiling : Horizontal Negative Image 3) Rear-Floor : Vertical Negative Image 4) Rear-Ceiling : Horizontal/Vertical Negative Image V-Keystone You can compensate for a slanted picture by using the Vertical Keystone function.
- Page 25 If Logo Mode is enabled, the Samsung Logo appears on the screen when the projector is switched on. If the Logo Mode is disabled, the Samsung Logo does not appear on the screen when the projector is switched on. Buttons...
- Page 26 * Click the Play( )/Stop( ) button in the table below to view the video file. Screen Description Play/Stop Adjustment Information Shows the setting information. (In Composite Mode, the Coarse, Fine, Resolution, H-Frequency and V-Frequency setting functions are not available. In PC Mode, the Color and Tint setting functions are not Composite available.) The icon appearing at the top right of the information display represents the current...
- Page 27 Installation and Connection Symptom Cannot turn the power on. When using the adaptor : Check the connection status between the projector and the power cable of the adaptor. When using the battery : Check the connection status of the battery and the projector, and the remaining battery charge.
- Page 28 Service Center or a distributor. Contact your distributor or a Service Center if dust or other substances are inside the projector. If you have any questions or comments relating to Samsung products, please contact a SAMSUNG customer care center. U.S.A 1-800-SAMSUNG (7267864)
- Page 29 BELGIUM 02 201 2418 CZECH REPUBLIC 844 000 844 DENMARK 70 70 19 70 FINLAND 030-6227 515 FRANCE 3260 SAMSUNG(7267864) (€ 0,15/min) GERMANY 01805-121213 (€ 0,14/Min) HUNGARY 06-80-SAMSUNG (7267864) ITALIA 800 SAMSUNG (7267864) LUXEMBURG 0032 (0)2 201 24 18 NETHERLANDS 0900 20 200 88 (€...
- Page 30 1800-SAMSUNG (7267864) THAILAND 1800-29-3232, 02-689-3232 TAIWAN 0800-329-999 VIETNAM 1 800 588 889 SOUTH AFRICA 0860 7267864 (SAMSUNG) U.A.E 800SAMSUNG (7267864) 8000-4726 Advantages of Pocket Imager Long Lifetime Replacing the lamp is not necessary. Low Power Consumption Since it consumes less power, it can run on battery power unlike other projectors.
- Page 31 ANSI Lumen Unit of brightness as defined by the American National Standards Institute. This value is determined as follows: project light onto a 40-inch screen, divide the screen into 9 rectangles and measure the average brightness of each of the rectangles.
- Page 32 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
