- Page 1 Read Me Before Usage! Manual of 1101H/P...
-
Page 2: Table Of Contents
Table of Contents Chapter 1 Content Description —1 Section 1 On-Lap Monitor and Accessories —1 Section 2 Notices of On-Lap Monitor —2 Section 3 Safety Precautions —3 Section 4 Safety Instructions —3 Section 5 Product Maintenance —3 Section 6 LCD Pixel Statement —4 Section 7 Disposal of Electronic Equipment —4... -
Page 3: Chapter 1 Content Description
Chapter 1 Content Description Section 1 On-Lap Monitor and Accessories Parts Description Fig.: On-Lap 1101 Series Front Fig.: 1101 buttons and LED light Description Fig.: On-Lap 1101 Series Input & Output ports... -
Page 4: Section 2 Notices Of On-Lap Monitor -2
Back Front Fig.: Parts Description of Protective Cover 2. Package & Accessories Accessories On-Lap1101H On-Lap1101P Cover Stand * 1 set Micro HDMI Video Cable*1 USB to Micro USB Cable*1 Charger(5V,2A)*1 Mini-HDMI to Micro HDMI Video Cable (0.6m) Optional VGA Video Cable(1.2m) Optional Optional mini-DisplayPort Video Cable(1.2m) -
Page 5: Section 3 Safety Precautions -3
Please do not use sharp objects to touch the screen. Please do not press the arm or other item to the screen or apply heavy pressure onto the screen. Disconnect power source before cleaning. Please use soft cloth to clean touch screen monitor. -
Page 6: Section 6 Lcd Pixel Statement
Section 6 LCD Pixel Statement The On-Lap Monitor uses a high quality LCD panel. Nevertheless, there might be instances where defective pixels may occur; however, this will not affect the normal functioning of the Product. Section 7 Disposal of Electronic Equipment The electronic equipment and batteries should not be disposed of with household waste but should be left at an appropriate collec- tion point for recycling. - Page 7 2 Tripod Mount Kit Installation (Optional) First Screw the Tripod Mount Kit in VESA 75 arm or camera cradle head/ tri- pod. Place the Monitor into Tripod Mount Kit, as shown in Fig, and secure the Monitor by screws in. Fig ：...
-
Page 8: Power Cable
Section 2 Connect the Video Cable and USB Power Cable 1. Connection method for On-Lap 1101 Connect USB Power cable first and then connect Video cable. USB power Cable can be connected to USB port of laptop or 5V 2A USB charger. Voice is transmitted by micro- HDMI or DisplayPort ports. -
Page 9: Chapter 4 Hot Keys And Osd Instructions
Resolution setting – Windows 7/ Windows 8.1/ Windows 10 system ● Click on icon ● Click on Control Panel > Appearance and Personalization ● Click on Display > Connect to an external display. Normally Display ① is the laptop’s monitor, Display ② is the external monitor. -
Page 10: Section 2 Osd Description -8
Section 2 OSD Description Basic Button Operation Press button to launch the OSD panel. Press to view the functions. To adjust a certain function, press to launch it. If the select- ed function consists of sub-menu, press again to view the sub- menu. - Page 11 Aspect Ratio Please refer to Fig. Suggested setting is 16:9. When HDMI image is 4:3 format, can select 4:3, make image not enlarge to 16:9 and change shape. Using VGA image input won’t have this function Overscan: Only when input HDMI Video signal (ex.
-
Page 12: Section 3 Low Power Protection Warning -10
Section 3 Low Power Protection Warning If the volume setting is too high, the power requirement may be greater than the power provided by computer or external 5V DC Charger. At this time, the Low Power Protection Warning will appear. Please reduce the volume immedi- ately. - Page 13 mini-DisplayPort Connector Pinout Name Name Name ML_Lane2(p) Hot Plug Detect ML_Lane1(p) AUX_CH(p) ML_Lane0(p) ML_Lane3(p) ML_Lane2(n) CONFIG1 ML_Lane1(n) AUX_CH(n) ML_Lane0(n) ML_Lane3(n) CONFIG2 DP PWR Pin ： mini-DisplayPort Connector (Connect mini-DisplayPort) VGA Connector Pinout Pin No. Name Pin No. Name Pin No. Name RGND GREEN...
-
Page 14: Section 3 Specification -12
Section 3 Specification Model On-Lap1101H On-Lap1101P 11.6" TFT IPS LCD 11.6" TFT IPS LCD Panel (16:9 Wide) LED Backlight (16:9 Wide) LED Backlight Resolution/ Color Depth 1920x1080/ 16.7M colors 1920x1080/ 16.7M colors Pixel Pitch 0.1335mm (H) *0.1335mm (V) 0.1335mm (H) *0.1335mm (V) Active Area 256mm x 144mm 256mm x 144mm... -
Page 15: Section 4 Troubleshooting -13
Please consult your laptop manufacturer or graphic chip manufacturer. GeChic Corporation 5 F- 3, No . 138, Z ho ng ming S . Rd ., West Dist., Taichung, Taiwan (R.O.C.) Customer Service: service@gechic.com...
