- Page 1 ASKEY Connected DashCAM CDR6013-WG User Manual Nov. 2017 ASKEY Computer Corp.
-
Page 2: Table Of Contents
Connected Car Cam CDR6012 User Manual Content Introduction ........................3 Features............................3 Package Contents ........................3 1.1.1 Device Overview ..........................4 Getting Started..........................5 Insert Memory Card and SIM Card..................5 1.3.1 Install in Vehicles ........................5 1.3.2 Power the Device On / Off......................5 Auto Power On/Off ........................ - Page 3 Computer Corp. reserves the right to make changes to the products described in this document without notice. ASKEY Computer Corp. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
-
Page 4: Introduction
Connected Car Cam CDR6012 User Manual 1.Introduction Thank you for purchasing this advanced Connected Car Cam. This device is specifically designed for the functions descript as the following. 1.1 Features • Full HD 1080p single camera driving recorder • 1920x1080p video recording •... -
Page 5: Device Overview
Connected Car Cam CDR6012 User Manual before your purchasing. 1.2 Device Overview Description Description Mount Bracket Up Button Knob/Hinge Enter/OK Button Power Button Down Button Main Device Microphone-2 Camera Call Button Speaker SIM Card Slot Back/Return Button Reset Button Microphone-1 Micro SD Card Slot USB port LED Indicator... -
Page 6: Getting Started
Connected Car Cam CDR6012 User Manual 1.3 Getting Started 1.3.1 Insert Memory Card and SIM Card Follow the direction indicated as the following to insert the memory card and SIM card. (Please contact with your Operator to get the SIM card.) Micro SIM card Micro SD card 1.3.2 Install in Vehicles... -
Page 7: Auto Power On/Off
Connected Car Cam CDR6012 User Manual Plug the other end of the car charger to the cigarette lighter socket of your vehicle. Once the vehicle engine is started, the device automatically turns on. 3. Switch key from ACC to OFF position, then device will enter sleep mode and start consuming battery power. -
Page 8: Reset The Device
Connected Car Cam CDR6012 User Manual 1.4.3 Reset the Device In case the device fails to function normally due to unknown causes, click the reset key on the bottom of the device. 1.4.4 Set the Date / Time Date and Time will be automatically updated after registered the LTE/3G network, connected to Wi-Fi or receive the GPS signal 1.4.5 LED Indicator LED Indicator Status... -
Page 9: Using The Driving Recorder
Connected Car Cam CDR6012 User Manual Using the Driving Recorder 2.1 Recording Videos Before starting recording, please insert a SD card into the SD card slot. With car charger connected the device will automatically turn on and start recording, the video recording icon shown on the left top of the screen and a red color LED blinks . -
Page 10: Voice On/Off When Recording
Connected Car Cam CDR6012 User Manual Connected to Wi-Fi network Wi-Fi hotspot allow other device sharing your 3G/LTE connection. Connected to 3G/LTE network and show the signal strength. 2.1.2 Voice On/Off when recording Enter the Video Setting to enable Voice when recording Off / On. 2.1.3 Take Picture During recording, press Back button can capture the current scenery as a picture. -
Page 11: Event Videos
Connected Car Cam CDR6012 User Manual 2.2.2 Event Videos The Event video record is triggered and activates in the case of a car collision accident which is determined by the gravitational acceleration. When collision is detected, this device will save the recorded video clips under \\sdcard DVR\event\event_data_video and upload them to cloud forcibly. -
Page 12: Network Settings
Connected Car Cam CDR6012 User Manual 2.3 Network Settings The device built-in LTE/3G, Wi-Fi and GPS module, please insert a SIM card before power on, when LTE/3G or GPS signal has been received, the recorded video can be tracked at this time. 2.3.1 LTE and 3G Frequency Bands Please make sure the LTE and 3G frequency bands with your operator in local before you insert the SIM card into the device. -
Page 13: Wi-Fi
Connected Car Cam CDR6012 User Manual 2.3.2 Wi-Fi The device support IEEE802.11 b/g/n, 2.4GHz Wi-Fi connections. Press Enter button to select Network Setting menu to activate the Wi-Fi hotspot function. Insert a SIM card before you activate the Wi-Fi hotspot function. (Please notice you will be charged by local operator if you activate it). -
Page 14: Menu Options
Connected Car Cam CDR6012 User Manual 2.4 Menu Options Main Menu Description Available Option Videos and Normal Playback recorded Review / Change to Event photo movies and view folder / Delete capture photos. Event Event data / Risky driving behaviors / FCWS: Review / Delete Parking Review / Delete... - Page 15 Connected Car Cam CDR6012 User Manual Wi-Fi Set the Wi-Fi connection. Set the LTE Roaming / Network / Access connection and APN. Point Name(APN) Wi-Fi Hotspot Set the Wi-Fi as an On / Off AP router. Set up ID/Password Bluetooth Set the Bluetooth On / Off connection.
- Page 16 Connected Car Cam CDR6012 User Manual data on the video recorded. Voice when Set the voice On / Off recording recording on / off when video recording. System Manufacture Display the setting manufacture. Model name Display the model name for the device. IMEI Display the IMEI for the device.
-
Page 17: Adas
Connected Car Cam CDR6012 User Manual Version Display the current firmware version of the device. 2.5 ADAS 2.5.1 Auto Calibration When the ADAS (containing the sub functions of LDW, FCW) is enabled, the ADAS engine will take around 1-2 minutes to calibrate its parameters of hood level, horizontal level and horizontal Pan automatically. -
Page 18: Ldws (Lane Departure Waring System)
Connected Car Cam CDR6012 User Manual • Notice FCWS turned on, a green square wireframe with distance is displayed on the screen from the moment the front vehicle is detected, and as long as the headway is greater than the predefined headway time threshold. -
Page 19: Firmware Upgrade
Connected Car Cam CDR6012 User Manual 2.6 Firmware Upgrade Check the device has already connected to the vehicle power before you activate the firmware upgrade service. While the firmware upgrading, do not remove or stop the vehicle engine. This information may be important for service and support communications. 2.6.1 Firmware Upgrade via OTA Enter the System Upgrade and select Check Version to check and upgrade the firmware version. -
Page 20: Technical Specifications
Connected Car Cam CDR6012 User Manual 2.8 Technical Specifications Model Name CDR6013-WG Support OS Android 6.0 Display 2inch LED backlight TFT panel, QVGA 320 x 240 pixel, brightness 200 nits , Dimensions 76mm (L) x 76mm (W) x 40.7mm (H) -
Page 21: Appendix
Connected Car Cam CDR6012 User Manual 3.Appendix 3.1. Package Planning. -
Page 22: Memory Card Capacity
The oldest files will be overwritten if the SD card fills up. 4.Troubleshooting Contact us if you have questions need some help or cannot use the device normally. Telephone: E-mail: sales@askey.com.tw Manufactured by Askey Computer Corporation 10F, No.119, Jiankang Road., Zhonghe Dist., New Taipei City 23585, Taiwan... - Page 23 Connected Car Cam CDR6012 User Manual FCC warning statement This radio transmitter has been approved by FCC to operate with the antenna types FCCID: H8NCDR6013 listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
