Page 1: Installation Instructions
4826L Installation Instructions KargoMaster 11261 Trade Center Dr, Rancho Cordova, CA 95742 800-343-7486... - Page 2 Installation Instructions When moving shelf unit, LIFT AND DO NOT DRAG THE SHELF UNITS INTO POSITION Installation in Transit Connect Step 1 Be sure to have 32” shelf installed in rear of van (Drivers Side Shown) Step 2 Locate mid support bracket towards the front of the van on the 32”...
- Page 3 Installation Instructions Step 4 Bolt strap bracket to small angle bracket in orientation shown. The small angle bracket will have 5 slots in one side. Place strap bracket flat against the front-most side of the 26” shelf. Align strap bracket with a hole near the top of the shelf side. ...
- Page 4 Installation Instructions Step 7 Bolt front side of 26” shelf to the brackets installed in Step 5 using ¼-20 x 7/8” hex head bolt, two flat washers and a nyloc nut. Step 8 Bolt 32” and 26” together using ¼-20 x 7/8” hex head bolt, two flat washers and a nyloc nuts where possible. ...
