  • Page 1 HumDT Series Master Development System User's Guide...

  • Page 2: Table Of Contents

    ANSI and NFPA standards. It is solely the responsibility Using the Programming Dock of any Linx customer who uses one or more of these products to The Development Kit Demonstration Software incorporate appropriate redundancies and safety standards for the Life and Property Safety Situation application.

  • Page 3: Introduction

    The boards serve several important functions: • Rapid Module Evaluation: The boards allow the performance of the Linx HumDT™ Series modules to be evaluated quickly in a user’s environment. The development boards can be used to evaluate the range performance of the modules.

  • Page 4: Ordering Information

    Ordering Information HumDT Series Carrier Board Pin Assignments Ordering Information 38 VCCD ANTENNA GND (RF Connector) 39 GPIO_7 Part Number Description 40 GPIO_6 MODE_IND 41 GPIO_5 MDEV-***-DT HumDT Series Master Development System RESET CMD_DATA_IN 42 GPIO_4 HUM-***-DT HumDT Series Transceiver POWER_DOWN 10 11 VCCD 43 GPIO_3...

  • Page 5: Prototype Board

    Prototype Board Initial Setup There are several boards that are included with the Development System. The Carrier Boards have a HumDT Series transceiver on a daughter board with headers. These boards snap into sockets on the other boards, enabling the modules to be easily moved among the test boards. There are two Programming Docks that have a socket for a Carrier Board and a USB interface for connection to a PC.

  • Page 6: Using The Prototype Board

    Using the Prototype Board The overload condition is reset once the excess current draw is removed. Supply for the module is connected through R17. This can be removed and Snap a Carrier Board onto the socket on the Prototype Board as shown in replaced by another supply or used to measure the current consumption of Figure 7.

  • Page 7: Using The Programming Dock

    If the range you are able to nickname is entered using the development kit software and can be achieve is significantly less than specified by Linx for the products you are any name that helps distinguish the modules from one another. This is...

  • Page 8: The Development Kit Demonstration Software

    Figure 10: The Master Development System Software Advanced Configuration Tab pull-up or pull-down. 1. Clicking the Contact Linx, Documentation and About labels on the 15. The module identity box shows the active module’s name, firmware left side expands them to show additional information and links to the version and serial number.
  • Page 9 The 868MHz version of the module operates on one of 68 channels as The modules are shown with four identifiers as shown in Figure 13. opposed to being agile among 4 channels. The software automatically detects the frequency band for the active module and adjusts the selection. The 868MHz module changes the channel selection from the check boxes to a drop-down menu in the Radio section (1).
  • Page 10 The Wireless Chat tab (Figure 15) offers a demonstration of sending data The Command Set tab (Figure 16) allows specific commands to be written between two modules. There is a window for each connected module. to the module. Figure 16: The Master Development System Software Command Set Tab 1.
  • Page 11 The Network tab shows the interaction of all of the connected modules on one screen. Figure 20 shows two modules on the screen, but up to 8 modules can fit at one time. Figure 17: The Master Development System Software Command Set Tab Commands Menu Figure 20: The Master Development System Software Network Tab The screen shows the network configuration of all modules that are connected to the PC.

  • Page 12: Development Kit Demonstration Software Example

    Development Kit Demonstration Software Example This example shows how to configure two modules to work with each other. The software defaults to the Advanced Configuration tab when opened (Figure 21). Figure 23: The Master Development System Software with Connected Modules Any changes to the current configurations are shown in red.
  • Page 13 Clicking on the Network tab shows the current state of all modules connected to the PC. Figure 25: The Master Development System Software Dragging to Change the Active Module Figure 26: The Master Development System Software Network Tab There are several settings that must match in order for the modules to be Both modules are set as End Devices.
  • Page 14 Figure 28: The Master Development System Software Network Tab A dotted line appears between the modules indicating that they are joining the network. Figure 30: The Master Development System Software Wireless Chat Tab Figure 29: The Master Development System Software Network Tab A solid line appears between the modules when they are joined and ready to communicate.

  • Page 15: Carrier Board Schematic

    TPS2552 LM3940IMP 3.3V Vout Carrier Board Schematic ILIM Programming Dock Board Schematic 100uF 0.47uF nPWREN FAULT 53.6k SIGNAL ROUTING CMD_DATA_OUT Buffer Bypass DNP R48 0 ohm CMD_DATA_IN 330 ohm Buffer Bypass DNP R49 0 ohm nCMD 0 ohm LADJ PAIR 0 ohm Figure 32: Programming Dock Board RF Carrier Area Schematic Figure 31: HumDT...
  • Page 16 MICROCONTROLLER AREA USB AREA POWER SUPPLY AREA RF MODULE CARRIER AREA POWER SUPPLY AREA RF MODULE CARRIER AREA 5VUSB nPDN 5VUSB TPS2552 TPS2552 LM3940IMP 3.3V LM3940IMP 3.3V Vout Vout 330 ohm VCCP ILIM ICSPDAT ILIM GPIO1 ICSPCLK 100uF 0.47uF nPWREN FAULT MCLR 100uF...

  • Page 17: Prototype Board Schematic

    MICROCONTROLLER AREA USB AREA Prototype Board Schematic nPDN 330 ohm VCCP ICSPDAT 100mil Header GPIO1 ICSPCLK Battery Input 10uF MCLR R42 DNP 5VUSB PIC16F1825-I/ST ILIM THERM 0.47uF FAULT THERM TPS2553 53.6k 53.6k 5VUSB BCD Charger 0 Ohm LCD1 LED+ 5VUSB FAULT FAULT VOUT...
  • Page 18 Figure 40: Prototype Board Prototype Area Schematic Figure 39: Prototype Board USB Area Schematic – – – –...
  • Page 19 Under no circumstances shall any user be conveyed any license or right to the use or ownership of such items. ©2018 Linx Technologies. All rights reserved. The stylized Linx logo, Wireless Made Simple, WiSE, CipherLinx and the stylized CL logo are trademarks of Linx Technologies.
