- Page 1 SADT - 104WM Wall Mount Adaptor imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/global/register SADT-104WM_ENG.indd 1 2008-01-24 오전 10:24:02...
-
Page 2: Installation
Overview The WALL MOUNT ADAPTOR is used to install the SMARTDOME CAMERA (SCC-C6433/C6435) in an indoor wall. Notice • Make sure that you must select an installation spot to endure the total weight of "Wall Mount Adapter", "Smart Dome Camera". •... - Page 3 3. If you install the Wall Mount Adaptor in a wall, place the template on the wall and drill 4 holes for the anchor bolts (M10) and nuts (M10) before inserting them. If you install it in a corner of the wall, use the Corner Mount Adaptor (SADT-110CM). If installing on the pole of the wall, use the Pole Mount Adaptor (SADT-100PM).
- Page 4 5. Remove the Connectors at the end of the Camera Adaptor. In the next step, peel off the coating of the cable and connect it to the external cable using soldering. (See the wiring diagram of the installation guide for the Camera to connect the cables.) Lastly, use an insulation tape to wrap up the soldering portion of two cables.
- Page 5 6. Prepare the Camera Adaptor for the applicable camera. Refer to the installation guide for the applicable camera and configure the initial settings of the Camera Adaptor. (For more information, see the installation guide for the Camera) Insert the cable of the Camera Adaptor into the Wall Mount Adaptor before pulling it out throught the hole of the Cover Fixing Part.
- Page 6 8. Pull out cables such as external power cable, BNC cable and communications cable through the rear of the Wall Mount Adaptor, which are necessary for connecting the camera. It is recommended to keep the cables about 100mm longer than the cover fixing part. 9. Use the anchor bolts and nuts to secure the Wall Mount Adaptor to the wall.
- Page 7 0. Connect the cables of the Camera Adaptor with the outward cables, which then you push in through the Cover Fixing Part to the Wall Mount Adaptor. Insert one piece of the two-strand cable into an empty area of the Wall Mount Adaptor as in the figure below and push the other one into the Wall Mount Adaptor.
- Page 8 2. Prepare the Camera Body. Put up the Safety Wire, attached to the camera, on the Safety Hook. To avoid accidental fall and consequent damage to the camera during installation or detachment, make sure the Safety Wire is secured to the hook. CAUTION WALL MOUNT ADAPTOR CAMERA ADAPTOR...
- Page 9 3. Align the Guide 1 of the Camera with the Guide 2 of the Camera Adaptor and insert the 3 Guides of the Camera into the corresponding Guide Holes of the Camera Adaptor. Then, turn the camera clockwise by 10 degrees. Make sure that the part "A"...
- Page 10 4. Use the screws, attached to the Camera, to firmly fix the Camera body with the Camera Adaptor. (Once you removed the camera from the Camera Adaptor, loosen the screw, turn the camera counterclockwise by about 10 degrees, and then pull it down.) If you do not fix the screws, CAMERA BODY could be separated from the CAMERA ADAPTER due to the shake.
-
Page 11: Product Specification
Product Specification Location for use: Indoors Installation Spot: Wall or Vertical Structure Dimension: See the figure Weight: 241g Material: plastic Operation Temperature: -10˚C ~ 50˚C Accessories Template ... 1 Cover ... 1 MANUAL ... 1 0_SADT-104WM SADT-104WM_ENG.indd 10 2008-01-24 오전 10:24:12... -
Page 12: Correct Disposal Of This Product
Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
