Owner's Instructions
please read this manual thoroughly,
and retain it for future reference.
Specification
System
CPU
Resolution
Power
HDD
Video
Audio
Video Output
Audio Output
Interface
Dimension (W x H x D)
Weight
MP-80S
Before operating the unit,
RISC Processor
480p/576p/720p/1080i
AC 100 ~ 240V (DC 14V), 50~60Hz
80GB
MPEG2 Transport Stream
Dolby Digital AC3
Component/HDMI
Analog R+L/Optical/Coaxial
USB2.0
90 x 199 x 192 mm
2.0Kg
Advertisement
Table of Contents
Related Manuals for Samsung Network Adapter MP-80S
Summary of Contents for Samsung Network Adapter MP-80S
- Page 1 Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. Specification System Resolution Power Video Audio Video Output Audio Output Interface Dimension (W x H x D) Weight MP-80S RISC Processor 480p/576p/720p/1080i AC 100 ~ 240V (DC 14V), 50~60Hz 80GB MPEG2 Transport Stream Dolby Digital AC3...
- Page 2 Warning! Important Safety Instructions (Please read the appropriate section that corresponds to the marking on your Samsung product CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE.
-
Page 3: Table Of Contents
Contents Operating ... - Front Panel ... - Rear Panel ... - Remote Control ... Connecting to the Component ... Connecting to the HDMI ... Copying of Video Files ... - Connecting to PC ... - Transferring Video Files ... - Removing the USB cable from the PC ... -
Page 4: I Operating
Operating Front Panel USB LED Indicator Lights up in blue when the unit is connected to PC using USB cable. POWER LED Indicator Lights up in red when the unit is on. HDD LED Indicator Lights up in blue when the HDD is accessed during operation. IR LED Indicator Lights up in blue when the remote control signal is received. -
Page 5: Rear Panel
Operating Rear Panel 1) S-Video Output (Not available) 2) Audio Output (R/L) 3) Video Output (Not available) 4) Component Video Output (Y/P 5) Component Audio Output (R/L) 6) Digital Audio Output (COAXIAL) 7) HDMI Output 8) Digital Audio Output (OPTICAL) 9) USB 2.0 10) Anynet Input/Output (Not available) -
Page 6: Remote Control
Operating Remote Control MP-80S only supports the Samsung universal remote control. Press the MODE button on your remote control until STB (Set- Top Box) mode is selected. Depending on the model of the remote control, STB may be displayed on the LCD or the STB LED lamp may be lit. -
Page 7: Connecting To The Component
Connecting to the Component Connect the component cables between the component output (Œ and one of the ´, ˇ, ¨, or ˆ) jacks on the MP-80S and the component input jacks on the TV. Supply power to the MP-80S and TV after making all the connections. Please be sure to match the color coded terminals and cable jacks. -
Page 8: Copying Of Video Files
PC. The drive letter of the local disk (e.g. E:, F:, G:, etc.) may differ depending on the computer configuration. ☛ The MP-80S only supports MPEG2 transport stream files distributed by Samsung Electronics. ☛ Warning: DO NOT DELETE or MODIFY the "System_Files"... -
Page 9: Play List
Play List Press the HOME button. Result: The main menu is displayed. Press the œ or √ button to select Play List. Press the ENTER ( ) button. Result: The Play List menu is displayed. Press the … or † buttons to move to the file to be played. ➢... -
Page 10: Video Out
Setup - Video Out / Resolution / Screen Size / S/PDIF / Auto Start Press the HOME button. Result: The main menu is displayed. Press the œ or √ button to select Setup. Press the ENTER ) button. Result: The Setup menu is displayed. Press the …... - Page 11 Memo English - 11...
- Page 12 - AFTER SALES SERVICE - Do not hesitate to contact your retailer if a change in the performance of your product indicates that a faulty condition may be present. MD68-00290A-00...
