Summary of Contents for Euroshine ITREAD
- Page 1 INSTRUCTION MANUAL...
- Page 2 Please read the instructions before use...
- Page 3 Contents PRODUCT INTRODUCTION SAFETY INSTRUCTION 01 Introduction and Function 09 Safety Instruction 02 Component List 11 Important Notice 03 Product Specifications...
- Page 4 ASSEMBLE INSTRUCTION MAINTENANCE 04 Assemble Instructions 12 Daily Maintenance USE INSTRUCTION 05 Start UP 07 Sleep Mode 06 Speed Up 07 Wake Up 06 Constant Speed 07 Protection 06 Slow Down 08 Handrail 06 Stop 08 Storage PRODUCT INTRODUCTION...
- Page 5 ITREAD INTRODUCTION DISPLAY TIME, STEPS, DISTANCE, START, SLEEP, START DISPLAY: WHEN STARTING THE ITREAD 6 SHORT STRINGS IN THE MIDDLE OF THE DISPLAY WILL LIGHT UP,AS SEEN TO THE LEFT. ITREAD IS STARTED SUCCESSFULLY WHEN 3 LINES ARE LIGHTED, AND BEGINS...
- Page 6 WHEN IN SLEEP MODE 2 SHORT STRINGS OF LIGHTS STEPS: Display single time distance. Becomes 0 when restart. WILL APPEAR ON THE DISPLAY, COMPONENTS LIST ITREAD HAS A STANDARD VERSION AND HANDRAIL VERSION, DIFFERENT COMPONENTS AS FOLLOWS: COMPONENTS Standard Version Handrail Version...
- Page 7 ITREAD Handrail Instruction Manual PRODUCT SPECIFICATION STANDARD ITREAD SPECIFICATION (2)HANDRAIL VERSION SPECIFICATION Product...
- Page 8 Color □Silver □Pink Product size 1450mm*670mm*90mm N.W. 29kg RUNNING BELT 1200mm*460mm SIZE Product size 1450mm*670mm*90mm Ground 47mm≦ITREAD≦90mm Clearance Running Belt 1200mm*460mm MAX Power 350W size Ground 47mm≦ITREAD ≦90mm MAX Speed 6km/h Clearance MAX Power 350W MAX Speed 8km/h ASSEMBLE INSTRUCTION...
- Page 9 ASSEMBLE INSTRUCTIONS ARE FOR USERS WHO BUY HANDRAIL SEPARATELY. ASSEMBLE INSTRUCTION FOR HANDRAIL 1. Put ITREAD face down; make sure surface that you are placing ITREAD on is clean and free of any items so that the surface of ITREAD does not get scratched.
- Page 10 5. Put ITREAD face up, plug in and start to enjoy the ITREAD. USE INSTRUCTION 1. HOW TO START (1) Put ITREAD on flat and open area (2) Plug in, display will light up...
- Page 11 Distance between two steps is smaller than 5cm or bigger than 10cm Children cannot start the ITREAD due to their size which is unable to activate the body sensor system Steps are too slow. Time interval between steps cannot be longer than 1.5 seconds...
- Page 12 CONSTANT SPEED Walk/run in the middle section of the running belt platform to keep a consistent speed. SLOW DOWN/STOP From the speed up area: slow down casually from jogging to fast walking and then move to the constant speed area . Keep walking slowly till you reach the slow down area until machine stops. From the constant speed section: slow down casually from fast walking by increasing your step size and moving to the slow down area.
- Page 13 ITREAD will enter sleep mode after 5 minutes of inactivity. Two short strings will be shown on the display. Wake up Step 3 times within 5 seconds at the end of the running belt. Make sure your heel keeps in touch with the running belt.
- Page 14 AUTOMATIC PROTECTION ITREAD will automatically stop for protection after 100 minutes of continuous use. Hydraulic Handrail Hydraulic handrail will lift automatically when it is lifted to a certain height. Hydraulic handrail will fold automatically when it is folded to a certain height.
-
Page 15: Safety Instruction
For wall suction storage; there are 2 magnets that are assembled in the end part of the foot rails. Place the round steel with sucker on a suitable position on the wall. They will attract together and insure the safety when the ITREAD is placed against the wall. SAFETY INSTRUCTION In order to avoid any injury, please read instruction manual carefully before using. - Page 16 Do not insert hand, foot or any other body parts into ITREAD or the intervals between running belt and foot rails. (10) ITREAD is to be used by only 1 user at a time. Failure to follow this could cause serious injuries.
- Page 17 (13) Max loading is 100kgs. (14) ITREAD will automatically stop for protection after 100 minutes of continuous use. Over use may cause machine to overheat causing damage to the motor. (15) When not in use, please turn off the power and unplug the power cord. Running electricity may present risks for electric shock or fire (16) If using wall suction storage insure the magnets are attracted to the steel.
- Page 18 Do not use in such conditions: outdoor, high humidity, freezing temperatures, direct sun exposure. Do not stomp on display. Do not overload ITREAD. Do not disassemble any parts forcibly. Do not shut power off when in use Please verify that power is off before daily cleaning and maintenance of ITREAD...
Need help?
Do you have a question about the ITREAD and is the answer not in the manual?
Questions and answers
What do I need to do for maintenance anything? Do I need to oil anything or clean anything specifically?
For maintenance of the Euroshine ITREAD:
1. Daily Cleaning and Maintenance: Ensure the power is turned off before performing any cleaning or maintenance.
2. Oiling: The manual does not mention specific oiling instructions, so no oiling procedure is indicated.
Only cleaning with the power off is required as part of daily maintenance.
