Brecknell MS-15 Operation Manual

1. Technical Specifications
•
Work temperature: 10 ~40℃
•
Environmental humidity: <80%
•
Maximum capacity: 20kg
•
Graduation: 5g
•
Power supply: 4 AA batteries (NOT INCLUDED)
•
Background color : Blue backlight
•
Low power: L o
•
Error of indication: Err
•
Unit change: kg or lb
•
Memory Function: optionally save and recall weighing value
•
Turn off Automatically
•
Over load: o_Ld
2. Key Functions
ON/TARE: Press the key to power on the scale and start up weighing process. For zero operation,
press the key again to clear the display and the "zero" annunciator will show in the top left corner of
the LCD. If you want to turn off the scale please press this key for 3 seconds until the scale switches off.
MODE: Weighing units exchange key. Press the key to select kg and lb in turn. The desired indicator
of unit is shown on the right side of the LCD by the kg or lb annunciator.
MEM: Memory key. While the scale is blinking a stable; consistent weight, press and hold the "MEM"
key until SET is on the display. Once the weight is removed, the scale returns to zero. If you want to
recall the last held weight in MEM mode, press the "MEM" key.
3. Operation
•
After the batteries are placed, press "ON/TARE" key to start the scale until "0.000" appearance.
•
Gently place object on the pan, weighing record will be flashed on the window after a few
seconds. If object remain lying on the pan after its weight value has shown, the weighing value
will continue to flash for 5 minutes and then turn off automatically.
•
If take object from the pan immediately after object's weight has been flashed, the scale will
return to "0.000" and then turn off automatically within 5 minutes if no operation again.
•
If see about the former saved weighing value, please press the "MEM" key while the scale is in
"0.000" position. The scale will save optional value during each weighing operation.
MS-15 Electronic Digital Bench Scale
Operation Manual
P/N AWT35-501573
Issue AB
1
