- Page 1 SIDNE Berchtold ® ® Chromophare E-Series ® Lighting Package REF 240-020-838 User Guide...
-
Page 3: Table Of Contents
SIDNE Berchtold ® ® Chromophare E-Series ® Lighting Package User Guide Contents Warnings and Cautions ............. 2 Product Description ..............3 Intended Use ..................3 Package Contents ................3 Setup and Interconnection ............. 4 Determining the Connections between SIDNE and the Berchtold Lights Control Box ................... -
Page 5: Warnings And Cautions
Warnings and Cautions Please read this manual and follow its instructions carefully. The words warning, caution, and note carry special meanings and should be carefully reviewed: Warning Warning indicate risks to the safety of the patient or user. Failure to follow warnings may result in injury to the patient or user. -
Page 6: Product Description
Product Description/Intended Use The SIDNE® Berchtold® Chromophare E-Series Surgical Lighting package (the Berchtold Lights package) is a hardware/software interface between the SIDNE voice-activation system and the Berchtold Chromophare E-Series Surgical Lighting system (the Berchtold Lights system). This interface provides voice- activated or touchscreen control of the Berchtold Lights system. -
Page 7: Setup And Interconnection
Setup and Interconnection Below is a block diagram of the necessary connections between SIDNE® and the Berchtold® Lights Control Center. SIDNE Interface Cable Device Adapter Berchtold SIDNE EDAM Lights System 1 = USB Type A 2 = USB Type B 3 = Female DB-9 4 = USB Type B Determining the Connections between SIDNE and... -
Page 8: Mounting The Edam
The SIDNE console is now connected to the Berchtold Lights System. Mounting the EDAM Stryker recommends securing the EDAM in a secure location on a cart. Remove the Velcro strips from the package. Carefully remove the protective paper backing covering the adhesive side of the Velcro strips. - Page 9 If this occurs, follow the steps below: 1. Remove the dongle, restart SIDNE, and reinsert the dongle. 2. If the same problem occurs again, contact Stryker Technical Support. “Programming complete. Wait for the next instruction. Please wait” “Software installation Wait for the next instruction.
-
Page 10: System Operation
Caution SIDNE should say “O. R. Lights Connected” and the EDAM LED should flash green within 30 seconds after the Berchtold® Lights Control Box and SIDNE have been powered on and initialized. A different LED output may indicate device problems. If this occurs, refer to the “Troubleshooting Guide” of this manual for instructions. -
Page 11: Touchscreen Commands
Touchscreen Commands The figure below shows the touchscreen controls for the Surgical Lights. The following table describes touchscreen buttons, level meters, and functions. Button Buttons/ Description Group Levels Power Turns a particular light on or off. The button also shows the state of that light; green indicates that the Light- light is on, while blue indicates that the light is off. - Page 12 Turns all the lights on. Turns all the lights off. All Light controls High Sets all lights to the maximum intensity. Sets all lights to the minimum intensity. Brighter Increases the intensity of all lights by one level, if possible. Darker Decreases the intensity of all lights by one level, if possible.
-
Page 13: Voice Commands
Voice Commands (For voice-enabled SIDNE® models only.) The table below shows the SIDNE voice commands for controlling the Berchtold Surgical Lights. Device Function Selection Description Level Selection SIDNE O. R. Light 1 or Activate Turns light on. Lights Light 2 or Brighter Increases light intensity by one level. -
Page 14: Notes On The Sidne® Berchtold Surgical Lights Interface
Status Bar The status bar, shown below, appears at the bottom of the monitor screen and indicates the light level for Lights 1 through 3 (marked “L1, ” “L2, ” and “L3, ” respectively). Indicates light 1 level Indicates light 2 level Indicates light 3 level Indicates if Endolite is on or off SIDNE Feedback Messages... -
Page 15: Troubleshooting Guide
No access to device This problem has several possible causes. Please see below. through SIDNE® EDAM LED continually Contact Stryker Endoscopy or your local Stryker sales flashes red* representative for firmware upgrade. EDAM LED shines The device is not communicating properly with the EDAM. -
Page 16: Electromagnetic Compatibility
Problem Possible Solution SIDNE says “O. R. • Power off the device. Lights Disconnected” • Ensure that the device is properly connected to SIDNE (See the “Setup and Interconnection” section of this manual for further instructions.) • Power on the device. *The EDAM LED should flash green when the system is functioning normally. - Page 17 Warning If the SIDNE Berchtold Lights package is used adjacent to, or stacked with other equipment, observe and verify normal operation of the SIDNE Berchtold Lights package in the configuration in which it will be used prior to using it in a surgical procedure.
- Page 18 Guidance and Manufacturer's Declaration: Electromagnetic Immunity SIDNE Berchtold Lights package is intended for use in the electromagnetic environment specified below. The customer or the user of SIDNE Berchtold Lights package should ensure that it is used in such an environment. Electrostatic Discharge ±6 kV contact ±2, 4, 6 kV contact...
- Page 19 Guidance and Manufacturer's Declaration: Electromagnetic Immunity SIDNE Berchtold Lights package is intended for use in the electromagnetic environment specified below. The customer or the user of SIDNE Berchtold Lights package should ensure that it is used in such an environment. Power frequency 3 A/m Power-frequency...
- Page 20 Guidance and Manufacturer's Declaration: Electromagnetic Immunity SIDNE® Berchtold Lights package is intended for use in the electromagnetic environment specified below. The customer or the user of SIDNE Berchtold Lights package should ensure that it is used in such an environment. Radiated RF 3 V/m 3 V/m...
- Page 21 NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects, and people. © Stryker and Stryker Endoscopy are registered trademarks of Stryker Corporation. Berchtold® is a registered trademark of the Berchtold Corporation.
- Page 23 Stryker Endoscopy 5900 Optical Court San Jose, CA 95138 USA 1-408-754-2000, 1-800-624-4422 www.stryker.com P11544 B 2010/01...
