Page 1: Theater System
Instruction Manual DIGITAL HOME THEATER SYSTEM HT-X200 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Samsung Electronics America, Inc. 1-800-SAMSUNG (7267864) www.samsung.com COMPACT AH68-01963R REV : 00 DIGITAL AUDIO... -
Page 2: Safety Warnings
Safety Warnings Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep TO REDUCE THE RISK OF ELECTRIC SHOCK, these operating instructions handy for future DO NOT REMOVE REAR COVER (or BACK). -
Page 3: Table Of Contents
Anynet+(HDMI-CEC) Function Anynet+ is a function that can be used to operate the main unit using a Samsung TV remote control, by connecting the Home Theater to a SAMSUNG TV using an HDMI Cable. (This is only available with SAMSUNG TVs that support Anynet+.) -
Page 4: Notes On Discs
Notes on Discs DVD players and the discs are coded by region. These regional codes must match in order for the disc to play. If the codes do not match, the disc will not play. The Region Number for this player is given on the rear panel of the player. (Your DVD player will only play DVDs that are labeled with identical region codes.) Playable Discs Disc Type... -
Page 5: Description
Description Front Panel Rear Panel 1. 2.1 Channel Speaker Output Connector 5. HDMI OUT Jack 2. Component Video Output Jacks 6. AUX IN 2 Jacks Connect a TV with Component video inputs to these jacks. 7. FM 75 COAXIAL Jack 3. - Page 6 Description (Con’t) Remote Control Insert Remote Batteries 1. DVD RECEIVER button 2. TV button 3. TV/VIDEO button 4. POWER button 5. Number (0~9) buttons 6. REMAIN button 7. STEP button 8. Tuning Preset/CD Skip buttons 9. VOLUME button 10. MENU button 11.
-
Page 7: Connecting The Speakers
Connecting the Speakers Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Selecting the Listening Position Position of the DVD Player • The listening position should be located about 2.5 to 3 times the Place it on a stand or cabinet shelf, or under the TV stand. -
Page 8: Installing The Main Unit
Installing the Main Unit Method 1 : Installing the Stand so that the DVD Player Lays Flat. Preparation Disconnect the AC power cord from the AC outlet before installing the main unit. Connect the cables before installation. Turn the stand counter-clockwise and pull it apart. The DVD Player and stand are separated. -
Page 9: Connecting The Video Out To Your Tv
Using Anynet+(HDMI-CEC) Anynet+ is a function that enables you to control other Samsung Devices with your Samsung TV's remote control, Anynet + can be used by connecting this Home Theater to a SAMSUNG TV using an HDMI Cable. This is only available with SAMSUNG TVs that support Anynet+. -
Page 10: Connecting Audio From External Components
Connecting Audio from External Components AUX1 : Side Panel AUX2 : Rear Panel Audio Cable (not supplied) If the external analog component has only one Audio Out, connect either left AUX1 : Connecting an External Component/MP3 player Connect AUX IN 1 (Audio) on the Home Theater to the Audio Out of the external component/MP3 player. Press the AUX button on the remote control to select <AUX1>... -
Page 11: Connecting The Fm Antenna
Connecting the FM Antenna FM Antenna (supplied) Connect the FM antenna supplied to the FM 75 COAXIAL Jack. Slowly move the antenna wire around until you find a location where reception is good, then fasten it to a wall or other rigid surface. •... -
Page 12: Before Using Your Home Theater
Before Using Your Home Theater To Operate your Samsung TV and the Home Theater with the HT-X200's Remote Control The DVD Home Theater's remote can be used to control Samsung TVs. Plug the main unit's power cord into the AC power supply. -
Page 13: Mp3/Wma-Cd Playback
MP3/WMA-CD Playback Data CDs (CD-R, CD-RW) encoded in MP3/WMA format can be played. Load the MP3 disc. The MP3/WMA menu screen will appear and playback will start. The appearance of the menu depends on the MP3/WMA disc. WMA-DRM files cannot be played. In Stop mode, use the Cursor and then press the ENTER button. -
Page 14: Divx Playback
DivX Playback DivX The functions on this page apply to DivX disc playback. Skip Forward/Back During playback, press the Goes to the next file whenever you press the Goes to the previous file whenever you press the Fast Playback To play back the disc at a faster speed, press the Each time you press either button, the playback speed will change as follows: Normal. -
Page 15: Using The Playback Function
Using the Playback Function Displaying Disc Information You can view disc playback information on the TV screen. Press the INFO button. Each time the button is pressed, the display changes as follows: Display disappears JPEG DivX Display disappears • Depending on the disc, the disc information display may appear different. •... -
Page 16: Skipping Scenes/Songs
Using the Playback Function Skipping Scenes/Songs Press the button. Each time the button is pressed during playback, the previous or next chapter, track or directory (file) will be played. You cannot skip chapters consecutively. TITLE 01/05 CHAPTER 002/045 (Con’t) Repeat Playback Repeat playback allows you to repeatedly play a chapter, title, track (song), or directory (MP3 file). -
Page 17: A-B Repeat Playback
Using the Playback Function A-B Repeat Playback You can repeatedly play back a designated section of a DVD. Press the INFO button twice. Press the Cursor button to move to the REPEAT PLAYBACK ( Press the Cursor button to select <A-> and then press the ENTER button at the beginning of the desired segment. -
Page 18: Ez View Function
Using the Playback Function EZ VIEW Function Press the EZ VIEW button. Each time the button is pressed, the zoom function will switch between On and Off. When a movie is played in Widescreen format, black bars at the top and bottom of the TV screen can be removed by pressing the EZ VIEW button. -
Page 19: Moving Directly To A Scene/Song
Using the Playback Function Moving Directly to a Scene/Song Press the INFO button. Press the Cursor button or numeric buttons to select the desired title/track ( ) and then press the ENTER button. Press the Cursor button to move to the Chapter ( Press the Cursor button or numeric buttons to select the desired chapter and then press the ENTER button. -
Page 20: Playing Media Files Using The Usb Host Feature
Playing Media Files using the USB Host Feature You can enjoy media files such as pictures, movies and music saved in an MP3 player, USB memory or digital camera in high quality video by connecting the storage device to the USB port of the home theater. Connect the USB device to the USB port on the side of the unit. -
Page 21: Settings
Settings Setting the Language OSD(On-Screen Display) language is set to English by default. In Stop mode, press the MENU button. Press the Cursor button to move to <Setup> and then press the ENTER button. Select <LANGUAGE> and then press the ENTER button. Press the Cursor button to select <OSD LANGUAGE>... -
Page 22: Setting Parental Controls (Rating Level)
This selects one of the 3 wallpaper screens Press the EXIT button to exit the setup screen. • ORIGINAL : Select this to set the Samsung Logo image as your wallpaper. • USER : Select this to set the desired image as your wallpaper. -
Page 23: Dvd Playback Mode
Settings (Con’t) DVD Playback Mode Some DVD-Audio discs contain DVD-Video as well as DVD-Audio. To play back the DVD-Video portion of the DVD-Audio disc, set the unit to DVD-Video mode. Press the EJECT button and then press the MENU button. Press the Cursor button to move to <Setup>... -
Page 24: Setting The Hdmi Audio
Settings (Con’t) Setting the HDMI Audio The audio signals transmitted over the HDMI Cable can be toggled ON/OFF. In Stop mode, press the MENU button. Press the Cursor button to move to <Audio> and then press the ENTER button. Press the Cursor button to move to <HDMI AUDIO>... -
Page 25: Presetting Stations
Listening to Radio (Con’t) Presetting Stations Example : Presetting FM 89.10 in the memory Press the TUNER button to select the FM band. Press the button to select <89.10>. Press the TUNER MEMORY button. <01> flashes in the display. Press the button to select preset number. -
Page 26: Operating A Tv With The Remote Control
• The remote control may not work on some brands of TVs. Also, some operations may not be possible depending on your brand of TV. • If you do not set the remote control with the code for your brand of TV, the remote control will work on a Samsung TV by default. a baseball... -
Page 27: Troubleshooting
Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact the nearest authorized dealer or Samsung Electronics Service Center. Brand... -
Page 28: Cautions On Handling And Storing Discs
Troubleshooting (Con’t) Symptom • Is the TV power on? • Disc is rotating but no • Are the video cables connected properly? picture is produced. • • Picture quality is poor and Is the disc dirty or damaged? • picture is shaking. A poorly manufactured disc may not be playable. -
Page 29: Language Code List
Nikon Digital Camera Creative MuVo NX128M Creative Nikon Digital Camera Iriver H320 Iriver 20G HDD MP3 Player Nikon Digital Camera YH-920 Samsung 20G HDD MP3 Player Nikon Digital Camera YP-T7 Samsung Olympus Digital Camera YP-MT6 Samsung Olympus Digital Camera YP-T6... -
Page 30: Specifications
Pr:0.70Vp-p(75 load) Pb:0.70Vp-p(75 load) SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if Impedance: 85~115 found to be defective during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. - Page 31 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Region Country Customer Care Center Web Site...
