Samsung PS-42C91H Owner's Instructions Manual

Pdp-television
Hide thumbs Also See for PS-42C91H:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
Owner's Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
Picture In Picture (PIP)

Energy Saving

TELETEXT

SRS TruSurround XT

Digital Natural Image engine
Register your product at www.samsung.com/global/register
Record your Model and Serial number here for future reference.
▪ Model _______________ ▪ Serial No. _______________
PDP-TELEVISION
(P
LASMA
(Option)
D
P
ISPLAY
)
ANEL

Advertisement

Table of Contents
loading

Related Manuals for Samsung PS-42C91H

Summary of Contents for Samsung PS-42C91H

  • Page 1: Energy Saving

    ON-SCREEN MENUS Picture In Picture (PIP) Energy Saving TELETEXT SRS TruSurround XT Digital Natural Image engine Register your product at www.samsung.com/global/register Record your Model and Serial number here for future reference. ▪ Model _______________ ▪ Serial No. _______________ LASMA ISPLAY (Option)

  • Page 2: User Instructions

    Failure to do so may cause a serious damage to your set. © 2007 Samsung Electronics Co., Ltd. All rights reserved. English - 2...

  • Page 3: Table Of Contents

    Contents General Information  User Instructions ... 2  Checking Parts ... 4  Using the Stand-Base ... 4  Control Panel ... 5  Connection Panel ... 6  Viewing the Remote Control (depending on the model) ... 8 Operation ...

  • Page 4: Checking Parts

    Checking Parts Owner’s Instructions Warranty Card/ Cover-Bottom / Screws (2ea) Registration Card/ Safety Guide Manual S-Video Cable Antenna Cable PC Cable PC Audio Cable ➢ Ferrite Core (Power Cord, Side-Video Cable, Headphones Cable, S-Video Cable) The ferrite core is used to shield the cable from interference.

  • Page 5: Control Panel

    Control Panel Front (or Side) Panel ➢ The product colour and shape may vary depending on the model. 1 SOURCE Displays a menu of all of the available input sources (TV, AV1, AV2, S-Video, Component1, Component2, PC, HDMI1, and HDMI2). 2 MENU Press to see the on-screen menu of your TV’s features.

  • Page 6: Connection Panel

    Connection Panel Side Panel ➢ The product colour and shape may vary depending on the model. ☛  Whenever you connect an audio or video system to your set, ensure that all elements are switched off.  When connecting an external device, match the colour of the connection terminal to the cable. 1 AV IN 2 (S-VIDEO or VIDEO / AUDIO L/R) Video (S-Video or Video) and audio inputs for external devices, such as a camcorder or VCR.
  • Page 7 Rear Panel ➢ The product colour and shape may vary depending on the model. ☛  Whenever you connect an audio or video system to your set, ensure that all elements are switched off.  When connecting an external device, match the colour of the connection terminal to the cable. 1 ANT IN 75Ω...

  • Page 8: Viewing The Remote Control (Depending On The Model)

    Viewing the Remote Control ➢  This is a special remote control for the visually impaired persons, and has Braille points on the POWER, Volume and Channel buttons.  The performance of the remote control may be affected by bright light. 1 POWER button (turns the TV on and off) 2 Number buttons for direct...

  • Page 9: Switching Your Television On And Off

    Installing Batteries in the Remote Control Lift the cover at the back of the remote control upward as shown in the figure. Install two AAA size batteries. ➢  Make sure to match the “+” and “–” ends of the batteries with the diagram inside the compartment.

  • Page 10: Viewing The Menus

    Viewing the Menus Press the MENU button. The main menu is displayed on the screen. Its left side has five icons: Picture, Sound, Channel, Setup, and Input. Press the ▲ or ▼ button to select one of the icons. Press the ENTER button to access the icon’s sub-menu. Press the ▲...
  • Page 11 Press the ◄ or ► button to select Shop or Home, then press the ENTER button. The message to check the connected status of the antenna is displayed. ➢  The default selection is Home.  We recommend setting the TV to Home mode for the best picture in your home environment.

  • Page 12: Viewing An External Signal Sources

    Viewing an External Signal Sources You can switch between viewing signals from connected equipment, such as a VCR, DVD, Set-Top Box, and the TV source (broadcast or cable). Press the MENU button to display the menu. Press the ▲ or ▼ button to select Input, then press the ENTER button.

  • Page 13: Storing Channels Automatically

    Storing Channels Automatically You can scan for the frequency ranges available to you (availability depends on your country). Automatically allocated programme numbers may not correspond to actual or desired programme numbers. However you can sort numbers manually and clear any channels you do not wish to watch.

  • Page 14: Storing Channels Manually

    Storing Channels Manually You can store television channels, including those received via cable networks. When storing channels manually, you can choose:  Whether or not to store each of the channels found.  The programme number of each stored channel which you wish to identify.

  • Page 15: Adding / Locking Channels

    Adding / Locking Channels Using the Channel Manager, you can conveniently lock or add channels. Press the MENU button to display the menu. Press the ▲ or ▼ button to select Channel, then press the ENTER button. Press the ▲ or ▼ button to select Channel Manager, then press the ENTER button.

  • Page 16: Assigning Names To Channels

    Assigning Names to Channels Channel names will be assigned automatically when channel information is broadcast. These names can be changed, allowing you to assign new names. Press the MENU button to display the menu. Press the ▲ or ▼ button to select Channel, then press the ENTER button.

  • Page 17: Changing The Picture Standard

    Changing the Picture Standard You can select the type of picture which best corresponds to your viewing requirements. Press the MENU button to display the menu. Press the ENTER button to select Picture. Press the ENTER button again to select Mode. Select the required mode by pressing the ▲...

  • Page 18: Configuring Detailed Settings On The Picture

    Configuring Detailed Settings on the Picture You can set detailed picture settings. Press the MENU button to display the menu. Press the ENTER button to select Picture. Press the ▲ or ▼ button to select Detailed Settings, then press the ENTER button. Select the required option by pressing the ▲...

  • Page 19: Selecting The Picture Size

    Selecting the Picture Size You can select the picture size which best corresponds to your viewing requirements. Press the MENU button to display the menu. Press the ENTER button to select Picture. Press the ▲ or ▼ button to select Size, then press the ENTER button.

  • Page 20: Digital Nr / Active Colour / Dnie

    Digital NR / Active Colour / DNIe Press the MENU button to display the menu. Press the ENTER button to select Picture. Select the required option by pressing the ▲ or ▼ button, then press the ENTER button. Available options: Digital NR, Active Colour, DNIe When you are satisfied with your setting, press the ENTER button.
  • Page 21  Mode: Standard/Music/Movie/Speech/Custom You can select the type of special sound effect to be used when watching a given broadcast. ➢  Choose Standard for the TV standard factory settings.  Choose Music when watching the music videos or concerts. ...

  • Page 22: Selecting The Sound Mode (Depending On The Model)

    Selecting the Sound Mode The DUAL I-II button displays/controls the processing and output of the audio signal. When power is switched on, the mode is automatically preset to either “DUAL-I” or “Stereo”, depending on the current transmission. Type of broadcast Regular broadcast (Standard audio) Regular + NICAM Mono...

  • Page 23: Time Features

    Time Features Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup, then press the ENTER button. Press the ▲ or ▼ button to select Time, then press the ENTER button. Select the required option by pressing the ▲ or ▼ button, then press the ENTER button.

  • Page 24: Language / Blue Screen / Melody / Light Effect / Energy Saving / Hdmi Black Level

    Language / Blue Screen / Melody / Light Effect / Energy Saving / HDMI Black Level Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup, then press the ENTER button. Select the required option by pressing the ▲ or ▼ button, then press the ENTER button.

  • Page 25: Using Game Mode

    Using Game Mode When connecting to a game console such as PlayStation Xbox , you can enjoy a more realistic gaming experience by selecting game menu. Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup, then press the ENTER button.

  • Page 26: Screen Burn Protection

    Screen Burn Protection To reduce the possibility of screen burn, this unit is equipped with screen burn prevention technology. This technology enables you to set picture movement up/down (Vertical Line) and side to side (Horizontal Dot). The Time setting allows you to program the time between movement of the picture in minutes.

  • Page 27: Wall- Mount Adjustment (Sold Separately)

    Wall- mount adjustment (Sold separately) Once the wall mount is installed, the position of your TV can be easily adjustable. TV Rear Panel Serial Cable(1P to 1P)(Not supplied) Entering the menu Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup, then press the ENTER button.

  • Page 28: Viewing The Picture In Picture (Pip)

    Viewing the Picture in Picture (PIP) You can display a sub picture within the main picture. In this way you can watch TV program or monitor the video input from any connected devices. Press the MENU button to display the menu. Press the ▲...

  • Page 29: Setting Up Your Pc Software (Based On Windows Xp)

    PC will probably be different, depending upon your particular version of Windows and your particular video card. But even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) Right click the mouse on the Windows Desktop, then click on Properties.

  • Page 30: Input Mode (Pc)

    Input Mode (PC) Both screen position and size will vary depending on the type of PC monitor and its resolution. The table below shows all of the display modes that are supported: Vertical Video Resolution frequency Signal (Dot X Line) 640 x 350 720 x 400 640 x 480...

  • Page 31: Setting The Pc

    Setting the PC ➢ Preset to the PC mode by pressing the SOURCE button. Press the MENU button to display the menu. Press the ▲ or ▼ button to select Setup, then press the ENTER button. Press the ▲ or ▼ button to select PC, then press the ENTER button.

  • Page 32: Setting The Home Theatre Pc

    Setting the Home Theatre PC ➢ Preset to the PC mode by pressing the SOURCE button. You can view higher quality pictures by configuring the screen settings in PC Mode. If you set the Home Theatre PC function to On, you can configure the Detailed Settings (when Picture Mode is set to Movie) as in PC Mode.

  • Page 33: Teletext Feature (Depending On The Model)

    Teletext Feature (depending on the model) Most television stations provide written information services via teletext. The index page of the teletext service gives you information on how to use the service. In addition, you can select various options to suit your requirements by using the remote control buttons. ☛...
  • Page 34 The teletext pages are organized according to six categories: Part Contents Selected page number. Broadcasting channel identity. Current page number or search indications. Date and time. Text. Status information. FASTEXT information. Teletext information is often divided between several pages displayed in sequence, which can be accessed by: ...

  • Page 35: Wall Mount Kit Specifications (Vesa)

    Samsung is not liable for these kinds of accidents. ➢ Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.

  • Page 36: How To Assemble The Stand-Base (Depending On The Model)

    How to assemble the Stand-Base Using the 6 screws for securing the stand base and the monitor, firmly attach the monitor to the stand base. (The exterior of the set may be different than the picture.) (depending on the model) Warning Firmly secure the stand to the TV before moving it, as the stand may fall and could cause serious injury.

  • Page 37: Troubleshooting

    Troubleshooting Before contacting the Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer. No sound or picture ...

  • Page 38: Specifications

    Specifications Model Name PS42C9H Screen Size (Diagonal) PC Resolution 1024 x 768 @ 60 Hz Sound (Output) 10 W +10W Dimensions (WxHxD) Body 1055.0 X 699.5 X 95.0 mm With stand 1055.0 X 759.0 X 316.0 mm Weight Body With stand Environmental Considerations Operating Temperature Operating Humidity...
  • Page 39 This page is intentionally left blank.
  • Page 40 Contact SAMSUNG WORLD-WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country AUSTRALIA 1300 362 603 CHINA 800-810-5858, 010- 6475 1880 HONG KONG 3698-4698 INDIA 3030 8282, 1800 1100 11...
