Summary of Contents for LXNAV MOP2
- Page 1 LX MOP2 Means of propulsion sensor 2 Installation manual Version 1.1 LXNAV d.o.o. • Kidričeva 24, 3000 Celje, Slovenia • tel +386 592 33 400 • fax +386 599 33 522 info@lxnav.com • www.lxnav.com...
-
Page 2: Table Of Contents
LX MOP2 March 2018 Important Notices Limited Warranty Packing list Fitting MOP2 Functional test Analysing MOP2 record Technical Revision history Page 2 of 10... -
Page 3: Important Notices
1.1 Limited Warranty This LX MOP2 product is warranted to be free from defects in materials or workmanship for two years from the date of purchase. Within this period, LXNAV will, at its sole option, repair or replace any components that fail in normal use. -
Page 4: Packing List
LX MOP2 March 2018 2 Packing list • MOP2 BOX with attached Hall current sensor • 3.5m RS485 extension cable (Male/Female) • Installation manual Page 4 of 10... -
Page 5: Fitting Mop2
Figure 1: MOP2 dimensions Figure 2: Hall current sensor dimensions • Install MOP2 and Hall current sensor close to the positive lead of battery of the E-motor (refer to Figure 1 and Figure 2 for detailed dimensions) • Unscrew the screw holding the hall current sensor frame closed and then open it •... - Page 6 LX MOP2 March 2018 Figure 3: Hall sensor - positive current flow direction Page 6 of 10...
-
Page 7: Functional Test
March 2018 4 Functional test Functional test can be performed on the LXxxxx system by 2 procedures. MOP2 Setup - option: 1. Switch on LXxxxx device and a FCU unit 2. On the LXxxxx device, go to Setup->Password menu 3. Insert password 09978 4. -
Page 8: Analysing Mop2 Record
LX MOP2 March 2018 5 Analysing MOP2 record Mop record is stored in IGC file as additional column, called MOP. Mop values are normally moving between 0 and 999. Page 8 of 10... -
Page 9: Technical
LX MOP2 March 2018 6 Technical Property Value Note MOP2 Current consumption 70Ma At 12V MOP2 Input voltage range 9-18V Hall current range +/- 300A Page 9 of 10... -
Page 10: Revision History
LX MOP2 March 2018 7 Revision history March 2018 Complete revision of this manual Page 10 of 10...
