  • Page 1 Owner’s Instructions HPL5025...
  • Page 2 Warning! Important Safety Instructions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates high voltage is present inside. It is dangerous to make any kind of contact with any inside part of this product.

  • Page 3: Important Safety Information

    Thank You for Choosing Samsung Thank you for choosing Samsung! Your new Samsung product represents the latest in television technol- ogy. We designed it with easy-to-use on-screen menus and closed captioning capabilities, making it one of the best products in its class. We are proud to offer you a product that will provide convenient, dependable service and enjoyment for years to come.
  • Page 4 • Protect the power cord. Power supply cords should be routed so that they won’t be walked on or pinched by objects placed on or against them. Pay particular attention to cords at plugs, convenience recepta- cles, and the point where they exit from the unit. •...

  • Page 5: Fcc Information

    U.S. Government Printing Office, Washington, DC 20402, Stock Number 004-000-00345-4 . The party responsible for product compliance: SAMSUNG ELECTRONICS CO., LTD America QA Lab of Samsung 3351 Michelson Drive, Suite #290, Irvine, CA92612 USA Tel) 949-975-7310 Fax) 949-922-8301...

  • Page 6: User Instructions

    Be careful in the selection and duration of television formats used for viewing. Uneven PDP aging as a result of format selection and use,as well as other burned-in images,is not covered by your Samsung limited warranty. User Instructions...

  • Page 7: Table Of Contents

    Table of Contents Setup Your New Plasma Display Panel ...10 Remote Control Buttons ...12 Wall Installation Instructions ...14 Turning the PDP On and Off...18 Connection (Connecting Speakers / Receiver) Connecting Speakers ...22 Connecting a VCR/Cable Box ...23 Connecting a DVD/Set-Top Box ...24 Picture Control Customizing the Picture ...26 Using Automatic Picture Settings ...27...

  • Page 9: Setup

    Setup Your New Plasma Display Panel ...10 Remote Control Buttons ...12 Wall Installation Instructions ...14 Turning the PDP On and Off ...18...

  • Page 10: Your New Plasma Display Panel

    Your New Plasma Display Panel Front Panel POWER Press to turn the PDP on and off. Checking Parts Remote Control/ AAA Batteries S-VIDEO Cable SOURCE, MENU, VOLUME (-,+), Remote Control Signal Receiver SELECT (▼,▲), MUTE Aim the remote control towards this spot on the Monitor.
  • Page 11 Rear Panel Œ External Speaker Out jacks Connect external speakers. ´ RGB Input 1 jack (15pin) Connect to the video output jack on your PC. ˇ RGB Input 2/Component Video Input jacks (H/V/R/G/B, Y/P RGB input2/Component video input jacks are BNC connectors.

  • Page 12: Remote Control Buttons

    ” Aspect button Press to change the screen size. ’ Mode button Selects a target device to be controlled by the samsung remote control (ie., VCR, Cable, or DVD players). ˝ Clock Display button Press to display clock on the PDP screen.
  • Page 13 ı VCR control buttons Controls VCR tape functions: Stop, Rewind, Play/Pause, Fast Forward. ˜ SET button Use during setting up of this remote control, so that it will work compatibly with other devices (VCR, cable box, DVD, etc.) ¯ Clock set button Press to clock setting.

  • Page 14: Wall Installation Instructions

    Wall Installation Instructions Installation Notes Do not install the PDP on any place other than vertical walls. To protect the performance of the PDP and prevent troubles, avoid the following. • Do not install next to smoke and fire detectors. •...

  • Page 15: Installing The Display On The Wall Attachment Panel

    Installing the Display on the Wall Attachment Panel See the drawing of the wall attachment panel shown in page 14 to check for the stability of the wall where the PDP is to be installed. If the wall is not enough strong to support the PDP, strengthen the wall before installation.
  • Page 16 Remove six large screws from the rear side of the display. Insert the bolts, dish-type washers, and insulation holder into the holes as shown in the following figure: Œ Bolt ´ Insulation holder Hang the protruding plastic part on the rear of the PDP up the groove on the top of the wall attachment panel.
  • Page 17 Separating the Display from the Wall Attachment Panel After lifting the PDP up, pull it forward and remove it from the wall attachment panel. Œ ´...

  • Page 18: Turning The Pdp On And Off

    Turning the Monitor(PDP) On and Off Turning the Monitor(PDP) On and Off Press the Power button on the remote control. The PDP will be turned on and you will be ready to use it’s features. You can also use the Power button on the front of the PDP.
  • Page 19 Displaying Status Information Press the Display button on the remote control. The PDP will display the Screen size, Resolution, Current time, and screen mode. Displaying Clock Press the Clock Display button on the remote control. The Current time will be displayed on the screen. DISPLAY Main : Video...

  • Page 21: Connection (Connecting Speakers / Receiver)

    Connection (Connecting Speakers / Receiver) Connecting Speakers ...22 Connecting a VCR/Cable Box ...23 Connecting a DVD/Set-Top Box ...24...

  • Page 22: Connecting Speakers

    Connecting Speakers ✱ The speakers MUST have more than 7watts rating (impedance 8ohm). How to Connect Connect the speaker audio cable to the external speaker output jack on the rear of the PDP matching the “+” and “-” ends of the cable with the diagram on the PDP. Connecting PDP and Speakers / Stand and Speakers Fix the bracket onto the guide pole located on the rear of speaker and fasten the screws.

  • Page 23: Connecting A Vcr/Cable Box

    Connecting a VCR/Cable Box How to Connect Connect Video/S-Video cable between the Video/S-Video Output jack on the VCR/Cable box and the Video Input jack on the PDP. • For better video, you can use a S-Video cable. • You can attach the (supplied) to the both jacks of the Video cable.

  • Page 24: Connecting A Dvd/Set-Top Box

    Connecting a DVD/Set-Top Box How to Connect Connect a Video cable between the DVD/Set-Top Box (Y,P Top Box and the Component1/2 Video Input (Y,P • You can attach the Ferrite Cores Simply set the Ferrite Cores Connect an Audio cable between the Audio Output jack on the DVD/Set-Top Box and the Audio Input jack (Component) on the PDP.

  • Page 25: Picture Control

    Picture Control Customizing the Picture ...26 Using Automatic Picture Settings ...27 Viewing the Picture-in-Picture...28 Changing the Screen Size ...31 Freezing the Picture ...32...

  • Page 26: Customizing The Picture

    Customizing the Picture You can use the on-screen menus to change the Brightness, Contrast, Sharpness, Color, and Tint settings of your PDP. Press the Menu button, then press the joystick to enter. Move the joystick left or right to select the “Custom”. You will also see the items “Contrast”, “Brightness”, “Sharpness”, “Color”...

  • Page 27: Using Automatic Picture Settings

    Using Automatic Picture Settings Your PDP has automatic picture settings that allow you to adjust the video display easily. Press the Menu button, then press the joystick to enter. Quick way to access the picture setting: Just press “P.Mode” on the remote control. Move the joystick left or right to select the “Custom”, “Standard”, or “Mild”...

  • Page 28: Viewing The Picture-In-Picture

    Viewing the Picture-in-Picture Selecting the PIP Screen Press the Menu button. Move the joystick up or down to select the “PIP”, then press the joystick to enter. Quick way to access the PIP: Just press “PIP” on the remote control. Move the joystick left or right to select the “On”.

  • Page 29: Selecting An External Signal

    Selecting an External Signal You can use PIP to view a signal from an external source, such as a VCR. Press the Menu button. Move the joystick up or down to select the “PIP”, then press the joystick to enter. Quick way to access the PIP source: Just press “Source”...

  • Page 30: Changing The Location Of The Pip Image

    Changing the Location of the PIP Image Press the Menu button. Move the joystick up or down to select the “PIP”, then press the joystick to enter. Quick way to access the PIP location: Just press “Locate” on the remote control. Move the joystick up or down to select the “Locate”.

  • Page 31: Changing The Screen Size

    Changing the Screen Size (When entering the Video mode) When you press the Aspect button on the remote control, the PDP’s screen mode should appear in sequence. The screen displays in this order: Wide, Panorama, Zoom1, Zoom2, Stretch, 4:3. Note •...

  • Page 32: Freezing The Picture

    Freezing the Picture Still Press the Still button on the remote control to freeze a mov- ing picture into a still one. Press again to cancel.

  • Page 33: Sound Control

    Sound Control Customizing the Sound ...34 Using Automatic Sound Settings ...35 Using the Surround ...36...

  • Page 34: Customizing The Sound

    Customizing the Sound Press the Menu button. Move the joystick up or down to select the “AUDIO”, then press the joystick to enter. Move the joystick left or right to select the “Custom”. You will also see the items “Treble”, “Bass”, “Balance”...

  • Page 35: Using Automatic Sound Settings

    Using Automatic Sound Settings Press the Menu button. Move the joystick up or down to select the “AUDIO”, then press the joystick to enter. Quick way to access the sound setting: Just press “S.Mode” on the remote control. Move the joystick left or right to select the “Custom”, “Standard”, “Music”, “Movie”...

  • Page 36: Using The Surround

    Using the Surround Press the Menu button. Move the joystick up or down to select the “AUDIO”, then press the joystick to enter. Move the joystick up or down to select the “Surround”, then move the joystick left or right to select the “Concert”, “Hall”...

  • Page 37: Time Setting

    Time Setting Setting the Clock ........38 Setting the Sleep Timer .

  • Page 38: Setting The Clock

    Setting the Clock This PDP has a built-in clock that will appear on screen when you press the Clock Display button on the remote control. Setting this clock also allows you to use it to automatically turn the PDP On or Off. Press the Menu button.

  • Page 39: Setting The Sleep Timer

    Setting the Sleep Timer You can set your PDP to automatically turn off after a preset interval. Press the Menu button. Move the joystick up or down to select “TIME”, then press the joystick to enter. Quick way to access the sleep timer: Just press “Sleep”...

  • Page 40: Setting The Timers

    Setting the Timers This PDP can be set to turn on or off automatically at specific times that you choose. Before using the timers, you must set the PDP’s clock, as described previously. Setting the On/Off Timer Press the Menu button. Move the joystick up or down to select the “TIME”, then press the joystick to enter.
  • Page 41 Move the joystick up or down to select “Off”, then move the joystick left or right to select “On”. If you want to set the Off Time, move the joystick down to select the “Off Time”. Set the “Off Time” just as you set the “On Time”. •...

  • Page 43: Connecting Pc And Operation

    Connecting PC and Operation Connecting to a PC ...44 Adjusting the PC Screen ...48 Changing the Position of the Image ...49 Changing the Size of the Image ...50 Enlarge of the Image (Zoom)...51 Move Expanded Picture ...52 Picture Quality Adjustment ...53 Information ...56 Power Saver (PC mode only)...57...

  • Page 44: Connecting To A Pc

    Connecting to a PC This PDP set is not compatible with Macintosh PC. PC (15pin) Cable Connecting a PC to the PDP Connect a PC (15pin) or BNC cable between the Video Output jack on the PC and the RGB1 (15p D-SUB) or RGB2 on the PDP. •...

  • Page 45: Pin Configuration

    Pin Configuration • 15Pin Signal Cable (based on protruded pin) Setting up Your Monitor Plug and Play  Our adoption of the new VESA Plug and Play solution eliminates complicated and time consuming setup. It allows you to install your monitor in a Plug and Play compatible system without the usual hassles and confusion.
  • Page 46 PC will probably be different, depending upon your particular version of Windows and your particular video card. But even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer. On the windows screen, select in the following sequence : Start ➝...
  • Page 47 Notes: Both screen position and size will vary, depending on the type of PC monitor and its resolution. The table below shows all of the display modes that are supported: Vertical Video signal Dot X Line Frequency (Hz) 640 X 350 70.086 85.080 640 X 400...

  • Page 48: Adjusting The Pc Screen

    Adjusting the PC Screen Adjusting the R.G.B Preset: • Press the RGB button to select the PC mode. Press the Menu button, then press the joystick to enter. Move the joystick up or down to select the “Color Control”, then move the joystick left or right to enter. Move the joystick up or down to select the item you want to change.

  • Page 49: Changing The Position Of The Image

    Changing the Position of the Image After connecting the PDP to your PC, adjust the position of screen if it is not well-aligned. Preset: • Press the RGB button to select the PC mode. Press the Menu button. Move the joystick up or down to select the “SETUP”, then press the joystick to enter.

  • Page 50: Changing The Size Of The Image

    Changing the Size of the Image Preset: • Press the RGB button to select the PC mode. Press the Menu button. Move the joystick up or down to select the SETUP, then press the joystick to enter. Quick way to access the Size: Just press “Scaling”...

  • Page 51: Enlarge Of The Image (Zoom)

    Enlarge of the Image (Zoom) Preset: • Press the RGB button to select the PC mode. Press the Menu button. Move the joystick up or down to select the SETUP, then press the joystick to enter. Quick way to access the Zoom: Just press “Zoom/Pan”...

  • Page 52: Move Expanded Picture

    Move Expanded Picture Preset: • Press the RGB button to select the PC mode. Press the Menu button. Move the joystick up or down to select the SETUP, then press the joystick to enter. Quick way to access the Zoom: Just press “Zoom/Pan”...

  • Page 53: Picture Quality Adjustment

    Picture Quality Adjustment Picture Automatic Adjustment On/Off Preset: • Press the RGB button to select the PC mode. Press the Menu button. Move the joystick up or down to select the SETUP, then press the joystick to enter. Quick way to access the Auto Adjust: Just press “Auto Adjust.”...
  • Page 54 Frequency Adjustment Preset: • Press the RGB button to select the PC mode. Press the Menu button. Move the joystick up or down to select the SETUP, then press the joystick to enter. Move the joystick up or down to select the “Image Lock”, then move the joystick left or right to enter.
  • Page 55 Fine Tuning (Phase) Preset: • Press the RGB button to select the PC mode. Press the Menu button. Move the joystick up or down to select the SETUP, then press the joystick to enter. Move the joystick up or down to select the “Image Lock”, then move the joystick left or right to enter.

  • Page 56: Information

    Information Preset: • Press the RGB button to select the PC mode. Press the Menu button. Move the joystick up or down to select the SETUP, then press the joystick to enter. Move the joystick up or down to select the “Miscel- laneous”, then move the joystick left or right to enter.

  • Page 57: Power Saver (Pc Mode Only)

    Power Saver (PC mode only) This monitor has a built-in power management system called Power Saver. This power management system saves energy by switching your monitor into a low-power mode when it has not been used for a certain amount of time. This power management system operates with a VESA DPMS compliant video card installed in your computer.

  • Page 59: Function Description

    Function Description Selecting a Menu Language ......60 Setting the Multi Control ....... .61 Using the Key Lock .

  • Page 60: Selecting A Menu Language

    Selecting a Menu Language Press the Menu button. Move the joystick up or down to select the “SETUP”, then press the joystick to enter. Move the joystick left or right to select the appropri- ate language: English, Spanish, or French. Press the Menu button to exit.

  • Page 61: Setting The Multi Control

    Setting the Multi Control Press the Menu button. Move the joystick up or down to select the “SETUP”, then press the joystick to enter. Move the joystick up or down to select the “Multi Control”, then move the joystick left or right to enter. Enter ID setup number.

  • Page 62: Using The Key Lock

    Using the Key Lock When setting Key Lock ON, the buttons (SOURCE, MENU, VOLUME, SELECT, MUTE, POWER) on the front of the PDP don’t operate. But those buttons will operate when setting Key Lock OFF. Press the Menu button. Move the joystick up or down to select the “SETUP”, then press the joystick to enter.

  • Page 63: Setting Up Your Remote Control

    Setting up Your Remote Control This PDP's remote control can operate almost any VCR, cable box, or DVD. After it has been set up properly, your remote control can operate in four different modes: VCR, Cable, or DVD. Pressing the corresponding button on the remote control allows you to switch between these modes, and control whichever piece of equipment you choose.
  • Page 64 Remote Control Codes VCR Codes Cable Box Codes DVD Codes...

  • Page 65: Appendix

    Appendix Troubleshooting...66 Care and Maintenance ...67 Specifications ...68...

  • Page 66: Troubleshooting

    Troubleshooting Before you call a service technician, please scan this list of problems and possible solutions. It may save you time and money. Problem Poor picture. The power indicator is amber blinking. Your Remote control does not operate the monitor. The monitor won’t turn on.

  • Page 67: Care And Maintenance

    Care and Maintenance With proper care, your PDP will give you many years of service. Please follow these guidelines to get the maximum performance from your PDP. Identifying Problems • Do not put the PDP near extremely hot, cold, humid or dusty places. •...

  • Page 68: Specifications

    RGB input VIDEO input HPL5025 1208.5 (W) X 89 (D) X 724 (H) mm ; 47.58 (W) X 3.50 (D) X 28.50 (H) inches 54 (W) X 31.5 (D) X 220 (H) mm ; 2.13 (W) X 1.24 (D) X 8.66 (H) inches 42kg ;...
  • Page 69 Memo...
  • Page 70 Memo...
  • Page 71 Memo...
  • Page 72 BN68-00263B-01(ENG)
