Operating
Manual
YM5 Recharger
007E100, 007E100B
Advertisement
Table of Contents
Related Manuals for Magnaflux YM5
Summary of Contents for Magnaflux YM5
- Page 1 Faraday Road, South Dorcan Industrial Estate, Swindon, SN3 5HE, UK Telephone: + 44 (0)1793 524566 Fax: +44 (0)1793 490459 Email: sales.eu@magnaflux.com Web: eu.magnaflux.com Bahnhofstr 94-98, 73457 Essingen, Deutschland YM5 Recharger Telephone: +49 (0) 7365 81-0 Fax: +49 (0) 7365 81-449 007E100, 007E100B Email: sales.de@magnaflux.com Web: eu.magnaflux.com/de...
- Page 2 Certificate of Conformity 2014/30/EU Certificate is issued under the auspices of the Equipment Product Manager: Magnaflux (A Division of ITW Ltd), Faraday Road, South Dorcan Industrial Estate, Swindon, SN3 5HE, UK Tel: +44 (0)1793 524566 Fax: +44 (0)1793 490459 Email: sales.de@magnaflux.com www.eu.magnaflux.com...
- Page 3 • Vacuum cleaners – 2-20 microtesla at 30 cm from the appliance • Electric drills – 2-20 microtesla at 30 cm from the appliance Typical magnetic field strengths for some Magnaflux MPI equipment: • MAG 50 coil – 1.3 millitesla at 30 cm •...
- Page 4 8-turn coils. Supplied loose with this is a battery charger, which operates at 220/240 V, 50 Hz and an extended keeper bar. The YM5 Recharger is designed to run from one 12 V car battery, part number Yuasa SWLL2250 (FR) or equivalent.
- Page 5 PARTS LIST OPERATION • Ensure that the feet of the YM5 are in good condition and flat to make good Item Quantity Description Part number contact with the keeper bar Main switch 015S230 • Position the Yoke by placing each leg through a coil (as shown in the diagram), Push button ‘Re-Mag’...
- Page 6 BATTERY HEALTH AND SAFETY Treat sulphuric acid with respect. It is a highly corrosive liquid and will cause severe injury if splashed on the skin or in the eyes, or if taken internally. It rapidly destroys most clothing. Sulphuric acid is scheduled as a poison in Part 2 of the Poisons List. Subsequent charging The charging current in amps should not be more than 10% of the battery’s rated Always:...
