40 C 3: C
HAPTER ONFIGURING
IP Telephony
Configuration
Table 4 VCX Basic Configuration Steps
Step
1 Access the VCX
Administrator Provisioning
application through a web
browser (Internet Explorer 6.0
or higher, or Firefox 2.0 or
higher).
2 Create dial string routing
patterns.
3 Define end points.
4 Add routes.
5 Add route plans.
6 Set up number translations.
IP T
ELEPHONY
Table 4 provides an overview of the steps involved in configuring the VCX
Connect product, including the location in the VCX Administration Guide
where detailed instructions can be found.
Purpose
Enables configuration of your VCX Connect
server.
A pattern defines the sequence of digits a
user dials to call another site, and the
sequence of digits dialed to reach an IP
Messaging voicemail server or Music On Hold
(MOH) server.
An end point is a device to which a call may
be sent. End points include the VCX Call
Processors (primary and secondary) that
process local (network) calls, gateways that
process out-of-network calls, and IP
Messaging servers that manage voice
mailboxes.
A route includes one or more end points.
A route plan associates a route with a dial
string pattern.
Note: You can create a dial string pattern,
define end points, add routes, and create a
route plan by running the Route Plan Wizard.
Allows calls to be routed based on source and
destination number patterns.
Related Section in the
VCX Administration Guide
(Revision AJ)
Accessing a VCX Site through the
Central Manager
Page 29
Configuring Patterns
Page 260
Managing End Points
Page 291
Route Plan Configuration
Requirements
Page 271
Managing Routes
Page 297
Managing Route Plans
Page 304
Using the Route Plan Wizard
Page 308
Configuring Number Translation
Page 263
Configuring Patterns (DIRECTORY)
Page 290
