Page 2
Trademarks • Windows is a trademark of Microsoft Corporation. • IBM is a trademark of International Business Machines. • Centronics is a trademark of Centronics Data Computer. • Other names and trademarks mentioned in this manual are trademarks of their respective holders.
Contents Chapter 1 Getting Started Setting up your machine ________________________________ 1.2 Unpacking ____________________________________________ 1.2 Control locations and functions __________________________ 1.3 Front view ___________________________________________ 1.3 Rear view ___________________________________________ 1.4 Inside _______________________________________________ 1.4 Choosing a location ____________________________________ 1.5 Setting up your machine ________________________________ 1.5 Installing the second cassette ___________________________ 1.5 Installing the toner cartridge ___________________________ 1.6 Loading paper into the cassette _________________________ 1.9...
Page 4
Chapter 2 Operation Using the control panel _________________________________ 2.2 Using the number keypad _______________________________ 2.4 Entering alphanumeric characters _______________________ 2.4 Entering numbers _____________________________________ 2.6 Editing numbers or names _____________________________ 2.6 Inserting pause _______________________________________ 2.6 Sending a fax ___________________________________________ 2.7 Preparing documents for faxing or copying ________________ 2.7 Setting document resolution and contrast _________________ 2.8 Resolution ___________________________________________ 2.8 Contrast _____________________________________________ 2.8...
Page 5
Chapter 2 Operation (Continued) Mail box ______________________________________________ 2.21 Confidential transmission _____________________________ 2.21 Setting up mail box for confidential receiving ____________ 2.23 Printing received confidential document ________________ 2.24 Polling ________________________________________________ 2.25 What is polling? ______________________________________ 2.25 Being polled by a remote machine (TX poll) ______________ 2.25 Adding documents to the job to be polled _______________ 2.26 Canceling a jab already in memory witch is waiting to be polled __________________________________________ 2.27...
Page 6
Chapter 2 Operation Other functions _________________________________________ 2.39 Using function buttons _________________________________ 2.39 Redial _______________________________________________ 2.39 Recall _______________________________________________ 2.40 Status _______________________________________________ 2.40 Printing reports ________________________________________ 2.41 User options ___________________________________________ 2.42 Setting an option _____________________________________ 2.42 Selectable options ____________________________________ 2.43 Maintenance ___________________________________________ 2.48 Cleaning drum _______________________________________ 2.48 Adjust shading _______________________________________ 2.48 Notify toner low _____________________________________ 2.49...
Page 7
Appendix FCC regulations ––––––––––––––––––––––––––––––––––––––––– 4.2 Canadian radio interference regulations –––––––––––––––––––– 4.2 EC declaration of conformity ––––––––––––––––––––––––––––– 4.3 Laser safety statement ––––––––––––––––––––––––––––––––––– 4.4 Safety information ––––––––––––––––––––––––––––––––––––––– 4.5 –––––––––––––––––––––––––––––––––––––––––––– 4.6 Power saver ––––––––––––––––––––––––––––––––– 4.7 Replacing the fitted plug Guarantee –––––––––––––––––––––––––––––––––––––––––––––– 4.8 Specifications ––––––––––––––––––––––––––––––––––––––––––– 4.9 Index ––––––––––––––––––––––––––––––––––––––––––––––––––...
Page 8
5. Unplug the fax machine from the AC wall socket and telephone jack before cleaning. Do not use liquid or aerosol cleaners. Use only a damp cloth for cleaning. 6. Do not place the fax machine on an unstable cart, stand, or table. It may fall, causing serious damage.
Setting up your machine Unpacking Machine Document tray Printer exit tray Laser facsimile user’s guide *1 The shape of AC power and telephone line cord plugs may differ, depends on your country. Setting up your machine Toner cartridge Second cassette Telephone/modem AC power cord One-touch...
Control locations and functions Take a moment to familiarize yourself with the main components and understand their functions. Caution : Use of controls or adjustments other than those specified herein may result in radiation exposure. Front view Document guide Control panel Document exit tray Cassette Second Cassette...
Rear view Telephone line jack Extension telephone jack Power cord connector Inside Cover Cover release button Toner cartridge Setting up your machine...
Choosing a location To help guarantee trouble-free operation of your machine, place it on a flat, stable surface near your workstation. Leave enough space to allow for easy paper loading, paper out and opening the front cover. Do not place your machine: - In direct sunlight.
Installing the toner cartridge 1. Open the cover by pressing the cover release button. 2. Raise the cover. 3. Unpack the toner cartridge. Grip the cartridge firmly and pull the sealing tape slowly from the cartridge. You may feel some initial resistance. As the tape will have a small amount of toner on both sides, take care not to get toner on your clothes.
Page 15
4. Gently shake the cartridge from side to side 5 or 6 times to distribute the toner evenly inside the cartridge. 5. Find the cartridge slots inside the machine, one on each side. 6. Grasp the handle and slide the cartridge down between the cartridge slots, until it drops into place.
Page 16
7. Close the cover. Make sure that the cover is securely closed. Notes: • Do not expose the cartridge to direct sunlight or strong room light. • To avoid damaging the photo-sensitive drum, never open the drum shutter. • To avoid damaging the cartridge, complete cartridge installation as quickly as possible.
Loading paper into the cassette You can load approximately 250 sheets of paper in the paper cassette. The window on the front of the paper cassette shows the amount of paper currently left in the cassette. When the cassette becomes empty, the window turns into red.
Page 18
If you are using a preprinted stock, such as letterhead, place the printed side face down with the top edge of the page toward the front of the cassette. 3. Make sure that the stack goes under the metal retaining clip overloading may cause paper jams.
Page 19
5. Pinch the side guide as shown below to adjust it to proper paper width. The paper cassette is preset to load letter size paper. If you want to load A4 or legal size paper, adjust the cassette for the paper you want to load. For details on how to adjust the paper cassette, see ‘How to adjust paper guides’...
How to adjust paper guides Length guides There are two main guides and one auxiliary guide as shown below to adjust for the paper length. One of main guide is for legal, A4, or folio size, and the other is for letter (LTR), executive (EXEC), or B5 size paper. When you load letter size paper, it is recommended that you use the auxiliary guide on the upper right corner of the cassette with the appropriate main guide.
Page 21
When you load letter, executive, or B5 size paper, it is recommended that you use the auxiliary guide with the main guide before loading paper. To adjust the auxiliary guide, remove the guide appropriate position Width guide Squeeze the guide as shown and slide the guide to the left until it lightly rests against the edge of the paper stack.
Manually feeding paper When you copy on heavier weight papers, transparencies, you must manually feed them one sheet at a time through the manual feed slot. The manual feed slot is located on the top of the paper cassette. 1. Pull out the paper cassette, raise and then lower the manual feed tray toward you.
Guidelines for the paper When selecting or loading paper, or other special media, keep these guidelines in mind: • Attempting to print on damp, curled, wrinkled, or torn paper can cause paper jams and poor print quality. • Use cut-sheet paper only. You cannot use multiparty paper. •...
Telephone line Plug one end of the telephone line cord into the LINE jack and the other end into a standard phone wall jack. To a standard phone wall jack Extension phone If you want to use a regular phone or answering machine with your machine, connect the phone into the TEL jack.
AC power cord Plug one end of the cord into the back of the machine and the other end into a standard AC power outlet (use 220 Volt only). The machine turns on. If there is no cartridge installed, or no paper, the display shows ‘DOOR OPEN OR NO TONER CARTRIDGE’...
Document exit tray Pull out the document exit tray, if necessary. Document exit tray Printer exit tray Holding the rounded end, insert the two tabs into the corresponding slots on the back of the machine. Place the printer exit tray up or down depending on the type of the paper. For transparencies such as OHP film, lay it down as show at up.
System setup Ringer volume You can adjust the volume of the ringer to the desired loudness. 1. Press Menu, then press System Setup on the one-touch keypad. The display shows ‘RINGER VOLUME ?’. 2. Press Start/Enter, then use " or ❷ to choose the desired loudness of the ringer.
Page 28
3. Press Start/Enter. The display asks you to choose the home resolution mode. 4. Press ➛ or ❿ repeatedly until you find the desired mode: •STANDARD–use with most documents. •FINE–use for documents with fine detail, such as small print. •SUPER FINE–use for documents that have extremely fine detail. 5.
Sound control You can choose an alarm tone to sound when an error occurs (ALARM SOUND) or any key is pressed (KEY SOUND). 1. Press Menu, then press System Setup on the one-touch keypad. The display shows ‘RINGER VOLUME ?’. 2.
Select language You can select the LCD display language between english, german, etc. 1. Press Menu, then press System Setup on the one-touch keypad. The display shows ‘RINGER VOLUME ?’. 2. Press " or ❷ until you find ‘SELECT LANGUAGE ?’, then press Start/Enter.
Adjusting speaker volume 1. Press OHD /V.Req. to adjust the speaker volume. If you cannot hear a dial tone, check the phone line connection. 2. Press " or ❷ repeatedly until you find the desired loudness. The display shows the current volume level. 3.
Setting the system ID The system ID will be printed at the top of each page sent from your machine. 1. Press Menu, then press System ID on the one-touch keypad. The display asks you to enter the telephone number. If there is a number previously registered, the number appears.
Using the control panel One-touch dial and special function buttons Use to call most frequently used numbers with one button. Also, use these buttons with Menu button to set up special functions or print lists. The display shows the current status of your machine and guides you through various tasks using a menu system for each operation.
Page 35
Search/Delete Rcv.Mode Resolution Speed/Status Redial/Pause PQRS Recall Symbols OHD/V.Req. Start/ Enter Speed/Status Use to dial calls and send fax documents by entering a speed dial number. Also use to switch the LCD while performing dual jobs. Redial/Pause Use to redial the last phone number called. You can also use it to add a pause when storing a number in memory.
Using the number keypad As you perform various tasks, you will need to enter names and numbers. For example, when you set up your machine you enter your name (or your company’s name) and telephone number. When you use the one-touch dial or speed dial, you also enter the telephone numbers and names.
Page 37
2. When the letter you want appears in the display, press the number key labeled with the next letter you want. If the next letter is found on the same number button, move the cursor by pressing ❿, then press the desired button. The blinking cursor moves right and the next letter appears in the display.
Entering numbers You can enter the number of the remote fax machine manually by using the number keypad. The number you pressed appears in the display. TEL)95551212_ When the display asks you to enter a number, you can also use a one-touch dial button (including group dial) and speed dial number.
Sending a fax Preparing documents for faxing or copying You can use the machine to fax, or copy documents that are printed on standard letter, legal, or A4 size paper. Follow these guidelines to prepare your documents. • Do not attempt to feed the following types of documents into the machine.
Setting document resolution and contrast We recommend sending documents printed using a typewriter, felt tip pen, black ink, or laserprinter. The paper should be white or very light, and of normal weight not cardboard. Blue lines on a ruled pad do not fax well. When you send normal documents, you need not adjust the resolution and the contrast.
Loading document 1. Turn the page face down. 2. Adjust the document guides to match the width of the document. 3. Slide the sheet down into the document tray until it’s gripped by the machine. document guide The automatic document feeder sizes and pulls in the page. The display shows ‘DOCUMENT READY’...
Sending a fax automatically 1. After loading a document, enter the number of the remote fax machine using the number keypad. You can store one-touch or speed dial numbers so that you can dial your most frequently used numbers with one touch of a button or speed dial number.
Sending a voice request 1. Press OHD/V.Req. while a document is being sent or received. Voice request signal is stored and then sent to the remote fax machine after the document has been sent or received. 2. When the phone rings, pick up the handset and answer it.
Delayed transmission You can configure your machine to send a fax at a specified time. Up to 50 delayed transmission operations can be reserved in your machine. 1. Place the document face down in the automatic document feeder. If desired, adjust the resolution and contrast. For details, see page 2.8. 2.
Page 45
7. Press Start/Enter. The display shows the current time on the upper line and prompts you to enter the time the fax will be sent. CURRENT 12:30AM START 8. Using the number keypad, enter the time the fax will be sent. Use the " or ❷...
Memory transmission (Broadcasting) With memory transmission, documents are stored in memory and automatically sent to one or more remote stations. Use this feature to send your documents to multiple locations. You can store a maximum of 25 fax numbers for a memory transmission. If you need to send your fax to more then 25 locations, you can increase the number of fax locations dialed by including a group dial number as one of the 25 numbers.
Priority transmission When priority transmission is enabled, a high priority document can be transmitted ahead of previously scheduled operations. In this operation, the document is scanned into memory. It is immediately transmitted at the conclusion of any operation already in progress. A priority transmission interrupts a broadcast operation between stations (for example, when transmission to station A ends but before transmission to station B begins), or between redial attempts.
3. Press ❷ or " repeatedly until you find the operation you want to cancel, then press Start/Enter when you find the operation. 2.16 Sending a fax OPERATION 1.ADD 2.CANCEL 10:00PM DELAY TX SAMSUNG (e.g. Delay transmission is 22:00 DELAY TX SAMSUNG scheduled to be sent at 10:00 PM.)
• ANS/FAX To use the ANS/FAX mode, you have to attach an answering machine to the TEL socket on your machine. If the fax machine senses a fax tone, it automatically switches to fax reception mode. However, if a fax is not sensed, the machine routes the call to answering machine, and the caller can leave a message.
Receiving automatically in FAX mode 1. Press and hold Rcv.Mode for about 2 seconds until the display changes. please repeatit until the display shows ‘FAX’ in the display window. 2. When a fax call comes in, the machine answers on the preset ring and receives it automatically.
Receiving automatically in ANS/FAX mode To use this mode, you must attach an answering machine to the TEL jack on the back of your machine. 1. Press and hold Rcv.Mode for about 2 seconds until the display changes. please repeat it until the display shows ‘ANS/FAX’ in the display window.
Receiving a fax when the machine is out of paper Incoming fax transmissions are automatically stored in memory under the following conditions: • Out of paper • A paper jam occurs • A document is copying • A list is printing After receiving documents, the machine display ‘MEMORY RECEIVED’...
Notes: • Make sure that the other party’s fax machine sured be are samsung fax machine confidential mail box feature. • Find out the confidential mail box number of the other party.
Page 54
9. Press Start/Enter. The LCD displays the current time on the upper line and asks you to enter the time when the fax is to be sent. 10. If you want to send it at a later time, enter the time you want your machine to send the document.
Setting up mail box for confidential receiving Before receiving confidential documents, you have to set up the following: • Confidential mail boxes. You can have up to 10 confidential mail boxes. • The password for each mail box • The names for each mail box. If you do not want to assign the name, you can skip this setup.
Printing received confidential document When you receive a confidential document, the fax machine displays ‘MAIL’, total number of mail box which has the confidential document received, and the mail box name in the lower line of the display. 1. Press Menu, then press Mail box on the one-touch keypad. The display prompts that you can choose the three mail box options;...
Note: The remote machine must also support polling to use this feature. Being polled by a remote machine (TX poll) You can program your fax machine to send documents when polled by a remote fax machine. It is possible to assign a poll code to prevent unauthorized polling of your fax machine.
6. The display prompts you to store the document in the machine bulletin board memory. Note: If you store the document in the bulletin board memory, more than one remote station can poll that document from your machine. If not, the file will be automatically erased after being polled by a remote machine.
2. Press 2 to select ‘DELAY RX POLL’. The display asks you to enter the number of the remote fax machine. 3. Enter the telephone number of the remote fax machine. There are several methods available to do this: • Direct entry of the telephone number using the numeric keypad •...
Page 60
4. Press Start/Enter. 5. The display asks you to enter another fax number to receive documents from another location. If you want to receive documents from more than one location: a) Press Start/Enter and enter another fax number using the numeric keypad, a one-touch button, or speed dial number The number appears in the display.
Making a copy Making a copy The resolution is automatically set to SUPER FINE while the copy feature is in use, however, the contrast can be changed to produce the best copy quality for particular documents containing faint markings, dark image, photographs or other halftone images.
Page 62
To set copy options: 1. Load a document with the print side facing down. If necessary, adjust Contrast button to change the contrast. For details on the contrast, see page 2.8. 2. Press Copy. The display asks you to enter the number of copies (1 to 99). 3.
Page 63
6. Press 1 or 2 to choose the desired collation method. You can also press ❷ without setting the collation (2:OFF is default value). The LCD display shows the next option; the paper cassette selection menu. The message ‘SELECT CASSETTE’ will appears when you set differant paper size for upper/lower cassette.
Automatic dialing One-touch dialing One-touch dialing lets you use any one of the 38 one-touch buttons located on the left of the machine’s control panel to automatically dial a number. Storing a number for one-touch dialing 1. Press and hold the one-touch button (01 through 19) for 2 seconds that you want to assign.
Press Shift, then the one-touch button (20 through 38) to witch you stored a number. The number will be automatically dialed, then the document begins to transmit when the remote fax machine answers the phone. Using one-touch label A one-touch label sheet is included with your machine. As you store numbers in one-touch dial buttons, make a note of the numbers on the label to remind you which number is stored in each position.
1. Load a document you want to send a fax. 2. Press Speed/Status, then enter a speed dial location number. 3. Press Start/Enter to dial the number. The number will be automatically dialed, and the document be transmitted when the remote fax machine answers the phone. 2.34...
Group dialing (for multi-address transmission) Numerous one-touch and speed dial numbers can be registered as a Group. By using the Group number, you can send a document to multiple parties in a single operation. Your machine will dial the remote numbers in stored sequence.
Editing the one-touch or speed dial numbers in a group dial After you have stored a group dial, you can edit a group dial at any time. 1. Press Menu, then press Group Dial on the one-touch keypad. The LCD display asks you to select ‘SET’...
Assigning a group to a one-touch button You can use a group number as one-touch dialing. Before you can use this feature, you must first register the group number (see ‘Storing a number for one-touch dialing’ on page 2.31), and then store the registered group number into an empty one-touch button.
Searching for a number in memory There are two ways to search for a number in memory. You can either scan from A to Z sequentially, or you can search using the first letter of the name associated with the number. Searching sequentially through memory 1.
Other functions Using function buttons Redial To redial the number last called Press Redial/Pause. If a document is loaded in the document tray, the machine automatically begins to send. To search through redial memory 1. Press and hold Redial/Pause for 2 seconds. The redial memory in your machine retains the last 10 numbers called.
Recall Some special phone services require a switch-hook signal for proper operation. For example, if you have call waiting, you can put a call on hold and take a second call on the same line by pressing the switch-hook button. Pressing Recall performs the equivalent of a switch-hook operation.
TX polling. The list shows the starting time, type of operation, etc. Phone book This list shows all of the numbers currently stored in the fax machine’s memory as one-touch dial numbers, speed dial numbers, and group dial numbers.
The selected list will be printed out. User Options Your fax machine has various user-selectable features. These options are preset at the factory, but you may select to change them. To find out how the options are currently set, print the System Data List. For more information on printing the list, see “To print list”.
Selectable options These instructions assume that you have followed the steps on page 2.41 under ‘Setting an option’ and that the machine is prompting you to change one of the options listed here. • PAPER SIZE—Select the paper size you will use for the recording paper. Press 1 for letter (LTR), 2 for A4 size, or 3 to use legal (LGL) size paper.
Page 76
If the fax machine cannot reduce the data to fit into one page with the feature enabled, the data is divided and printed in actual size on two or more sheets if needed.
Page 77
• ANSWER ON RING —You can select the number of times your machine rings before answering an incoming call. If you are using your machine as both a telephone and a fax machine, we suggest you set the ring count to at least 4 to give you time to answer.
Page 78
Using the distinctive ring pattern detection feature, your fax machine can ‘learn’ the ring pattern you designate to be answered as a fax machine. Unless you change it, this ringing pattern will continue to be recognized...
Page 79
• SEND FROM MEMORY —With this feature enables all transmission documents are automatically scanned into memory, and it will not be necessary to wait until documents in the ADF (Automatic Document Feeder) are sent out before you can send or store other fax jobs. Press 1 to turn this feature on.
Maintenance If you are getting streaks or spots on your print, you may run the maintenance. Cleaning drum If print output quality decreases due to the presence of black streaks or ghost images appearing on printouts, drum cleaning should be performed as an attempt to rectify the problem.
Notify toner low If you have set this notify toner low menu option to ON, when the toner cartridge needs to be replaced, your machine automatically sends a fax to your service company or the dealer to notify them that your machine requires a new toner cartridge.
Troubleshooting Clearing jams Document jams while sending a fax If a document jams while you are sending it, ‘DOCUMENT JAM’ appears in the display. Do not pull the document out of the slot, as this could harm your machine. 1. Open the control panel by hand. 2.
Paper jams while the machine is printing By carefully selecting paper type and loading paper properly, you should be able to avoid most paper jams. If a paper jam occurs, an error message appears in the display. Follow the steps below to clear the jam. To avoid tearing the paper, pull the jammed paper out gently and slowly.
Page 85
2. If you see that the paper is jammed, pull the paper out. 3. Slide the upper cassette back into the machine. Note : If a short piece is visible and you cannot grasp it, or if you do not see the 4.
Page 86
If jammed inside the machine (JAM 1) 1. Pull the cover release button toward you and open the cover. 2. Remove the toner cartridge. 3. Gently pull the paper toward you. 4. Check that there is no other paper in the machine. 5.
If jammed in the printer output area (JAM 2) 1. If the paper jams as it exits to the printer exit tray and a long portion of the paper is visible, pull the paper straight out. Stop pulling on the paper if you feel resistance, and the paper does not move immediately when you pull.
Display The machine is waiting for the programmed interval to RETRY REDIAL? automatically redial a previously busy station. A problem with facsimile COMM. ERROR communications has occurred. Remote party did not have the requested feature, such as polling. INCOMPATIBLE This also occurs if the remote machine has insufficient memory to complete the operation you are attempting.
Page 89
Recording paper has jammed inside the unit. The jammed paper still remains inside the unit. The remote fax machine you want to poll is not ready to respond to your poll. When setting up to poll another fax machine, you have used an incorrect poll code.
Fax problems Symptom The machine is not working, there is no display and the buttons are not working. No dial tone. The numbers stored in the memory do not dial correctly. The document does not feed into the machine. You cannot receive faxes automatically.
Page 91
• The fax machine you are polling may be using a poll code. • The machine sending you the fax may be faulty. • The fax machine sending you a fax may have a dirty scan glass. • A noisy phone line can cause line errors.
Maintenance Clearing memory You can selectively clear information stored in your machine’s memory. 1. Press Menu, then press Memory Clear on the one-touch keypad. The display shows the options you can choose to clear. 1. SYSTEM ID : your system ID number and name are cleared from the 2.
To keep your machine working properly, occasionally clean the white roller, ADF (automatic document feeder) rubber, and the scanning glass. If they are dirty, documents sent to another fax machine will not be clear. 1. Open the control panel with hand.
Page 94
5. Clean the ADF (automatic document feeder) rubber piece. 6. Carefully wipe the scanning glass with a soft, dry cloth. If the glass is very dirty, first wipe it with a slightly dampened cloth, then with a dry cloth. Be very careful not to scratch the glass surface. 7.
Managing toner cartridge Expected cartridge life The life of your toner cartridge depends on the amount of toner used in each print job. For instance, when you print a typical business letter with about 5% page coverage, you can expect a toner cartridge life of approximately 6,000 pages.
Page 96
To replace the toner cartridge: 1. Pull the cover release button toward you, open the machine cover. 2. Remove the old toner cartridge. Follow the instructions printed on the cartridge box to recycle the used cartridge. 3. Install new toner cartridge, see page 1.5. 3.15 Maintenance...
FCC regulations This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
EC declaration of conformity SAMSUNG ELECTRONICS CO.,LTD #259, Gong Dan-Dong, Gumi-City, Kyung Buk, Korea declare sole responsibility that the SF-6900/SF-6800/SF-6750 Laser Facsimile Msys 6900/Msys 6800/Msys 6750 Laser Facsimile meets the intent of Directive 89/336/EEC for Electromagnetic Compatibility and Low Voltage Directive 73/23/EEC.
Laser safety statement The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR subchapter J for class I(1) laser products, and elsewhere is certified as a class I laser product conforming to the requirements of IEC 825. Class I laser products are not considered to be hazardous.
Power saver This printer contains advanced energy conservation technology that reduces power consumption when it is not in active use. When the printer does not receive data for an extended period of time, power consumption is automatically lowered. For potentially faster printing of the first page, you may turn the power save off from the Remote Control Panel setting.
Replacing the fitted plug Important The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug and has a 13 amp fuse. When you change or examine the fuse, you must re-fit the correct 13 amp fuse.
The guarantee does not cover the machine's appearance, lamps and glass. Any changes to the machine which are explained in the guide to using your Samsung fax are not covered under the terms of the guarantee. This guarantee will not apply if your machine does not have a serial number or the serial number is changed.
Specifications Applicable line Compatibility Data coding Modem speed Transmission speed Effective scanning width Effective printing width Scanning method Memory Halftone Printing speed Automatic document feeder Dimension (W Including the second cassette Weight Second cassette Power requirements Power consumption Environmental conditions Noise level Auto dialer Document size –...
