A grounding type plug has two blades and a third grounding prong. The wide blade and the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the outlet.
FCC NOTE (for U.S.A): This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Before connecting other components to this player, be sure to turn them all off. • Do not move the player while a disc is being played, or the disc may be scratched or broken, and the player’s internal parts may be damaged.
E F O R E Y O U S TA R T Before you start Accessories Remote Control AK59-00061J Install Batteries in the Remote Control Open the battery cover on the back of the remote control. Insert two AAA batteries.
Connecting to a TV (Video)...18 Connection to an Audio System ...19 Connecting to an Audio System (2 Channel Amplifier, Analog) ...19 Connecting to an Audio System (Dolby digital, MPEG2 or DTS Amplifier)...20 Connecting the Power Cord ...21 Chapter 3: Initial Setup Selecting a Menu Language ...22...
Page 7
A B L E O F O N T E N T S Selecting the Subtitle Language ...38 Changing the Camera Angle ...39 Using the Bookmark Function (DVD) ...39 Using the Zoom Function (DVD) ...41 Clips Menu for CD Audio/MP3/WMA/JPEG/MPEG4 files ...42 Folder Selection ...42...
Many DVD discs are encoded with copy protection. Because of this, you should only connect your DVD- VCR directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy- protected DVD discs.
Video AUDIO-CD Audio CD-R,CD-RW and DVD-RW, -R, DVD+RW, +R discs may not be playable in all cases due to the disc ■ type or condition of the recording. Do not run the player with two discs loaded at the same time.
Press to open and close the disc VCR Deck Insert a standard VHS video tape. EJECT Press to eject a video tape if the tape is stopped. (POWER) Press to turn the DVD-VCR on and LINE IN 2 Connects to the Video/Audio output jack of your external device.
HDMI OUT Notes ■ Consult your TV User’s Manual to find out if your TV supports Progressive Scan. If Progressive Scan is supported, follow the TV User’s Manual regarding Progressive Scan settings in the TV’s menu system. ˆ ˆ ¨ ¨...
(VCR). TV VOL (+,-) button 11 MENU button Brings up the DVD-VCR player’s menu. 12 ENTER/ ¦ ¦ buttons This button functions as a toggle switch. DISC MENU button Brings up the Disc menu.
- If you want to connect to an Amplifier, please refer to the Amplifier connection page. (See pages 19 to 20) - When you connect a STB through the LINE IN 1 jack of the DVD-VCR, you still can see the picture from the STB on your TV set if the DVD-VCR is turned off.
- For better picture quality, set the HDMI output resolution to 720p or 1080p (see page 56). - If you connect an HDMI cable between Samsung TV and this DVD player, you can operate this DVD player using your TV remote control. This is only available with Samsung TVs that support Anynet+(HDMICEC).(...
Page 15
HDMI (High Definition Multimedia Interface) HDMI is an interface that enables the digital transmission of video and audio data with just a single cable. Using HDMI, the DVD player transmits a digital video and audio signal and displays a vivid picture on a TV having an HDMI input jack.
Progressive scan has twice as many scanning lines as the interlace output method. Progressive scanning method provides better and clearer picture quality. The Component Video jacks only output video from the DVD player. To view video from the VCR, you must have Video/Line Out (yellow) jack Only the 480p output resolution is possible with Component.
If you want to connect to an Amplifier, please refer to the Amplifier connection page. (See pages 19 to 20) - The component jack of your TV may be marked “R-Y, B-Y, Y” or “Cr, Cb, Y” instead of “PR, PB, Y”...
- The number and position of jacks may vary depending on your TV set. Please refer to the user's manual of your TV. - If there is one audio input jack on the TV, connect it to the LINE OUT AUDIO OUT Left (white) jack of the DVD-VCR.
Amplifier's audio input. Notes - Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause damage to the speakers and your ears. Please set the audio in the menu screen according to the Amplifier. (See pages 52 to 53) - The position of jacks may vary depending on the Amplifier.
Amplifier's audio input. Notes - Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause damage to the speakers and your ears. Please set the audio in the menu screen according to the Amplifier. (See pages 52 to 53) - The jack position may vary depending on the Amplifier.
O N N E C T I O N S Connecting the Power Cord Your DVD-VCR's power cord should be plugged into a standard 120V/60Hz wall outlet. Turn on the power by pressing the button on the remote control or panel.
C h a p t e r 3 N I T I A L Selecting a Menu Language Follow these steps to change the on-screen MENU language to English, French or Spanish. Press the MENU button. Press the buttons to Setup, then press the ...
Setting the Clock This menu is used to set the current time. Setting the Clock Manually Auto Setup fails to set the DVD-VCR’s internal clock by locating a local TV station, follow these steps to set the date and time manually. Note: For accurate Timer Recording, your DVD-VCR's internal clock must be set correctly.
N I T I A L Setting the Front Panel Display You can set the Front Panel Display to be bright, dim, or to automatically dim during power off. Press the MENU button. Press the buttons to Setup, then press the ...
DVD-VCR will auto shut off 2 hours after the last button ■ is pressed or no signal is received. E T U P off your DVD-VCR if no signal is received and you do not press any buttons for ENG-25...
Before Play Turn on your TV and set it to the correct Video Input on your TV's remote control. - If you connected an external Audio System, turn on your Audio System and set it to the correct Audio Input. Playback Press the OPEN/CLOSE ( button on the front panel.
Page 27
Screen stops, no sound. - To resume, press the (Play/Pause) button once again. Note If the player is left for about 5 minutes in pause mode, it will stop. Each time the button is pressed, a new frame will appear.
P E R AT I O N S Using the Search and Skip Functions During play, you can search quickly through a chapter or track, and use the skip function to jump to the next selection. Searching through a Chapter or...
D V D O P E R AT I O N S Using the Display Function When Playing a DVD/MPEG4 During play, press the INFO button on the remote control. Press the buttons to select the desired item. Press the ¦ buttons to...
Page 30
Refers to the subtitle languages available in the disc. SUBTITLE You will be able to choose the subtitle languages or, if you prefer, turn them off from the screen. A DVD disc can have up to 32 different subtitles. ENG-30...
Notes Depending on the disc, the Disc Menu or Title Menu may not work. - You can also use the Disc Menu by using the DISC MENU button on the remote control. - The Title Menu will only be displayed if there are at least two titles on the disc.
D V D O P E R AT I O N S Using the Function Menu (DVD) During the playback of a DVD disc, press the MENU button on the remote control. Press the buttons to select Function, then press ...
ENTER button at the point where you want the repeat play to stop (B). To return to normal play, press the CANCEL button. Note REPEAT allows you to set point (B) 5 seconds after point (A) has been set. To return to normal play, press REPEAT...
D V D O P E R AT I O N S Slow Play This feature allows you to slowly to repeat scenes containing sports, dancing, musical instruments being played etc., so you can study them more closely. When playing a DVD...
The top, bottom, left and right of the screen are cut off and the central portion of the screen is enlarged. Aspect Ratio (EZ View) TV screen so the DVD-VCR will display movies at the appropriate WIDE SCREEN For 4:3 aspect ratio discs - NORMAL WIDE Displays the content of the DVD title in 16:9 aspect ratio.
Page 36
For 16:9 aspect ratio discs - 4:3 Letter Box Displays the content of the DVD title in 16:9 aspect ratio. The black bars will appear at the top and bottom of the screen. 4:3 Pan Scan The left and right portions of the screen are cut off and the central portion of the 16:9 screen is displayed.
D V D O P E R AT I O N S Selecting the You can select a desired audio language quickly and easily with the AUDIO button. Using the AUDIO button (DVD/MPEG4) During play, press the AUDIO button. Audio languages change ¦...
D V D O P E R AT I O N S Selecting the Subtitle Language You can select a desired subtitle quickly and easily with the SUBTITLE button. Using the SUBTITLE button (DVD/MPEG4) During play, press the SUBTITLE button.
) icon, press the CLEAR or RETURN button. Using the Bookmark Function This feature lets you bookmark sections of a DVD so you can quickly find them at a later time. Using the MARK button (DVD) During play, press the MARK button on the remote control.
Page 40
D V D O P E R AT I O N S Recalling a Marked Scene During play, press the MARK button on the remote control. Press the ¦ buttons to select a marked scene. Press the (Play/Pause) button to play the marked scene.
D V D O P E R AT I O N S Using the Zoom Function (DVD) During the playback of a DVD disc, press the MENU button on the remote control. Press the buttons to select Function, then press ...
Clips Menu for CDAudio/ MP3/ WMA/JPEG/ MPEG4 Discs with MP3/WMA/JPEG/MPEG4 contain individual songs and/or pictures that can be organized into folders as shown below. They are similar to how you use your computer to put files into different folders. Open the disc tray.
P l a y O f f O f f B e c a u s e Y o u 0 0 : 0 0 : 2 3 0 0 : 0 0 : 2 3 1 _ m p 3 .
Page 44
When you record MP3 or WMA files on a CD-R, please refer to the following. - Your MP3 or WMA files should be ISO 9660 or JOLIET format. ISO 9660 format and Joliet MP3 or WMA compatible with Microsoft's DOS and Windows, and with Apple's Mac.
D V D O P E R AT I O N S MPEG4 Playback MPEG4 Play Function AVI files are used to contain the audio and video data. Only AVI format files with the “.avi” extensions can be played. Open the disc tray.
Page 46
That is why Codec Type, Version and Higher resolution higher than the specifications are not supported. - This unit supports CD-R/RW written in MPEG4 in accordance with the “ISO9660 format”. - When unsupported AVI file is played, there will be a message “This file format is not supported”. CD-R...
Notes Depending on a file size, the amount of time between each picture may be different from the set interval time. - If you don’t press any button, the slide show will start automatically in about 10 seconds by default.
Page 48
Only files with the “.jpg” and “.JPG” extensions can be played. - If the disc is not finalized, it will take longer to start playing and not all of the recorded files may be played. - Only CD-R discs with JPEG files in ISO 9660 or Joliet format can be played.
Œ Language Setup: Setup of the Language. ´ Audio Setup: Setup of the Audio Options. ˇ Display Setup:Setup of the Display Options. Used to select which type of screen you want to watch and several display options. ¨ Parental Setup: Setup of the Parental Level.
P E R AT I O N S Setting Up the Language Features If you set the audio and subtitle language in advance, the settings will automatically be applied every time you watch a movie. With the unit in Stop mode,...
Page 51
D V D O P E R AT I O N S Language Function Disc Menu To set the Disc Menu Language to your preferred language, follow these steps. If your preferred language is available on a DVD, your Disc Menu Language will automatically be set to the language you selected.
D V D O P E R AT I O N S Setting Up the Audio Options allows you to set up sound for use with your external audio system. With the DVD in Stop mode, press the MENU button on the remote control.
D V D O P E R AT I O N S Audio Options Dolby Digital Out PCM: Converts to PCM(2CH) audio. - Bitstream: Outputs Dolby Digital via the digital output. Dynamic Compression On: When the movie- soundtracks are played at...
D V D O P E R AT I O N S Setting Up the Display Options Display options enable you to set various video functions of the With the unit in Stop mode, press the MENU button on the remote control.
(screen setting). - 4:3 Letter Box: Select when you want to see the total 16:9 ratio screen the DVD supplies, even though you have a TV with a 4:3 ratio screen. Black bars will appear at the top and bottom of the screen.
Page 56
D V D O P E R AT I O N S HDMI This setting is used when the DVD-VCR is connected by HDMI to Display devices (TV, projector, etc). Resolution Setting Auto : Resolution setting automatically - Manual : Resolution setting Manually.
Page 57
The resolutions available for HDMI output depend on the connected TV or see the user’s manual of your TV or projector. ● When the resolution is changed during playback, it may take a few seconds for a normal image to appear. ●...
The Parental Control function works in conjunction with DVDs that have been assigned a rating, which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc. Setting Up the Rating Level...
Enter your password. Note The default password is 0000. To make the DVD setup menu disappear, press the MENU button. - For example, if you select up to Level 6, discs that contain Level 7 or 8 will not play. ENG-59...
Page 60
D V D O P E R AT I O N S Press the buttons to select Change Password, or ENTER then press the button. Enter your password, then or ENTER press the button. Enter your new password, ...
D V D O P E R AT I O N S DivX(R) Registration DivX Registration menu has the Registration Code that enables your DivX Certified Player to play DivX(R) Video On Demand file format. With the unit in Stop mode,...
P E R AT I O N S In this chapter, you will learn how to play a video cassette tape, how to use the time counter and memory stop features, and how to record a program as you are watching TV.
Note To view VCR playback, you must connect the Video Out (Yellow) to your TV. The VCR does not output video through the Component jacks. Video Cassette Tape For more information on the safety tab, see page 74.
P E R AT I O N S Special VCR Playback Features While a videotape is playing, you can enjoy a variety of special playback features, including Still, Frame Skip, Repeat, and more. Press the Play/Pause button again to resume normal playback.
Tracking adjustment removes the white lines that sometimes appear during playback because of slight differences in recording decks. The TRK button will automatically align the recorded tracks with the playback heads to solve this problem. You may also set tracking manually.
P E R AT I O N S Selecting the Cassette If you wish to use the tape counter to display the time remaining on a cassette, you must indicate the type of cassette inserted. Press the MENU button on the remote control.
V C R O P E R AT I O N S Setting the Auto Play If you want your videotapes to play automatically when you insert them, turn on Press the MENU button on the remote control. Press the buttons to...
V C R O P E R AT I O N S Setting the Auto Repeat If you want your videotapes to play Press the MENU button on the remote control. Press the buttons to select VCR, then press the ...
- Is reset when a cassette is inserted in the DVD-VCR. - Allows you to easily find the beginning of a sequence. - If the remaining time is to be calculated correctly, you must indicate the type of cassette being used. Insert a cassette in your DVD- VCR.
P E R AT I O N S Using the Assemble Edit Function This function allows you to start a new recording at a specific position on the cassette while maintaining a very smooth scene change. Insert the cassette to be edited in your DVD-VCR.
When you have finished recording, press the (Stop) button. Selecting the You can select the mode in which the sound is reproduced on the loudspeakers and AV outputs. The following options are available. Press the AUDIO button on the remote control until the required option is displayed.
Each time you record a cassette on this DVD-VCR, an “index” is automatically marked on the tape when recording starts. The Search function allows you to fast-forward or rewind to a specific index and start playback from that point. Depending on the direction selected, the indexes are numbered as follows: Prev Seq.
The VCR will fast forward, searching for a blank position, and then automatically stop at that position. If the VCR reaches the end of the tape during end search, the tape will be ejected. Scan and Play Use scan and play when you don’t know exactly where a...
You can even add time in 30-minute increments up to 4 hours by pressing the REC button repeatedly; see page 76. Note Be sure your videotape has a Record Safety piece of tape. Warning: Do not cover this opening unless you are sure you want to record over the tape. Before You Begin... Power on the DVD-VCR...
Press the (Stop) button. Special Recording Features While a recording is in progress, you can watch a DVD, or add recording time in 30-minute increments. To Watch a DVD while Recording Insert a DVD in the DVD tray and press the (Play/Pause).
P E R AT I O N S Using One-Touch Recording One-Touch Recording (OTR) allows you to add recording time in 30-minute increments up to 4 hours at the touch of a button. Insert a blank VHS tape into the VCR deck.
DVD-VCR will automatically be turned off when the OTR finished. Selecting the Recording Speed You can slow down the recording speed from SP to SLP in order to fit six hours of programming on a T-120 tape. Press the SPEED button on the remote control to select the Record Speed.
Timer Recording Insert a blank videotape into the VCR deck. Be sure to leave the Record Safety With the Timer Recording function, you can program up to 7 events at a time to record up to a month in advance.
Page 79
Selecting Auto Speed If the length of the videotape is not long enough for a timer recording in the SP mode, set the recording tape speed to “Auto”. Recording will start in the SP mode. If the length is not long enough, the tape speed will automatically change from SP mode to SLP mode.
If your television is compatible with the remote control, it will switch off. It is now programmed to operate with the remote control. If several codes are indicated for your television brand, try each one in turn until you find one that works. You can then control the television using the following buttons.
E M O Troubleshooting Before contacting a Samsung authorized service If you are unable to solve the problem after reading the above instructions, note: - The model and serial number on the rear of your DVD-VCR - The warranty information - A clear description of the problem Then contact your nearest SAMSUNG service center.
Page 82
Don't use this unless absolutely necessary. • Go to the contents and find the section of the instruction book If you experience that contains the explanations regarding the current problem, and other problems.
POWER REQUIREMENT SYSTEM ENVIRONMENT WEIGHT - Samsung Electronics Co., Ltd reserves the right to change the specifications with out notice. - Weight and dimensions are approximate. 2 Stereo audio inputs, RCA Connector, -8dbm, 47KΩ, front and rear 2 Composite video inputs, RCA Connector, 75Ω, 1Vp-p 1 Stereo audio outputs, RCA Connector, -8dbm, 1.5KΩ...
Page 86
Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Region Country CANADA North America MEXICO U.S.A ARGENTINE BRAZIL CHILE COSTA RICA ECUADOR EL SALVADOR GUATEMALA Latin America...
Page 87
One (1) Year Parts / Ninety days (90) Labor This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States, and does not include transportation, installation, removal or reinstallation.
Page 88
Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. ☎ 1-800-SAMSUNG (7267864) / www.samsung.com Samsung Electronics America, Inc. 105 Challenger Road Ridgefield Park, NJ 07660-0511 1-800-SAMSUNG (7267864) www.samsung.com...
