  • Page 1 User Manual soft air ® Art. No. 110 400-wds Pressure ulcer prevention and treatment-system Assembly and Operation instructions Health. Security. Independence.

  • Page 2: Table Of Contents

    List of contents 1 Foreword Page 3 2 Safety instructions Page 4 3 Product overview soft air® wds Page 4 4 Introduction Page 5 5 Explanation of indication and functions Page 5 6 Installation and setting up the mattress Page 6 7 To set soft air®...

  • Page 3: Foreword

    (Stage 3). With the writing of this user manual the product management of the ADL® GmbH has set itself the goal, to create a good and understandable aid and guidance for the employment of the system. If nevertheless questions remain, please ask your provider for direction and assistance.

  • Page 4: Safety Instructions

    2 Safety instructions • The system may not be used in presence of open flames, heaters a.o’s. Protect the equipment against humidity. Operate it only in dry areas. No combustible gases or liquids may enter into the system. EXPLOSION DANGER! Warning! Note! The compressor is under power, as soon as the power supply plug is put in.

  • Page 5: Introduction

    4 Introduction soft air® wds system is an overlay mattress system, therefor please make sure that a foam mattress is used underneath the soft air mattress and the minimum distance of the bed side guard must comply with DIN EN 1970.

  • Page 6: Installation And Setting Up The Mattress

    6 Installation and setting up the mattress Place the soft air wds on the existing mattress and fix fixation straps only to the moving parts of the bed. When not correctly attached to the bed this may lead to bed- and mattress damages.

  • Page 7: To Set Soft Air® Wds

    7 To set soft air® wds Switch on the power unit The alarm light is blinking and the system will start to be filled with air. The alarm light is put out of circuit when inflation of the mattress is completed. Depending on if it is switched on, an acoustic signal sounds.
  • Page 8 Steps Weight 1. Step = 1 led light ca. 30 – 40 kg 2. Step = 2 led lights ca. 40 – 50 kg 3. Step = 3 led lights ca. 50 – 70 kg 4. Step = 4 led lights ca.

  • Page 9: Alternating Function

    8 Alternating function In the case of the contraindications for the alternating pressure mentioned in the indication table, the mattress pressure can be switched from alternate to static soft storage by pressing button 4 (Static / Alternate) on the pump, during which the display changes the operating mode from blue (alternate) to green (static).

  • Page 10: Cpr-Function

    10 CPR-function Please make sure that the CPR plug (Cardio Pulmonary Resuscitation) is always closed. This CPR plug is located on the head end of the mattress and is marked with a red flag labeled CPR. To verify if CPR is tightly closed, the cover near the CPR plug must be opened by partly unzipping the cover.
  • Page 11 • Disinfection with cleaning on locations is also possible, when instructions for use and process time are properly kept. • ADL® GmbH prescribes safety-related revisions of all electric powered parts after at least 2 years. The accident prevention regulations DGUV regulation 3 remain unaffected.

  • Page 12: Troubleshooting

    12 Troubleshooting Problem Cause Solution Mattress does not Connectors are not Check connection and inflate or inflates accurately locked. Tubes position of the tubes. insufficiently. are twisted or kinked. Exchange possible defect cells. Defect cell. The unit does not No power available. Check plug and partition.

  • Page 13: Technical Data

    14 Technical data Mattress Pump Material PU-Nylon Dimensions 190 x 86,5 x 13,5 23 x 15 x 8,5 in cm ~1,5 Weight in kg Warranty* 2 years 2 years Electr. 230 V /7 W connections Protection class Protection class ll Fuse 230 V/F500mA (slow) Cover...
  • Page 14 In case of technical problems please contact your appointed dealer or directly to ADL® GmbH. (Dealer stamp) ADL® GmbH ADL® GmbH An der Germania Brauerei 1 Production- and servicer center 48159 Münster Im Flürchen 1 Germany 99334 Amt Wachsenburg Phone: + 49 251 149896-0...
