Summary of Contents for Samsung L83T
-
Page 2: Getting To Know Your Camera
● Please check that the camera is operating properly prior to when you intend to use it (e.g. for a trip or an important event) to avoid disappointment. Samsung camera takes no responsibility for any loss or damages that may result from camera malfunction. - Page 3 ● Should any form of liquid or a foreign object enter the camera, do not use it. Switch off the camera, and then disconnect the power source. You must contact your dealer or Samsung Camera Service centre. Do not continue to use the camera as this may cause a fire or electric shock.
-
Page 4: Table Of Contents
Caution CAUTION indicates a potentially hazardous situation which, if not avoided, may result in a minor or moderate injury. ● Leaking, overheating, or burst battery could result in fire or injury. - Use battery with the correct specification for the camera. - Do not short circuit, heat or dispose of battery in fire. - Page 5 Contents 024 Using the camera buttons to set the camera POWER button SHUTTER button ZOOM W / T button Face recognition(FR) button Info / Up button Macro / Down button Focus lock Flash / Left button Self-timer / Right button MENU / OK button M (Mode) button E (Effect) button...
- Page 6 Contents Beep Sound AF sound 055 Setup menu 056 Setup menu 1 File name LANGUAGE Setting up the Date / Time / Date type World Time Imprinting the recording date LCD brightness Auto Focus lamp Start up image 059 Setup menu 2 Quick view Auto power off LCD save...
- Page 7 100 Setting up the application software 102 Starting PC mode 105 Removing the removable disk 106 Setting up the USB Driver for MAC 106 Using the USB Driver for MAC 106 Removing the USB Driver for Windows 98SE 107 Samsung Master 110 FAQ...
-
Page 8: System Chart
System chart Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the optional equipment, contact your nearest Samsung dealer or Samsung service centre. < Included items >... -
Page 9: Identification Of Features
Identification of features Front & Top Shutter button Power button FR (Face Recognition) button Speaker Flash Microphone AF sensor/Self-timer lamp Lens 《8》... -
Page 10: Back
Identification of features Back Camera status lamp Zoom T button (Digital zoom) Zoom W button (Thumbnail) M (Mode) button LCD monitor Eyelet for camera strap E (Effect) button 5-function button Fn/Delete button Play mode/Print button 《9》... -
Page 11: Bottom
Identification of features Bottom Battery holder Memory card slot Battery chamber Battery chamber cover USB/AV connection terminal Tripod socket ※ To open the battery chamber cover, slide it in the direction shown above. 《10》 5 Function button Information / Up button Flash / Left button Macro / Down button... - Page 12 Identification of features ■ Self-timer lamp Icon Status Description - For the first 7 seconds, the lamp blinks at 1 second intervals. Blinking - For the final 3 seconds, the lamp blinks quickly at 0.25- second intervals. For the 2 seconds, the lamp blinks quickly at 0.25-second Blinking intervals.
-
Page 13: Connecting To A Power Source
Powering it off for 1 minute. 《12》 Movie ※ These figures are measured under Samsung’ s standard conditions and shooting conditions and may vary depending on the user’ s methods. Important information about battery usage. ● When the camera is not used, turn off the camera power. - Page 14 Connecting to a Power Source You can charge the rechargeable battery SLB-0837(B) by using the SAC-45 KIT which consists of the AC adapter (SAC-45) and the USB cable (SUC-C2). When the SAC-45 and SUC-C2 are combined, they can be used as an AC cable.
- Page 15 Connecting to a Power Source ■ How to charge the rechargeable battery (SLB-0837B) Charging LED ● Before inserting any cables or AC adapter, check the directions and do not insert by force. It may cause breakage of cable or camera. ●...
-
Page 16: Inserting The Memory Card
Connecting to a Power Source Insert the battery as shown - If the camera does not turn on after you have inserted battery, please check whether the battery is inserted with the correct polarity (+ / -). - When the battery chamber cover is opened, do not force it. -
Page 17: Instructions On How To Use The Memory Card
● Repeated use of the memory card will eventually reduce the memory card’s performance. Should this be the case, you will need to purchase a new memory card. Wear and tear on the memory card is not covered by the Samsung warranty. -
Page 18: Instructions On How To Use The Memory Card
Instructions on how to use the memory card The camera can use SD/ SDHC Memory Cards and MMC (Multi Media Cards). Card pins Write protect switch Label [SD (Secure Digital) memory card] The SD/ SDHC memory card has a write protect switch that prevents image files from being deleted or formatted. -
Page 19: Lcd Monitor Indicator
LCD monitor indicator ■ The LCD monitor displays information about the shooting functions and selections. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ [Image & Full Status] Description Recording mode Color / Saturation Face Recognition Flash Self-timer Macro 《18》... -
Page 20: Changing The Recording Mode
Changing the recording mode You can select the desired working mode by the M (mode) button located on the back of the camera. Auto, Program, movie clip, ASR, scene (night, portrait, children, landscape, close-up, text, sunset, dawn, backlight, fireworks, beach & snow, Self-shot, Food, Cafe) camera modes are available. ■... -
Page 21: How To Use The Program Mode
Starting the recording mode How to use the Program mode Selecting the automatic mode will configure the camera with optimal settings and you can manually configure various functions. 1. Select the Program mode by pressing the M (Mode) button (p.33). 2. -
Page 22: How To Use The Movie Clip Mode
Starting the recording mode How to use the Movie clip mode A movie clip can be recorded for as long as the available recording time of the memory capacity allows. 1. Select the Movie clip mode by pressing the M (Mode) button.(p.33) 2. -
Page 23: How To Use The Scene Modes
Starting the recording mode How to use the Scene modes Use the menu to easily configure optimal settings for a variety of shooting situations. 1. Select the Scene mode by pressing the M (Mode) button (p.33). 2. Point the camera towards the subject and compose the image by using the LCD monitor. -
Page 24: Things To Watch Out For When Taking Pictures
Things to Watch Out for When Taking Pictures ● Pressing the shutter button down half way. Lightly press the shutter button to confirm focus and flash battery charge. Press the shutter button all way down to take the picture. [Lightly press the shutter button] [Press the shutter button] ●... -
Page 25: Using The Camera Buttons To Set The Camera
Using the camera buttons to set the camera The recording mode function can be set up by using the camera buttons. POWER button Used for turning the camera’s power on / off. If there is no operation during the specified time, the camera's power will be turned off automatically to save battery life. - Page 26 ZOOM W / T button ■ WIDE Zoom Optical zoom WIDE : Pressing the ZOOM W button. This will zoom out from the subject i.e. the subject will appear further away. Pressing the ZOOM W button continuously will set the camera to its minimum zoom setting i.e.
-
Page 27: Face Recognition(Fr) Button
Face recognition(FR) button This mode detects the face position of the subject automatically and then sets the focus and exposure. Select this mode for quick and easy face picture. ※ Selectable modes : Auto, Program, ASR, Scene modes (Portrait, Children, Beach & Snow, Self-shot, Cafe) 1. -
Page 28: Info / Up Button
Info ( ) / Up button While the menu is showing, the Up button operates as a direction button. In the recording modes or playback mode, pressing this button will display the image information. Info ( ) button Macro ( ) / Down button While the menu is showing, press the DOWN button to move from the main menu to a sub menu, or to move down the sub menu. - Page 29 Macro ( ) / Down button ■ Types of focus mode and focus range (W : Wide, T : Tele) Mode Auto ( Focus Type Super macro ( Auto macro ( W : 1 ~ 5 W : 5 ~ Infinity Focus range (Wide only) T : 40 ~ Infinity...
-
Page 30: Focus Lock
Focus lock To focus on a subject not positioned in the centre of the picture, use the focus lock function. ■ Using the Focus Lock 1. Ensure the subject is in the centre of the autofocus frame. 2. Press the SHUTTER button halfway. When the green auto focus frame lights up, it means the camera is focused on the subject. - Page 31 Flash ( ) / Left button ● If you press the shutter button after selecting the Auto, Fill-in, Slow synchro flash, the first flash fires to check the shooting condition (Flash range and Power ratio of flash). Do not move the camera until the second flash fires. ●...
-
Page 32: Self-Timer / Right Button
Flash ( ) / Left button ■ Available flash mode, by recording mode ● ● ● ● ● ● ● ● ● Self-timer ( When the menu is displayed on the LCD monitor, pressing the Right button (●: Selectable) makes the cursor shift to the right tab. When the menu is not displayed on the LCD monitor, the RIGHT button ●... -
Page 33: Self-Timer ( ) / Right Button
Self-timer ( ) / Right button ■ Selecting the self-timer 1. Select a RECORDING mode with the exception of VOICE RECORDING mode. (p.33) 2. Press the SELF-TIMER ( ) button until the desired mode indicator displays on the LCD monitor. A 10 second, 2 second, Double self-timer or Motion timer icon appears on the LCD monitor. -
Page 34: Menu / Ok Button
MENU / OK button ■ MENU button - When you press the MENU button, a menu related to each camera mode will be displayed on the LCD monitor. Pressing it again will return the LCD to the initial display. - A menu option can be displayed when the following are selected : MOVIE CLIP and STILL IMAGE mode. -
Page 35: E (Effect) Button
E (Effect) button It is possible to add special effects to your images by using this button. ■ Still image mode : You can select the colour, special colour, image editing and Fun menu. In the Auto mode, you can select the [COLOR] menu only. -
Page 36: E (Effect) Button : Colour
E (Effect) button : Colour By using the camera’ s digital processor, it is possible to add special effects to your images ■ Press the E button in an available recording mode. (p.34) COLOR 이동 Move Exit 해제 [Still image mode] 1. -
Page 37: E (Effect) Button : Colour Mask
E (Effect) button : Colour Mask With this menu, you can select a part you want to highlight. The rest of the image will be black and white. ■ Press the E button in an available recording mode. (p.34) Color Mask Press the OK button and the Mask mark will be displayed on the LCD monitor. -
Page 38: E (Effect) Button : Saturation
E (Effect) button : Saturation You can change the saturation of the image. ■ Press the E button in an available recording mode. (p.34) IMAGE ADJUST Select Saturation menu ( for changing the saturation will be displayed. Move Exit Press the Shutter button to take a picture. [Final Image] Saturation ) and a bar... -
Page 39: E (Effect) Button : Fun
E (Effect) button : FUN Cartoon You can add a text box on the image to make the image cartoon like. ■ Press the E button in an available mode. (p.34) Select Cartoon ( Move Exit Select the text box position of the third image with the same procedure and take the third image. - Page 40 E (Effect) button : FUN ■ Before saving the cartoon image, you can take images again. 1. Select an image to delete by using the Left/Right button. 2. Press the Fn button and the image deletes. Pressing the Fn button Capture Move 3.
-
Page 41: Pre-Set Focus Frame
E (Effect) button : FUN Pre-set focus frame You can make the subject stand out from its surroundings. The subject will be sharp and in focus while making the rest out of focus. ■ Press the E button in an available recording mode. (p.34) Move Exit 1. -
Page 42: Composite Shooting
E (Effect) button : FUN Composite shooting You can combine 2 - 4 different shots in a still image. ■ Press the E button in an available recording mode. (p.34) Move Exit 1. Select a desired menu by pressing Left/Right button and press the OK button. Composite Composite Composite... - Page 43 E (Effect) button : FUN ■ Changing a part of composite shot before taking the last shot Before taking the last composite shot, you can change a part of composite shot. 1. During the composite shots, press the Fn button. 2.
-
Page 44: Photo Frame
E (Effect) button : FUN Photo Frame You can add 9 types of frame-like borders to a still image you want to capture. Date & Time information will not be printed on the stored image taken with Photo Frame menu. ■... -
Page 45: Fn Button
Fn button You can use the Fn button to set the following menus. ● ● ● Size Quality/ ● ● ● Frame Rate ● Metering ● ● Drive ● ● White Balance ● Stabilisation *1. This menu is only available in the Children scene mode ( *2. -
Page 46: Size
Size You can select the image size appropriate for your application. Icon Still image 3264x 3264x 3264x Size mode 2448 2176 1824 Icon Movie clip mode 800x592 720x480 Size SIZE 3264X2448 [ STILL IMAGE mode ] ● The higher the resolution, the lower the number of shots available because high resolution images require more memory. -
Page 47: Metering
Metering If you cannot obtain suitable exposure conditions, you can change the metering method to take brighter pictures. [Multi] : Exposure will be calculated based on an average of the available light in the image area. However, the calculation will be biased towards the centre of the image area. -
Page 48: Iso
Drive mode ■ How to use the wise shot 1. Select the ASR mode bu pressing the mode button. 2. Select the wise shot menu in the [DRIVE] menu. 3. Press the Shutter button to take image. 4. The captured images are displayed. - To select an image, press the Left/Right button. -
Page 49: White Balance
White balance The white balance control allows you to adjust the colours to appear more natural. [Auto WB] : The camera automatically selects the appropriate white balance settings, depending on the prevailing lighting conditions. [Daylight] : For taking images outside. [Cloudy] : For taking images under a cloudy and overcast sky. -
Page 50: Exposure Compensation
Exposure compensation This camera automatically adjusts the exposure according to the ambient lighting conditions. You can also select the exposure value by using the Fn button. ■ Compensating Exposure 1. Press the Fn button, and then use the UP and DOWN buttons to select the exposure compensation icon ( The exposure compensation menu bar will... -
Page 51: Movie Clip Frame Stabiliser
Movie Clip frame stabiliser This function helps stabilize images captured during movie recording. You can select this menu only in the MOVIE CLIP mode. If the memory card is not inserted, this function will not operate. [Off] : Movie clip frame stabilizer function is disabled. -
Page 52: Sharpness
Sharpness You can adjust the sharpness of the picture you are about to take. You cannot check the sharpness effect on the LCD monitor before you take a picture, because this function is applied only when the captured image is stored on the memory. -
Page 53: Voice Memo
Voice Memo You can add your voice-over to a stored still image. (Max. 10 sec.) - If the voice memo indicator is displayed on the LCD monitor, the setting is completed. - Press the shutter button and take a picture. The picture is stored on the memory card. -
Page 54: Recording The Movie Clip Without Voice
Voice Recording ■ Pausing while recording a voice Using this function, you can record your favourite voice clips into a voice recording file without having to create multiple voice recording files. 1. Press the Pause button ( ) to pause recording. -
Page 55: Sound Menu
Sound menu In this mode, you can set up sound settings. You can use the setup menu in all camera modes, except Voice Recording mode. ■The items indicated by are default settings. Mode Menu Sub Menu Volume Medium High Sound 1 Start Sound Sound 2 Sound 3... -
Page 56: Beep Sound
Sound ( Beep Sound If you set sound to ON, various sounds will be activated for camera startup, when buttons are pressed, so that you can be aware of the camera operation status. - [Beep Sound] sub menu : [Off], [Sound 1, 2, 3] AF sound If you set AF sound to ON, AF sound will be activated when a subject is focused so that you can be aware of the camera operation status. -
Page 57: Setup Menu 1
Setup menu Sub menu Menu tab Main menu Guam, Sydney Wellington, Auckland Honolulu, Hawaii LA, San Francisco World Time Chicago, Dallas Caracas, La Paz Buenos Aires Cape Verde (Setup menu 1) Imprint Date&Time Dark Bright AF Lamp Start Image User Image Quick View Power Off LCD Save... -
Page 58: Language
Setup menu 1 ( LANGUAGE There is a choice of languages that can be displayed on the LCD monitor. Even if the battery is removed and inserted again, the language setting will be preserved. - LANGUAGE sub menu : English, Korean, French, German, Spanish, Italian, S.Chinese, T.Chinese, Russian, Portuguese, Dutch, Danish, Swedish, Finnish, Thai, Bahasa (Malay / Indonesian), Arabic,... -
Page 59: Imprinting The Recording Date
Setup menu 1 ( Imprinting the recording date There is an option to include DATE / TIME on still images. - Sub menus [Off] : The DATE & TIME will not be imprinted on the image file. [Date] : Only the DATE will be imprinted on the image file. -
Page 60: Setup Menu 2
Setup menu 2 ( Quick view If you enable Quick View before capturing an image, you can view the image you just captured on the LCD monitor for the duration set in the [Quick View] setup. Quick view is possible only with still images. - Sub menus [Off] : The quick view function can’t be... -
Page 61: Selecting Video Out Type
Setup menu 2 ( Selecting Video out type The Movie output signal from the camera can be NTSC or PAL. Your choice of output will be governed by the type of device (monitor or TV, etc.) to which the camera is connected. PAL mode can support only BDGHI. ■... -
Page 62: Formatting A Memory
Setup menu 2 ( Formatting a memory This is used for formatting the memory. If you run [Format] on the memory, all images, including the protected images, will be deleted. Be sure to download important images to your PC before formatting the memory. - Sub menus [No] : The memory will not be formatted. -
Page 63: Play
Starting play mode Turn the camera on and select Play mode by pressing the play mode button ). The camera can now play back the images stored in the memory. If the memory card is inserted in the camera, all the camera functions apply only to the memory card. -
Page 64: Movie Clip Capture Function
Starting play mode Movie clip capture function You can capture still images from the movie clip. ■ How to capture the movie clip 1. Press the Play / Pause button while playing the movie clip. Then press the E button. 2. -
Page 65: Playing Back A Recorded Voice
Starting play mode Playing back a recorded voice 1. Select the recorded voice that you want to play back by using the Left/Right button. 2. Press the play & pause button ( ) to play back a recorded voice file. - To pause a recorded voice file, while playing it back, press the play &... -
Page 66: Lcd Monitor Indicator
LCD monitor Indicator The LCD monitor displays shooting information about the displayed image. ④ ③ ② ⑤ ⑥ ⑦ Description Battery Folder name & File name Memory card indicator Playback mode Voice Memo Protect DPOF Recording date Image size 3264x2448 ~ 256X192 Flash Shutter speed Aperture value... -
Page 67: Thumbnail / Enlargement Button
Thumbnail ( ) / Enlargement ( ■Image enlargement 1. Select an image that you want to enlarge and press the enlargement button. 2. Different parts of the image can be viewed by pressing the 5 function button. 3. Pressing the thumbnail button will zoom back to the original full sized image. -
Page 68: Info / Up Button
Info( ) / Up button When the menu is displayed on the LCD monitor, the UP button operates as a direction button. When the menu is not displayed on the LCD monitor, pressing the Info button will display image information on the LCD monitor. Info ( ) button Info (... -
Page 69: Left / Right / Menu / Ok Button
Left / Right / Menu / OK button LEFT / RIGHT / MENU / OK buttons activate the following. - LEFT button : While the menu is showing, the LEFT button operates as a direction button. While the menu is not showing, press the LEFT button to select the previous image. -
Page 70: E (Effect) Button : Resize
E (Effect) button : Resize Change the resolution (size) of pictures taken. Select [Start image] to save an image to be the start-up image. 1. Press the play mode button and press the E button. 2. Press the Left / Right button and select the [RESIZE] ( ) menu tab. -
Page 71: E (Effect) Button : Rotating An Image
E (Effect) button : Rotating an image You can rotate the stored images by various degrees. 1. Press the play mode button and press the E button. 2. Press the LEFT / RIGHT button and select the [ROTATE] ( ) menu tab. 3. -
Page 72: E (Effect) Button : Special Colour
E (Effect) button : Colour ■ Custom colour You can change the R (Red), G (Green) and B (Blue) values of the image. - OK button : Select / setup the Custom Colour - Up / Down button : Selects R, G, B - Left / Right button : Change the values E (Effect) button : Special Colour 1. -
Page 73: Colour Mask
E (Effect) button : Special Colour Colour mask With this menu, you can select a part you want to highlight. The rest of the image will be in black and white. SPECIAL COLOR Select and a mark for selecting part will display. Move Exit 《72》... -
Page 74: E (Effect) Button : Image Editing
E (Effect) button : Image editing 1. Press the play back button and press the E button. 2. Select menu tab by pressing the Left/Right button. Red eye Removal Red eye effect can be removed from the captured image. 1. Select ( ) by pressing the Up/Down button and press the OK button. -
Page 75: Saturation Control
E (Effect) button : Image editing Saturation control You can change the saturation of the image. 1. Select ( ) by pressing the Up/Down button and a bar for selecting the saturation will be displayed. 2. Change the saturation by pressing the Left/Right button. -
Page 76: Cartoon
E (Effect) button : FUN Cartoon You can add a text box on the image to make the image cartoon like. ※ The cartoon image is saved as 1M image size. Select Cartoon ( Move Exit Press the OK button and the image is saved. -
Page 77: Preset Focus Frames
E (Effect) button: FUN ■ Before saving the cartoon image, you can change the selected image. 1. Pressing the Fn button deletes the images in order. 2. Press the OK button and you can select images. Pressing the Fn button Save Delete 3. -
Page 78: Composite Image
E (Effect) button: FUN ■Moving and changing the focus frame You can change the focus frame after selecting a Range menu. 1. Select a focus frame by pressing the Left/Right button and press the OK button. 2. Move the location of the frame by pressing the Up/Down/Left/Right button. 3. - Page 79 E (Effect) button: FUN ※ Selecting 2 composite shots Pressing the Up/Down/Left/Right button Move Pressing the OK button Select Back [Selecting the second image] Select an image by pressing the 5 function button and press the OK button Change the location of second image by pressing the Up/Down/Left/Right button button and press the OK button to save the image.
-
Page 80: Photo Frame
E (Effect) button: FUN Photo Frame You can add 9 types of frame-like borders to a still image you want to capture. Date & Time information will not be printed on the stored image taken with Photo Frame menu. Move Exit Select a desired sub menu by pressing the Up/Down/Left/Right button. -
Page 81: Sticker
E (Effect) button : FUN Sticker You can add various stickers to the image. Select ( Move Exit Select a location of sticker by pressing the Up/Down/Left/Right Save button Move ※ You can add additional stickers by pressing the Fn button. Press the OK button to store the image. -
Page 82: Setting Up The Play Back Function Using The Lcd Monitor
Setting up the play back function using the LCD monitor This menu is available while the camera is connected to a PictBridge supporting printer (direct connection to the camera, sold separately) with a USB cable. Menu tab Main menu Sub menu One Pic Images All Pics... -
Page 83: Starting The Slide Show
Starting the slide show ( Images can be displayed continuously at pre-set intervals. You can view the slide show by connecting the camera to an external monitor. 1. Press the play mode button and press the menu button. 2. Press the LEFT / RIGHT button and select the [SLIDE SHOW] menu tab. Start the slide show The slide show can start only in the [Show] menu. -
Page 84: Configure Slide Show Effects
Starting the slide show ( Configure slide show effects Unique screen effects can be used for the slide show. 1. Select the [Effect] sub menu by pressing the UP / DOWN button and press the RIGHT button. 2. Use the Up / Down button to select the type of effect. -
Page 85: Playback
Playback ( Voice memo You can add your voice to a stored still image. PLAYBACK Veice Memo 끄기 Delete Protect DPOF Copy to Card 정지 00:00:00 ◀ Back [Voice memo menu] [Ready for recording] - Press the shutter button to take a picture. The images are saved on the memory. -
Page 86: Protecting Images
Playback ( Protecting images This is used to protect specific shots from being accidentally erased (Lock). It also unprotects images that have been previously protected (Unlock). 1. Press the Up / Down button and select the [Protect] menu tab. And then press the Right button. - Page 87 Playback ( ■ Standard This function allows you to embed printing quantity information on a stored image. 1. Press the Up / Down button and select the [DPOF] menu tab. And then press the Right button. 2. Press the Right button again and [Standard] sub menu will display.
-
Page 88: Copy To Card
Playback ( ■ Print size You can specify the print size when printing images stored on the memory card. The [Size] menu is available only for DPOF 1.1 compatible printers. 1. Press the Up / Down button and select the [DPOF] menu tab. -
Page 89: Pictbridge
Playback ( ● When this menu is selected without inserting a memory card, the [No Card] message will be displayed. ● If there is not enough space available in the memory card to copy saved images in the internal memory (19 MB), the [Copy To Card] command will copy only some of the images and display [Memory Full!] message. -
Page 90: Pictbridge : Picture Selection
PictBridge ※ If the [USB] menu is set to the [Computer], you cannot connect a Pictbridge compatible printer to the camera through USB cable with [Connecting Computer] message. In this case, remove the cable and do the step 1 and 2 again. ■... -
Page 91: Pictbridge : Print Setting
PictBridge : Print Setting You can select the Paper Size, Print Format, Paper Type, Print Quality, Date Print, and File Name Print menus for printed pictures. 1. Press the Menu button and the PictBridge menu will display. 2. Use the Up / Down buttons to select the desired menu, and then press the Right button. -
Page 92: Important Notes
- Take care not to get fingerprints or foreign substances on the surface of the lens. ● If the digital camera is not used for a long period, an electric discharge can occur. It is a good idea to remove the battery and the memory card if you do not intend using the camera for an extended period of time. -
Page 93: Warning Indicator
● Before an important event or going on a trip, you should check the camera condition. - Take a picture for testing the camera condition and prepare extra battery. - Samsung cannot be held responsible for camera malfunctions. 《92》 Warning indicator There are several warnings that may appear on the LCD display. -
Page 94: Before Contacting A Service Centre
Warning indicator [ File Error! ] ㆍFile error → Delete the file ㆍMemory card error → Contact a camera service centre [ Low Battery! ] ㆍThere is low battery capacity → Insert fresh batteries. [ Low Light! ] ㆍWhen taking pictures in dark places →... - Page 95 Before contacting a service centre Camera does not take images when pressing the Shutter button ㆍThere is insufficient memory capacity → Delete unnecessary image files ㆍThe memory card has not been formatted → Format the memory card (p.61) ㆍThe memory card is exhausted →...
-
Page 96: Specifications
Before contacting a service centre Images are too bright ㆍExposure is excessive → Reset exposure compensation No image on external monitor ㆍThe external monitor has not been connected properly with the camera → Check the connection cables ㆍThere are incorrect files in the memory card →... - Page 97 Specifications Flash - Modes : Auto, Auto & Red-eye reduction, Fill-in flash, Slow sync, Flash off, Red-eye Fix - Range : Wide : 0.2m ~ 3.0m, Tele : 0.5m ~ 2.5m - Recharging Time : Approx. 4 sec Sharpness - Soft+, Soft, Normal, Vivid, Vivid+ Color Effect - Normal, B&W, Sepia, Red, Blue, Green, Negative, Custom Color...
- Page 98 - Capacity (256 MB Size) Super Fine Fine Normal ※ These figures are measured under Samsung standard conditions and may vary depending on shooting conditions and camera settings. “ “ E” ” Button - Effect : Color, Image Adjust, Special Colour,...
-
Page 99: Software Notes
- Using a Hand-made PC or a PC and OS that has not been guaranteed by the manufacturer is not covered by the Samsung warranty. - Before reading this manual, you should have a basic knowledge of computers and O/S (Operating Systems). -
Page 100: About The Software
MAC is not included with the Application CD. You can use the camera with Mac OS 10.0~10.4. ■ ■ Samsung Master : This is the all-in-one multi media software solution. You can download, view, edit and save your digital images and movie clips with this software. -
Page 101: Setting Up The Application Software
Click the [Install] menu in the Auto run frame. 2. Install the camera driver, DirectX, XviD, Samsung Master and Adobe Reader by selecting a button shown on the monitor. If a latest version of DirectX was installed on your computer, DirectX may not be installed. - Page 102 ※ If your OS is Windows XP/ Vista, an image viewer program will open. If the download window of Samsung Master opens after starting Samsung Master, the camera driver was set up successfully.
-
Page 103: Starting Pc Mode
Setting up the application software ● If you have installed the camera driver, the [Found New Hardware Wizard] may not open. ● On a Windows 98SE system, the Found New Hardware Wizard dialog box opens and a window asking you to select a driver file may appear. In this case, specify "USB Driver"... - Page 104 Starting PC mode ■ Connecting the camera to a PC ※If you selected [Printer] in Step 5, when you connect the camera to your computer, the [Connecting Printer] message will display and the connection will not be established. In this case, disconnect the USB cable, and then follow the procedure from Step 2 and onward.
- Page 105 PC. 《104》 - By using [Samsung Master], you can see the stored images in the memory directly on the PC monitor and you can copy or move the image files. ● We recommend that you should copy the images to the PC to view them.
-
Page 106: Removing The Removable Disk
Removing the removable disk ■ Windows 98SE 1. Check whether the camera and PC are transferring a file. If the camera status lamp blinks, please wait until the lamp has finished blinking and is constantly on. 2. Unplug the USB cable. ■... -
Page 107: Setting Up The Usb Driver For Mac
1. Connect the camera to your PC and turn them on. 2. Check whether the Removable Disk is on the [My Computer]. 3. Remove the [Samsung Digital Camera] on the Device manager. 4. Disconnect the USB cable. 5. Remove the [Samsung USB Driver] on the Add/Remove Programs Properties. -
Page 108: Samsung Master
You can download, view, edit and save your images and movies with this software. This software is only compatible with Windows. To start the program, click [Start → Programs → Samsung → Samsung Master → Samsung Master]. ■ Downloading images 1. - Page 109 ③ Image display window : A selected image displays in this window. ④ Preview window : You can preview the changed image. ※ A still image edited with Samsung Master can’t be played back on the camera. ※ Refer to the [Help] menu in Samsung Master for further information.
- Page 110 ② Frame display window : You can insert multi media in this window. ※ Some movie clips that were compressed with a codec that is not compatible with the Samsung Master can’t play back in the Samsung Master. ※ Refer to the [Help] menu in Samsung Master for further information. ② 《109》...
-
Page 111: Faq
Please check the following if the USB connection malfunctions. Case 1 USB cable is not connected or it is not the supplied USB cable. → Connect the supplied USB cable. Case 2 The camera is not recognised by your PC. Sometimes, the camera may appear under [Unknown Devices] in Device Manager. - Page 112 → If you install only the Samsung Master, the problems mentioned above occasionally happen. - Close the Digimax Master program by clicking the Samsung Master icon on the Taskbar. - Install all the application programs included in the software CD.
-
Page 113: Correct Disposal Of This Product
This product should not be mixed with other commercial wastes for disposal. Samsung Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products. - Page 114 SAMSUNG OPTO-ELECTRONICS AMERICA, INC. 1-800-SAMSUNG (726-7864) www.samsungcamerausa.com If you have any questions or comments relating to Samsung cameras, Please contact the SAMSUNG customer care center SAMSUNG FRANCE S.A.S. HOTLINE PHOTO NUMÉRIQUE : 00 800 22 26 37 27 (Numéro Vert-Appel Gratuit) www.samsungphoto.fr...
