Page 3: Table Of Contents
Table of Contents Safety Precautions ..............................3 System Overview ............................... 4 Features..................................4 T110c Dimensions and Controls ..........................4 Installing the Receiver ..............................5 Installation Considerations ............................6 Power the Transmitter ..............................7 Test the Transmitter / Receiver Link .......................... 7 J1939 Data Frame Structure ............................. -
Page 4: System Overview
System Overview The OMNEX Trusted Wireless™ T110c / R260 is a portable, long range, programmable radio remote control system. Designed as a compact and easy-to-use product, this Trusted Wireless™ system puts complete control of your ma- chine where it’s needed most, with the operator. It’s robust, easy to install and has complete self-diagnostics. This sys- tem can be a simple cable replacement or add intelligence to make it a total control package. -
Page 5: Installing The Receiver
R260 Output Cables can be provided with every system to simplify the wiring pro- cess. The Wire Color column below only applies to the Eaton Output Cable configuration. Tips on mounting, power connections and filtering are also provided under Installation Considerations. -
Page 6: Installation Considerations
The FCC and ISC require that the antenna be restricted to that supplied by the manufacturer and approved for use with this product. An op- tional 0dB coax wire antenna may be supplied. For other antenna options, please contact Eaton Wireless Business Unit. -
Page 7: Power The Transmitter
Power the Transmitter Install Batteries Remove the battery cover on the back of the transmitter using a slotted screwdriver and insert 4 "AA" alkaline batteries. When purchased with the CCDOCK™, insert ei- ther NiCd or NiMH (recommended) rechargeable AA batteries. Orientation of the bat- teries is embossed inside the battery housing. -
Page 8: J1939 Data Frame Structure
Each node on a J1939 network must have a unique name. To facilitate this, the R260’s J1939 name is dependent on the Iden ty Number. More specifically the Iden ty number field is broken down in to two EATON fields, Device Type &... - Page 9 J1939 Data Frame Structure (cont) PGN: 65280 (0xFF00) Period: 50ms Priority: Device ID: 0x71 (factory default) Note: All data in decimal Data Length: 8 Bytes ID Format: 29‐Bit Position Bit T110 Data Description Data Range Length 65280 On/Shift 0 = not active (OFF) 0 to 1 (0xFF00) 1 = active (ON)
- Page 10 J1939 Data Frame Structure (cont) PGN: 65281 (0xFF01) Period: 50ms Priority: Device ID: 0x71 (factory default) Note: All data in decimal Data Length: 8 Bytes ID Format: 29‐Bit Position Bit T110 Data Description Data Range Length 65281 Func on 1 (0xFF01) Func on 2 Func on 3 Func on 4...
-
Page 11: Special Functions
Special Functions The [Shift] Function Outputs 1-10 are controlled by the T110C [Function] buttons “1-10”. Outputs 11-18 are controlled by holding the T110C [Shift] button and pressing the [Function] buttons “1-8” (the GREEN Power [ON] button acts as the [Shift] button when the T110C is on). - Page 12 Associate a Transmitter (Use in case of Link Test failure) 3. Power T110C into Configuration Mode A. Press and Hold Power [OFF] B. Press and Hold Power [ON] C. Release Power [OFF] button D. Release Power [ON] button 4a. Put R260 into Setup Mode (with Magnet on A.
- Page 13 Associate a Transmitter (Use in case of Link Test failure) 5. Send Code NOTE: When downloading a new ID to a receiver, a safety feature requires that the transmitter be in close proximity to the receiver. This will prevent a transmitter from accidentally reprogramming a different receiver in the area. STATUS E-STOP CAN1...
-
Page 14: Diagnostics-T110C Transmitter
Diagnostics—T110C Transmitter Indicator Lights Description Solution Occurs when ever a function is pressed. Will also remain on momentarily on Pow- er Up. To take it out of Download mode turn transmit- Transmitter is in Download mode. ter off and turn it back on again. Transmitter is in Operating mode. -
Page 15: Diagnostics-R260 Receiver
Recycle the Receiver power. Refer to Troubleshooting Chart #1 for STATUS I/O E-STOP CAN1 CAN2 Internal fault or PLC program is solutions. If the problem persists than contact Eaton Wireless Busi- not loaded or stopped. ness Unit service providing part and serial number. -
Page 16: Troubleshooting Guide
Troubleshooting Guide Chart #1 Test the Receiver—R260 Start Initial Condition: Turn off transmitter (all lights are off—press the E-Stop button) Cycle power to receiver (turn off and back on) Receiver OK: Receiver lights? Error Condition: Note: If there is a short to ground on an output, it is not Status –... - Page 17 Troubleshooting Guide (continued) Chart #2 Test the Transmitter—T110C 1. Turn off the receiver 2. Ensure transmitter batteries are good/charged 3. Turn on the transmitter Transmitter lights? Active – steady for 3 Press one of the buttons seconds then fast flash. Battery light –...
- Page 18 Troubleshooting Guide (continued) Chart #3 Testing the Transmitter / Receiver Communication Transmitter: Transmitter: What is Active light is flashing Active light is flashing light status of both Receiver: transmitter and Receiver: Status—GREEN receiver? Status—GREEN E-Stop—RED E-Stop—Flashing GREEN Transmitter and receiver There is no LINK between should be working properly.
- Page 19 Troubleshooting Guide (continued) Chart #4 Considerations when Downloading the ID Potential downloading issues If testing of the receiver and transmitter both show the system as working (Chart 1 & 2), then the transmitter and receiver will both go into Download/Configuration mode. Possible issues could arise during Step 4, the download phase of reprogramming.
-
Page 20: Parts & Accessories
SUBJECT TO UNAUTHORIZED REPAIR OR MODIFICATION) and labor from Port Coquitlam, BC, Canada (1) This device may not cause the date of delivery as evidenced by a copy of the receipt. Eaton's entire liability V3C 6G5 harmful interference, and and your exclusive remedy shall be, at Eaton's option, either the (a) repair or (b)
