Replacing the Filter Pump and Motor
Removing the Filter Pump and Motor
1. Loosen the pump inlet tube using a crescent
wrench.
2. Unscrew and remove the inlet valve of the filter
pump system.
SG/SSH Series Service Manual
3. Pull out pump inlet tube.
4. Remove filter pan cover (not shown).
5. Disconnect the connections and power supply
cords from the filter pump.
6. Remove the lower connection at the 3-way
return valve using a 15/16 inch wrench.
