Install Inside Trim Plate
Fasten Inside Trim Plate using two#8-32 x 3/8"
!
Flat Head Machine Screws (item #4c).
User codes are located
on the inside trim plate
& back cover page.
!
Inside
Correct position for installation.
Thumbcam must be positioned
as shown (Neutral Position)*
*Neutral position is required for installation and removal of the Inside Trim Plate Assembly.
Screws (item #4c)
