- Page 1 T X P 1 4 3 0 F / T X P1 6 3 4 F T X P2 0 2 2 Owner’s Instructions Printed in Mexico AA68-02833A (ENG) C O L O R T E L E V I S I O N...
-
Page 2: Safety Instructions
As an ENERGY STAR Part n e r. Samsung Electronics America, Inc. has determined that this product or pro d u c t model meets the ENERGY STAR guidelines for energy eff i c i e n c y. - Page 3 Thank You for Choosing Samsung Thank you for choosing Samsung! Your new Samsung TV receiver represents the latest in television technology. It has easy-to-use, on-screen menus and closed-captioning capabilities, making this TV one of the best products in its class. This product will provide convenient, dependable service and enjoyment for years to come.
- Page 4 • Protect the power cord. Power supply cords should be routed so that they will not be walked on or pinched by items placed on or against them. Pay particular attention to cord placement at plugs, convenience receptacles, and at the point where they exit from the unit. •...
- Page 5 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, Install in accordance with the manufacturer’ s instructions.
-
Page 6: Table Of Contents
O N T E N T S Chapter 1: Your New TV ....1 . 1 Chapter 2: Installation ....2 . 1 Chapter 3: Operation . - Page 7 O N T E N T S Chapter 4: Special Feature s ... . 4 . 1 Customizing Your Remote Control ......4.1 Setting Up Your Remote Control to Operate Your VCR or DVD .
-
Page 8: List Of Features
C h a p t e r O n e O U R List of Features Your Samsung TV was designed with the latest technology. This TV is a high-performance unit that includes the following special features: • Easy-to-use remote control •... -
Page 9: Familiarizing Yourself With The Tv
O U R Familiarizing Yourself with The TV F ront Panel Buttons The buttons on the front panel control your TV’ s basic features, including the on-screen menu. To use the more advanced features, you must use the remote control. •... -
Page 10: Rear Panel Jacks
O U R Rear Panel Jacks Use the rear panel jacks to connect an A/V component that will be connected continuously, such as a VCR. For more information on connecting equipment, see pages 2.1 Р2.6. ΠDVD VIDEO input jacks (Option) Use these jacks to connect the component video signal from a DVD player. -
Page 11: Remote Control
O U R Remote Contro l You can use the remote control up to about 23 feet from the TV. When using the remote, always point it directly at the TV. Œ POWER P ress to turn the TV on and off. ´... -
Page 12: Number Buttons
O U R Remote Contro l You can use the remote control up to about 23 feet from the TV. When using the remote, always point it directly at the TV. You can also use your remote control to operate your VCR, DVD and cable box. See page 4.1 for details. - Page 13 O U R Remote Contro l ¯ VCR Contro l s REW (Rewind) Press to rewind a tape in your VCR. S T O P Press this button to stop a tape during play, record, rewind or fast forward. If the button is pressed during Full-Automatic play, the function will be can- celled.
-
Page 14: Chapter 2: Installation
C h a p t e r Tw o N S TA L L AT I O N Connecting VHF and UHF Antennas If your antenna has a set of leads that look like this, see “Antennas with 300-ohm Flat Twin Leads,” below. If your antenna has one lead that looks like this, see “Antennas with 75-ohm Round Leads,”... -
Page 15: Antennas With 75-Ohm Round Leads
N S TA L L AT I O N Antennas with 75-ohm Round Leads Plug the antenna lead into the VHF/UHF terminal on the bottom of the back panel. Separate VHF and UHF Antennas If you have two separate antennas for your TV (one VHF and one UHF), you must combine the two antenna signals before connecting the antennas to the TV . -
Page 16: Connecting To A Cable Box That Descrambles All Channels
N S TA L L AT I O N Connecting to a Cable Box that Descrambles A l l C h a n n e l s Find the cable that is con- nected to the ANTENNA OUT terminal on your cable box. - Page 17 N S TA L L AT I O N Connect a coaxial cable between the ANTENNA OUT terminal on the cable box and the B–IN terminal on the A/B switch. Connect another cable between the other OUT terminal on the splitter and the A–IN terminal on the RF (A/B) switch.
-
Page 18: Connecting A Vcr
N S TA L L AT I O N Connecting a VCR These instructions assume that you have already connected your TV to an antenna or a cable TV system (according to the instructions on pages 2.1-2.4). Skip step 1 if you have not yet connected to an antenna or a cable system. -
Page 19: Connecting A Camcorder
N S TA L L AT I O N Connecting a Camcorder The front panel jacks on your TV make it easy to connect a camcorder to your TV. They allow you to view the camcorder tapes without using a VCR. (Also see “Viewing a VCR or Camcorder Tape”... -
Page 20: Installing Batteries In The Remote Control
N S TA L L AT I O N Installing Batteries in the Remote Control Slide the cover out com- pletely. Install two AA size batteries. Replace the cover. HAPTER NSTALLATION Make sure to match the “ ” and – “... -
Page 21: Chapter 3: Operation
C h a p t e r T h r e e P E R AT I O N P E R AT I O N Turning the TV On and Off Press the POWER button on the remote control. You can also use the POWER button on the front panel. -
Page 22: Selecting A Menu Language
P E R AT I O N Selecting a Menu Language Press MENU to display the menu. Press CH three times to select “Function”, then press the VOL + but- ton. Press VOL + to select the appropriate language: English, Spanish, or French. -
Page 23: Memorizing The Channels
P E R AT I O N Memorizing the Channels Your TV can memorize and store all of the available channels for both “off-air” (antenna) and cable channels. After the available channels are memorized, use the CH buttons to scan through the channels. This eliminates the need to change chan- nels by entering the channel digits. -
Page 24: Storing Channels In Memory (Automatic Method)
P E R AT I O N Storing Channels in Memory (Automatic Method) First, select the correct signal source (ANT, STD, HRC, IRC). See steps 1~3 on previous page. Press the MENU button, then press the CH ton twice to select “Channel,”... -
Page 25: Adding And Erasing Channels (Manual Method)
P E R AT I O N Adding and Erasing Channels (Manual Method) Press the MENU button. Press the CH button twice to select "Channel", then press the VOL+ but- ton. Press the CH or CH button to select “Add/Erase”. Press the VOL+ button. -
Page 26: Changing Channels
P E R AT I O N Changing Channels Using the Channel Buttons Press the CH When you press CH channels that the TV has memorized. (The TV must have memorized at least three channels.) You will not see channels that were either erased or not memorized. D i rectly Accessing Channels Use the number buttons to quickly tune to any channel. -
Page 27: Setting The Clock
P E R AT I O N Setting the Clock Press the MENU button to display the on-screen menu. Press the CH button three times to select "Function". Press the VOL + button. Press the CH button to select the “Time” menu. Press the VOL + button: The Time menu will appear on the screen, and... -
Page 28: Customizing The Picture
P E R AT I O N Customizing the Picture You can use the on-screen menus to change the contrast, brightness, tint, color, and sharpness according to personal preference. (Alternatively, you can use one of the “automatic” settings. See next page.) Press the MENU button to display the menu. -
Page 29: Using Automatic Picture Settings
P E R AT I O N Using Automatic Picture Settings Your TV has three automatic picture settings (“Standard”, “Natural”, and “Mild”) that are preset at the factory. You can activate either Standard, Natural or Mild by making a selection from the menu. Or, you can select “Custom” which automatically recalls your personalized picture settings. -
Page 30: Using Automatic Sound Settings
P E R AT I O N Using Automatic Sound Settings Your TV has four automatic sound settings (“Standard,” “Music,” “Movie,” and “Speech”) that are preset at the factory. You can activate any of them by making a selection from the on-screen menu. -
Page 31: Viewing A Vcr Or Camcorder Tape
P E R AT I O N Viewing a VCR or Camcorder Tape You must select the appropriate mode in order to view the VCR or Camcorder signal on the TV . Press the MENU button to display the menu. Press the CH button twice to select... -
Page 32: Customizing Your Remote Control
TV , the universal remote can also operate a VCR, DVD and a cable box (even if your VCR, DVD and cable box are made by manufacturers other than Samsung). Setting Up Your Remote Control to Operate Your VCR or DVD Turn off your VCR or DVD. -
Page 33: Vcr Codes
P E C I A L E AT U R E S VCR Codes DVD Codes HAPTER PECIAL EATURES... -
Page 34: Setting Up Your Remote Control To Operate Your Cable Box
Setting Up Your Remote Control to Operate Your Cable Box Turn off your cable box. On your Samsung remote control, press SET. Press the CABLE button on the top right of your remote control. Enter both digits of the cable box code listed below for your brand of cable box. -
Page 35: Fine Tuning Channels
P E C I A L E AT U R E S Fine Tuning Channels Use fine tuning to manually adjust a particular channel for optimal reception. Select the appropriate channel. Press the MENU button to display the menu. Press the CH button twice to select the “Channel”... -
Page 36: Changing The Screen Size
P E C I A L E AT U R E S Changing the Screen Size Press the MENU button to display the menu. Press the VOL + button to select the “Picture” menu. Press the CH twice to select "Size." Press the VOL + or VOL - button repeatedly to select “Normal”... -
Page 37: Using The Surf Feature
P E C I A L E AT U R E S Using the Surf Feature This feature allows you to set the TV to return to a particular channel after a certain amount of time. For example, you may be watching a channel when commercials start. -
Page 38: Setting The On/Off Timer
P E C I A L E AT U R E S Setting the On/Off Timer Press the MENU button to display the menu. Press the CH three times to select "Function" menu, then press the VOL+ button. Press the CH select "Time", then press the VOL+ button. -
Page 39: Setting The Sleep Timer
P E C I A L E AT U R E S Press the VOL + button to select “On/Off.” Press the CH (or CH button to turn the on- timer “On.” (Repeatedly pressing the CH button will alter- nate between on and off.) When finished, press the VOL + button. -
Page 40: Sound Features
P E C I A L E AT U R E S Sound Features Choosing a Multi-Channel Sound (MTS) Soundtrack Depending on the particular program being broadcast, you can listen to Stereo, Mono or a Separate Audio Program. (SAP audio is usually a foreign-language translation. Sometimes SAP has unrelated information like news or weather.) Press the MENU button to display the menu. -
Page 41: Extra Sound Settings
Turbo sound emphasizes the bass and treble frequencies to add fullness to the sound. • Surround Your Samsung TV creates a "Surround" effect such that the sound seems to come from all directions. Once the “Surround” is set to “On” or “Off”, the setting applies to the sound effects such as Standard, Music, Movie and Speech. -
Page 42: Viewing Closed Captions
P E C I A L E AT U R E S Viewing Closed Captions Your TV decodes and displays the closed captions that are broadcast with certain TV shows. These captions are usually subtitles for the hearing impaired or foreign-language trans- lations. -
Page 43: Using The V-Chip
P E C I A L E AT U R E S Using the V- C h i p The V-Chip feature automatically locks out programming that is deemed inappropriate for children. The user must first enter a PIN (personal ID number) before any of the V-Chip restrictions can be set up or changed. -
Page 44: How To Enable/Disable The V-Chip
P E C I A L E AT U R E S How to Enable/Disable the V- C h i p Press the MENU button to display the menu. Press the CH three times to select the “Function” menu. Press the VOL+ button. Press the CH three times to select the “V-chip”... - Page 45 P E C I A L E AT U R E S Press the CH button three times to select the “V-chip” menu. Press the VOL+ button. The “Enter pin” screen will appear. Enter your 4- digit PIN number. The “V-chip” screen will appear.
-
Page 46: How To Set Up Restrictions Using The Mpaa Ratings: G, Pg, Pg-13, R, Nc-17, X
P E C I A L E AT U R E S How to set the FV, D, L, S and V sub-ratings: First, highlight one of these TV-Ratings: TV-Y7, TV-PG, TV-14 or TV-MA (See Step 4, on previous page). Next, while the TV-Rating is highlighted (BLUE), repeatedly press the VOL + button. -
Page 47: How To Reset The Tv After The V-Chip Blocks A Channel ("Emergency Escape")
P E C I A L E AT U R E S The “V-chip” screen will appear. Press the CH button twice, and select “MPAA rating.” While “MPAA rating” is selected, press the VOL + button. The “MPAA rat- ing” screen will appear. Repeatedly press the CH button to select a particular MPAA category. -
Page 48: Identifying Problems
R O U B L E S H O O T I N G If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, then call your nearest Samsung authorized service center. -
Page 49: Appendix
P P E N D I X Cleaning and Maintaining Your TV With proper care, your TV unit will give you many years of service. Please follow these guidelines to get the maximum performance from your TV . Placement • Do not place the TV near extremely hot, cold, humid or dusty places. •...
