Page 1: Lcd Monitor
SyncMaster XL2370, P2570 LCD Monitor User Manual The appearance and the color may differ depending on the model. -
Page 3: Table Of Contents
Power Saving Function ........6-2 Contact SAMSUNG WORLDWIDE ......6-3 Correct Disposal of This Product (Waste Electrical &... -
Page 5: Major Safety Precautions
The contents of this manual may not be partially or in whole reproduced, distributed or used in any form without the written permission of Samsung Electronics, Co., Ltd. The SAMSUNG logo and SyncMaster are the registered trademarks of Samsung Electronics, Co., Ltd. Microsoft, Windows and Windows NT are the registered trademarks of Microsoft Corporation. -
Page 6: Custody And Maintenance
Custody and Maintenance External Surface and Screen Maintenance Clean the product with a soft dry cloth. • Do not clean the product with an inflammable substance such as benzene or thinner or with a wet cloth. This may result in a problem with the product. -
Page 7: Safety Precautions
Safety Precautions Icons used for safety precautions ICON NAME Warning Caution Meaning of Signs Do not perform. Do not disassemble. Do not touch. Power Related The following images are for your reference and may differ depending on models and countries. Warning Avoid using a damaged power cord or plug or a loose power outlet. -
Page 8: Installation Related
Caution Avoid unplugging the power plug while the product is operating. • Otherwise, it may damage the product due to electric shock. When unplugging the power plug from the wall outlet, make sure to hold it by the plug and not by the cord. •... -
Page 9: Cleaning Related
Avoid installing the product in a location exposed to dust, moisture (sauna), oil, smoke or water (rain drops) and installing it within a vehicle. • This may result in electric shock or fire. Avoid installing the product at an easily reachable height where children may reach •... -
Page 10: Usage Related
Before cleaning the product, unplug the power cord. • Otherwise, it may result in electric shock or fire. Caution Avoid spraying cleansing agent directly onto the product. • This may result in discoloration or cracking of the exterior of the product or the panel coming off. - Page 11 When thunder or lighting occurs, unplug the power cord and under no circumstance touch the antenna cable as this is danger- ous. • Otherwise, it may result in electric shock or fire. Avoid moving the product by pulling the power cord or antenna cable. •...
- Page 12 Do not place the adapter on top of another adapter. • Otherwise, it may result in fire. Remove the vinyl cover of the adapter before using the adaptor. • Otherwise, it may result in fire. Be careful that adaptor should not be in contact with water and therefore not be wet.
-
Page 13: Installing The Product
Installing the Product Package Contents • Unpack the product and check if all of the following contents have been included. • Store the packaging box in case you need to move the Product at a later stage. Installation Manual Power Cord Stand HDMI Cable The cleaning cloth is supplied with black high-glossy models only. -
Page 14: Installing The Stand
Installing the Stand Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards. Insert the Stand Connector into the Stand in the direction shown by the figure. Check if the Stand Connector is firmly connected. Turn the connecting screw at the bottom of the stand fully so that it is completely fixed. - Page 15 - Caution Avoid lifting the product holding only the stand. Installing the Product...
-
Page 16: Removing The Stand
Removing the Stand Before removing the stand, place the product down on a flat and stable surface so that the screen faces downwards. Place a soft cloth over the table to protect the product and place the product onto the cloth so that the front of the product faces downwards. -
Page 17: Connecting With A Pc
Connecting with a PC The connecting part may differ depending on the product model. 1. Connect the product to a PC depending on the video output supported by the PC. • When the graphics card provides D-Sub (Analog) output • Connect the [DVI IN] port of the product to the [D-Sub] port on your PC using the DVI-A to D-Sub cable. -
Page 18: Connecting An Hdmi Cable
Connecting an HDMI cable 1. Connect the HDMI output port of your digital output device to the [HDMI IN] port of the product using the HDMI cable. 2. Connect a speaker to the [AUDIO OUT] port of the product. This product won't make any sound when only the HDMI cable is connected without a speaker connected. When all the connections are complete, you can turn on and use the product and your DVD player (or digital output device). -
Page 19: Connecting To An Amplifier
Connecting to an Amplifier 1. Connect the [DIGITAL AUDIO OUT] terminal of your monitor to the optical input of your amplifier using an optical cable. • If no sound is emitted from the monitor, you need to use an amplifier. •... -
Page 20: Kensington Lock
Kensington Lock A Kensington Lock is an anti-theft device that enables users to lock the product so that they can safely use it in public locations. Since the shape and usage of the locking device may differ depending on the model and the manufacturer, for more information, refer to the User Manual supplied with the locking device. -
Page 21: Using The Product
Using the product Setting the Optimal Resolution If you turn the power on after purchasing the product, a message regarding the optimal resolution setting appears on the screen. Select a language and the optimal resolution. • The message appears up to 3 times if the resolution has not been set to the optimal resolution. •... -
Page 22: Standard Signal Mode Table
Standard Signal Mode Table The LCD monitor has one optimal resolution for the best visual quality depending on the screen size due to the inherent characteristics of the panel, unlike for a CDT monitor. Therefore, the visual quality will be degraded if the optimal resolution is not set for the panel size. It is recommended setting the resolution to the optimal resolution of the product. -
Page 23: Installing The Device Driver
If you install the device driver, you can set up the appropriate resolution and frequency for the product. The device driver is included on the CD-ROM supplied with the product. If the supplied drive file is corrupted, please visit a service center or Samsung Electronics website(http://www.samsung.com/), and download the driver. 1. Insert the driver installation CD-ROM into the CD-ROM drive. -
Page 24: Product Operating Buttons
Product Operating Buttons Product Operating Buttons ICON MENU Press this button to view the On Screen Display (OSD). This button is also used to exit the OSD or to return to a higher-level OSD menu * OSD Adjustment Lock This function locks the OSD in order to maintain the current settings or to prevent the settings from being changed by another person On: If you press and hold the MENU button down for 5 seconds, the OSD Adjustment Lock function is activated. - Page 25 ICON AUTO Press [AUTO] button to adjust the screen settings automatically If the resolution settings are changed in the Display Properties, the AUTO adjustment func- tion is performed. Press this button to turn the product on or off Power LED This LED is turned on when the product works normally.
-
Page 26: Using The Screen Adjustment Menu (Osd: On Screen Display)
Using the Screen Adjustment Menu (OSD: On Screen Display) The Screen Adjustment Menu (OSD: On Screen Display) Structure TOP MENUS Brightness PICTURE Coarse MagicColor COLOR Color Effect H-Position SIZE & POSI- TION Reset SETUP&RESET Off Timer On/Off Customized Key INFORMA- TION PICTURE <PC signals>... - Page 27 MENU MagicBright Provides preset picture settings optimized for various user environments such as editing a document, surfing the Internet, playing games, watching sports or movies and so on. • <Custom> If the preset picture modes are not sufficient, users can configure the <brightness> and <Contrast>...
- Page 28 MENU Response Time Accelerates the response time of the LCD panel faster than the original response time so that moving pictures appear sharper and more natural. • <Normal> • <Faster> • <Fastest> It is recommended setting the Normal or Faster when not viewing a movie. HDMI Black Level When a DVD or set-top box is connected to your TV via <HDMI>, it may cause a degradation in the screen quality, such as an increase in the black level, a low contrast, or discoloration, etc., depending...
-
Page 29: Size & Position
MENU MagicColor Expresses natural colors more clearly without changing the picture quality using proprietary digital picture quality improvement technology developed by Samsung Electronics. • <Off> - Turns the MagicColor function off. • <Demo> - You can compare the pictures processed by MagicColor with the original pictures. - Page 30 MENU H-Position Moves the position of the display area on the screen horizontally. This function is only available in Analog mode. V-Position Moves the position of the display area on the screen vertically. This function is only available in Analog mode. Image Size PC signals •...
- Page 31 MENU Language Select a language for the OSD. The selected language is only applied to the product OSD. This setting does not affect the other functions of the PC. LED On/Off Turns the Menu button LED on or off. • <Off>...
-
Page 32: Installing The Software
What is Natural Color ? This software works only for Samsung products and enables adjusting the displayed colors on the product and matches the colors on the product with the colors of the printed pictures. For more information, refer to the online help of the software (F1). -
Page 33: Magictune
MagicTune What is MagicTune? MagicTune is a software program that helps with monitor adjustments by providing comprehensive descriptions of monitor functions and easy-to-understand guidelines. Users can adjust the product with the mouse and the keyboard without using the operating buttons of the product. Installing the Software 1. - Page 34 4. Click [Change or Remove Programs] to remove the software. 5. Select [Yes] to start removing MagicTune™. 6. Wait until a message box appears informing you that the software has been removed completely. For technical support, the FAQ (frequently asked questions) or information about the software upgrade for MagicTune™, please visit our website.
-
Page 35: Multiscreen
MultiScreen What is MultiScreen ? MultiScreen enables users to use the monitor by partitioning multiple sections. Installing the Software 1. Insert the installation CD into the CD-ROM drive. 2. Select the MultiScreen setup program. If the pop-up screen for the software installation does not appear on the main screen, find and double-click the MultiScreen setup file on the CD-ROM. -
Page 36: Troubleshooting
Troubleshooting Monitor Self-Diagnosis • You can check if the product is working properly using the Self-Diagnosis function. • If a blank screen is displayed and the Power LED blinks even if the product and the PC are properly connected, perform the self-diagnosis function according to the procedures below. -
Page 37: Before Requesting Service
Before Requesting Service Please check the following before requesting After-Sales service. If the problem continues, please contact your nearest Samsung Electronics Service Center. A BLANK SCREEN APPEARS / I CANNOT TURN THE PRODUCT ON Is the power cord connected properly? Is the “Check Signal Cable”... - Page 38 THE COLOR IS DISPLAYED IN 16 BIT (16 COLORS). THE COLOR HAS BEEN CHANGED AFTER CHANGING THE Did you install the device driver for the product? Is the graphics card configured correctly? WHEN I CONNECT THE MONITOR, THE 'UNKNOWN MONITOR, PLUG&PLAY (VESA DDC) MONITOR FOUND' Did you install the device driver for the product? Check if all the Plug&Play (VESA DDC) functions are sup- ported referring to the User Manual of the graphics card.
-
Page 39: Faq
FAQ! How can I change the frequency of the video signal? How can I change the resolution? How can I use the power saving function? Troubleshooting PLEASE TRY THE FOLLOWING! You have to change the frequency of the graphics card. (For more information, refer to the User Manual of the com- puter or the graphics card.) Windows XP : Change the resolution by selecting Control... -
Page 40: More Information
More Information Specifications MODEL NAME LCD Panel Size Display area Pixel Pitch Synchroniza- Horizontal tion Vertical Display Color Resolution Optimum resolution Maximum resolution Input Signal, Terminated Maximum Pixel Clock Power Supply Signal connectors Dimensions (WxHxD) / Weight (Simple stand) Environmen- Operating tal consider- ations... -
Page 41: Power Saving Function
Power Saving Function This product provides a power saving function that automatically turns the screen off when the product is not used for a predetermined period of time to reduce power consumption. If the product enters power saving mode, the power LED turns to a different color to indicate that the product is in power saving mode. -
Page 42: Contact Samsung Worldwide
Contact SAMSUNG WORLDWIDE • If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. U.S.A CANADA MEXICO ARGENTINA BRAZIL CHILE COLOMBIA COSTA RICA ECUADOR EL SALVADOR GUATEMALA HONDURAS JAMAICA NICARAGUA PANAMA PUERTO RICO REP. - Page 43 3 - SAMSUNG (7267864) 0 801 1SAMSUNG (172678) 022 - 607 - 93 - 33 808 20 - SAMSUNG (7267864) 0800-SAMSUNG(726-7864) 902 - 1 - SAMSUNG (902 172 678) 075 - SAMSUNG (726 78 64) 0848-SAMSUNG(7267864, CHF 0.08/ min) 0845 SAMSUNG (7267864)
- Page 44 PHILIPPINES SINGAPORE THAILAND TAIWAN VIETNAM SOUTH AFRICA TURKEY U.A.E ASIA PACIFIC 1800-10-SAMSUNG(726-7864) 1800-3-SAMSUNG(726-7864) 02-5805777 1800-SAMSUNG(726-7864) 1800-29-3232 02-689-3232 0800-329-999 1 800 588 889 MIDDLE EAST & AFRICA 0860-SAMSUNG(726-7864) 444 77 11 800-SAMSUNG(726-7864) 8000-4726 http://www.samsung.com/ph http://www.samsung.com/sg http://www.samsung.com/th http://www.samsung.com/tw http://www.samsung.com/vn http://www.samsung.com/za http://www.samsung.com/tr http://www.samsung.com/ae...
-
Page 45: Correct Disposal Of This Product (Waste Electrical & Electronic Equipment) - Europe Only
Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Europe only (Applicable in the European Union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. - Page 46 More Information...
