ENGINEERING COMPANY INC.
Route 145, Winthrop Road,
Chester, Connecticut 06412
Phone: (860) 526-9504
Fax: (860) 526-4078
Internet: www.whelen.com
Sales e-mail: autosale@whelen.com
Canadian Sales e-mail: autocan@whelen.com
Customer Service e-mail: custserv@whelen.com

Safety First

This document provides all the necessary information to allow your Whelen product to be properly and safely installed.
Before beginning the installation and/or operation of your new product, the installation technician and operator must
read this manual completely. Important information is contained herein that could prevent serious injury or damage.
Proper installation of this product requires the installer to have a good understanding of automotive
electronics, systems and procedures.
If mounting this product requires drilling holes, the installer MUST be sure that no vehicle components or
other vital parts could be damaged by the drilling process. Check both sides of the mounting surface
before drilling begins. Also de-burr any holes and remove any metal shards or remnants. Install grommets
into all wire passage holes.
If this manual states that this product may be mounted with suction cups, magnets, tape or Velcro™,
clean the mounting surface with a 50/50 mix of isopropyl alcohol and water and dry thoroughly.
Do not install this product or route any wires in the deployment area of your air bag. Equipment mounted
or located in the air bag deployment area will damage or reduce the effectiveness of the air bag, or
become a projectile that could cause serious personal injury or death. Refer to your vehicle owners
manual for the air bag deployment area. The User/Installer assumes full responsibility to determine proper
mounting location, based on providing ultimate safety to all passengers inside the vehicle.
For this product to operate at optimum efficiency, a good electrical connection to chassis ground must be
made. The recommended procedure requires the product ground wire to be connected directly to the
NEGATIVE (-) battery post.
If this product uses a remote device to activate or control this product, make sure that this control is
located in an area that allows both the vehicle and the control to be operated safely in any driving
condition.
Do not attempt to activate or control this device in a hazardous driving situation.
It is recommended that these instructions be stored in a safe place and referred to when performing
maintenance and/or reinstallation of this product.
FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT IN DAMAGE
TO THE PRODUCT OR VEHICLE AND/OR SERIOUS INJURY TO YOU AND YOUR PASSENGERS!
For warranty information regarding this product, visit www.whelen.com/warranty
©2002 Whelen Engineering Company Inc.
Form No.13683B (072507)
®
Page 1
Installation Guide:
Models CSP8120 / CSP8180
Strobe Power Supplies

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSP8120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Whelen Engineering Company CSP8120

  • Page 1: Safety First

    ® ENGINEERING COMPANY INC. Installation Guide: Route 145, Winthrop Road, Chester, Connecticut 06412 Models CSP8120 / CSP8180 Phone: (860) 526-9504 Strobe Power Supplies Fax: (860) 526-4078 Internet: www.whelen.com Sales e-mail: autosale@whelen.com Canadian Sales e-mail: autocan@whelen.com Customer Service e-mail: custserv@whelen.com Safety First This document provides all the necessary information to allow your Whelen product to be properly and safely installed.
  • Page 2 Violet wire: This wire controls the HI/LO feature. (see BREAKERS WITH THIS PRODUCT! wiring diagram) Note: Although a fuse is required to be used in the fuse block, (20-amp: CSP8120 or 30-amp: CSP8180) do not install the fuse until all of the wire connections are completed. Page 2...
  • Page 3 SPECIFICATIONS CSP8180 CSP8120 INPUT VOLTAGE 12.8 VDC +/-20% 12.8 VDC +/-20% LAMP 1 INPUT CURRENT 18 AMPS 12 AMPS INPUT POWER 230 WATTS 154 WATTS LAMP 2 ANODE VOLTAGE 450 VDC / MAX 450 VDC / MAX ENERGY / TOTAL...
