Page 1: Lcd Monitor
LCD MONITOR quick start guide 460UT, 460UTn... -
Page 2: Package Contents
Introduction Package Contents Note Please make sure the following items are included with your LCD Display. If any items are missing, contact your dealer. Contact a local dealer to buy optional items. Note This stand is not for the Floor Standing Type. Unpacking Manuals Quick Setup Guide... - Page 3 Others (Not available in all loca- BNC to RCA Adaptor Jack Sold separately DVI Cable NetWork Box (Applicable to the UT mod- el only) Semi Stand KIT For more information on the use of the calibrater, see Natural Color Expert D-Sub Cable Note •...
- Page 4 Your LCD Display Front Note The buttons are on the right at the back of your product. MENU button [MENU] Opens the on-screen menu and exits from the menu. Also use to exit the OSD menu or return to the previous menu. Navigate buttons (Up-Down buttons) Moves from one menu item to another vertically or adjusts selected menu values.
- Page 5 Note • This is available when a TV tuner box is installed. Power button [ Use this button for turning the LCD Display on and off. Brightness Sensor The product's Brightness Sensor function automatically detects the sur- rounding brightness using a brightness sensor and adjusts its brightness accordingly.
- Page 6 RS232C OUT/IN (RS232C Serial PORT) MDC(Multiple Display Control) Program Port DVI / PC / HDMI IN [DVI/PC/HDMI AU- DIO IN] (PC/DVI/HDMI Audio Connection Terminal (Input)) DVI / PC / HDMI IN [HDMI] Connect the HDMI terminal at the back of your LCD Display to the HDMI terminal of your digital output device using a HDMI ca- ble.
- Page 7 BNC/COMPONENT OUT[R/PR, G/Y, B/ PB, H, V] (BNC/Component Connection (Output)) BNC (Analog PC) Connection: connecting the R, G, B, H, V ports. Component Connection: connecting the PR, Y, PB ports. BNC/COMPONENT IN[R/PR, G/Y, B/ PB, H, V] (BNC/Component Connection Terminal (In- put)) RGB OUT (Applicable to the UTn model only)
-
Page 8: Remote Control
Note See Connecting Cables for further information regarding cable connections. Remote Control Note The performance of the remote control may be affected by a TV or other electronic device operating near the LCD Display , causing a malfunction due to interference with the frequen- Using the Anti-Theft Kensington Lock Insert the locking device into the Ken- sington slot on the Monitor... - Page 9 POWER 3. Number Buttons 4. DEL button 5. + VOL - MUTE 7. TV/DTV 8. MENU INFO 11.COLOR BUTTONS TTX/MIX 13.STILL 14.AUTO 15. S.MODE RETURN Up-Down Left-Right buttons EXIT MagicInfo P.MODE DUAL/MTS SWAP Turns the product On. Turns the product Off. Press to change the channel.
- Page 10 16.MDC 17.LOCK SOURCE ENTER/PRE-CH 20. CH/P 21.D.MENU 22.GUIDE RETURN 24. Up-Down Left-Right but- tons EXIT 27.MagicInfo 28. P.MODE DUAL/MTS built-in high fidelity stereo amplifier. Then press the button again to circle through available preconfigured modes. ( Standard → Music → Movie → Speech → Custom ) MDC Quick Launch Button.
- Page 11 SWAP Where and How to assemble the bracket panel Unpacking Bracket Panel- Bracket Panel- MTS- You can select MTS (Multichannel Television Stereo) mode. Audio Type FM Stereo Mono Stereo Every time you press the button, a PIP screen appears. - This fuction does not work for this LCD Display. Swaps the contents of the PIP and main image.
- Page 12 Assembling the bracket panel Before mounting the set’s outer cover after installing a Video Wall or Samsung UD, remove the stickers attached to the connecting screw holes first. Note Do not remove the stickers if you are not going to assemble the bracket panel.
-
Page 13: Connecting A Computer
Connections Connecting a Computer Using a Power cord with Earth • In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. When un-wiring the earth lead, make sure to disconnect the AC power in advance. -
Page 14: Connecting To Other Devices
Note • Turn on both your computer and the LCD Display. • Contact a local SAMSUNG Electronics Service Center to buy optional items. Connecting to Other devices Using a Power cord with Earth • In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. -
Page 15: Connecting To A Camcorder
Select AV using the SOURCE . Note The LCD Display has AV connection terminals to connect AV input devices like DVDs, VCRs or Camcorders. You may enjoy AV signals as long as the LCD Display is turned on. Connecting to a Camcorder Locate the AV output jacks on the camcorder. -
Page 16: Connecting A Dtv Set Top Box
Connect a set of audio cables between the AV AUDIO IN [L-AUDIO-R] on the LCD Dis- play and the AUDIO OUT jacks on the DVD player. Connect a Component cable between the BNC/COMPONENT IN - P LCD Display and the P Note •... -
Page 17: Connecting To An Audio System
Connecting Using a HDMI Cable Note • Input devices such as digital DVD are connected to the HDMI terminal of the LCD Display using the HDMI cable. • You cannot connect a PC to the HDMI terminal. Connecting Using a DVI to HDMI Cable Note •... -
Page 18: Connecting A Usb Device
Connecting a LAN Cable Using a Power cord with Earth • In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. When un-wiring the earth lead, make sure to disconnect the AC power in advance. -
Page 19: Troubleshooting
Troubleshooting Self-Test Feature Check Note Check the following items yourself before calling for assistance. Contact a Service Center for problems that you cannot solve by yourself. Self-Test Feature Check Turn off both your computer and the LCD Display. Unplug the video cable from the back of the computer. Turn on the LCD Display. -
Page 20: Symptoms And Recommended Actions
• Do not use benzene, thinner or other flammable sub- stances, or a wet cloth. • We recommend that a SAMSUNG cleansing agent is used to prevent damage to the screen. • Never use acetone, benzene or thinner. (They may cause flaws or deformation of the screen surface.) -
Page 21: Problems Related To The Screen
Check if the signal cable between the computer and the LCD Display is securely con- nected. (Refer to Connecting a Computer) Shadowiness on the fringe of the panel due to technical limitations. The slight shadowiness on the fringe of the panel is due to the inside sheet that is seen through the thin outer bezel, which is not a defect but a technical limitation for the panel in the slim bezel design. -
Page 22: Problems Related To Audio
The image is too light or too dark. Adjusts the brightness and contrast. (Refer to the Brightness, Contrast) The screen color is inconsistent. Adjust color using Custom under OSD Color Adjustment menu. The color image is distorted by dark shadows. Adjust color using Custom under OSD Color Adjustment menu. -
Page 23: Problems Related To The Remote Control
Problems related to the Remote Control Note Problems related to the remote control and their solutions are listed. The remote control buttons do not respond. Check the polarities (+/-) of the batteries. Check if the batteries are empty. Check if the power is on. Check if the power cord is securely connected. - Page 24 Disconnect the power cord and then clean the LCD Display with a soft cloth, using either a cleaning solution or plain water. Do not leave any detergent or scratches on the case. Do not let any water enter the LCD Display. How can I play the video? The video supports the MPEG1 and WMV codecs only.
