Samsung SyncMaster 170T Owner's Instructions Manual
Dual interface(analog/digital) flat panel monitor
Hide thumbs
Also See for SyncMaster 170T:
- Owner's instructions manual (30 pages) ,
- Instrucciones de usuario (25 pages) ,
- Service manual (41 pages)
Related Manuals for Samsung SyncMaster 170T
Summary of Contents for Samsung SyncMaster 170T
- Page 1 SyncMaster 170T Dual Interface(Analog/Digital) Flat Panel Monitor Owner’s Instructions...
- Page 2 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Table of Contents Safety Instructions ..............2 Unpacking Your LCD Monitor . -
Page 4: Safety Instructions
Safety Instructions Before connecting the AC power cord to the DC adapter outlet, make sure the voltage designation of the DC adapter corresponds to the local electrical supply. Never insert anything metallic into the openings in the cabinet of the liquid cristal display (LCD) monitor;... -
Page 5: Unpacking Your Lcd Monitor
Unpacking Your LCD Monitor Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Colorific & Driver Warranty Card (not available everywhere) Manual AUTO EXIT AUTO EXIT MENU MENU 15-pin D-Sub Signal Cable Monitor and Base DC-Adapter Power Cord... -
Page 6: Setting Up Your Lcd Monitor
Setting up your LCD Monitor Setting up an Ergonomic Workstation Consider the advice given below before you install your monitor. Monitor location Choose a position that exposes you monitor to the least reflection from lights or windows, usually at a right angle to any window. Workstation height Place your LCD Monitor so that the top of the screen is slightly below your eye level when you are comfortably seated. -
Page 7: Connecting Your Lcd Monitor
Setting up your LCD Monitor Connecting Your LCD Monitor This monitor offers a method for connection to both a PC and a workstation. One or both types of signal cables can be connected to the monitor simultaneously. Determine which connection method(s) you need and refer to the instructions below. Figure 3. - Page 8 Setting up your LCD Monitor Figure 4. Cable connections (Digital) Turn off your computer and unplug its power cord. Connect the signal cable to the DVI-D connector (1) on the back of your monitor. Connect the other end of the cable to the video port on the back of your workstation. Connect the power cord for your monitor to the power port on the power adapter.
-
Page 9: Getting Help
Setting up your LCD Monitor Getting Help If your monitor does not display an image, check your cable connections and refer to “Troubleshooting” on page 17. If you experience difficulties with the quality of the displayed image, run auto adjustment again and refer to “Adjusting Your LCD Monitor” on page 10 or “Troubleshooting”... -
Page 10: Self-Test Feature Check (Stfc)
Setting up your LCD Monitor Self-Test Feature Check (STFC) Your monitor provides a self test feature that allows you to check whether your monitor is functioning properly. If your monitor and computer are properly connected but the monitor screen remains dark and the power indicator is blinking, run the monitor self-test by performing the following steps: Turn off both your computer and the monitor. -
Page 11: Adjusting Your Lcd Monitor
Adjusting Your LCD Monitor User Controls Your LCD Monitor allows you to easily adjust the characteristics of the image being displayed. All of these adjustments are made using the control buttons on the front of the monitor. While you use these buttons to adjust the controls, an on-screen menu shows you their numeric values as the change. -
Page 12: Automatic Save
Adjusting Your LCD Monitor Automatic Save Whenever you open the on-screen menu and allow an adjustment window to remain active for about 3 seconds without pressing another button, the monitor automatically saves any adjustments you have made. These changes are saved into a user area in the monitor. User areas are reserved according to the signal frequency from your computer. -
Page 13: Auto Adjustment
Adjusting Your LCD Monitor Auto Adjustment Auto Adjustment OSD Lock/Unlock Use this function to secure the current settings, while allowing you to adjust the Brightness and Contrast, so that they cannot be inadvertently changed. You can unlock the OSD controls at any time by using the same procedure. -
Page 14: On-Screen Menu System (Osd)
Adjusting Your LCD Monitor On-Screen Menu System (OSD) Function icons Function name Setting slidebar Numeric value indicator Figure 7. On-Screen Menu (OSD) Accessing the Menu System With the menu off, push the MENU button to open the menu system and display the main function menu. - Page 15 Adjusting Your LCD Monitor Table 1. Menu Adjustments Settings and Icon Sub-menus Image Lock: Fine Coarse Position: Horizontal Vertical Color Control: R(ed) G(reen) B(lue) Description Image Lock controls adjust for and limit the amount of noise in the video signal which causes horizontal lines or areas on the screen where the image appears to be unstable and jitters or shimmers.
- Page 16 Adjusting Your LCD Monitor Table 1. Menu Adjustments ( Continued ) Settings and Icon Sub-menus Reset: Geometry Color Language: English Deutsch Español Français Italiano Svenska Menu Display Time: 5 Seconds 10 Seconds 20 Seconds 200 Seconds Menu Position: Horizontal Vertical English Description Reset controls return the settings to the factory preset...
- Page 17 Adjusting Your LCD Monitor Table 1. Menu Adjustments ( Continued ) Settings and Icon Sub-menus Image Size: Normal Expanded 1 Expanded 2 Image Effect: Scaling Filtering Description If your computer or video board supplies a signal rate and addressability lower than 1280 x 1024, this LCD Monitor provides a scaling processor that can expand the addressability up to 1280 x 1024.
-
Page 18: Appendix
PowerSaver This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor into a low-power mode when it has not been used for a certain amount of time. The available modes are “On”, “Standby”, “Sleep”, and “Deep Sleep”. -
Page 19: Troubleshooting
Troubleshooting Before calling for service, check the information in this section to see if you can remedy any problems yourself Table 3. Troubleshooting problems Symptom No Picture “No Connection, Check Signal Cable” appears “Video mode not supported” Picture is scrambled Picture is not clear Picture is fuzzy Picture bounces or has wavy... - Page 20 The LCD Monitor is saving your changes to the OSD. The LCD Monitor is using its power management system. Check the power management utility on your computer. Please contact Samsung customer service. You can download the driver from the internet at http://www.samsungelectronics.com/support/ downloads/monitor/index.html...
-
Page 21: Specifications
Specifications Table 4. Specifications LCD Monitor Panel 43 cm (17") LCD Monitor 0.264 mm Pixel pitch Viewing Angle: 80/80/80/80 (U/D/L/R) (Degrees) Horizontal: 30 kHz to 81 kHz Synchronization Vertical: 56 Hz to 85 Hz (~XGA) Display Colors 16.7 Million Colors Maximum Resolution Horizontal: Vertical:... -
Page 22: Pin Assignments
Pin Assignments Table 5. 15-Pin D-SUB connector 15-Pin Side of the Pin No. Signal Cable GND (DDC Return) Table 6. DVI-D Connector Signal Assignent T.M.D.S. Data2- T.M.D.S. Data2+ T.M.D.S. Data2 Shield No Connect No Connect DDC Clock DDC Data No Connect T.M.D.S. -
Page 23: Display Modes
Display Modes For the display modes listed below, the screen image has been optimized during manufacture. Table 7. Preset timing modes Horizontal Frequency Display Mode (kHz) 720 x 400 31.469 640 x 480 31.469 640 x 480 37.500 640 x 480 43.269 800 x 600 46.875... -
Page 24: Changing The Stand
Changing the Stand Removing the Stand Turn off your monitor and unplug its power cord. Lay the LCD Monitor face-down on a flat surface with a cushion beneath it to protect the screen. Remove the 4 screws (a) and then remove the Stand from the LCD Monitor. English Appendix... -
Page 25: Attaching An Arm-Type Stand Or Wall Mount Hanger
Attaching an Arm-Type Stand or Wall Mount Hanger NOTE: This monitor accepts a 100mm x 100mm VESA-compliant mounting interface pad . Align the Mounting Interface Pad with the holes in the Rear Cover and secure it with the four screws that came with the Arm-type Stand or Wall Mount Hanger. Maintenance of Your LCD Monitor WARNING: To avoid risk of electric shock, do not disassemble the monitor cabinet (except for gaining access to the cable connectors as described on page 6). -
Page 26: Regulatory Information
The party responsible for product compliance: SAMSUNG ELECTRONICS CO., LTD America QA Lab of Samsung 85 West Tasman Drive San Jose, CA 95134 USA Tel) 408-544-5124 Fax) 408-544-5191 Provided with this monitor is a detachable power supply cord with IEC320 style terminations. - Page 27 Saturno 44 Col. Nva. Industrial Vallejo Del. Gustavo A. Madero C.P. 07700 Mexico D.F. Tel. 5747-5100 RFC: SEM950215S98 IMPORTADO POR:SAMSUNG ELECTRONICS MEXICO S.A. DE C.V. SATURNO 44 COL. NVA. INDUSTRIAL VALLEJO DEL. GUSTAVO A. MADERO C.P. 07700 MEXICO D.F. TEL. 5747-5100 RFC: SEM950215S98 EXPORTADO POR: SAMSUNG ELECTRONICS CO.,LTD.
