Samsung SyncMaster 150T Owner's Instructions Manual
Dual interface(analog/digital) flat panel monitor
Hide thumbs
Also See for SyncMaster 150T:
- Instrucciones de usuario (32 pages) ,
- Service manual (41 pages)
Related Manuals for Samsung SyncMaster 150T
Summary of Contents for Samsung SyncMaster 150T
- Page 1 SyncMaster 150T Dual Interface(Analog/Digital) Flat Panel Monitor Owner’s Instructions...
- Page 2 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Table of Contents Safety Instructions ..............2 Unpacking Your Monitor . -
Page 4: Safety Instructions
Safety Instructions Before connecting the AC power cord to the DC adapter outlet, make sure the voltage designation of the DC adapter corresponds to the local electrical supply. Never insert anything metallic into the openings in the cabinet of the flat panel display (FPD) monitor;... -
Page 5: Unpacking Your Monitor
Unpacking Your Monitor Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Colorific Pivot software & Driver (optional) Warranty Card (not available everywhere) Manual DC Adapter (Optional) Your monitor may come equipped with one of five different stands, or none at all, according †... -
Page 6: Setting Up Your Monitor
Setting up Your Monitor Setting up an Ergonomic Workstation Consider the advice given below before you install your monitor. Monitor location Choose a position that exposes you monitor to the least reflection from lights or windows, usually at a right angle to any window. Workstation height Place your flat panel display (FPD) monitor so that the top of the screen is slightly below your eye level when you are comfortably seated. -
Page 7: Connecting Your Fpd Monitor
Setting up Your Monitor Connecting Your FPD Monitor Figure 3.1 Cable connections (Analog) Turn off your computer and unplug its power cord. Connect the signal cable to the 15-pin, D-sub connector on the back of your monitor. Connect the signal cable to the video port on your computer, video board, video card, or graphics card. - Page 8 Setting up Your Monitor Figure 3.2 Cable connections (Digital) Turn off your computer and unplug its power cord. Connect the signal cable to the DVI-D connector (1) on the back of your monitor. Connect the other end of the cable to the video port on the back of your workstation. Connect the power cord for your monitor to the power port on the power adapter.
-
Page 9: Connecting Your Multimedia Fpd Monitor
Setting up Your Monitor Connecting Your Multimedia FPD Monitor AUDIO E F G Figure 4. Multimedia connections Follow steps 1 through 3 on the previous page. If you have a Multimedia or Multimedia Pivot stand, connect the attached power adapter jack (A) to the DC power port on the back of your monitor. Connect the power cord to the power port on the back of the stand. -
Page 10: Plug And Play
Setting up Your Monitor Table 1. Connector locations for multimedia bases ( Continued ) Item Name Description External microphone jack Headphone jack Plug and Play ® Our adoption of the new VESA Plug and Play solution eliminates complicated and time consuming setup. -
Page 11: Windows 95
Setting up Your Monitor ® Windows To determine the version of Windows Computer” icon on the Windows desktop and select “Properties”. The version number can be seen on the “General” section under “System:”. Follow the directions given below according ® to the version of your Windows 95 operating system: Version 4.00.950A... -
Page 12: Getting Help
Setting up Your Monitor If the monitor is functioning properly, you will see a white box with a red border and black text inside as shown in the following illustration: No Connection C h e c k S i g n a l C a b l e Figure 5. -
Page 13: Adjusting Your Fpd
Adjusting Your FPD User Controls Y our flat panel display allows you to easily adjust the characteristics of the image being displayed. All of these adjustments are made using the control buttons on the front of the monitor. While you use these buttons to adjust the controls, an on-screen menu shows you their numeric values as they change. -
Page 14: Automatic Save
Adjusting Your FPD Automatic Save Whenever you open the on-screen menu and allow an adjustment window to remain active for about 3 seconds without pressing another button, the monitor automatically saves any adjustments you have made. These changes are saved into a user area in the monitor. User areas are reserved according to the signal frequency from your computer. -
Page 15: Brightness
Adjusting Your FPD Brightness Brightness Exit : Exit Key OSM Lock/Unlock Use this function to secure the current settings so that they cannot inadvertently be changed, while still allowing you to adjust Brightness and Contrast. You can unlock the OSM controls at any time by using the same procedure as described below. -
Page 16: Accessing The Menu System
Adjusting Your FPD Accessing the menu system With the OSM off, push the MENU button to open it and display the main function menu. Use the “ ” and “ ” buttons to move between the function icons. As you move from –... - Page 17 Adjusting Your FPD Table 2. Screen controls ( Continued ) Menus and Icon Sub-menus Image Lock: Fine Coarse A.O. H-Position A.O. V-Position A.O. Function Descriptions – Image Lock controls adjust for and limit the amount of noise in the video signal which causes horizontal lines or areas on the screen where the image appears to be unstable and jitters or shimmers.
- Page 18 Adjusting Your FPD Table 2. Screen controls ( Continued ) Menus and Icon Sub-menus Reset Geometry Reset Color Reset A.O. Color Temperature Mode 1 Mode 2 Mode 3 A.O. Color Control R(ed) G(reen) B(lue) A.O. Function Descriptions – Restores the viewing area and color settings to their original manufacturing levels Resets the H-Position and V-Position of the viewing area...
- Page 19 Adjusting Your FPD Table 2. Screen controls ( Continued ) Menus and Icon Sub-menus Language: English Deutsch Español Français Italiano Svenka Miscellaneous Menu Position H-Position • V-Position • Menu Display Time: 5 Seconds 10 Seconds 20 Seconds 200 Seconds Function Descriptions –...
- Page 20 Adjusting Your FPD Table 2. Screen controls ( Continued ) Menus and Icon Sub-menus Display Mode Function Descriptions – This screen shows the horizontal and vertical frequencies, sync polarity and the display resolution of the images received from the computer or video card.
-
Page 21: Audio Controls
Adjusting Your FPD Audio Controls ON/OFF VOLUME MIN MAX Figure 8. Multimedia stand audio controls To access the On/Off, Volume, Bass and Treble functions, rotate the appropriate control button to the right or left to adjust the function. Table 3. Audio Control Function Function Internal Picks up sound and sends it to the sound card in your PC... -
Page 22: Appendix
Appendix PowerSaver This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor into a low-power mode when it has not been used for a certain amount of time. The available modes are “On”, “Standby”, “Sleep”, and “Deep Sleep”. -
Page 23: Troubleshooting
Appendix Troubleshooting If you have a problem setting up or using your FPD monitor, you may be able to solve it yourself. Before contacting customer service, try the suggested actions that are appropriate to your problem. Table 5. Troubleshooting problems – Image What you see... - Page 24 Appendix Table 5. Troubleshooting problems – Image ( Continued ) What you see... Screen is blank and The monitor is using its power power indicator light is management system. steady amber or blinks Move the computer’s mouse or every 0.5 or 1 seconds press a key on the keyboard Image is not stable and Check that the display resolution...
- Page 25 Appendix Table 6. Troubleshooting problems – Audio Problem Suggested Action No sound Ensure that the audio cable is firmly connected to both the audio-in port on your monitor and to the audio–out port on your sound card or computer. Rotate the Audio On/Off and Volume control to the right to turn it on and raise the volume.
- Page 26 Appendix Table 6. Troubleshooting problems – Audio Problem Suggested Action Microphone is Check the microphone cable not working connection. Your sound card must be compatible with an internal, embedded microphone. If it is not, use the microphone that came with your computer or sound card.
-
Page 27: Specifications
Appendix Specifications Table 7. Technical and environmental specifications Panel Size Display Size Type Pixel pitch Viewing Angle Frequency Horizontal Vertical Display color Display Optimum Mode Resolution Maximum Mode Input Signal Sync Video signal Power Supply Power Normal Consumption Power Saving Dimensions / Unit (WxHxD) with: Unit Weight /... -
Page 28: Pin Assignments
Appendix Table 7. Technical and environmental specifications Audio Built-in Mic. Characteristics Audio Input (Available with Sound Output Multimedia Frequency Response bases only) Headphone Pin Assignments Table 8.1 15 pin D-sub connector Separate H/V Green Blue GND (DDC Return) GND-Red GND-Green GND-Blue No Connection GND-Sync/Self Test... - Page 29 Appendix Table 8.2 DVI-D Connector Signal Assignent T.M.D.S. Data2- T.M.D.S. Data2+ T.M.D.S. Data2 Shield No Connect No Connect DDC Clock DDC Data No Connect T.M.D.S. Data1- T.M.D.S. Data1+ T.M.D.S. Data1 Shield No Connect Signal Assignen No Connect +5V Power Ground(for +5V) Hot Plug Detect T.M.D.S.
-
Page 30: Display Modes
Appendix Display Modes For the display modes listed below, the screen image has been optimized during manufacture. Table 9.1 Preset timing modes (Analog) Horizontal Frequency Display Mode (kHz) VGA, 640 x 350 31.47 VGA, 720 x 400 31.47 VGA, 640 x 480 31.47 VGA, 640 x 480 37.50... -
Page 31: Changing The Base
Appendix Changing the Base Removing the base Turn off your monitor and unplug its power cord. Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the screen. Remove the four screws and then remove the Stand from the LCD monitor. -
Page 32: Attaching A Base
Appendix Attaching a base NOTE: This monitor accepts a 75mm x 75mm VESA-compliant mounting interface pad . Align the Mounting Interface Pad with the holes in the Rear Cover Mounting Pad and secure it with the four screws that came with the arm-type base, wall mount hanger or other base. -
Page 33: Regulatory Information
The party responsible for product compliance: SAMSUNG ELECTRONICS CO., LTD America QA Lab of Samsung 85 West Tasman Drive San Jose, CA 95134 USA Tel) 408-544-5124 Fax) 408-544-5191 Provided with this monitor is a detachable power supply cord with IEC320 style terminations. - Page 34 50 and 61 Streets Sta, Cecilia Bdl. Don Camilo, Panama City Tel.: (507) 264-0195 or 269-5571 Fax: (507) 269-5568 MEXICO: Samsung Electronics Mexico S.A. de C.V. Saturno 44 Col. Nva. Industrial Vallejo Del. Gustavo A. madero C.P. 07700 Mexico D.F. Tel. 5747-5100 RFC: SEM950215S98 ESPAÑA:...
