  • Page 1 SyncMaster 770P / 970P...
  • Page 2 Notational Failure to follow directions noted by this symbol could result in bodily harm or damage to equipment. Prohibited Do not disassemble Do not touch Power When not used for extended period of time, set your computer to DPMS. If using a screen saver, set it to the active screen mode. Important to read and understand at all times Disconnect the plug from the outlet Grounding to prevent an electric shock...
  • Page 3 Do not use a damaged or loose plug. This may cause an electric shock or fire. Do not pull the plug out by the wire nor touch the plug with wet hands. This may cause an electric shock or fire. Use only a properly grounded plug and receptacle.
  • Page 4 Do not drop the monitor when moving it. This may cause damage to the product or human body. Install the monitor base in a showcase or shelf so that the end of the base does not protrude from the showcase or shelf. Dropping the product may cause damage to the product or personal injury.
  • Page 5 Do not place the monitor face down. The TFT-LCD surface may be damaged. Installing a wall bracket must be done by a qualified professional. Installation by unqualified personnel may result in injury. Always use the mounting device specified in the owner's manual. When installing the product, make sure to keep it away from the wall (more than 10 cm/4 inch ) for ventilation purposes.
  • Page 6 Unplug the power cord from the power outlet and wipe the product using a soft, dry cloth. Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air freshener, lubricant or detergent. Contact the once a year. Keep the product's interior clean. Dust which has accumulated in the interior over an extended period of time may cause malfunction or fire.
  • Page 7 Do not try to move the monitor by pulling only the wire or the signal cable. This may cause a breakdown, electric shock or fire due to damage to the cable. Do not move the monitor right or left by pulling only the wire or the signal cable.
  • Page 8 Adjust the resolution and frequency to the levels appropriate for the model. Inappropriate resolution may cause undesirable picture quality. 17 inch (43 cm), 19 inch (48 cm) - 1280 X 1024 Be careful that adapter should not be in contact with water and therefore not be wet.
  • Page 9 Do not install the product on an unstable, uneven surface or a location prone to vibrations. Dropping the product may cause damage to the product or personal injury. Using the product in a location prone to vibrations may shorten the lifetime of the product or may catch fire. When moving the monitor, turn off and unplug the power cord.
  • Page 10 List of Features Implements deeper colors in contrast rates of 1500:1 for Magic Contrast 770P and 1000:1 for 970P . Provides a sharp image without causing an afterimage at a fast Magic speed of 6ms. Allows you to adjust the height up to 170mm for the Magic Stand 770P and 134mm for the 970P .
  • Page 11 Quick Setup Guide Cable 'DVI-A to D-SUB' Cable Sold separately DVI Cable Front Power indicator / The blue light is on in its normal working condition and blinks when setting the adjustments of the monitor. Power button [ User's Guide, Warranty Card Monitor Driver, (Not available in all...
  • Page 12 Use this button for power the monitor on and off, change the input source, or perform Auto Adjustment. Power On/Off : When you press the power button, the monitor is on/off. >>Click here to see an animation clip Input Source : When you press the power button, the input source may be changed to Analog or Digital, blinking once with blue lihgt.
  • Page 13 Connecting the Monitor Connect the DC 14V adapter for the monitor to the power port on the Signal Box . Plug the power cord for the monitor into a nearby outlet. Using the D-Sub (analog) connector on the video card. 2-1.
  • Page 14 Using the Stand Pivot Stand (When pivoting the monitor, rotation angle is displayed on screen of the monitor.) 0° 90° 180° When pivoting the monitor, the corner of the monitor may reach to the floor. Tilt the monitor backward more than 45 degrees and then pivot it. Failure to do so may damage the monitor.
  • Page 15 Follow the directions appropriate for the operating system you have. Prepare a blank disk and download the driver program file at the Internet web site shown here. Internet web site : http://www.samsung.com/ http://www.samsung.com/monitor http://www.sec.co.kr/monitor http://www.samsungmonitor.com.cn/ Windows ME 1.

  • Page 16: Microsoft ® Windows ® Xp Operating System

    Then click "OK" button. This monitor driver is under certified MS logo,and this installation doesn't damage your system.The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/. 5. Monitor driver installation is completed. Installing the Monitor Driver (Manual) When prompted by the operating system for the monitor driver, insert the CD-ROM included with this monitor.
  • Page 17 4. Click the "Properties" button on the "Monitor" tab and select "Driver" tab. 5. Click "Update Driver.." and select "Install from a list or.." then click "Next" button. 6. Select "Don't search ,I will.." then click "Next" and then click "Have disk". 7.

  • Page 18: Microsoft ® Windows ® 2000 Operating System

    8. If you can see following message window, then click the "Continue Anyway" button. Then click "OK" button. This monitor driver is under certified MS logo,and this installation doesn't damage your system.The certified driver will be posted on Samsung Monitor homepage. http://www.samsung.com/ 9. Click the "Close" button then click "OK" button continually.
  • Page 19 1. Click "Start" , "Setting" , "Control Panel". 2. Double click the "Display" Icon. 3. Choose the "Settings" tab and then click "Advanced..". 4. Choose "Monitor". Case1: If the "Properties" button is inactive, it means your monitor is properly configured. Please stop installation Case2: If the "Properties"...
  • Page 20 Samsung Electronics in association with Korea Electronics & Telecommunications Research Institute (ETRI). This system is available only for Samsung monitors and makes the color of the images on the monitor the same as the printed or scanned images.

  • Page 21: Installation

    Installation 1. Insert the installation CD into the CD-ROM drive. 2. Click the AutoRotation installation file. 3. Select installation Language, Click "Next". 4. When the Installation Shield Wizard window appears, click "Next."...
  • Page 22 5. Select "I agree to the terms of the license agreement" to accept the terms of use. 6. Choose a folder to install the AutoRotation program. 7. Click "Install."...
  • Page 23 8. The "Installation Status" window appears. 9. Click "Finish." 10. When the installation is complete, the MagicRotation, MagicTune™ executable icon appears on your desktop.
  • Page 24 Double-click the icon to start the program. MagicTune™ execution icon may not appear depending on specification of computer system or monitor. If that happens, press F5 Key. Installation Problems (MagicTune™) The installation of MagicTune™ can be affected by such factors as the video card, motherboard and the network environment.
  • Page 25 e.g. 3D games 4. DOS based applications in Full Screen Mode will not function as per the orientation mode selected (90, 180, 270). 5. Dual is not supported in Windows™ 98, ME, NT 4.0. 6. MagicRotation does not provide support for 24 bits per pixel (Bit depth/Color Quality). 7.
  • Page 26 OSD Mode Overview Overview What is MagicTune™? Monitor performance can vary due to the graphics card, host computer lighting conditions and other environmental factors. In order to get the best image on a monitor requires you to adjust it for your unique setting. Unfortunately, the manual controls available to tune the image often prove to be challenging.

  • Page 27: Osd Mode

    When Pivot is functioning, part of MagicTune™ Program may not operate normally. AutoRotation : AutoRotation will automatically pivots the monitor to 0, 90, 180degrees when you pivots the monitor. To execute Rotation, it should be done as below. Please install both of Rotation program and MagicTune™ 3.6 in your PC. Launch MagicTune™...
  • Page 28 - including web images and ones produced by a digital camera or scanner. MagicColor is a new technology that Samsung has exclusively developed to improve digital image and to display natural color more clearly without disturbing image quality.
  • Page 29 3. Full : Displays not only vivid natural color but also more realistic natural skin color with clearness. 4. Intelligent : Displays vivid natural color with clearness. 5. MagicZone The MagicZone ensures the clear and sharp display of animated multimedia or photo images by enhancing the brightness, sharpness, saturation, Hue of a certain area on the screen.
  • Page 30 Fine : Removes noise such as horizontal stripes. If the noise persists even after Fine tuning, repeat it after adjusting the frequency (clock speed). Coarse : Removes noise such as vertical stripes. Image Setup Coarse adjustment may move the screen image area. You may relocate it to the center using the Horizontal Control menu.

  • Page 31: Color Calibration

    Server IP Department Location Version Displays the version of MagicTune™. Overview OSD Mode Color Calibration Color Calibration Color Calibration guides you to get optimal color condition for your monitor. Proceed following 5steps for getting optimal monitor color condition . 1. Control "Brightness control bar" for matching the brightness of control patch and the brightness of background pattern 2.

  • Page 32: Troubleshooting

    Products from other manufacturers may cause errors. Only Samsung products are able to support this feature. An error may occur even when your monitor is manufactured by Samsung but is out of date. Check if your monitor is able to support MagicTune™.
  • Page 33 As the Highlight program uses the communication lines, please exit the Highlight program before you can access MagicTune™. Some of Samsung CDT monitors support the Highlight feature. When using both the Highlight feature and MagicTune™ simultaneously, conflicts occur, which cause errors.
  • Page 34 Some graphic cards may not support your monitor. When you have a problem with the graphic card, visit our website to check the compatible graphic card list provided. http://www.samsung.com/monitor/magicTune Download the latest program. The program can be downloaded http://www.samsung.com/monitor/magicTune for technical support for MagicTune™, FAQs (questions and...
  • Page 35 This greatly improves the user's productivity allowing him the flexibility to switch between landscape and portrait modes. The MagicRotation Software from Samsung Electronics, Inc. provides the user with a rotation feature (0, 90, 180, 270 orientation) that facilitates the optimum utilization of computer display screen, better viewing and improved user productivity.
  • Page 36 Rotate : Display will get rotated by the unit of 90 degree Rotate to 0 : Display will get rotated to 0 degree from the current angle of rotation. Rotate to 90 : Display will get rotated to 90 degree from the current angle of rotation.
  • Page 37 Rotate to 180 : Display will get rotated to 180 degree from the current angle of rotation. Rotate to 270 : Display will get rotated to 270 degree from the current angle of rotation.
  • Page 38 Hot key : Hot Keys are available by default and can be changed by user. It can be assigned by user directly with keyboard after changing the existing HotKey. User can create the hot key with the combination of Shift, Ctrl, Alt and general keys. In case only general key is pressed, it will be assigned in the form of Alt+general key.
  • Page 39 2. Check if the problem occurs with different color depths (8/16/32 bits per pixel) and different resolution modes (800 x 600, 1024 x 768). 3. Check if the problem occurs without installing MagicRotation Software. If the problem is repeating in any/all of the following scenarios then it may be the problem with your installed "Display Driver"...

  • Page 40: Check List

    Check List Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call Information section or contact your Symptom Check List No images on the Is the power cord screen.
  • Page 41 Some graphic cards may not support your monitor. When you have a problem with the graphic card, visit our website to check the compatible graphic card list provided. http://www.samsung.com/monitor/magictune Download the latest program. The program can be downloaded Driver...

  • Page 42: Check The Following Items If There Is Trouble With The Monitor

    2. Unplug the video cable from the back of the computer. 3. Turn on the monitor. If the monitor is functioning properly, you will see a box in the illustration below. http://www.samsung.com/monitor/magictune. contact an authorized service Answer Frequency can be changed by reconfiguring the video card.
  • Page 43 This box appears during normal operation if the video cable becomes disconnected or damaged. 4. Turn off your monitor and reconnect the video cable; then turn on both your computer and the monitor. If your monitor screen remains blank after using the previous procedure, check your video controller and computer system;...
  • Page 44 General General Model Name SyncMaster 770P LCD Panel Size 17" Diagonal (43 cm) Display area 337.92mm (H) x 270.336mm (V) Pixel Pitch 0.264mm (H) x 0.264mm (V) Type a-si TFT active matrix Synchronization Horizontal 30 ~ 81 kHz (Analog/Digital) Vertical 56 ~ 75 Hz (Analog/Digital) Display Color 16.7 M Colors...

  • Page 45: Environmental Considerations

    ENERGY STAR Preset Timing Modes Power saving mode EPA/ENERGY 2000 Blue Black Less than 1 W (Off-mode) ® ® Partner, SAMSUNG has determined that this ® guidelines for energy efficiency. Power off Black Less than 1 W compliant and ENERGY2000...

  • Page 46: Vertical Frequency

    If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically (Exception : 640 x 480/60 Hz, 720 x 400/70Hz, 800 x 600/60 Hz) However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows.
  • Page 47 General General Model Name SyncMaster 970P LCD Panel Size 19" Diagonal (48 cm) Display area 376.32 mm (H) x 301.056 mm (V) Pixel Pitch 0.294 mm (H) x 0.294 mm (V) Type a-si TFT active matrix Synchronization Horizontal 30 ~ 81 kHz (Analog/Digital) Vertical 56 ~ 75 Hz (Analog/Digital) Display Color...
  • Page 48 ENERGY STAR Preset Timing Modes Power saving mode EPA/ENERGY 2000 Blue Black Less than 1 W (Off-mode) ® ® Partner, SAMSUNG has determined that this ® guidelines for energy efficiency. Power off Black Less than 1 W compliant and ENERGY2000...
  • Page 49 If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically (Exception : 640 x 480/60 Hz, 720 x 400/70Hz, 800 x 600/60 Hz) However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows.
  • Page 50 Contact SAMSUNG WORLD-WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. CANADA 1-800-SAMSUNG (7267864) MEXICO 01-800-SAMSUNG (7267864) U.S.A 1-800-SAMSUNG (7267864) ARGENTINE 0800-333-3733 BRAZIL 0800-124-421 CHILE 800-726-7864 (SAMSUNG) COSTA RICA 0-800-507-7267...
  • Page 51 JAPAN 0120-327-527 MALAYSIA 1800-88-9999 PHILIPPINES 1800-10-SAMSUNG (7267864) SINGAPORE 1800-SAMSUNG (7267864) THAILAND 1800-29-3232, 02-689-3232 TAIWAN 0800-329-999 VIETNAM 1 800 588 889 SOUTH AFRICA 0860 7267864 (SAMSUNG) U.A.E 800SAMSUNG (7267864) http://www.samsung.com/cz http://www.samsung.com/dk http://www.samsung.com/fi http://www.samsung.com/fr http://www.samsung.de http://www.samsung.com/hu http://www.samsung.com/it http://www.samsung.lu http://www.samsung.com/nl http://www.samsung.com/no http://www.samsung.com/pl http://www.samsung.com/pt http://www.samsung.com/sk...
  • Page 52 Terms Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution. The distance between two dots of the same color is called the 'Dot Pitch'. Unit: mm Vertical Frequency The screen must be redrawn several times per second in order to create and display an image for the user.
  • Page 53 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 54: Product Information (Image Retention Free)

    PRODUCT INFORMATION (Image Retention Free) LCD Monitors and TVs may have image retention when switching from one image to another especially after displaying a stationary image for a long time. This guide is to demonstrate correct usage of LCD products in order to protect them from Image retention.
  • Page 55 The best way to protect your monitor from Image retention is to set your PC or System to operate a Screen Saver program when you are not using it. Image retention may not occur when a LCD panel is operated under normal conditions. Normal conditions are defined as continuously changing video patterns.

  • Page 56: Correct Disposal Of This Product (Waste Electrical & Electronic Equipment) - Europe Only

    Correct Disposal of This Product (Waste Electrical & Electronic Equipment) - Europe only (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
