SGH-B110
User's Guide
Some of the contents in this guide may differ from your phone depending on
the software of the phone or your service provider.
Printed in Korea
World Wide Web Code No.:GH68-17912A
English (SEA). 02/2008. Rev. 1.0
http://www.samsungmobile.com
Press and hold in Idle mode to disable all sounds on the
Silent
phone. To exit, press and hold this key again.
mode
Keypad Press and hold in Idle mode and then press the Yes
lock mode to lock the keypad and ignore accidental key pressing. To
unlock, press the Unlock soft key and then .
Press C four times in Idle mode with the keypad locked to send
SOS
an SOS message to preset phone numbers. Once the SOS
mode
message is sent, the phone will change to SOS mode and will
receive calls only from the registered recipients. Upon
receiving a call from the SOS message recipients, the phone
will automatically answer the call. Press to exit SOS mode.
Display
Your phone is in Idle mode when you are not on a call or using a menu.
You must be in Idle mode to dial a phone number.
Icons
Text and graphics
Soft key function
Msg. Contacts
indicators
Using the menus
In Idle mode, press to enter the main menu.
Labels at the bottom corners of the display show the
current soft key functions. Press the left soft key or
right soft key to perform the function indicated.
To return to the To exit the menu
previous menu without changing
the menu settings,
level, press the
Back soft key press this key.
C
or .
Use the 4-way navigation keys to scroll up, down,
left, or right through the menu system, highlight
menu items, and change feature settings.
Installing the SIM card and battery
1.Remove the battery cover and insert the SIM card.
Battery cover
2.Install the battery and reattach the cover.
Battery
Your phone displays the following status indicators on the top of the
screen:
Icon Description
soft key
Signal strength
Call in progress
Out of your service area; you cannot make or receive calls
except for emergency calls
SOS message feature active
GPRS network
Alarm set
Silent mode (Vibration)
Silent mode (Mute)
Ringer type
• None: Melody
• : Vibration
• : Vibration then melody
Home Zone, if registered for the appropriate service
Call diverting feature active
New text message
New voicemail message
Battery power level
To select or modify a menu or feature:
1. In Idle mode, press .
2. Press the Navigation keys to reach a desired menu and then press
the Select soft key or .
3. If the menu contains any submenus, locate the one you want by
pressing the Navigation keys. Press the Select
enter the submenu.
If the selected menu contains additional submenus, repeat this step.
4. Press the Navigation keys to find the setting of your choice.
5. Press the Select soft key or to confirm your chosen setting.
Shortcut numbers
You can quickly access the menu you want by using shortcut numbers.
The shortcut number displays in front of the menu name in Menu mode.

Charging the battery

1.Plug the supplied travel adapter.
With the triangle facing up
Note: When you plug in the travel adapter, the charging indicator may not
appear for up to 5 minutes, but the battery is charging properly.
2.When charging is finished, unplug the adapter.
Note: Do not remove the battery from the phone without unplugging the
adapter first. Otherwise, the phone may be damaged.
Switching on or off the phone
1. Press and hold for more than one second to switch on the phone.
2. If the time & date message appears, press the
the time and date by following the onscreen instructions.
3. Press and hold for more than two seconds to switch off the phone.
Changing the display language
1. In Idle mode, press .
2. Select Phone settings → Language.
3. Select a language.
Making a call
1. In Idle mode, enter an area code and phone number, and press
2. Press to end the call.
Answering a call
1. When the phone rings, press the
call.
Press to reject the call.
2. Press to end the call.
Menu map
1. Call log 4. Alarm
1.1 Missed calls
5. Messages
1.2 Received calls
1.3 Dialled calls
5.1 Text messages
1.4 Delete all
5.2 Preset messages
1.5 Call time
5.3 Voice mail
1.6 Call costs*
5.4 Broadcast
5.5 Settings
soft key or to
2. Phonebook 5.6 SOS messages
5.7 Memory status
2.1 Find name
2.2 FDN list
6. My files
2.3 Add entry
2.4 Speed-dial list
6.1 Images
2.5 Own number
6.2 Sounds
2.6 Management
6.3 Delete all
2.7 Search by initials
6.4 Memory status
3. Applications
7. Network services
3.1 Clock
7.1 Call diverting
3.2 Calculator
7.2 Call barring
3.3 Converter
7.3 Call waiting
3.4 SIM-AT*
7.4 Network selection
7.5 Caller ID
Phone layout and key functions
Menu access/
Confirm key
In Idle mode, accesses
Menu mode. In Menu
mode, selects the
highlighted option or
confirms input.
Soft keys
Perform functions
indicated by the text
above the key.
Dial key
Makes and answers a
call. In Idle mode,
retrieves the most
recent calls.
Voicemail server key
In Idle mode, accesses
your voicemail server
when held down.
Keypad lock key
Keypad lock mode
Alphanumeric keys

Adjusting the volume

1. In Idle mode, press
Yes soft key and set
2. Select Sound settings
3. Press the Navigation keys to adjust the volume level.
4. Press the Save
While a call is in progress, press
volume.
Changing a ringtone for calls
1. In Idle mode, press
2. Select Sound settings
.
Sounds.
3. Select a ringtone and press the
Redialling recent numbers
Accept soft key or to answer a
1. In Idle mode, press
2. Press Up or Down
3. Press to dial the number.

Entering text

Changing the text input mode
8. Sound settings
In a text input field, press the right soft key until the input mode indicator
8.1 Incoming calls
you want appears.
8.2 Messages
8.3 Power on/off
8.4 Connection tone T9 mode
8.5 Keypad tone
8.6 Minute minder
1. Press 2 to 9 to start entering a word. Press each key once for one
8.7 Silent mode
letter.
8.8 Alerts on call
The word you are entering appears on the display. It may change with
9. Phone settings each keypress. Finish entering the word before editing or deleting any
keystrokes.
9.1 Display
9.2 Greeting message
Example: To enter "Hello" in T9 mode, press 4, 3, 5, 5, and 6.
9.3 Language
9.4 Security
2. Press to insert a space and enter the next word.
9.5 Auto redial
9.6 Anykey answer
ABC mode
9.7 Auto answer
9.8 Auto keypad lock
Press the keys labelled with the letter you want once for the first letter,
9.9 Reset settings
twice for the second letter, and so on.
* Shows only if supported by
For example, press
your SIM card.
"K".
4-way navigation keys
In Idle mode, access the
following menus or
functions directly.
Up/Down: Key volume
Left: Create
Right: Alarm
In Menu mode, scroll
through menu options.
Power/End key
Turns the phone on or
off when held down.
Also ends a call.
Cancel/Clear key
Deletes characters from
the display. Returns the
display to the previous
menu level.
Sends SOS messages
when pressed four times.
SOS mode
Silent mode key
Silent mode
.
→ Incoming calls → Ring volume.
soft key.
Up or Down to adjust the earpiece
.
→ Incoming calls → Default ringtones or
Yes soft key.
.
to scroll to the number you want.
2 three times to enter "C" and 5 two times to enter
