Linutop 3 Quick User Manual

Quick user guide
Small low maintenance PC
Linutop Setup Menu:
Linutop configuration menu will help you to set up linutop software.
You can select the language, keyboard layout and time zone, Screen
size and auto started applications.
Linutop can be configured to start automatically after reboot:
Multimedia files: audio, video or play list, slideshows, Linutop Kiosk or
any added software.
Linutop Kiosk has a separated configuration menu.
At each start you can have your linutop:
- Display a Web page,
- Display a presentation,
- Play music or Video stream or file
Or you can start automatically a specific application.
Once validated all changes will take effect at the next reboot
You can access the menu in:
Applications > Settings > Linutop Setup
Linutop3_quick_user_guide_April2010.docThe
3
information contained herein is subject to change without notice.
Linutop connectors:
Specifications:
Processor: Intel ATOM 1.6 GHz
Memory RAM: 1 GB up to 2GB DDR2
Memory Flash: 2 GB internal
6x USB 2.0 ports, 1 COM Port RS232
Audio: 2 in & 2 out 3mm
Internal : 2 Sata, 1 PCIe
Network: Giga Lan Ethernet (RJ-45)
PXE Boot: thin client use
Video: VGA + DVI
Power: DC in 19V (<18W)
Strong Metal Case with security slot
Linutop Applications
Linutop's Kiosk Software, Firefox 3.6, Open Office 3.2, VLC Media
Player 1.1, GNOME 2.3 , Pidgin 2.6, PDF Viewer, Text editor,
On screen keyboard, GQ view Picture viewer, File manager, Network
manager,
supported Formats:
Documents: DOC, DOCX, XLS, XLSX, PPT, PPTX,
PDF, RAR, ZIP ...
Multimedia: MP3, MP4, MPG, DVIX, AVI, FLV ...
Linutop Network Setup:
- Enable Network Manager:
it simplifies the uses of USB wifi keys
- Network configuration:
By default the network uses DHCP to connect to a local network and/or
internet and no action from your part should be needed.
You can configure Static IP, Wifi usb key with WEP, WAP, Or Modem
- Share folders:
Helps you to set up and share linutop data with your network.
- Windows Shares:
Helps you to set up an access to a shared directory on a Windows
system via the network. Enter the IP address of the Windows unit and
the name of the shared directory.
- Remote access
Configure the remote access to your linutop network and a VNC client,
with its IP address on the 'About' tab of the linutop setup menu.
You can access the menu in:
Applications > Settings > Linutop Setup Network tab
© Linutop 2010
www.linutop.com
