ASG Pre-Set Instruction Manual

Safety Instructions

WARNING
RISK OF FLYING PARTICLES
• Use of damaged hand tools, sockets,
extensions and accessories may result
in injury
• Do not use torque screwdriver as a
hammer
• Torque screwdriver not in calibration
may cause damage to parts or tools
• Do not use extensions on handle as
damage to torque screwdriver will
result
• To avoid a "side load" occurred with
inaccurate torque readings, please keep
torque screwdriver vertical to the flat
of use.
ALWAYS USE EYE PROTECTION
WHILE USING HAND TOOLS
WARNING
INJURY MAY RESULT FROM
ELECTRICAL SHOCK
• Handle is not insulated, do not use
on live electrical or high voltage
circuit
Standard
We calibrate each torque screwdriver at the
factory using torque standards according to
DIN ISO 6789 and ASME B107.14M-2004 for
Adjustable (ASME B107.300-2010 for Pre-Set)
and certify it meets the accuracy requirements
of specifications DIN ISO 6789 and ASME
B107.14M-2004 for Adjustable (ASME
B107.300-2010 for Pre-Set)
Convert From To
ozf.in lbf.in
lbf.in ozf.in
lbf.in kgf.cm
lbf.in lbf.ft
lbf.in kgf.m
lbf.in N.m
lbf.in dN.m
lbf.ft N.m
lbf.ft kgf.m
lbf.ft lbf.in
N.m dN.m
N.m kgf.cm
N.m kgf.m
N.m lbf.in
N.m lbf.ft
dN.m lbf.in
dN.m N.m
kgf.cm lbf.in
kgf.cm N.m
kgf.m lbf.ft
kgf.m N.m
Torque Screwdrivers
Pre-Set and Adjustable
Multiply By
0.0625
16
1.1519
0.083333
0.011519
0.1130
1.130
1.356
0.1382
12
10
10.20
0.10197
8.8507
0.73756
ASG, Division of Jergens, Inc.
0.885
15700
0.100
Cleveland, OH
0.8681
Phone: (
0.09807
Email: asginfo@asg-jergens.com
7.233
Web: www.asg-jergens.com
9.807
Premium Manual
Please Read Instructions
Before Operating
S. Waterloo Road
44110-3898
888) 486-6163 | Fax: ( 216) 481-4519
