Samsung GH68-10696A User Manual

SGH-X210
USER'S GUIDE
This guide explains how to set up your phone and gives a quick overview
of the main functions of the phone.
* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
Printed in Korea
Code No.: GH68-10696A
World Wide Web
http://www.samsungmobile.com English (SEA). 04/2006. Rev.1.0
Silent disables all sounds on the phone, when pressed and held
mode mode. To exit, press and hold this key again.
Display
Your phone is in Idle mode when you are not on a call or using a menu.
You must be in Idle mode to dial a phone number.
Icons
Text and graphics
Menu Phonebook Soft key function
indicators
Using the menus
In Idle mode, press the Menu soft key to enter the main menu.
Labels at the bottom corners of
the display show the current soft
key functions. Press the left soft
key ( ) or right soft key ( ) to
perform the function indicated.
To exit the menu
without changing the
To return to the
menu settings, press
previous menu
this key.
level, press the
soft key or c .
Use the 4-way navigation keys ( ) as
shortcuts to access your favourite menus. Up is fixed
as a shortcut to FM radio.
1. In Idle mode, press the Menu soft key.
2. Select Phone settings → Shortcuts.
3. Select a key.
4. Select a menu to be assigned to the key.
Installing the SIM card and battery
1. Remove the battery cover and insert the SIM card.
Battery cover
2. Install the battery and reattach the cover.
Battery
Your phone displays the following status indicators on the top of the
in Idle screen:
Icon Description
Received signal strength
Call in progress
Out of your service area; you cannot make or receive calls.
GPRS network
Roaming network
Silent mode or the call ringer set to Vibration
Mute mode
Call diverting feature active
IrDA feature active
New text message
New multimedia message
New voicemail message
SOS message
Alarm set
Battery power level
To select or modify a menu or feature:
1. In Idle mode, press the Menu soft key.
2. Press the Navigation keys to reach a desired menu and then press the
Select soft key or .
3. If the menu contains any submenus, locate the one you want by
pressing the Navigation keys. Press the Select
the submenu.
If the selected menu contains additional submenus, repeat this step.
4. Press the Navigation keys to find the setting of your choice.
5. Press the Select soft key or to confirm your chosen setting.
Shortcut numbers
You can quickly access the menu you want by using shortcut numbers.
The shortcut number displays in front of the menu name in Menu mode.

Charging the battery

1. Plug the supplied travel adapter.
2. When charging is finished, unplug the adapter.
Note: Do not remove the battery from the phone without unplugging the
adapter first. Otherwise, the phone may be damaged.
Switching on or off the phone
1. Press and hold for more than one second to switch on the phone.
2. To switch off the phone, press and hold
Changing the display language
1. In Idle mode, press the Menu
2. Select Phone settings → Language.
3. Select a language.
Making a call
1. In Idle mode, enter the area code and phone number, and press
2. When you want to end the call, press
Answering a call
1. When the phone rings, press the
To reject the call, press the
2. When you want to end the call, press
Menu map
1. SIM AT
2. Call records
2.1 Missed calls
2.2 Received calls
2.3 Dialled calls
2.4 Delete all
soft key or to enter
2.5 Call time
2.6 Call cost*
3. Network services
3.1 Call diverting
3.2 Call barring
3.3 Call waiting
3.4 Network selection
3.5 Caller ID
3.6 Closed user group
3.7 Band selection
Phone layout and key functions
Web access/
In Idle mode, access the
web browser. Select the
highlighted option or
confirm input in a menu.
To AC wall outlet
Make and answer a call.
In Idle mode, retrieve
the most recent calls.
Voluem keys
Adjust the volume level
of the phone sounds.
Cancel/Clear key
Delete characters from
the display. Return the
display to the previous

Adjusting the volume

1. In Idle mode, press the
for more than two seconds. 2. Select Sound settings
3. Press Up
4. Press the
soft key. While a call is in progress, press the Volume keys to adjust the earpiece
volume.
Changing a ringtone for calls
1. In Idle mode, press the
2. Select Sound settings
.
3. Select a ringtone.
.
Redialling recent numbers
1. In Idle mode, press
Accept soft key or to answer a call.
2. Press Up
Reject soft key or .
3. Press
.
4. Sound settings
7. Organiser
4.1 Ring tone
7.1 Alarm
4.2 Ring volume
7.2 Calendar
4.3 Alert type
7.3 Time & Date
4.4 Keypad tone
7.4 Calculator
4.5 Message tone
7.5 To do list
4.6 Alert on call
7.6 Voice memo
4.7 Folder tone
7.7 Currency exchange
4.8 Power on/off
4.9 Extra tones
8. FM radio
5. Messages
9. Phone settings
5.1 Text messages
9.1 Infrared activate
5.2 Multimedia messages
9.2 Display settings
5.3 Push messages
9.3 Greeting message
9.4 Own number
6. Funbox
9.5 Language
9.6 Security
6.1 WAP browser
9.7 Extra settings
6.2 Games
9.8 Shortcuts
6.3 Sounds
9.9 Reset settings
6.4 Images
6.5 Delete all
6.6 Memory status
Soft keys
Perform functions
indicated by the
text above the key.
Confirm key
4-way navigation keys
In Menu mode, scroll
through menu options.
In Idle mode, access your
favourite menus directly.
Dial key
Power/End key
Turn the phone on or
off when pressed and
held. Also end a call.
Silent mode key
menu level.
Alphanumeric
keys
Menu soft key.
Ring volume.
→
or Down to adjust the volume level.
OK soft key.
Menu soft key.
→ Ring tone.
.
or Down to scroll to the number you want.
to dial the number.
Press the Phonebook soft key
in Idle mode.
1 Search
2 New entry
3 Group search
4 Edit group
5 Speed dial
6 Delete all
7 Copy all to
8 Memory status
9 SDN*
* Show only if supported by your SIM
card.
