DVD Camcorder

user manual

imagine
the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please
nregister your product at
www.samsung.com/global/register
DVD-Camcorder
Benutzerhandbuch
Für
unbegrenzte
Wir freuen uns, dass Sie sich für dieses Produkt
von Samsung entschieden haben.
Registrieren Sie Ihr Gerät auf der folgenden
Webseite, um unsere Serviceleistungen vollständig
in Anspruch nehmen zu können:
www.samsung.com/global/register
VP-DX10
VP-DX10H
Möglichkeiten

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP-DX10 and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung VP-DX10

Summary of Contents for Samsung VP-DX10

  • Page 1: Dvd Camcorder

    DVD Camcorder user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please nregister your product at www.samsung.com/global/register VP-DX10 VP-DX10H DVD-Camcorder Benutzerhandbuch Für unbegrenzte Möglichkeiten Wir freuen uns, dass Sie sich für dieses Produkt von Samsung entschieden haben.
  • Page 2 Capture visions farther than the eye can see (26X optical/1200X digital zoom) Samsung’s powerful optical zoom lenses bring the world closer without sacrifi cing image quality. In addition, digital zoom interpolation means that extreme digital zooming is clearer, with less distortion than previous types of digital zooms.

  • Page 3: Safety Warnings

    safety warnings What the icons and signs in this user manual mean: Means that death or serious personal injury is a risk. WARNING Means that there is a potential risk for personal injury or material damage. CAUTION To reduce the risk of fire, explosion, electric shock, or personal injury when using your DVD camcorder, follow these basic safety CAUTION precautions:...

  • Page 4: Important Information On Use

    Samsung cannot be responsible for your recorded video and audio. Recorded contents may be lost due to a mistake when handling this DVD camcorder or memory card, etc. Samsung shall not be responsible for compensation for damages due to the loss of recorded contents. •...

  • Page 5: Notes Regarding A Trademark

    NOTES REGARDING A TRADEMARK • All the trade names and registered trademarks mentioned in this manual or other documentation provided with your Samsung product are trademarks or registered trademarks of their respective holders. • Windows® is registered trademark or trademark of Microsoft Corporation, registered in the United States and other countries.

  • Page 6: Precautions When Using

    precautions when using IMPORTANT NOTE • Handle the liquid crystal display (LCD) with care: The LCD is a very delicate display device: Do not press its surface with force, hit it or prick it with a sharp object. If you push the LCD surface, unevenness in display may occur. If unevenness does not disappear, turn the camcorder off, wait for a few moments, then turn it on again.
  • Page 7 • Do not use the DVD camcorder near TV or radio: This could cause noise to appear on the TV screen or in radio broadcasts. • Do not use the DVD camcorder near strong radio waves or magnetism: If the DVD camcorder is used near strong radio waves or magnetism, such as near a radio transmitter or electric appliances, noise could enter video and audio that are being recorded.

  • Page 8: Table Of Contents

    contents contents INTRODUCTION TO BASIC FEATURES GETTING TO What’s included with your DVD camcorder KNOW YOUR DVD Front and right view CAMCORDER Left side and bottom view Rear and top view Remote control PREPARATION Using the accessories Installing the button type battery Connecting a power source Basic DVD camcorder operation Screen indicators...
  • Page 9 BEFORE Selecting a storage media RECORDING RECORDING Recording movie images Taking photo images Recording with ease for beginners (EASY Q mode) Capturing still images during movie images playback Zooming PLAYBACK Changing the playback mode Playing movie images Viewing photo images CONNECTION Connecting to a TV USING THE MENU...

  • Page 10: Deutsch

    contents IMAGE Protection from accidental erasure MANAGEMENT Deleting images Copying images from the built-in memory EDITING MOVIE Dividing a movie image IMAGES Combining two movie images Playlist Creating the playlist Arranging order of movie images within playlist Deleting movie images from playlist Copying playlists from built-in memory...
  • Page 11 USB INTERFACE System requirements Installing the CyberLink PowerDirector Connecting the USB cable Viewing the contents of storage media Transferring files from the DVD camcorder to your PC MAINTENANCE & Maintenance ADDITIONAL Additional information INFORMATION Using your DVD camcorder abroad TROUBLESHOOTING Troubleshooting SPECIFICATIONS 05_ English...

  • Page 12: Zu Den Grund Funktionen

    introduction to basic features This chapter introduces you to the basic features of your DVD camcorder. See the reference pages below for more information. Step 1 : Preparation • Charging the battery pack page 18 • Setting the date/time and OSD language pages 29, 30 •...
  • Page 13 Step 2 : Recording • Recording the movie or photo images pages 39-44 Step3: Playing back / Editing • Selecting an image to play back from the thumbnail index views pages 46, 48 • Viewing playback from your DVD camcorder on your PC or TV pages 50, 98 •...

  • Page 14: Überblick Über Den Dvd-Camcorder

    CD/CD-R/CD-RW/DVD-ROM/DVD+R (Single Layer)/DVD-RAM/ DVD-R (Dual Layer), Disketten, MO, MD, iD, LD • Samsung haftet nicht für den Verlust der auf einer Disk befindlichen Daten. • Samsung haftet nicht für Beschädigung oder Verlust von Daten aufgrund einer Fehlfunktion der Disk, der Speicherkarte oder des internen Speichers bei der Aufnahme oder Wiedergabe.

  • Page 15: Getting To

    WHAT IS INCLUDED WITH YOUR DVD CAMCORDER Your new DVD camcorder comes with the following accessories. If any of these items is missing from your box, call Samsung’s Customer Care Centre. ✪ The exact appearance of each item may vary by model.

  • Page 16: Front And Right View

    FRONT AND RIGHT VIEW Lens open/close switch Lens Remote sensor Light Record/Photo button Internal microphone AV jack AV jack cover Zoom ( ) lever Grip belt hook Grip belt Swivel handle Disc cover 10_ English ANSICHT: VORDERSEITE UND RECHTE SEITE Schalter zum Öffnen/Schließen des Objektivs Objektiv Sensor für Fernbedienung...

  • Page 17: Getting To Know Your Dvd Camcorder

    getting to know your DVD camcorder LEFT SIDE AND BOTTOM VIEW EASY Q button COPY/FINALIZE button BATT. (Battery release) switch Battery pack TFT LCD screen (Touch panel) LCD enhancer ( ) button Display ( ) / iCHECK button Q.MENU button Built-in speaker Tripod receptacle Memory card slot...

  • Page 18: Rear And Top View

    REAR AND TOP VIEW Viewfi nder Zoom (W/T) lever PHOTO button Focus adjustment knob MODE button / Mode indicator (Movie ( )/Photo ( ) mode) Recording start/stop button POWER switch OPEN switch USB jack DC IN /USB jack cover DC IN jack ACCESS/CHG indicator Play mode button 12_ English...

  • Page 19: Remote Control

    getting to know your DVD camcorder REMOTE CONTROL START/STOP button DISPLAY button Skip ( ) button Stop ( ) button Play/Pause ( ) button MENU button Control ( )buttons PHOTO button Zoom (W/T) button Search ( ) button Slow playback ( ) button Q-MENU button The buttons on the remote control...

  • Page 20: Using The Accessories

    preparation This section provides information on using this DVD camcorder; such as how to use the provided accessories, how to charge the battery, how to setup the operation mode and initial setup. USING THE ACCESSORIES Holding the DVD camcorder Attaching a grip belt Insert your right hand from the bottom of the DVD camcorder up to the base of your thumb.

  • Page 21: Knopfzelle Einsetzen

    IINSTALLING THE BUTTON-TYPE BATTERY Installing the button-type battery in the remote control 1. Turn the battery holder counterclockwise (as indicated with () mark) using your fi ngernail or a coin to open it. The battery holder opens. 2. Insert the battery into the battery holder with the positive (+) terminal facing down and press it fi...

  • Page 22: Connecting A Power Source

    DVD camcorder. Use only Samsung-approved battery packs. Do not use batteries from other manufacturers. Otherwise, there is a danger of overheating, fi re or explosion. Samsung is not responsible for problems occurring due to using unapproved batteries. 16_ English vorbereitung STROMVERSORGUNG •...
  • Page 23 • We recommend only using the original battery pack that is available from your Samsung retailer. When the battery reaches the end of its life, please contact your local dealer. The batteries have to be treated as chemical waste. •...

  • Page 24: Charging The Battery Pack

    preparation Charging the battery pack • Use IA-BP85SW battery pack only. • The battery pack may be charged a little at the time of purchase. 1. Slide the POWER switch downwards to turn off the power. 2. Open the LCD screen and attach the battery pack to the DVD camcorder.
  • Page 25 It may differ depending on Super Fine or Normal mode. The time is only for reference. Figures shown above are measured under Samsung’s test environment, and may differ from your actual use. The battery pack is charged over 95% after 1 hour 40 minutes, then the ACCESS/CHG (charging) indicator lights green.
  • Page 26 Schlag oder einem Brand kommen.  Das Netzteil kann überall auf der Welt verwendet werden. In einigen Ländern kann ein Adapterstecker erforderlich sein. Bei Bedarf erhalten Sie diesen Stecker bei einem Samsung Fachhändler vor Ort. • Der DVD-Camcorder muss ausgeschaltet sein, bevor Sie ihn von der Stromversorgung trennen.

  • Page 27: Basic Dvd Camcorder Operation

    BASIC DVD CAMCORDER OPERATION Set the appropriate operation mode according to your preference using the POWER switch, MODE button and Play mode ( ) button. Turning the DVD camcorder on and off You can turn the camcorder on or off by sliding the POWER switch down.

  • Page 28: Screen Indicators

    preparation SCREEN INDICATORS Movie record mode Movie record mode Operating mode (STBY (standby) or  (recording)) Time counter (movie recording time) Warning indicators and messages Remaining time Storage media (Built-in memory, DVD or memory card ) Battery info.(remaining battery level/time) LCD enhancer Disc format type(DVD-RW disc only) Quality...

  • Page 29: Movie Play Mode

    Movie play mode Movie play mode Operating status (Play/Pause) File name (Folder_File name) Time code (elapsed time / total recorded time) Warning indicators and messages/Volume control Storage media (Built-in memory, DVD or memory card ) Battery info (remaining battery level/time) LCD enhancer Disc format type (DVD-RW disc only) Quality...
  • Page 30 preparation Photo record mode Photo record mode Operating mode Warning indicators and messages Image counter (remain counter) Storage media (Built-in memory or memory card ) Battery info LCD enhancer Back light Menu Zoom position Date/Time Record/Play mode Manual Exposure* Manual Focus* White Balance Photo image quality Photo image resolution...

  • Page 31: Photo Play Mode

    Photo play mode Photo play mode Slide Show File name (Folder_File name) Warning indicators and messages Image counter (Selected/Total fi le number) Storage media (Built-in memory, DVD or memory card ) Battery info LCD Enhancer Date/Time Previous image/Next image Menu Return tab Print Mark(DPOF) Erase protection...

  • Page 32: Using The Display

    preparation USING THE DISPLAY ( )/iCHECK BUTTON Switching the information display mode You can switch between the on-screen information display modes: Press the Display ( ) / iCHECK button when the power is on. Each press of the button toggles the OSD (On Screen Display) function on and off.

  • Page 33: Adjusting The Lcd Screen

    USING THE LCD ENHANCER ( Contrast is enhanced for a clear and bright image on the LCD screen. This effect is also implemented outdoors in bright daylight. 1. Slide the POWER switch downwards to turn on the power. 2. Press the LCD enhancer ( ) button.

  • Page 34: Using The Viewfinder

    preparation Using the touch panel You can play recorded images and set the functions by using the touch panel. Place your hand on the rear side of the LCD panel to support it. Then, touch the items displayed on the screen. •...

  • Page 35: Initial Setting: Osd Language & Date And Time

    INITIAL SETTING: OSD LANGUAGE & DATE AND TIME • Initial setting is available in all operating modes. page 21 • To read the menus or messages in your desired language, set the OSD language. To store the date and time during record, set the date/time.
  • Page 36 preparation Setting the date and time Set the date and time when using this DVD camcorder for the fi rst time. The recording start date/time is recorded on the movie/photo images. Touch the Menu ( ) tab. • The menu will appear. Touch the Settings ( ) tab.

  • Page 37: Before Recording

    before recording SELECTING THE STORAGE MEDIA You can record movie and photo images on the desired storage media (built-in memory, a DVD disc or a memory card) so you should select the desired storage media before starting recording or playback. Note that photo images can not be recorded onto a DVD disc.
  • Page 38 before recording Method 2: Using a memory card (not supplied) • This DVD camcorder has multi card-slot for access to SDHC (Secure Digital High Capacity) and MMCplus cards. Some cards are not compatible depending on the memory card manufacturer and memory card type.
  • Page 39 SDHC memory card • SDHC memory card complies with new SD specifi cation Ver.2.00. This latest specifi cation was established by SD card association to realize data capacity over 2GB. • SDHC memory card supports a mechanical write-protection switch. Setting the switch prevents accidental erasure of fi...
  • Page 40 Note on use • Samsung is not responsible for data loss due to misuse. • We recommend using a memory card case to avoid losing data from moving and static electricity. • After a period of use, the memory card may become warm. This is normal, not a malfunction.
  • Page 41 Method 3: Using a DVD disc • When inserting a disc or closing the disc cover, do not apply excessive force. It may cause a malfunction. • You cannot open the disc cover while loading. • You can use a new 3 1/2 inch(8cm) DVD-RW, DVD+RW, DVD-R or DVD+R DL (Dual Layer) disc for movie recording.
  • Page 42 before recording When using a new disc: formatting a new disc Formatting may be required if a new disc is inserted. Recognition of the disc will start. For a DVD-R/+R DL disc: Formatting will automatically begin. For a DVD-RW disc: The Format menu is offered. Select the recording format, Video mode or VR mode.

  • Page 43: Aufnahmezeit Und Anzahl Der Bilder

    Recordable time and number of images Recordable time for movie images DVD+RW/ DVD+R Built-in Storage -RW/-R memory Capacity 1.4GB 2.6GB 256MB Movie Quality Approx. Approx. Approx. Approx. Super Fine 20min 35min 65min 4min Approx. Approx. Approx. Approx. Fine 30min 53min 95min 5min Approx.
  • Page 44 • The above figures are measured under Samsung’s standard recording test conditions and may differ depending on actual use. • The DVD camcorder provides three quality options for movie recordings: “Super Fine,” “Fine” and “Normal.” The higher the quality setting, the more memory is used.

  • Page 45: Recording Movie Images

    recording Basic procedures to record a movie or photo image are described below and on the following pages. RECORDING MOVIE IMAGES • You can record movie images in the Movie mode only. page 21 • You can record movie images using the remote control.
  • Page 46 recording • The recorded movie image size is 720X576. • Eject the battery pack when you have finished recording to prevent unnecessary battery power consumption. • For on-screen information display, see page 22. • For approximate recording time, see page 37. •...

  • Page 47: Taking Photo Images

    TAKING PHOTO IMAGES • You can take photo images in Photo mode only. page 21 • The DVD camcorder provides two PHOTO buttons. One is on the top and the other is on the front of the camcorder. • Taking a photo image is possible on the built-in memory and memory card.
  • Page 48 STBY 00:00:00 [95Min] <Movie record mode> <Movie record mode> <Movie record mode>...
  • Page 49 CAPTURING STILL IMAGES DURING MOVIE IMAGE PLAYBACK • This function works only in the Play mode. page 21 • If you press the PHOTO button or Record/Photo button on the front during playback, it stops playing and saves one image of the current movie scene that is paused.

  • Page 50: Zoomfunktion Verwenden

    recording ZOOMING Use the zoom function for close-up or wide-angle recording. This DVD-Camcorder allows you to record using optical 26x power zoom and 1200x digital zoom. • The DVD-Camcorder provides two zoom levers. One is on the top side and the other is on the front side of the camcorder.

  • Page 51: Changing The Playback Mode

    playback You can view recorded movie and photo images in the thumbnail index view and play them in various ways. CHANGING THE PLAYBACK MODE • You can easily switch between Record mode and Play mode by touching the Play mode ( ) tab.

  • Page 52: Playing Movie Images

    playback PLAYING MOVIE IMAGES • This function works only in the Play mode. page 21 • You can switch to the Play mode by using the Play mode ( ) button. Alternatively, you can switch to the Play mode by touching Playback ( ) tab on the screen in the Movie ) or Photo (...

  • Page 53: Adjusting The Volume

    Adjusting the volume • Touch the Volume ( ) tab on the LCD screen. • You can control the volume by using decrease ( or increase ( ) tab on the LCD screen. • You can hear the recorded sound from the built-in speaker. •...

  • Page 54: Viewing Photo Images

    playback Slow playback • Whenever touching Reverse slow ( ) / Forward slow ) tab while paused, you can play the movie forward or reverse at the 1/2x speed. • To resume normal playback, touch Playback ( ) tab. • You can play the image forward at the 1/2x speed by using the Slow playback ( ) button on the remote control.

  • Page 55: To View A Slide Show

    To view a slide show Set the slide show function for continuous display. Touch the Menu ( ) tab in the thumbnail index view or single-image display mode. • The menu will appear. Touch “Slide Show.” • The ( ) indicator is displayed. The slide show will start from the current image.

  • Page 56: Connecting To A Tv

    connection You can view the recorded movie and photo images on a large screen by connecting the DVD-Camcorder to a TV. CONNECTING TO A TV • To play back your recordings, the television must be PAL compatible. page105 • We recommend that you use the AC power adaptor as the power source for the DVD-Camcorder.
  • Page 57 Image display depending on TV screen ratio Recording ratio Wide (16:9) TV Images recorded in the 16:9 ratio (16:9 Wide: On) • Movie images Photo images recorded in the 4:3 ratio (16:9 Wide: Off) • Movie images • Photo images •...

  • Page 58: Using The Menu Items

    using the menu items You can use the DVD-Camcorder more easily by setting menus related to recording, playback and setting. HANDLING MENU AND QUICK MENU • You can change the menu settings to customise your DVD-Camcorder. Access the desired menu screen by following the steps below and change the various settings.
  • Page 59 Follow the instruction below to use each of the menu ✪ items listed on this page. For example: setting the Focus When using the Menu ( ) tab; Slide the POWER switch downward to turn on the power. The Movie ( ) mode screen is displayed.
  • Page 60 using the menu items MENU ITEMS • Accessible items in menu vary depending on the operation mode. • For operation details, see the corresponding page. Recording menu items ( Operating mode Movie ( ) Photo ( Scene Mode(AE)  Resolution ...

  • Page 61: Playback Menu Items

    Playback menu items ( Movie Operating mode Play Option  Slide Show Delete  Protect  Multi Select to DVD  Copy All to DVD (built-in  memory Multi Select to Card  only) All to Card  Divide  Edit Combine ...

  • Page 62: Quick Menu Items

    using the menu items QUICK MENU ITEMS • Accessible items in the quick menu vary depending on the operation mode. • For operation details, see the corresponding page. Recording menu items Operating mode Movie ( Photo ( Copy   Finalise/Unfinalise (only ...

  • Page 63: Recording Menu Items

    RECORDING MENU ITEMS ( You can set up the menu items for movie and photo images recording. Scene Mode(AE) This DVD-Camcorder automatically sets the shutter speed and aperture according to thesubject brightness for optimum recording: You can also specify one of six modes depending on conditions, recording environment or purpose of filming.

  • Page 64: White Balance (Weißabgleich)

    using the menu items White Balance This DVD-Camcorder automatically adjusts the colour of subject. Change the white balance setting depending on the recording conditions. Settings Contents This option is generally used to control the white Auto balance automatically. This controls the white balance according to the Daylight outdoor ambience, especially for close up and when the subject is of one dominant colour.
  • Page 65 • A subject can be shot under various types of lighting conditions indoors (natural, fl uorescent, candlelight, etc.). Because the colour temperature is different depending on the light source, the subject tint will differ depending on the white balance settings. Use this function for a more natural result.
  • Page 66 using the menu items Manual exposure is recommended in situations listed below: • When shooting using reverse lighting or when the background is too bright. • When shooting on a reflective natural background such as at the beach or when skiing.

  • Page 67: Digital Effect

    Digital Effect The digital effect enables you to give a creative look to your recording. Select the appropriate digital effect for the type of picture that you wish to record and the effect you wish to create. There are 10 different digital effect options. On-screen Settings Contents...
  • Page 68 using the menu items Focus The DVD-Camcorder usually focusses on a subject automatically (auto focus). When the DVD-Camcorder is turned on, auto focus will always be set. You can also manually focus a subject depending on the recording conditions. Settings Contents In most situations, it is better to use the automatic focus Auto...
  • Page 69 • “Focus” function will alternate between manual focus and auto focus. With auto focus, no indication will appear on the screen. • If you are inexperienced in the use of DVD-Camcorders, we recommend that you use auto focus. • This function will be set to “Auto” in the EASY Q mode. Shutter The DVD-Camcorder automatically sets the shutter speed depending on the subject brightness.
  • Page 70 using the menu items • We recommend using a tripod when recording with a slow shutter speed. • If you manually change the shutter speed value when “Scene Mode(AE)” function is selected, manual changes are applied first. • The image may not seem smooth when a high shutter speed is set. •...

  • Page 71: Wind Cut (Rauschunterdrückung)

    • Recorded files are encoded with Variable Bit Rate (VBR). VBR is an encoding system that automatically adjusts the bit rate according to the recording image. Wind Cut You can reduce wind noise when recording sound from the built-in microphone. If “Wind Cut: On”...

  • Page 72: On-Screen Display

    using the menu items Back lighting influences recording when the subject is darker than the background: The subject is in front of a window. The person to be recorded is wearing white or shiny clothes and is placed against a bright background;...
  • Page 73 • The LED light enables you to record a subject in dark places. • The LED light can be used with C. Nite function only. • When using C. Nite, the focus adjusts slowly and white dots may appear on the screen, this is not a defect.
  • Page 74 using the menu items Resolution You can select the resolution of photo images to record. Settings Contents 1152x864 Select to record at high-resolution. 800x600 Select to record at medium-resolution. • Regarding detailed image capacity, see page 37. • For photo development, the higher the resolution, the fi ner the image quality. •...

  • Page 75: Playback Menu Item

    PLAYBACK MENU ITEM You can set up these menu items for playing movies. Play Option You can set up play options for movie image playback. Settings Contents Play All Plays the movie images from the selected one to the last. Plays the selected movie image only and returns to the thumbnail Play One index view.

  • Page 76: Lcd Control

    using the menu items File No. File numbers are assigned to photo images in the order they were recorded. Settings Contents Assigns file numbers in sequence even if the memory card is replaced with another one or after formatting, or after Series deleting all fils.
  • Page 77 Storage Info It shows you the storage information (the storage media, used space and available space, selected recording quality). So you can fi nd out how long you will be able to record on the storage media. Settings Contents You can view the used space, available Memory space and the selected recording quality on the Built-in memory.
  • Page 78 using the menu items Beep Sound You can turn the beep sound on or off. Settings Contents Cancels the beep sound. When on, a beep will sound every time a button is pressed. • The beep sound is off while recording movies. •...
  • Page 79 TV Display The TV Display function works in recording and play modes. You can select the output path of the OSD (On Screen Display). This allows you to set the OSD for viewing on the viewfinder, LCD screen or an external TV. Settings Contents The OSD appears in the LCD screen and viewfinder...
  • Page 80 using the menu items Calibration The items on the touch panel may not work correctly. If this happens, follow the procedure below. It is recommended you connect your DVD-Camcorder to the wall outlet using the supplied AC power adaptor during the operation. 1.

  • Page 81: Image Management

    image management This chapter describes information about movie or photo fi le management tools such as protection, deletion and copy. They are not performed at low battery for storage protection. PROTECTION FROM ACCIDENTAL ERASURE • This function works only in the Play mode. page 21 •...

  • Page 82: Deleting Images

    image management DELETING IMAGES • This function works only in the Play mode. page 21 • You can erase the images recorded on the storage media. • If the storage media is set to DVD, this function works only on a DVD-RW disc (VR mode).
  • Page 83 COPYING IMAGES FROM THE BUILT-IN MEMORY • You can copy images from the built-in memory onto a DVD disc or memory card. • This function works only in the Play mode. page 21 • Make sure that a memory card or DVD disc has been inserted. Slide the POWER switch downwards to turn on the power and press the Play mode ( ) button to set the Play mode.

  • Page 84: Bearbeiten Von

    editing movie images You can edit recorded movie images in various ways. • Select the desired storage media to edit. • If the storage media is set to DVD, this function works only on a DVD-RW disc (VR mode). DIVIDING A MOVIE IMAGE •...

  • Page 85: Combining Two Movie Images

    COMBINING TWO MOVIE IMAGES • This function works only in the Play mode. page 21 • You can combine two different movie images. Slide the POWER switch downwards to turn on the power and press the Play ( ) button to set the Play mode. •...

  • Page 86: Wiedergabelisten Verwenden

    editing movie images PLAYLIST What’s a Playlist? • You can create a playlist on the same disc by gathering your favourite scenes from the recorded movie images. When creating or deleting playlists, the original movie image will not be erased. Adding or deleting movie images from a playlist does not affect the actual movie images.

  • Page 87: Creating The Playlist

    CREATING THE PLAYLIST • This function works only in Play mode using the Q.MENU button. page 53 • You can create a playlist on this DVD-Camcorder by gathering favourite recorded movie images. Since the playlist is not created by copying data, you will consume little of the storage capacity by making a playlist.
  • Page 88 editing movie images ARRANGING THE ORDER OF MOVIE IMAGES WITHIN PLAYLIST • This function works only in Play mode using the Q.MENU button. page 53 • You can arrange movie images within a playlist by moving them to desired positions. 1.

  • Page 89: Deleting Movie Images From A Playlist

    DELETING MOVIE IMAGES FROM A PLAYLIST • This function works only in Play mode using the Q.MENU button. page 53 • You can delete undesired movie images within a playlist. 1. Press the Q.MENU button. • The quick menu will appear. 2.

  • Page 90: Copying Playlists From The Built-In Memory

    editing movie images COPYING PLAYLISTS FROM THE BUILT-IN MEMORY • This function works only in Play mode using the Q.MENU button. page 53 • You can copy playlists from the built-in memory into a DVD disc or memory card. • Make sure to insert a disc or a memory card to copy into the camcorder.

  • Page 91: Disc Management

    disc management You can manage a DVD disc for recording. DISC INFORMATION -RW +RW • This function works in both Movie mode and Play mode. page 21 • It shows you disc information such as the disc name, disc type, disc format, etc. NOTICE: Make sure that you insert a disc.

  • Page 92: Disc Format

    disc management DISC FORMAT -RW +RW • This function works in both Movie mode and Play mode. page 21 • You can format a recorded disc for re-use. By formatting, all existing data will be deleted. Slide the POWER switch downwards to turn on the power.
  • Page 93 DISC FINALISATION • This function works in both Movie mode and Play mode. page 21 • To play the contents of a DVD-RW/-R/+R DL on other DVD players/recorders/drives, you must fi nalise the disc. When fi nalising, there should be enough power in the batteries. If the AC power adaptor is to be used, make sure that the jack is properly connected.
  • Page 94 disc management • The fi nalise function is not available at the battery level under ( • Once fi nalised, the movie images or playlists in the disc cannot be deleted or edited. • Time required for fi nalising may differ by disc type. •...
  • Page 95 Playing back a fi nalised disc on a DVD player / recorder To playback a disc You can playback fi nalised DVD-R/-RW (Video mode)/+R DL discs on DVD players/recorders. Playback is not guaranteed in all DVD players/ recorders. For compatibility details, refer to your DVD player/recorder owner’s manual.
  • Page 96 disc management DISC UNFINALISATION • This function works in both Movie mode and Play mode. page 21 • If a DVD-RW disc had been fi nalised in the VR mode or Video mode, you can unfi nalise the disc for further recording.

  • Page 97: Drucken Von

    printing photo images You can print photo images by inserting the DPOF setting card to the DPOF-compatible printer or connecting the DVD-Camcorder to the PictBridge printer. DPOF PRINT SETTING • This function works only in the Play mode. page 21 •...

  • Page 98: Direct Printing With A Pictbridge

    printing photo images DIRECT PRINTING WITH A PICTBRIDGE • If your printer is compatible with PictBridge, photo images can be printed easily by connecting the camcorder with the USB cable directly to the printer. DPOF setting can also be used. page 91 NOTICE: After selecting “PictBridge”...
  • Page 99 PictBridge menu Setting the date/time imprint option Touch the Menu ( ) tab  “Date/Time”  “Off,” “Date,” “Time,” or “Date&Time”  Return ( ) tab. To print using the DPOF setting If the printer is compatible with DPOF, you can use the DPOF setting.

  • Page 100: Usb Interface

    USB interface This chapter explains how to connect the camcorder to a PC using the USB cable for various functions. ✪ When connecting a USB cable to a PC, refer to the software installation instructions and PC specifications below. SYSTEM REQUIREMENTS CyberLink PowerDirector Following requirements must be satisfied to use CyberLink PowerDirector.
  • Page 101 INSTALLING THE CyberLink PowerDirector PowerDirector is a software for easy of editing MPEG, AVI, and other video fi les, still images, and other contents for creating a movie. This software has an interface that allows editing in either timeline or storyboard mode, maintains superior image quality, uses SVRT (Smart Video Rendering Technology) for high-speed rendering, and has a host of other advanced video editing features.
  • Page 102 USB interface 4. Confi rm your information and click “Next.” • It is possible to change the information. • The “Choose Destination Location” screen appears. 5. Click “Next.” • “Setup will install...” screen appears. 6. Click “Next.” • The “Setup status” screen appears and CyberLink PowerDirector is installed.

  • Page 103: Disconnecting The Usb Cable

    CONNECTING THE USB CABLE To copy the movie fi les and photo fi les to your PC, connect your DVD-Camcorder to the PC with a USB cable. 1. Set the “USB Connect” to “Mass Storage.” page 73 2. Connect the DVD-Camcorder to the PC with a USB cable.

  • Page 104: Viewing The Contents Of Storage Media

    USB interface VIEWING THE CONTENTS OF STORAGE MEDIA • You can transfer or copy the fi les saved on built-in memory or memory card into PC using USB cable. • You cannot transfer the movies recorded on a DVD disc to PC using USB cable. You can play the movies directly in the PC which DVD drive is installed.
  • Page 105 Structure of folders and fi les on the storage media • The folder and fi le structure for the built-in memory or memory card is as follows: • Do not arbitrarily change or remove the folder or fi le name. It may not be playable. •...

  • Page 106: Transferring Files From The Dvd-Camcorder To Your Pc

    USB interface TRANSFERRING FILES FROM THE DVD-Camcorder TO YOUR PC You can copy the movie and photo images to your PC and play them back. 1. Execute the procedure in “Viewing the contents of storage media.” page 98 • The folders in the storage media appear. 2.

  • Page 107: Maintenance & Additional Information

    maintenance & additional information MAINTENANCE Your DVD-Camcorder is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you fulfill any guarantee obligations and allow you to enjoy this product for many years. •...

  • Page 108: Ergänzende Informationen

    Do not store the storage media in locations with high temperature or high humidity. Do not touch the metal parts. • Copy the recorded files to your PC. Samsung shall not be responsible for any lost data. • A malfunction may cause the storage media to fail to operate properly. Samsung will not provide any compensation for any lost contents.
  • Page 109 Remove from charger or powered unit when not in use, as some machines use electric current even when switched off. • It is recommended that only genuine Samsung batteries are used in this camcorder. Using generic non-Samsung batteries can cause damage to the internal charging circuitry. •...
  • Page 110 maintenance & additional information On charging the built-in rechargeable battery Your camcorder has a built-in rechargeable battery to retain the date, time, and other settings even when the power switched off. The built-in rechargeable battery is always charged while your camcorder is connected to the wall outlet via the AC power adaptor or while the battery pack is attached.

  • Page 111: Using Your Dvd-Camcorder Abroad

    You must format a new disc before recording on it.  When loading a DVD-RW disc you must format it in Video or VR mode.  When loading a DVD+RW disc you must format it.  We cannot guarantee that you will be able to play back in all other manufacturer’ ...

  • Page 112: Troubleshooting

    TROUBLESHOOTING Before contacting a Samsung authorised service centre, perform the following simple checks. They may save you the time and expense of an unnecessary call. Warning indicators and messages Power source Message Icon Informs that... Action Replace with a charged battery or connect the AC power The battery pack is almost adaptor.
  • Page 113 Message Icon Informs that... There is no memory card inserted in the Insert Card card slot. There is no enough space to record in Card Full the memory card. The DVD-Camcorder cannot record Low speed card with a low speed card. File system does not match the built- in memory or memory card.
  • Page 114 Je nach Problem muss der interne Speicher möglicherweise zurückgesetzt oder ausgetauscht werden, wobei die Daten gelöscht werden. Sichern Sie wichtige Daten auf dem PC, bevor Sie den Camcorder zur Reparatur einschicken. Samsung haftet nicht für verloren gegangene Daten. Überprüfen Sie die Druckerkartusche.

  • Page 115: Symptoms And Solutions

    109_ English Wenn bei der Verwendung des Camcorders Probleme auftreten, prüfen Sie zunächst ✪ folgende Punkte. Wenn Sie das Problem mit den folgenden Maßnahmen nicht beheben können, wenden Sie sich an den zuständigen Samsung-Kundendienst. Fehler und Lösungen Stromversorgung Fehler Erklärung/Abhilfe •...
  • Page 116 troubleshooting Symptom Explanation/Solution An afterimage remains on • This occurs if you disconnect the AC power adaptor or remove the LCD screen. the battery pack before turning the power off • Ambient light is too bright. Adjust the brightness and angle of The image on the LCD LCD.
  • Page 117 Recording Symptom Explanation/Solution • The internal temperature of your camcorder is extremely low. Keep it turned on and wait until it warms up. • If you make a frequent recording or deletion of files, the performance of the storage The recording stops media will deteriorate.
  • Page 118 troubleshooting Symptom Explanation/Solution The shutter sound is not heard when you record a photo • Set “Shutter Sound” to “On.” image. • On your camcorder, there may be a There is a time difference slight time delay between the point between the point where you when you press Recording Start/Stop press Recording Start/Stop...
  • Page 119 Adjusting the image during recording Symptom Explanation/Solution • Set “Focus” to “Auto.” page 62 • The recording conditions are not suitable for auto focus. Adjust the focus manually. page 62 Focus does not adjust • The lens is dusty on the surface. Clear the lens automatically.
  • Page 120 troubleshooting Symptom Explanation/Solution • If the temperature inside the camcorder is too high, The Skip or Search function it may not function properly. does not work properly. Turn the camcorder off, wait for a few moments, and turn it on again. Photo images stored on •...

  • Page 121: Connecting To A Computer

    Connecting to a computer Symptom Explanation/Solution • Disconnect any other USB device than the keyboard, mouse and camcorder from the computer. The computer does not • Disconnect the USB cable from the computer recognise your camcorder. and camcorder, restart the computer, then connect it again correctly.

  • Page 122: Allgemeine Funktionen

    troubleshooting Symptom Explanation/Solution • Check the system requirements to play a movie. page 94 The playback • Exit other all applications running on the current computer. screen is paused • If a recorded movie is played on your camcorder connected to a or distorted.

  • Page 123: Technische Daten

    specifications MODEL NAME: VP-DX10/VP-DX10H System Video signal Picture compression format MPEG-2 ® Audio compression format DOLBY DIGITAL STEREO CREATOR SF (about 9Mbps), F (about 6Mbps), N (about 3Mbps) Recording quality CCD (Charge-coupled device) 1M pixels Image device Lens F1.6 26x (Optical), 1200x (Digital) Electronic zoom lens Focal length f2.5 ~ 65mm Filter diameter...
  • Page 124 Originalrechnung oder den vom Händler ausgestellten Kassenbeleg oder eine entsprechende Bestätigung vorlegen. Die Seriennummer am Gerät muss lesbar sein. 2. Es liegt im Ermessen von Samsung, ob die Garantie durch Reparatur oder durch Austausch des Gerätes bzw. des defekten Teils erfüllt wird. Weitere Ansprüche sind ausgeschlossen.
  • Page 125 Händler ausgestellten Kassenbeleg oder eine entsprechende Bestätigung vorlegen. Die Seriennummer am Gerät muss lesbar sein. 2. Es liegt im Ermessen von Samsung, ob die Garantie durch Reparatur oder durch Austausch des Gerätes bzw. des defekten Teils erfüllt wird.
  • Page 126 Originalrechnung oder den vom Händler ausgestellten Kassenbeleg oder eine entsprechende Bestätigung vorlegen. Die Seriennummer am Gerät muss lesbar sein. 2. Es liegt im Ermessen von Samsung, ob die Garantie durch Reparatur oder durch Austausch des Gerätes bzw. des defekten Teils erfüllt wird. Weitere Ansprüche sind ausgeschlossen.

  • Page 127: Contact Samsung Worldwide

    COLOMBIA 01-8000112112 BELGIUM 0032 (0)2 201 24 18 844 000 844 CZECH REPUBLIC Distributor pro Českou republiku :Samsung Zrt., česka organizační složka Vyskočilova 4, 14000 Praha 4 DENMARK 70 70 19 70 FINLAND 030-6227 515 FRANCE 3260 SAMSUNG(726-7864) or 08 25 08 65 65 (€ 0,15/Min) GERMANY 01805 - SAMSUNG (726-7864) (€...

  • Page 128: Rohs Compliant

    RoHS compliant Our product complies with “The Restriction Of the use of certain Hazardous Substances in electrical and electronic equipment,” and we do not use the 6 hazardous materials- Cadmium(Cd), Lead (Pb), Mercury (Hg), Hexavalent Chromium (Cr +6), Poly Brominated Biphenyls (PBBs), Poly Brominated Diphenyl Ethers(PBDEs)- in our products.

This manual is also suitable for:

Vp-dx10h

Table of Contents
