Digital Video Camcorder
VP-D300/D301(i)/D303(i)/
AF
Auto Focus
CCD
Charge Coupled Device
LCD
Liquid Crystal Display
Owner's Instruction Book
Before operating the unit, please read this
instruction book thoroughly, and retain it for
future reference.
This product meets the intent of
Directive 89/336 CEE, 73/23 CEE, 93/68 CEE.
D303D(i)/D305(i)/
D307(i)
Videocámara digital
VP-D300/D301(i)/D303(i)/
AF
CCD
LCD
Manual de instrucciones
Antes de emplear la cámara, lea
detenidamente este manual de instrucciones
ELECTRONICS
y consérvelo para consultas posteriores.
Este producto cumple con las normas
CEE 89/336, CEE 73/23 y CEE93/68.
ESPAÑOL
D303D(i)/D305(i)/
D307(i)
Autofoco
Dispositivo acoplado por carga
Visualización en cristal líquido
AD68-00752H
