Samsung SMX-K40BP User Manual

Memory camcorder
Hide thumbs Also See for SMX-K40BP:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Memory Camcorder

user manual

imagine
the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please
register your product at
www.samsung.com/register
SMX- K40BP/SMX- K40SP/SMX- K40LP
SMX- K44BP/SMX- K44SP/SMX- K44LP
SMX-K45BP/SMX- K45SP/SMX- K45LP

Advertisement

Table of Contents
loading

Related Manuals for Samsung SMX-K40BP

Summary of Contents for Samsung SMX-K40BP

  • Page 1: User Manual

    Memory Camcorder user manual imagine Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register SMX- K40BP/SMX- K40SP/SMX- K40LP SMX- K44BP/SMX- K44SP/SMX- K44LP SMX-K45BP/SMX- K45SP/SMX- K45LP the possibilities...
  • Page 2 In addition to this slot, the memory camcorder has built-in memory. High-resolution image through Mobile DNIe The Samsung memory camcorder has 3DNR (3-dimensional noise reduction), high-sensitivity colour expression (intelligent colour expression), High performance Anti-Shake (OIS: Optical Image Stabiliser), and automatic face detection features.
  • Page 3 Capturing photo image This function captures a moving subject instantly and saves the scene as a photo image. Time lapse recording catches the moment You can record a long scene in short intervals. Record artistic, documentary videos including the passage of clouds, blooming fl owers etc. Use this function to make UCC (User Created Contents) videos, educational programmes or for other purposes.

  • Page 4: Safety Warnings

    safety warnings What the icons and signs in this user manual mean : Death or risk of serious personal injury. WARNING Potential risk of personal injury or material damage. CAUTION To reduce the risk of fire, explosion, electric shock, or personal injury when using your camcorder, follow these basic safety precautions: CAUTION Hints or referential pages that may be helpful when operating the camcorder.

  • Page 5: Important Information On Use

    Also, Samsung cannot be held responsible for your recorded video and audio. Recorded contents may be lost due to an error when handling this camcorder or memory card, etc. Samsung shall not be held responsible for the loss of recorded contents, and cannot compensate for any damages.
  • Page 6 important information on use Liquid crystal display: • The LCD screen is a product of high precision technology. Out of the total pixels (approx. 230,000 pixels of an LCD monitor ), 0.01% or less pixels may be out (black dots) or may remain lit as coloured dots (red, blue, and green). This shows the limitations of the current technology, and does not indicate a fault that will interfere with recording.
  • Page 7 ABOUT THIS USER MANUAL Thank you for purchasing this Samsung Camcorder. Please read this user manual carefully before you use • the camcorder and keep it handy for future reference. Should your camcorder fail to operate correctly, refer to Troubleshooting.
  • Page 8 NOTES REGARDING TRADEMARK All the trade names and registered trademarks mentioned in this manual or other documentation provided with • your Samsung product are trademarks or registered trademarks of their respective holders. Windows ® is registered trademark or trademark of Microsoft Corporation, registered in the United States and other •...

  • Page 9: Precautions During Use

    precautions during use The safety precautions illustrated below are to prevent personal injury or material damage. Heed all instructions carefully. WARNING Prohibited action. Death or risk of serious personal injury. CAUTION Do not disassemble product. Means that there is a potential risk of personal injury or material damage.
  • Page 10 If the camcorder makes an abnormal sound, or smells or smokes, unplug the power-cord immediately and request service from a Samsung service centre. There is a risk of fire or personal injury. Do not dispose of battery pack in a fire as it may explode.
  • Page 11 CAUTION Do not press the surface of the LCD with force, or hit it with a sharp object. If you push the LCD surface, display unevenness may occur. Do not use the camcorder in direct sunlight or near heating equipment. This will especially shorten the operation range of the remote control which uses infrared rays.
  • Page 12 Noise could enter video or audio that are being recorded. Keep important data separately. Samsung is not responsible for data loss. xii_English Do not place the camcorder with the open LCD screen down.

  • Page 13: Table Of Contents

    contents qUICK START GUIDE GETTING TO KNOW YOUR CAMCORDER PREPARATION ABOUT THE STORAGE MEDIA RECORDING You can record videos in H.264 format! What's included with your camcorder Front & left view Right & top / bottom view Rear view Attaching the grip belt Attaching the core filter Adjusting the LCD screen Connecting a power source...
  • Page 14 contents PLAYBACK RECORDING OPTIONS PLAYBACK OPTIONS 04_English Changing the playback mode Playing videos Viewing photos Changing the menu settings Menu items Using the recording menu items iSCENE Video Resolution Photo Resolution 16:9 Wide White Balance Aperture Shutter Speed EV (Exposure Value) C.Nite Back Light Focus...
  • Page 15 SETTINGS OPTIONS Using the VIEW Story-board print Edit (Divide) Edit (Combine) Slide show Slide show option File info Changing the menu settings in "Settings" Menu items Using the settings menu items Storage Type (SMX-K44/K45 only) Storage Info Format File No. Time Zone Date/Time Set Date Type...
  • Page 16 contents CONNECTING TO OTHER DEVICES USING WITH A WINDOWS COMPUTER MAINTENANCE & ADDITIONAL INFORMATION TROUBLESHOOTING SPECIFICATIONS POWER SOURCES (UNITED KINGDOM ONLY ) 06_English Connecting to a TV Viewing on a TV screen Recording (dubbing ) images on a VCR or DVD/HDD recorder Checking your computer type 101 What you can do with a Windows computer 102 Using the Intelli-studio programme...

  • Page 17: Quick Start Guide

    quick start guide ✪ This quick start guide introduces the basic operation and features of your camcorder. See the reference pages for more information. You can record videos in H.264 format! You can record videos in H.264 format, which enables you to conveniently email and share videos with your friends and family.

  • Page 18: Recording Photos

    quick start guide Step 2: Record with your camcorder LCD screen RECORDING VIDEOS WITH H.264 FORMAT Your camcorder uses advanced H.264 compression technology to realize the clearest video quality. 1. Open the LCD screen to turn on the camcorder. You can also turn the camcorder on by •...
  • Page 19 Step 3: Play back videos or photos VIEWING THE LCD SCREEN OF YOUR CAMCORDER You can fi nd your desired recordings quickly by using the thumbnail index view. 1. Press the MODE button to select the Play mode. The thumbnail index view appears. The thumbnail of the latest created or •...

  • Page 20: Sharing Videos/Photos On Youtube/Flickr

    quick start guide IMPORTING AND VIEWING VIDEOS/PHOTOS FROM THE CAMCORDER TO YOUR PC 1. Launch the Intelli-studio programme by connecting the camcorder to your PC via the USB cable. • A new fi le saving screen appears with the Intelli-studio main window. Click “Yes”, the uploading procedure will start.

  • Page 21: Getting To Know Your Camcorder

    A memory card is not included. See page 38 for memory cards compatible with your camcorder. • Your camcorder includes a user manual CD and a quick start guide (printed). • * : This is an optional accessory. To buy one, contact your nearest Samsung dealer. memory LCD screen Lens...
  • Page 22 getting to know your camcorder FRONT & LEFT VIEW MENU button Control button (//// OK), Zoom (W/T) button Recording start/stop button LCD screen Power ( ) button 12_English Anti-Shake (OIS) ( LCD Enhancer ( EASY Q button Display ( HD OUTPUT switch (ON/OFF) ) button ) button )/ VIEW button...
  • Page 23 RIGHT & TOP / BOTTOM VIEW Zoom lever (W/T) PHOTO button Grip belt Grip belt hook Built-in speaker Internal microphone Be careful not to cover the internal microphone and lens during recording. CAUTION 4 5 6 Battery pack/ Memory card cover ⓐ...

  • Page 24: Rear View

    getting to know your camcorder REAR VIEW ⓐ ⓑ ⓒ ⓓ Mode indicator : Record mode (Video/Photo) : Play mode MODE button Recording start/stop button CHG (charging) indicator 14_English Jack cover ⓐ HDMI jack ( ⓑ USB jack ( ⓒ AV jack (AV) ⓓ...

  • Page 25: Attaching The Core Filter

    preparation This section provides information that you should know before using this camcorder: such as how to use the provided accessories, how to charge the battery, and how to setup the operation mode and initialise setup. ATTACHING THE GRIP BELT Adjust the length of grip belt so that the camcorder is stable when you press the Recording start/stop button with your thumb.

  • Page 26: Connecting A Power Source

    1. Slide and open the battery slot cover as shown in the diagram. 2. Insert the battery pack into the battery slot until it locks. Make sure that the SAMSUNG logo is facing up while • the battery pack is placed as shown in the diagram.

  • Page 27: Charging The Battery

    Charging the battery You can charge the battery using the AC power adaptor or USB cable. 1. Press the Power ( ) button to turn off the camcorder. ➥page 23 2. Insert the battery in the camcorder. ➥page 16 3. Open the connector cover of the unit. 4.

  • Page 28: Battery Level Display

    preparation Charging indicator Tips for battery identifi cation The colour of the LED indicates the charging status. ✪ If the battery has been fully charged, the charge indicator is green. • While the battery is being charged, the charge indicator lights orange. •...
  • Page 29 Mode Playback time - The time is only for reference. Figures shown above are measured under Samsung's test environment, and may differ according to user and condition. - We recommend using the AC power adaptor when using the Time Lapse REC function.
  • Page 30 preparation About the battery pack The benefits of the battery pack: the Battery pack is small but has a large power capacity. It should be recharged • at temperatures between 50°F ~ 86°F (10°C ~ 30°C). However, when it is exposed to cold temperatures (below 32°F (0°C)), its usage time is reduced and it may cease to function.
  • Page 31 Maintaining the battery pack We recommend only using the original battery pack that is available from your Samsung retailer. When the battery • reaches the end of its life, please contact your local dealer. The batteries have to be dealt with as chemical waste.

  • Page 32: Using A Household Power Source

    preparation Using a household power source Make the same connections as you do when charging the battery pack. The battery pack will not lose its charge in this case. Using the camcorder with the AC power adaptor It is recommended that you use the AC power adaptor to power the camcorder from a household AC outlet when you perform settings on it, play back, or use it indoors.

  • Page 33: Basic Operation Of Your Camcorder

    BASIC OPERATION OF YOUR CAMCORDER This section explains the basic techniques of recording videos or photos and also basic settings on your camcorder. Set the appropriate operation mode according to your preference using Power ( Turning the camcorder on or off 1.

  • Page 34: Switching To The Power Saving Mode

    preparation SWITCHING TO THE POWER SAVING MODE If you need to use camcorder for the extended time, the following functions enable you to prevent unnecessary energy consumption. In STBY mode: • The camcorder switches to "Quick On STBY" mode when the LCD screen is closed. In Playback mode (Includes the thumbnail view mode): •...

  • Page 35: Lcd Screen Indicators

    LCD SCREEN INDICATORS 0:00:00 [475Min] STBY 1Sec / Time Lapse Recording +0.3 01/JAN/2009 00:00 1/25 • The above screen is an example for explanation: It is different from the actual display. The on-screen indicators are based on an 16GB SDHC •...
  • Page 36 preparation LCD SCREEN INDICATORS 0:00:00 [475Min] STBY 0:00:00 [475Min] STBY 26_English Video and Photo record mode : Shortcut menu (OK Guide) 9999 Quick View Focus* (Auto Focus/Face Detection/Manual Focus) Shortcut menu (OK Guide) / Return EV (Exposure Value) * iSCENE Video and Photo record mode : Shortcut menu (Manual) Manual Control Bar/ Value...
  • Page 37 Normal View 100-0006 0:00:55 Photo Move 0:00:00/0:00:55 01/JAN/2009 00:00 Video Play mode : Thumbnail View Video Play mode Copy Selected (SMX-K44/K45 only) Storage media (Memory card or built-in memory (SMX-K44/K45 only)) 1/10 Battery info (Remaining battery level) Now / Total fi le number Error File Scroll bar Delete Selected...
  • Page 38 preparation LCD SCREEN INDICATORS 0:00:00/0:00:55 Multi View 0:00:00/0:00:55 01/JAN/2009 00:00 28_English Video Play mode : Shortcut menu (OK Guide) Reverse playback search ➥page 33 ( Skip/Search/Slow motion/Frame-by-frame) Volume Down Play (  Forward playback search ➥page 33 ( Skip/Search/Slow motion/Frame-by-frame) Volume Up 100-0001 Video Play mode : Single (Volume)
  • Page 39 Normal View 100-0001 Video Move 1/10 Multi View Photo Play mode : Thumbnail View Photo Play mode Protection Storage media (Memory card or built-in memory (SMX-K44/K45 only)) 1/10 Battery info (Remaining battery level) Now / Total fi le number Error File Scroll bar Delete Selected Button Guide...

  • Page 40: Turning The Screen Indicators On/Off

    preparation TURNING THE SCREEN INDICATORS ON/OFF ( Switching the information display mode You can switch the on-screen information display mode: • Press the Display ( ) button while the camcorder is on. The full and minimum display modes will alternate. Full display mode: All relevant information will appear.

  • Page 41: Setting The Anti-Shake (Ois: Optical Image Stabilizer

    SETTING THE ANTI-SHAKE (OIS: OPTICAL IMAGE STABILIZER) ( This function works only in Record mode. ➥page 23 • Anti-Shake (OIS) is a function that, within reasonable limits, compensates for shaking • movements produced when fi lming hand-held. Anti-Shake (OIS) provides a more stable image when: - Recording with deep zooming - Recording a close up picture of a small object...

  • Page 42: Shortcut Menu (Ok Guide

    preparation SHORTCUT MENU (OK GUIDE) The Shortcut menu (OK guide) represents the most frequently accessed functions according to the selected mode. ✪ For example: Setting EV (Exposure Value) in the Record mode using the Shortcut menu (OK guide). 1. Press the OK button in STBY mode. The Shortcut menu (OK guide) is displayed.

  • Page 43: Using The Control Buttons

    SHORTCUT FUNCTION USING THE CONTROL BUTTONS Button Record ( - Access the shortcut menu - Confirm selection - Exit the shortcut menu - iSCENE - Zoom (wide) - Focus - Zoom (tele) DOWN LEFT quick View RIGHT ) mode Video Play ( - Shortcut menu (OK guide) is displayed...

  • Page 44: Initial Setting : Time Zone, Date And Time & Osd Language

    preparation INITIAL SETTING : TIME ZONE, DATE AND TIME & OSD LANGUAGE Initial setting is available in all operating modes. • To read the menus or messages in your desired language, set the OSD language. • To store the date and time during recording, set the time zone and date/time. •...
  • Page 45 Selecting the OSD language You can select the desired language to display the menu screen and the messages. 1. Press the MENU button. The menu screen appears. • Press the Control button ( / ) to select "Settings." The menus in "Settings" mode will appear. •...

  • Page 46: About The Storage Media

    about the storage media SELECTING THE STORAGE MEDIA (SMX-K44/K45 ONLY) You can record on the built-in memory or a memory card, so you should select the desired storage media before • starting recording or playback. You can use SDHC cards on your camcorder. •...

  • Page 47: Inserting / Ejecting A Memory Card

    Never format the built-in memory or memory card using a PC. • If you insert a memory card when the camcorder is on, the pop-up message will prompt you automatically to select • the storage type. (SMX-K44/K45 only) If there is no memory card inserted, only the built-in memory will be available. (SMX-K44/K45 only) •...

  • Page 48: Selecting A Suitable Memory Card

    about the storage media SELECTING A SUITABLE MEMORY CARD A memory card is a compact portable storage media. You can use an SDHC memory card. • (Memory cards must be purchased separately.) - You can also use an SD memory card, but recommended that you use an SDHC memory card with your camcorder.
  • Page 49 • Actual formatted capacity may be less as the internal firmware uses a portion of the memory. Samsung is not responsible for data loss due to misuse. • We recommend using a memory card case to avoid losing data from moving and static electricity.

  • Page 50: Recordable Time And Capacity

    about the storage media RECORDABLE TIME AND CAPACITY The following shows the camcorder’s maximum recording time and number of images according to the resolution • / memory capacity. For recording videos and photos, please note the approximate maximum limits. • Recordable time for videos Media Capacity...
  • Page 51 The previous figures are measured under Samsung’s standard recording test conditions and may differ depending • on the test or use condition. The camcorder provides five resolution options for video recordings: • - "TV Super Fine", "TV Fine", "TV Normal", "Web Fine", "Web Normal."...

  • Page 52: Recording Videos

    - If the mode has been changed after the recording or the camcorder is connected USB cable. - If the camcorder has been turned off and on again after the recording. Samsung is not responsible for any loss or damages due to the memory card problem such as saving failures and abnormal •...

  • Page 53: Recording With Ease For Beginners (Easy Q Mode

    • Sound is recorded from the internal stereo microphone on the front of the camcorder. Take care that this microphone is not blocked. Before recording an important video, make sure to test the recording function to check if there is any problem with the audio •...

  • Page 54: Taking Photos

    recording TAKING PHOTOS You can take photos with the PHOTO button. • 1. Open the LCD screen to turn on the camcorder. You can also turn the camcorder on by pressing the Power • Set the appropriate storage media. ➥page 36 •...

  • Page 55: Zooming In And Out

    ZOOMING IN AND OUT Use the zoom function for close-up or wide-angle recording. This camcorder allows you to record using 52x optical power zoom, 65x Intelli-zoom and 2200x digital zoom. To zoom in Slide the Zoom lever towards T (telephoto). •...

  • Page 56: Changing The Playback Mode

    playback You can view recorded videos and photos in thumbnail index view and play them in various ways. • In the thumbnail index view, you can directly select and display a desired image without using fast forwarding and rewinding. This camcorder provides one combined video and photo record mode. You can easily record videos or photos in the •...

  • Page 57: Playing Videos

    PLAYING VIDEOS This function works only in Video Play ( • You can fi nd a desired video image quickly using the thumbnail index view. • 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.

  • Page 58: Adjusting The Volume

    playback If there is no fi le stored to view, the message "Empty" appears. • Video fi les may not playback on the camcorder in the following cases: • - Video fi les edited or renamed on a PC - Video fi les recorded by devices other than the camcorder - Video fi le formats that are supported The built-in speaker automatically turns off when the Audio/Video cable is connected to the camcorder.

  • Page 59: Various Playback Operations

    Various Playback Operations Still playback (pause) ( / ❙❙ Press the OK button during playback. • - To resume normal playback, press the OK button again. Search playback ( During playback, press and hold the Control button () for forward search, •...

  • Page 60: Viewing Photos

    playback VIEWING PHOTOS This function works only in Photo Play ( • You can fi nd and view desired photos quickly using the thumbnail index view. • 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.

  • Page 61: Recording Options

    recording options CHANGING THE MENU SETTINGS You can change the menu settings to customise your camcorder. Access the desired menu screen by following the steps below, then change the various settings. 1. Open the LCD screen to turn on the camcorder. You can also turn the camcorder on by pressing the Power •...
  • Page 62 recording options ✪ Follow the instructions below to use each of the menu items listed after this page. For example: Setting the iSCENE in Record mode. 1. Open the LCD screen to turn on the camcorder. You can also turn the camcorder on by pressing the Power •...

  • Page 63: Menu Items

    MENU ITEMS Accessing items in the menu depends on the operation mode. • For operation details, see the corresponding page. ➥pages 54~68 • Recording menu items Items iSCENE Video Resolution Photo Resolution 16:9 Wide White Balance Aperture Shutter Speed C.Nite Back Light Focus Digital Effect...

  • Page 64: Using The Recording Menu Items

    recording options USING THE RECORDING MENU ITEMS You can the menu items for video or photos recording. SCENE This camcorder automatically sets the shutter speed and aperture according to the subject brightness for optimum recording: You can also specify one of various modes depending on subject conditions, recording environment or purpose of fi lming. item "Auto"...

  • Page 65: Video Resolution

    Video Resolution You can select the resolution of a video to be recorded. This camcorder can record in "TV Super Fine", "TV Fine", "TV Normal", "Web Fine" and "Web Normal" modes. The "TV Fine" mode is set as the factory default. item "TV Super Fine"...

  • Page 66: Wide

    recording options 16:9 Wide You can select the desired LCD display aspect ratio for recording or playback (16:9 Wide/4:3 aspect ratio). item Disables the function. Displays the image in 4:3 aspect ratio. "Off" Select to use the standard display aspect ratio of 4:3 on the screen. Recording and viewing of 16:9 aspect ratio.

  • Page 67: Aperture

    A subject can be recorded under various types of lighting conditions indoors (natural, fl uorescent, candlelight, etc.). • Because the colour temperature is different depending on the light source, the subject tint will differ depending on the white balance settings. Use this function for a more natural result. Reset the white balance if lighting conditions change.

  • Page 68: Shutter Speed

    recording options Shutter Speed The memory camcorder automatically sets the shutter speed depending on the subject brightness. You can also manually adjust the shutter speed according to the scene conditions. item "Auto" The memory camcorder automatically sets the appropriate aperture value. "Manual"...

  • Page 69: Ev (Exposure Value

    EV (Exposure Value) The camcorder usually adjusts the exposure automatically. You can also manually adjust the exposure depending on the recording conditions. Settingtheexposuremanually: When manually setting the exposure, the default setting appears as the value is automatically adjusted according to the environmental light conditions. Press the Control button (...

  • Page 70: C.nite

    recording options C.Nite You can adjust the shutter speed when recording a slow moving object, or record a brighter image in dark places without a compromise in colours. item "Off" Disables the function. "Auto" The memory camcorder automatically adjusts image brightness. "1/25"...

  • Page 71: Focus

    Focus The camcorder usually focuses on a subject automatically (auto-focus). • You can also manually focus on a subject depending on the recording conditions. • item In most situations, it is better to use the automatic focus feature, as it enables you "Auto"...
  • Page 72 recording options Focussingmanuallyduringrecording: This camcorder automatically focuses a subject from close-up to infi nity. However, the correct focus may not be obtained depending on the recording conditions. In this case, use the manual focus mode. 1. Press the Control button (  /  ) to select "Manual." The manual focus adjustment indicator appears.

  • Page 73: Digital Effect

    Digital Effect The digital effect enables you to give a creative look to your recording. • Select the appropriate digital effect for the type of picture that you wish to record and the effect you wish to create. • There are 10 different digital effect options. •...

  • Page 74: Fader

    recording options Fader You can give your recording a professional look by using special effects such as fade in at the beginning of a sequence or fade out at the end of a sequence. item "Off" Disables the function. "In" As soon as you start recording, the fader will be executed.

  • Page 75: Zoom Type

    Zoom Type The memory camcorder offers three types of zoom: optical, intelligent and digital zoom when recording videos. This right side of the bar shows the digital zooming zone. The zooming zone appears when you move the zoom lever. item "OpticalZoom"...

  • Page 76: Time Lapse Rec

    recording options Time Lapse REC • Time Lapse REC records still images at specifi c intervals you can set, and plays them as one video fi le. • This function is useful for observing the movement of clouds, the changes in daylight or blooming fl owers, etc. item "Off"...
  • Page 77 Example of Time Lapse REC Total time for recording Recording interval Time for recording on the storage media (a video clip of Time Lapse REC) 0:00:00/0:01:55 100-0001 • This function is disabled after being used one time. • 25 captured images compose a video of 1 second length. Since the minimum length of a video to be saved by your camcorder is one second, the interval defi nes how long the Time Lapse Recording should be set for.

  • Page 78: Guideline

    recording options Guideline Guideline displays a certain pattern on the LCD screen so that you can easily set the image composition when • recording images. The camcorder provides 3 types of guidelines. • item "Off" Disables the function. "Cross" Records the subject placed in the centre. "Grid"...

  • Page 79: Playback Options

    playback options MENU ITEMS Accessible items in the menu vary depending on the operation mode. • See pages 46-50 for playback information and button operation. • See pages 70-81 for details on menu items during playback. • Playback menu items Items Multi View Option (Thumbnail index view only)

  • Page 80: Multi View Option

    playback options MULTI VIEW OPTION Multi View Option provides sorting thumbnails of recorded video or photos by order of recording, recorded date, and the iSCENE mode which can be used for playback at your preferred order. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.

  • Page 81: Play Option

    PLAY OPTION You can set a specifi c playback style according to your preference. 1. Press the MENU button  Control button ( / ) to select "PlayOption." 2. Select an option by pressing theControlbutton ( / ) and then press the OKbutton.

  • Page 82: Delete

    playback options DELETE You can erase your recordings one by one, or all at once. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media. (SMX-K44/K45 only) ➥page 36 • (If you want to playback images on a memory card, insert a memory card.) 2.

  • Page 83: Protect

    PROTECT You can protect saved important videos (or photos) from accidental deletion. • Protected images will not be deleted unless you release the protection or format the memory. • 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.

  • Page 84: Copy (Smx-K44/K45 Only

    playback options COPY (SMX-K44/K45 ONLY) • Images are copied to the destination storage while original images are left in the source storage. It copies from the currently used memory to another. For example, if the built-in memory was used, • it copies to a memory card.

  • Page 85: Using The View

    USING THE VIEW This function provides the preview of storyboard to be printed, which gives you digest of the recorded video without viewing the whole sequence of it. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.

  • Page 86: Story-Board Print

    playback options STORY-BOARD PRINT This function captures 16 still images arbitrarily from the selected video and saves them into the storage media. It presents a quick overview of your video, helping you to understand the overall topic. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.

  • Page 87: Edit (Divide)

    EDIT (DIVIDE) You can divide a video clip as many times as you want in order to delete a section you no longer need. The videos will be divided in groups of two. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.
  • Page 88 - If the remaining section of the storage media space is less than - Videos recorded or edited by other devices. - Videos transferred to this camcorder by using Samsung Intelli-studio. You can not delete a protected image. You must fi rst release the protect function to delete it. page 73 •...

  • Page 89: Edit (Combine)

    "TVFine" resolution and quality.) - Videos recorded or edited by other devices. - Videos transferred to this camcorder by using Samsung Intelli-studio. • You cannot combine protected images. You must fi rst release the protect function to paste it. page 73 The original video clips will not be preserved.

  • Page 90: Slide Show

    playback options SLIDE SHOW You can playback all the photos stored in the storage media automatically. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media. (SMX-K44/K45 only) ➥page 36 •...

  • Page 91: Slide Show Option

    SLIDE SHOW OPTION You can enjoy a slide show with various effects. 1. Press the MENU button  Control button ( / ) to select "SlideShowOption." 2. Select an option by pressing theControlbutton ( / /  / ) and then press theOKbutton.
  • Page 92 settings options CHANGING THE MENU SETTINGS IN "SETTINGS" You can change the menu settings to customise your camcorder. Access the desired menu screen by following the steps below and change the various settings. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 2.
  • Page 93 MENU ITEMS You can setup the date/time, OSD language and display settings of the camcorder. • Settings menu items ( Record Items mode Storage Type *  Storage Info  Format  File No.  Time Zone  Date/Time Set ...

  • Page 94: Using The Settings Menu Items

    settings options USING THE SETTINGS MENU ITEMS Storage Type (SMX-K44/K45 only) You can record videos (or photos) on the built-in memory or a memory card, so you should select the desired storage media before starting recording or playback. settings Select the built-in memory for storage medium. You can record or play back images on "Memory"...

  • Page 95: File No

    Format Use this function if you want to delete all files completely or to correct problems on the storage media. settings "Memory" Formats the built-in memory. (SMX-K44/K45only) "Card" Formats a memory card. Do not remove the recording medium or perform any other operation (such as turning off the power) during formatting. •...

  • Page 96: Time Zone

    settings options Time Zone You can easily set the clock to the local time when using your camcorder while travelling. settings The clock will be used according to your setting on the"Date/TimeSet" menu. "Home" Select it when using this camcorder for the fi rst time or when returning the clock to your hometown date/time setting.
  • Page 97 Cities used to set the time zone Cities London, Lisbon Rome, Paris, Berlin, Stockholm, Madrid, Frankfurt Athens, Helsinki, Cairo, Ankara Moskva, Riyadh Teheran Abu Dhabi, Muscat Kabul Tashkent, Karachi Calcutta, New Delhi Almaty, Kathmandu Dacca Yangon Bangkok Hong Kong, Beijing, Taipei, Singapore, Manila Seoul, Tokyo, Pyongyang The times are based on Greenwich Mean Time (GMT).
  • Page 98 settings options Date/Time Set Set the current date and time so they can be recorded correctly. ➥page 34 Date Type You can select the desired date type. settings 2009/01/01 Displays the date in the order of year, month (two-digit) and day. JAN/01/2009 Displays the date in the order of month, day and year.

  • Page 99: Lcd Brightness

    Date/Time Display You can set the date and time to display on the LCD screen. • Before you use the “Date/TimeDisplay” function, you must set the date and time. ➥page 34 settings Current date and time information is not displayed. Date Displays the current date.

  • Page 100: Menu Design

    settings options Auto LCD Off To reduce power consumption, the brightness of the LCD screen is automatically dimmed if the camcorder is idle for more than 2 minutes. settings "Off" Disables the function When the camcorder is idle for more than 2 minutes in STBY mode, or for more than "On" 5 minutes when recording a video, the power saving mode starts by dimming the LCD screen.

  • Page 101: Beep Sound

    Beep Sound You can set the beep sound to on/off. If there is a beep sound when operating the menu settings, the setting is turned on. settings "Off" Disables the function "On" When on, a beep will sound every time a button is pressed. TheBeepsound functioniscanceledinthefollowingcases: - During recording, playing - When the camcorder has a cable connection.
  • Page 102 settings options Quick On STBY When you are going to record frequently for an extended time, use the Quick On STBY function. In standby mode, closing the LCD screen will commence the Quick On STBY mode to reduce energy consumption. Once you are ready to record again, this function enables to the camcorder to come on quickly from the power saving mode.

  • Page 103: Default Set

    You can select a desired language to display the menu and messages. ➥page 35 contents contents on-screen display None None on-screen display None None Version Samsung Electronics Co., LTD. S/W 1.00, Jul 7 2009, 22:10:46 MICOM 1.00, JUL 7 2009 Exit Exit Exit English_93...

  • Page 104: Anynet+ (Hdmi-Cec)

    (Anynet+ supported) is automatically turned on. If you do not want to use this Anynet+ function, set the “Anynet+ (HDMI-CEC)” to“Off.” For details on the Anynet+ (HDMI-CEC) function, refer to the user manual of Samsung’s Anynet+ supported TV. • 94_English...

  • Page 105: Connecting To Other Devices

    connecting to other devices You can enjoy high fi delity viewing of your video recorded in SD quality if your TV supports HD quality displaying by set the HDOUTPUT switch on the side of your camcorder to “ON”. This connection is used when up-converting recorded SD- quality images to HD-quality images for playback.
  • Page 106 connecting to other devices WhatisAnynet+function? You can use the same remote control for devices that support the Anynet + function. You can use the Anynet + function if the camcorder is connected with an HDMI cable to an Anynet+ supported TV. For more information, refer to the Anynet+ support TV’s user manual.
  • Page 107 Connectingtoanormal(standarddefi  nition)TV(16:9/4:3) Camcorder Use the provided Audio/Video cable to connect the camcorder to a TV as follows: 1. Connect the provided Audio/Video cable to the Audio/Video cable to the TV. 2. Turn on your TV and set the TV’s input selector to the Input your camcorder is connected to. Refer to the TV’s instruction manual to see how to select the TV input.
  • Page 108 connecting to other devices VIEWING ON A TV SCREEN You can enjoy the enjoy widescreen videos on a HDTV (or a regular TV) after recording videos using the camcorder. 1. Y ou see video from the camcorder on your TV if the connection status is set correctly.
  • Page 109 RECORDING (DUBBING) IMAGES ON A VCR OR DVD/HDD RECORDER You can record (dub) images played back on this camcorder onto other video devices, such as VCRs or DVD/HDD recorders. Use the Audio/Video cable (provided) to connect the camcorder to another video device as shown in the following diagram: Camcorder 1. Turn on the camcorder and press the MODEbutton to select the Play mode.

  • Page 110: Using With A Windows Computer

    using with a Windows computer CHECKING YOUR COMPUTER TYPE This chapter explains how to connect the camcorder to a computer using the USB cable. Checkyourcomputertypebeforeusing!!! To view your recordings on a computer, you need to check your computer type first. Then, take the steps below according to your computer type.

  • Page 111: System Requirements

    WHAT YOU CAN DO WITH A WINDOWS COMPUTER You can enjoy the following operations by connecting your camcorder to your Windows computer by using a USB cable. Main Functions • By using the built-in editing software, ‘Intelli-studio’ on your camcorder, you can enjoy the following operations: - Playing back recorded videos or photos.
  • Page 112 • desired CD-ROM drive that has the Intelli-studio programme in My Computer and run iStudio.exe. When a USB cable is connected, if you have EmoDio (Samsung's MP3 player software) installed on your computer, • the EmoDio software may load fi rst.
  • Page 113 Step2.AbouttheIntelli-studiomainwindow • When the Intelli-studio starts up, thumbnails of videos and photos are displayed in the main window. ❶ ❷ ❸ ❹ ❺ ❽ ❾ ❿   ❻ ❼ 1. Menu items Selects the Desktop or Favorite on the PC. Slide show of the photo files from the PC.
  • Page 114 using with a Windows computer Step3.Playingbackvideos(orphotos) You can play back the recordings conveniently using the Intelli-studio application. 1. Run the Intelli-studio programme. 2. Click the desired folder to display your recordings. • Video (or photo) thumbnails appear on the screen, according to the selected source.
  • Page 115 Step5.Sharingthevideo/photosonline Share your contents with the world by uploading photos and videos directly to a web site with one click. 1. To do this, select “Share” in the main Video window. 2. Click“Add” and move the video or photo (drag and drop) to the sharing window for upload.
  • Page 116 using with a Windows computer Other functions with the Intelli-Studio Importingandviewingthevideo/photosfromyourPC 1. Launch the Intelli-studio programme by double clicking the programme icon on the desktop screen or connect the camcorder to your PC. 2. Click “ImportFolder” to import the video or photo files from your PC.
  • Page 117 InstallingIntelli-studioapplicationonaWindowscomputer • When the Intelli-studio application is installed on a Windows computer, it will run faster after connecting the camcorder to your computer. Moreover, the application can be updated automatically and run directly on the Windows computer. • The Intelli-studio application can be installed on a Windows computer as follows: Click on “Menu”“InstallIntelli-studioonPC.”...

  • Page 118: Transferring Videos/Photos From The Camcorder To Your Computer

    (If you have video or photos recorded on a memory card, insert a memory card.) (SMX-K44/K45 only) 3. Connect the camcorder to the PC with the USB cable. • The “Removable Disk” or “Samsung” window appears on the PC’s screen after a moment. • The removable disk appears when connecting a USB.
  • Page 119 Structureoffoldersandfi  lesonthestoragemedia The folder and fi le structure for built-in memory or memory card is as follows. • Don’t arbitrarily change or remove the folder or fi le name. It may not be playable. • Videos (H.264) ① The SD-quality videos are named as “SDV_####.MP4” and Web videos are named as •...

  • Page 120: Cleaning The Camcorder

    maintenance & additional information MAINTENANCE Your camcorder is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you fulfil any warranty obligations and allow you to enjoy this product for many years. ✪...

  • Page 121: Additional Information

    Do not bring the storage media near objects that have a strong magnetic field or that emit strong electromagnetic waves. Do not store the storage media in locations with high temperature or high humidity. Do not touch the metal parts. CopytherecordedfilestoyourPC.Samsungshallnotberesponsibleforanylostdata. • (ItisrecommendedthatyoucopythedatafromyourPCtoothermediaforstorage.) Amalfunctionmaycausethestoragemediatofailtooperateproperly.Samsungwillnotprovideany •...
  • Page 122 Fully charge the battery pack at least every 6 months when storing the battery pack over a long period of time. Remove from your camcorder when not in use, as these components may use current even when switched off. It is recommended that only genuine Samsung batteries be used in this camcorder. •...

  • Page 123: Using Your Camcorder Abroad

    PAL-system-based TV or an external device having the appropriate Audio/Video jacks. Otherwise, you may need to use a separate video format transcoder (PAL-NTSC format converter). The format transcoder is not provided by SAMSUNG. PAL-compatible countries/regions...

  • Page 124: Troubleshooting

    TROUBLESHOOTING ✪  B efore contacting a Samsung authorised service centre, perform the following simple checks. They may save you the time and expense of an unnecessary call. Warningindicatorsandmessages Power source Message Icon Low Battery The battery pack is almost discharged.
  • Page 125 Message Icon The memory card has some problem and Card Error cannot be recognised. The write protection tab on an memory Card Locked card has been set to lock. The memory card is not supported in this Not Supported Card camcorder.
  • Page 126 Note before sending your camcorder for repair. If these instructions do not solve your problem, contact your nearest Samsung authorised service centre. • Depending on the problem, the camcorder's built-in memory (SMX-K44/K45 only) may need to be initialised or •...
  • Page 127 ✪ If you encounter any problems using your camcorder, check the following before asking for service repair. If these instructions do not solve your problem, contact the nearest Samsung authorised service centre. Symptomsandsolutions Power Symptom The camcorder does not turn on.
  • Page 128 troubleshooting Displays Symptom The TV screen or LCD display has distorted images • or has stripes at the top/ bottom or on the left/right. Unknown image appears on • the LCD screen. Unknown indicator appears • on the screen. The after image remains on •...
  • Page 129 Copy all important recorded files to your PC before formatting. • Samsung shall not be responsible for any loss of data. (It is recommended that you copy the data to your PC or other storage media.) The file may be corrupted.
  • Page 130 troubleshooting Recording Symptom Pressing the Recordingstart/ stop button does not start recording. The actual recording time is less than the estimated time. The recording stops automatically. When recording a subject illuminated by bright light, vertical lines appear. 120_English Explanation/Solution There is not enough free space to record on the the storage media. •...
  • Page 131 Recording Symptom When the screen is exposed to direct sunlight during recording, the screen turns red or black for an instant. During recording, the date/time does not display. The beep sound is not heard. There is a time difference between the point where you press Recordingstart/stop button and the point where the recorded video...
  • Page 132 troubleshooting Adjusting the image during recording Symptom Focus does not adjust automatically. The image appears too bright or flickering, or changes in colour. Playback on your camcorder Symptom Pressing the playback (Play/Pause) button did not start playing. The Skip or Search function does not work properly.
  • Page 133 Connecting to a computer Symptom When using the videos, • a computer does not recognise your camcorder. • • Cannot play a video file properly on a PC. • • • • Intelli-studio does not • function properly. • • The image or sound on your camcorder is not played on •...
  • Page 134 troubleshooting Connecting/Dubbing with other devices (TV, DVD recorder, etc.) Symptom You cannot dub correctly The Audio/Video cable is not connected properly. Make sure that the Audio/Video • using the Audio/Video cable is connected to the proper jack, i.e. to the input jack of the device used for cable.
  • Page 135 Menu Symptom You cannot select greyed items in the current recording/playback mode. • Most of the menu items cannot be selected when you set the EASYQ function. • If there is no storage media inserted, it cannot be selected and will be dimmed on the menu : •...

  • Page 136: Specifications

    specifications Model Name: SMX-K40BP/SMX-K40SP/SMX-K40LP/SMX-K44BP/SMX-K44SP/SMX-K44LP SMX-K45BP/SMX-K45SP/SMX-K45LP Video signal Picture compression format H.264/AVC Format Audio compression format AAC (Advanced Audio Coding) TV Super Fine (about 5.0Mbps), TV Fine (about 4.0Mbps), TV Normal (about 3.0Mbps), Recording resolution Web Fine (about 4.0Mbps), Web Normal (about 3.0Mbps) Image device CCD (Charge Coupled Device) (Max: 800K pixels) Lens...
  • Page 137 Power Sources (United Kingdom Only) The mains lead on the power adapter is supplied with a moulded plug incorporating a fuse. The value of the fuse is indicated on the pin face of the plug and, if it requires replacing, a fuse approved to BS1362 of the same rating must be used.
  • Page 138 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Region Country CANADA North America MEXICO U.S.A ARGENTINE BRAZIL CHILE NICARAGUA HONDURAS COSTA RICA ECUADOR EL SALVADOR Latin America GUATEMALA JAMAICA PANAMA PUERTO RICO REP.
  • Page 139 RoHScompliant Our product complies with “The Restriction Of the use of certain Hazardous Substances in electrical and electronic equipment”, and we do not use the 6 hazardous materials- Cadmium(Cd), Lead (Pb), Mercury (Hg), Hexavalent Chromium (Cr +6), Poly Brominated Biphenyls (PBBs), Poly Brominated Diphenyl Ethers(PBDEs)- in our products.

This manual is also suitable for:

Smx-k44bpSmx-k44lpSmx-k44spSmx-k45lpSmx-k45spSmx-k40lp ... Show all

Table of Contents
