Page 1: User Manual
Memory Camcorder user manual imagine Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register SMX- K40BN/SMX- K40SN/SMX- K40LN SMX- K44BN/SMX- K44SN/SMX- K44LN SMX-K45BN/SMX- K45SN/SMX- K45LN SMX-K400BN/SMX- K400SN/SMX- K400LN the possibilities...
Page 2 SSD (Solid State Drive) adopted as built-in memory (16GB (SMX-K44 only), 32GB (SMX-K45 only)) SSD based on flash memory has been adopted as built-in memory for the camcorder. SSD helps the camcorder boot, read data and operate the software much faster than normal HDD (Hard Disk Drives). Also, SSD is very stable, durable and makes less noise while in operation.
Page 3 You can enjoy viewing your video recorded in SD in HD quality by setting the HD OUTPUT switch on the side of your camcorder to “ON”. This function is used when upconverting SD recordings to HD for playback on a HDTV.
Page 4: Safety Warnings
WARNING Potential risk of personal injury or material damage. CAUTION To reduce the risk of fire, explosion, electric shock, or personal injury when using your camcorder, follow these basic safety precautions: CAUTION Hints or referential pages that may be helpful when operating the camcorder.
Page 5 Also, Samsung cannot be held responsible for your recorded video and audio. Recorded contents may be lost due to an error when handling this camcorder or a memory card, etc. Samsung shall not be held responsible for the loss of recorded contents, and cannot compensate for any damages.
Page 6: Important Safety Instructions
important safety instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE REFFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Warning To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture. Caution Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.
Page 7 CAMCORDER and to protect it from overheating. These openings must not be blocked or covered.Never place your CAMCORDER on a bed, sofa, rug, or other similar surface: on or near a radiator or heat register. This CAMCORDER should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions...
Page 8 When the power-supply cord or plug is damaged. b. If any liquid has been spilled onto, or objects have fallen into the CAMCORDER. c. If the CAMCORDER has been exposed to rain or water. d. If the CAMCORDER does not operate normally...
Page 9 Hg LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. For details see lamprecycle.org, eiae.org, or call 1-800-Samsung (7267864) CALIFORNIA USA ONLY This Perchlorate warning applies only to primary CR...
Page 10: Important Information On Use
Normal brightness will be restored when the temperature inside the camcorder rises. Note that this will have no effect on the image in a storage media, so there is no cause for concern.
Page 11 - Using the camcorder in a place where the temperature is over 104°F (40°C) or lower than 32°F (0°C) may result in abnormal recording/playback. - Do not leave the camcorder on a beach or in a closed vehicle where the temperature is very high for a long time: This could cause a malfunction.
Page 12 ABOUT THIS USER MANUAL Thank you for purchasing this Samsung Camcorder. Please read this user manual carefully before you use • the camcorder and keep it handy for future reference. Should your camcorder fail to operate correctly, refer to Troubleshooting.
Page 13: Precautions During Use
This precaution must be kept. Do not allow water or metal and inflammable matter to No sand or dust! Fine sand or enter the camcorder or AC dust entering the camcorder power adaptor. Doing so may or AC power adaptor could pose a fire hazard.
Page 14 If the camcorder makes an abnormal sound, or smells or smokes, unplug the power-cord immediately and request service from a Samsung service center. There is a risk of fire or personal injury. Do not dispose of battery pack in a fire as it may explode.
Page 15 Doing so may corrode the external or internal terminals, disabling normal operation. Do not use the camcorder on a tripod (not supplied) in a place where it is subject to severe vibrations or impact.
Page 16 Noise could enter video or audio that is being recorded. Keep important data separately. Samsung is not responsible for data loss. xvi_English Do not place the camcorder with the open LCD screen down.
Page 17: Table Of Contents
GETTING TO KNOW YOUR CAMCORDER PREPARATION ABOUT THE STORAGE MEDIA RECORDING You can record videos in H.264 format! What's included with your camcorder Front & left view Right & top / bottom view Rear view Attaching the grip belt Attaching the core filter...
Page 18 contents PLAYBACK RECORDING OPTIONS PLAYBACK OPTIONS 04_English Changing the playback mode Playing videos Viewing photos Changing the menu settings Menu items Using the recording menu items iSCENE Video Resolution Photo Resolution 16:9 Wide White Balance Aperture Shutter Speed EV (Exposure Value) C.Nite Back Light Focus...
Page 19 SETTINGS OPTIONS Using VIEW Story-board print Edit (Divide) Edit (Combine) Slide show Slide show option File info Changing the menu settings in "Settings" Menu items Using the settings menu items Storage Type (SMX-K44/K45 only) Storage Info Format File No. Time Zone Date/Time Set Date Type Time Type...
Page 20 Recording (dubbing ) images on a VCR or DVD/HDD recorder Checking your computer type 101 What you can do with a Windows computer 102 Using the Intelli-studio program 108 Transferring videos/photos from the camcorder to your computer 110 Maintenance 111 Additional information...
Page 21: Quick Start Guide
You can record videos in H.264 format! You can record videos in H.264 format, which enables you to conveniently email and share videos with your friends and family. You can also take photos with your camcorder. Step1: Get ready 1. Insert a memory card.
Page 22: Recording Photos
0:00:00 [475Min] 9999 • Your camcorder is compatible with H.264 recording format, which achieves effi cient coding of high quality video with less capacity. • You can record videos in SD (standard defi nition). The default setting is “TV Fine (720x480/60i).” ➥page 55 •...
Page 23 Simple and fun! Enjoy the various features of Intelli-studio on your Windows computer. Using the Intelli-studio program built in your camcorder, you can import videos/photos into your computer, edit or share the videos/photos with your friends. For details, see page 102.
Page 24: Sharing Videos/Photos On Youtube/Flickr
Share your contents with the world, by uploading photos and videos directly to a web site with a single click. Click on the “Share”  “Upload to Share Site” tab on the browser. The Intelli-studio runs automatically once the camcorder is connected to a Windows computer (when you specify “PC Software: On”).
Page 25: Getting To Know Your Camcorder
WHAT'S INCLUDED WITH YOUR CAMCORDER Your new camcorder comes with the following accessories. If any of these items are missing from your box, call Samsung’s Customer Care Center. ✪ The exact shape of each item may vary by model.
Page 26 FRONT & LEFT VIEW MENU button Control button (//// OK), Zoom (W/T) button Recording start/stop button LCD screen Power ( ) button 12_English Anti-Shake (OIS) ( LCD Enhancer ( EASY Q button Display ( HD OUTPUT switch (ON/OFF)
Page 27: Right & Top / Bottom View
RIGHT & TOP / BOTTOM VIEW Zoom lever (W/T) PHOTO button Grip belt Grip belt hook Built-in speaker Internal microphone Be careful not to cover the internal microphone and lens during recording. CAUTION 4 5 6 Battery pack/ Memory card cover ⓐ...
Page 28: Rear View
REAR VIEW ⓐ ⓑ ⓒ ⓓ Mode indicator : Record mode (Video/Photo) : Play mode MODE button Recording start/stop button CHG (charging) indicator 14_English Jack cover ⓐ HDMI jack ( ⓑ USB jack ( ⓒ AV jack (AV)
Page 29: Attaching The Core Filter
This section provides information that you should know before using this camcorder: such as how to use the provided accessories, how to charge the battery, and how to setup the operation mode and initialize setup. ATTACHING THE GRIP BELT Adjust the length of grip belt so that the camcorder is stable when you press the Recording start/stop button with your thumb.
Page 30: Connecting A Power Source
• Battery pack insertion/ejection It is recommended you purchase one or more additional battery packs to allow continuous use of your camcorder. Inserting the battery pack 1. Slide and open the battery slot cover as shown in the fi gure.
Page 31: Charging The Battery
When charging, if both the USB cable and AC power adaptor are connected, the AC power adaptor will override • the USB. If the camcorder is turned on, the battery will still charge, but more charging time will be needed. It is recommended • you to keep the camcorder turned off while charging.
Page 32: Battery Level Display
Change the battery pack as soon as possible. (fl ickers): The device will be forced to turn off after 3 seconds. Before using the camcorder, charge the battery. • Above fi gures are based on a fully charged battery pack at normal temperature.
Page 33 Mode Playback time - The time is only for reference. Figures shown above are measured under Samsung's test environment, and may differ according to user and condition. - We recommend using the AC power adaptor when using the Time Lapse REC function.
Page 34 To preserve battery power, keep your camcorder turned off when you are not operating it. • To save battery power, you can set the "Auto Power Off" function, which turns off the camcorder if there is no • operation for 5 minutes. To disable this option, change the setting of "Auto Power Off" to "Off." ➥page 91 Do not allow metallic objects to come into contact with the terminals.
Page 35 Maintaining the battery pack We recommend only using the original battery pack that is available from your Samsung retailer. When the battery • reaches the end of its life, please contact your local dealer. The batteries have to be dealt with as chemical waste.
Page 36: Using A Household Power Source
The battery pack will not lose its charge in this case. Using the camcorder with the AC power adaptor It is recommended that you use the AC power adaptor to power the camcorder from a household AC outlet when you perform settings on it, play back, or use it indoors.
Page 37: Basic Operation Of Your Camcorder
To play videos or photos, or edit them. When using this camcorder for the fi rst time When you use your camcorder for the fi rst time or reset it, the time zone screen appears for the startup display. Select your •...
Page 38: Switching To The Power Saving Mode
In Playback mode (Includes the thumbnail view mode): • The camcorder switches to the sleep mode when the LCD screen is closed, and then if idle for more than 20 minutes the camcorder turns off. However, if “Auto Power Off: 5 Min” is set, the camcorder turns off in 5 minutes.
Page 39: Lcd Screen Indicators
It is different from the actual display. • The on-screen indicators are based on an 16GB SDHC memory card capacity. Functions marked with * will not be kept when the camcorder • is turned off and on again. For enhanced performance, the display indications and the •...
Page 40 The illustration to the left shows the EV (Exposure Value) screen. Functions marked with * will not be kept when the camcorder restarts. The shortcut menu (OK guide) represents the most frequently accessed functions according to the selected mode. Pressing the OK button will display a shortcut menu of frequently used functions on the LCD screen.
Page 41 Normal View 100-0006 0:00:55 Photo Move 0:00:00/0:00:55 JAN/01/2009 12:00 AM Video Play mode : Thumbnail View Video Play mode Copy Selected (SMX-K44/K45 only) Storage media (Memory card or built-in memory (SMX-K44/K45 only)) 1/10 Battery info (Remaining battery level) Now / Total fi le number Error File Scroll bar Delete Selected...
Page 42 preparation LCD SCREEN INDICATORS 0:00:00/0:00:55 Multi View 0:00:00/0:00:55 JAN/01/2009 12:00 AM 28_English Video Play mode : Shortcut menu (OK Guide) Reverse playback search ➥page 33 ( Skip/Search/Slow motion/Frame-by-frame) Volume Down Play (  Forward playback search ➥page 33 ( Skip/Search/Slow motion/Frame-by-frame) Volume Up 100-0001 Video Play mode : Single (Volume)
Page 43 Normal View 100-0001 Video Move 1/10 Multi View Photo Play mode : Thumbnail View Photo Play mode Protection Storage media (Memory card or built-in memory (SMX-K44/K45 only)) 1/10 Battery info (Remaining battery level) Now / Total fi le number Error File Scroll bar Delete Selected Button Guide...
Page 44: Turning The Screen Indicators On/Off
The full and minimum display modes will alternate. Full display mode: All relevant information will appear. • Minimum display mode: Only operating status indicators will appear. If the camcorder has warning information, a warning message will appear. • In the menu screen, the Display ( •...
Page 45: Setting The Anti-Shake (Ois: Optical Image Stabilizer
• Firmly hold the camcorder with both hands. It is recommended that you specify Anti-Shake (OIS): Off when using the camcorder on a desk or tripod (not supplied). • When you record images with high magnifi cation and the Anti-Shake (OIS) is set to On in dark locations, after-images •...
Page 46: Shortcut Menu (Ok Guide
preparation SHORTCUT MENU (OK GUIDE) The Shortcut menu (OK guide) represents the most frequently accessed functions according to the selected mode. ✪ For example: Setting EV (Exposure Value) in the Record mode using the Shortcut menu (OK guide). 1. Press the OK button in STBY mode. The Shortcut menu (OK guide) is displayed.
Page 47: Shortcut Function Using The Control Buttons
SHORTCUT FUNCTION USING THE CONTROL BUTTONS Button Record ( - Access the shortcut menu - Confirm selection - Exit the shortcut menu - iSCENE - Zoom (wide) - Focus - Zoom (tele) DOWN LEFT quick View RIGHT ) mode Video Play ( - Shortcut menu (OK guide) is displayed...
Page 48: Initial Setting : Time Zone, Date And Time & Osd Language
Turning the power on and setting the date and time Set the date and time when using the camcorder for the fi rst time. If you do not set date and time, the date and time (time zone) screen appears every time you turn on your camcorder.
Page 49 Selecting the OSD language You can select the desired language to display the menu screen and the messages. 1. Press the MENU button. The menu screen appears. • Press the Control button ( / ) to select "Settings." The menus in "Settings" mode will appear. •...
Page 50: About The Storage Media
• 5. Press the MENU button to exit. Using the built-in memory (SMX-K44/K45 only) Because this camcorder has an embedded 16GB (SMX-K44 only), 32GB (SMX-K45 only) memory, it is not • necessary to buy extra storage media. Using a memory card (not supplied) This camcorder has a card slot for access to SDHC (Secure Digital High Capacity).
Page 51: Inserting / Ejecting A Memory Card
If there is no memory card inserted, only the built-in memory will be available. (SMX-K44/K45 only) • Do not eject a memory card while it is being used in the camcorder. A memory card and its data may be damaged. •...
Page 52: Selecting A Suitable Memory Card
Turning the power off or removing a memory card during operations such as formatting, deleting, recording, and • playback may cause data loss. After you modify the name of a fi le or folder stored in a memory card using your PC, your camcorder may not • recognize the modifi ed fi le.
Page 53 • recognize or are saved by other devices. Note that formatting erases all data on a memory card. If you cannot use a memory card that has been used with another device, format it with your camcorder. • Note that formatting erases all information on a memory card.
Page 54: Recordable Time And Capacity
RECORDABLE TIME AND CAPACITY The following shows the camcorder’s maximum recording time and number of images according to the resolution • / memory capacity. For recording videos and photos, please note the approximate maximum limits. •...
Page 55 The previous figures are measured under Samsung’s standard recording test conditions and may differ depending • on the test or use condition. The camcorder provides five resolution options for video recordings: • - "TV Super Fine", "TV Fine", "TV Normal", "Web Fine", "Web Normal."...
Page 56: Recording Videos
- If the mode has been changed after the recording or the camcorder is connected USB cable. - If the camcorder has been turned off and on again after the recording. Samsung is not responsible for any loss or damages due to the memory card problem such as saving failures and abnormal •...
Page 57: Recording With Ease For Beginners (Easy Q Mode
• Sound is recorded from the internal stereo microphone on the front of the camcorder. Take care that this microphone is not blocked. Before recording an important video, make sure to test the recording function to check if there is any problem with the audio •...
Page 58: Taking Photos
LCD screen brightness and color can be adjusted from the menu. Adjusting the brightness or color of the LCD • screen does not affect the image to be recorded. ➥page 89 Do not turn off the camcorder or remove a memory card when taking photos as it may damage the storage media • or data.
Page 59: Zooming In And Out
ZOOMING IN AND OUT Use the zoom function for close-up or wide-angle recording. This camcorder allows you to record using 52x optical power zoom, 65x Intelli-zoom and 2200x digital zoom. To zoom in Slide the Zoom lever towards T (telephoto).
Page 60: Changing The Playback Mode
In the thumbnail index view, you can directly select and display a desired image without using fast forwarding and rewinding. This camcorder provides one combined video and photo record mode. You can easily record videos or photos in the •...
Page 61: Playing Videos
• You can fi nd a desired video image quickly using the thumbnail index view. • 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media. (SMX-K44/K45 only) ➥page 36 •...
Page 62: Adjusting The Volume
- Video fi les recorded by devices other than the camcorder - Video fi le formats that are not supported The built-in speaker automatically turns off when the Audio/Video cable is connected to the camcorder. (When • connected to external devices, volume adjustment should be done on the connected external device.) You can playback recorded video fi les on a TV or a PC.
Page 63: Various Playback Operations
Various Playback Operations Still playback (pause) ( / ❙❙ Press the OK button during playback. • - To resume normal playback, press the OK button again. Search playback ( During playback, press and hold the Control button () for forward search, •...
Page 64: Viewing Photos
- A photo with its fi le name changed on a PC. - A photo recorded on other devices. - A photo with a fi le format not supported on this camcorder (does not conform to DCF standards). Loading time may vary depending on the size and quality of the selected photo.
Page 65: Recording Options
CHANGING THE MENU SETTINGS You can change the menu settings to customise your camcorder. Access the desired menu screen by following the steps below, then change the various settings. 1. Open the LCD screen to turn on the camcorder.
Page 66 Follow the instructions below to use each of the menu items listed after this page. For example: Setting iSCENE in the Record mode. 1. Open the LCD screen to turn on the camcorder. You can also turn the camcorder on by pressing the Power • 2. Press the MENU button.
Page 67: Menu Items
MENU ITEMS Accessing items in the menu depends on the operation mode. • For operation details, see the corresponding page. ➥pages 54~68 • Recording menu items Items iSCENE Video Resolution Photo Resolution 16:9 Wide White Balance Aperture Shutter Speed C.Nite Back Light Focus Digital Effect...
Page 68: Using The Recording Menu Items
You can the menu items for video or photos recording. SCENE This camcorder automatically sets the shutter speed and aperture according to the subject brightness for optimum recording: You can also specify one of various modes depending on subject conditions, recording environment or purpose of fi lming.
Page 69: Video Resolution
Video Resolution You can select the resolution of a video to be recorded. This camcorder can record in "TV Super Fine", "TV Fine", "TV Normal", "Web Fine" and "Web Normal" modes. The "TV Fine" mode is set as the factory default.
Page 70: Wide
Please set the aspect ratio before recording. The default setting is "16:9 Wide : On." • If you record videos in 4:3 mode, then connect the camcorder to an HDTV via HDMI, your videos will play back in 16:9 mode. •...
Page 71: Aperture
Do not use a colored object when setting white balance: The appropriate tint cannot be set. • Aperture The camcorder adjusts the aperture automatically depending on the subject and recording conditions. You can also manually adjust the Aperture to your preference. item "Auto"...
Page 72: Shutter Speed
Shutter Speed The memory camcorder automatically sets the shutter speed depending on the subject brightness. You can also manually adjust the shutter speed according to the scene conditions. item "Auto" The memory camcorder automatically sets the appropriate aperture value.
Page 73: Ev (Exposure Value
EV (Exposure Value) The camcorder usually adjusts the exposure automatically. You can also manually adjust the exposure depending on the recording conditions. Settingtheexposuremanually: When manually setting the exposure, the default setting appears as the value is automatically adjusted according to the environmental light conditions.
Page 74: C.nite
"Off" Disables the function. "Auto" The memory camcorder automatically adjusts image brightness. "1/30" Record a brighter image by extending the low shutter speed range to "1/30". "1/15" Record a brighter image by fixing the shutter speed to "1/15" in a dark location.
Page 75: Focus
Focus The camcorder usually focuses on a subject automatically (auto-focus). • You can also manually focus on a subject depending on the recording conditions. • item In most situations, it is better to use the automatic focus feature, as it enables you "Auto"...
Page 76 Focusingmanuallyduringrecording: This camcorder automatically focuses a subject from close-up to infi nity. However, the correct focus may not be obtained depending on the recording conditions. In this case, use the manual focus mode. 1. Press the Control button (  /  ) to select "Manual."...
Page 77: Digital Effect
Digital Effect The digital effect enables you to give a creative look to your recording. • Select the appropriate digital effect for the type of picture that you wish to record and the effect you wish to create. • There are 10 different digital effect options. •...
Page 78: Fader
recording options Fader You can give your recording a professional look by using special effects such as fade in at the beginning of a sequence or fade out at the end of a sequence. item "Off" Disables the function. "In" As soon as you start recording, the fader will be executed.
Page 79: Zoom Type
The zooming zone appears when you move the zoom lever. item "OpticalZoom" Only optical zoom is available up to 52x. - The camcorder zooms the full width of the image sensor to obtain a larger zoom range "Intelli-Zoom" without any deterioration in image quality.
Page 80: Time Lapse Rec
recording options Time Lapse REC • Time Lapse REC records still images at specifi c intervals you can set, and plays them as one video fi le. • This function is useful for observing the movement of clouds, the changes in daylight or blooming fl owers, etc. item "Off"...
Page 81 30 captured images compose a video of 1 second length. Since the minimum length of a video to be saved by your camcorder is one second, the interval defi nes how long the Time Lapse Recording should be set for. For example, if you set the interval to “30Sec,”...
Page 82: Guideline
Guideline Guideline displays a certain pattern on the LCD screen so that you can easily set the image composition when • recording images. The camcorder provides 3 types of guidelines. • item "Off" Disables the function. "Cross" Records the subject placed in the center.
Page 83: Playback Options
playback options MENU ITEMS Accessible items in the menu vary depending on the operation mode. • See pages 46-50 for playback information and button operation. • See pages 70-81 for details on menu items during playback. • Playback menu items Items Multi View Option (Thumbnail index view only)
Page 84: Multi View Option
The Multi View Option enables you to sort thumbnails of recorded video or photos in the order of recording, recorded date, and the iSCENE mode for playback. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.
Page 85: Play Option
PLAY OPTION You can set a specifi c playback style according to your preference. 1. Press the MENU button  Control button ( / ) to select "PlayOption." 2. Select an option by pressing theControlbutton ( / ) and then press the OKbutton.
Page 86: Delete
DELETE You can erase your recordings one by one, or all at once. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media. (SMX-K44/K45 only) ➥page 36 •...
Page 87: Protect
Protected images will not be deleted unless you release the protection or format the memory. • 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media. (SMX-K44/K45 only) ➥page 36 •...
Page 88: Copy (Smx-K44/K45 Only
It copies from the currently used memory to another. For example, if the built-in memory was used, it copies to a memory card. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media. (SMX-K44/K45 only) ➥page 36 •...
Page 89: Using View
USING VIEW This function provides a preview of the 16 image storyboard from a selected video to be printed. ➥page 76 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media. (SMX-K44/K45 only) ➥page 36 •...
Page 90: Story-Board Print
This function captures 16 still images arbitrarily from the selected video and saves them into the storage media. It presents a quick overview of your video, helping you to understand the overall topic. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.
Page 91: Edit (Divide)
You can divide a video clip as many times as you want in order to delete a section you no longer need. The videos will be divided in groups of two. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media.
Page 92 - If the remaining section of the storage media space is less than - Videos recorded or edited by other devices. - Videos transferred to this camcorder by using Samsung Intelli-studio. You can not delete a protected image. You must fi rst release the protect function to delete it. ➥page 73 •...
Page 93: Edit (Combine)
"TVFine" resolution and quality.) - Videos recorded or edited by other devices. - Videos transferred to this camcorder by using Samsung Intelli-studio. You cannot combine protected images. You must fi rst release the protect function to paste it. ➥page 73 •...
Page 94: Slide Show
SLIDE SHOW You can playback all the photos stored in the storage media automatically. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 Set the appropriate storage media. (SMX-K44/K45 only) ➥page 36 •...
Page 95: Slide Show Option
SLIDE SHOW OPTION You can enjoy a slide show with various effects. 1. Press the MENU button  Control button ( / ) to select "SlideShowOption." 2. Select an option by pressing theControlbutton ( / /  / ) and then press theOKbutton.
Page 96 You can change the menu settings to customise your camcorder. Access the desired menu screen by following the steps below and change the various settings. 1. Open the LCD screen and then the camcorder is powered on automatically. ➥page 23 2.
Page 97 • • Items marked with * are available only with SMX-K44/K45 models. • Items marked with ** are available only when the camcorder is supplied the power using the battery pack. Play mode (Thumbnail index screen) (Full image display mode)
Page 98: Using The Settings Menu Items
settings options USING THE SETTINGS MENU ITEMS Storage Type (SMX-K44/K45 only) You can record videos (or photos) on the built-in memory or a memory card, so you should select the desired storage media before starting recording or playback. settings Select the built-in memory for storage medium. You can record or play back images on "Memory"...
Page 99: File No
If the recording medium becomes corrupted, format it again. • • DonotformatthestoragemediaonaPCorotherdevice. Make sure to format the storage media on this camcorder. Format the memory card in the following cases: • - before using a new memory card - a memory card formatted/recorded on other devices - when this camcorder cannot read the memory card A memory card with the protection tab set to lock will not be formatted.
Page 100: Time Zone
The clock will be used according to your setting on the"Date/TimeSet" menu. "Home" Select it when using this camcorder for the fi rst time or when returning the clock to your hometown date/time setting. When you visit a different time zone, it allows you to use the local time without changing your "Visit"...
Page 101 Cities used to set the time zone Cities London, Lisbon Rome, Paris, Berlin, Stockholm, Madrid, Frankfurt Athens, Helsinki, Cairo, Ankara Moskva, Riyadh Teheran Abu Dhabi, Muscat Kabul Tashkent, Karachi Calcutta, New Delhi Almaty, Kathmandu Dacca Yangon Bangkok Hong Kong, Beijing, Taipei, Singapore, Manila Seoul, Tokyo, Pyongyang The times are based on Greenwich Mean Time (GMT).
Page 102 settings options Date/Time Set Set the current date and time so they can be recorded correctly. ➥page 34 Date Type You can select the desired date type. settings 2009/01/01 Displays the date in the order of year, month (two-digit) and day. JAN/01/2009 Displays the date in the order of month, day and year.
Page 103: Lcd Brightness
Date/Time Display You can set the date and time to display on the LCD screen. • Before you use the “Date/TimeDisplay” function, you must set the date and time. ➥page 34 settings Current date and time information is not displayed. Date Displays the current date.
Page 104: Menu Design
Auto LCD Off To reduce power consumption, the brightness of the LCD screen is automatically dimmed if the camcorder is idle for more than 2 minutes. settings "Off" Disables the function When the camcorder is idle for more than 2 minutes in STBY mode, or for more than "On"...
Page 105: Beep Sound
When on, the shutter will sound with each press of the PHOTO button. Auto Power Off To save battery power, you can set the "AutoPowerOff"function which turns off the camcorder if there is no operation for a certain period of time.
Page 106 When you are going to record frequently for an extended time, use the Quick On STBY function. In standby mode, closing the LCD screen will commence the Quick On STBY mode to reduce energy consumption. Once you are ready to record again, this function enables the camcorder to come on quickly from the power saving mode. settings "Off"...
Page 107: Default Set
If you set PC Software to on, you can simply use the PC software by connecting the USB cable between the camcorder and your PC. You can download the stored videos and photos stored on the camcorder to your PC’s hard disk. Editing video/photo fi les is also available using the PC software.
Page 108: Anynet+ (Hdmi-Cec)
(Anynet+ supported) is automatically turned on. If you do not want to use this Anynet+ function, set the “Anynet+ (HDMI-CEC)” to“Off.” For details on the Anynet+ (HDMI-CEC) function, refer to the user manual of Samsung’s Anynet+ supported TV. • 94_English...
Page 109: Connecting To Other Devices
nitionvideotransfer. CONNECTING TO A TV You can view the recorded videos and photos on a large screen by connecting the camcorder to an HDTV or normal TV. • Select the HDMI jack on your TV. For more information about the connectors and the connection methods, refer to your •...
Page 110 • on. If you don’t want this function, set “Anynet+(HDMI-CEC)” to “Off.” ➥page 94 Use only the HDMI 1.3 cable when connecting to the HDMI jack of this camcorder. If the camcorder is connected • with other HDMI cables, the screen display may not work.
Page 111 1. Connect the provided Audio/Video cable to the Audio/Video cable to the TV. 2. Turn on your TV and set the TV’s input selector to the Input your camcorder is connected to. Refer to the TV’s instruction manual to see how to select the TV input.
Page 112 You will only hear audio from the camcorder on your TV in Video playback mode. • If you record videos in 4:3 mode, then connect the camcorder to an HDTV via HDMI, your videos will play back in • 16:9 mode.
Page 113 RECORDING (DUBBING) IMAGES ON A VCR OR DVD/HDD RECORDER You can record (dub) images played back on this camcorder onto other video devices, such as VCRs or DVD/HDD recorders. Use the Audio/Video cable (provided) to connect the camcorder to another video device as shown in the...
Page 114: Using With A Windows Computer
Windows computer CHECKING YOUR COMPUTER TYPE This chapter explains how to connect the camcorder to a computer using the USB cable. Checkyourcomputertypebeforeusing!!! To view your recordings on a computer, you need to check your computer type first. Then, take the steps below according to your computer type.
Page 115: System Requirements
WHAT YOU CAN DO WITH A WINDOWS COMPUTER You can enjoy the following operations by connecting your camcorder to your Windows computer by using a USB cable. Main Functions • By using the built-in editing software, ‘Intelli-studio’ on your camcorder, you can enjoy the following operations: - Playing back recorded videos or photos.
Page 116 • desired CD-ROM drive that has the Intelli-studio program in My Computer and run iStudio.exe. When a USB cable is connected, if you have EmoDio (Samsung's MP3 player software) installed on your computer, • the EmoDio software may load fi rst.
Page 117 Selects the Desktop or Favorite on the PC. Slide show of the photo files from the PC. Playback of the video files from the PC. S witches to Library of the PC and connected camcorder. Switches to Edit mode. Switches to Share mode.
Page 118 using with a Windows computer Step3.Playingbackvideos(orphotos) You can play back the recordings conveniently using the Intelli-studio application. 1. Run the Intelli-studio program. 2. Click the desired folder to display your recordings. • Video (or photo) thumbnails appear on the screen, according to the selected source.
Page 119 Step4.Editingvideos(orphotos) With Intelli-studio, you can edit videos or photos in various ways. (Movie Effect, Fine-Tuning, Transition Effect, Insert Text etc.) • To edit a file using the Intelli-studio, ensure to use a copy of the desired file saved in My Computer before clicking on the “Edit” icon. English_105...
Page 120 using with a Windows computer Step5.Sharingthevideo/photosonline Share your contents with the world by uploading photos and videos directly to a web site with one click. 1. To do this, select “Share” in the main Video window. 2. Click“Add” and move the video or photo (drag and drop) to the sharing window for upload.
Page 121 InstallingIntelli-studioapplicationonaWindowscomputer • When the Intelli-studio application is installed on a Windows computer, it will run faster after connecting the camcorder to your computer. Moreover, the application can be updated automatically and run directly on the Windows computer. • The Intelli-studio application can be installed on a Windows computer as follows: Click on “Menu”“InstallIntelli-studioonPC.”...
Page 122: Transferring Videos/Photos From The Camcorder To Your Computer
Windows computer TRANSFERRING VIDEOS/PHOTOS FROM THE CAMCORDER TO YOUR COMPUTER You can transfer or copy recorded data to a Windows computer by connecting the USB cable to the camcorder. Step1.Viewingthecontentsofstoragemedia(built-inmemoryormemorycard) 1. Check the “PCSoftware:Off” setting. 2. Check the storage media.
Page 123 We don't recommend you modify the name of a fi le/folder stored in the storage media using a PC. • If you modify it, this camcorder may not recognise the modifi ed fi les. • You can use your camcorder as a storage device.
Page 124: Cleaning The Camcorder
- Wipe gently with a soft dry cloth. Do not apply excessive force when cleaning, gently rub the surface. - Do not use benzene or thinner to clean the camcorder. The coating of exterior could peel off or the case could deteriorate.
Page 125: Additional Information
Do not use, replace, or store the storage media in locations that are exposed to strong static electricity or electrical noise. Do not turn off the camcorder power or remove the battery or AC power adaptor during recording, playback, or when otherwise accessing the storage media.
Page 126 Fully charge the battery pack at least every 6 months when storing the battery pack over a long period of time. Remove from your camcorder when not in use, as these components may use current even when switched off. It is recommended that only genuine Samsung batteries be used in this camcorder.
Page 127: Using Your Camcorder Abroad
On TV color systems Your camcorder is an NTSC-system-based camcorder. If you want to view your recordings on a TV or to copy it to an external device, it must be an NTSC-system-based TV or an external device having the appropriate Audio/Video jacks.
Page 128: Troubleshooting
TROUBLESHOOTING ✪ B efore contacting a Samsung authorized service center, perform the following simple checks. They may save you the time and expense of an unnecessary call. Warningindicatorsandmessages Power source Message Icon Low Battery The battery pack is almost discharged.
Page 129 Please format The memory card is not formatted. Not formatted. The format of the file is not supported by Format the Card? this camcorder. (Format the memory?) Low speed card. The memory card does not have Please record a lower enough speed to record.
Page 130 Depending on the problem, the camcorder's built-in memory (SMX-K44/K45 only) may need to be initialized or • replaced and the data will be deleted. Be sure to back up the data on the camcorder to other storage media before sending your camcorder in for repair. Samsung cannot guarantee any loss of your data.
Page 131 ✪ If you encounter any problems using your camcorder, check the following before asking for a service repair. If these instructions do not solve your problem, contact the nearest Samsung authorized service center. Symptomsandsolutions Power Symptom The camcorder does not turn on.
Page 132 It can occur when recording or viewing a 16:9-ratio image on a 4:3-ratio TV, or vice versa. For more details, see the display specification. The camcorder is in Demo mode. If you do not want to see Demo images, change the setting of "Demo" to "Off."...
Page 133 Copy all important recorded files to your PC before formatting. • Samsung shall not be responsible for any loss of data. (It is recommended that you copy the data to your PC or other storage media.) The file may be corrupted.
Page 134 Turn off your camcorder and leave it for a while in a cool place. Your camcorder is damp and moist inside (condensation). • Turn off your camcorder and leave it for about 1 hour in a cool place. The estimated recording time may vary depending on contents and features •...
Page 135 The recording stops. You cannot record a photo image. Explanation/Solution Do not leave the camcorder with the LCD screen exposed to direct sunlight. • "Date/TimeDisplay" to on. ➥page 89 • Set the "BeepSound" to "On."...
Page 136 If the temperature inside the camcorder is too high, it cannot function properly. • Turn the camcorder off, wait for a few moments, and turn it on again. • Check if the AC adaptor or battery pack is properly connected and stable.
Page 137 Disconnect the USB cable from the computer and camcorder, restart the computer, then reconnect it correctly. A video codec is needed to play the file recorded on your camcorder. Install or run the built-in edit software (Intelli-studio). Make sure you insert the connector in the correct direction, and connect the USB cable to the USB jack on your camcorder firmly.
Page 138 ➥page 95 General operations Symptom The date and time are Has the camcorder been left unused for a long period of time? • incorrect. The backup built-in rechargeable battery may be discharged. ➥page 34...
Page 139 Menu Symptom You cannot select grayed items in the current recording/playback mode. • Most of the menu items cannot be selected when you set the EASYQ function. • If there is no storage media inserted, it cannot be selected and will be dimmed on the menu : •...
Page 140: Specifications
Model Name: SMX-K40BN/SMX-K40SN/SMX-K40LN/SMX-K44BN/SMX-K44SN/SMX-K44LN SMX-K45BN/SMX-K45SN/SMX-K45LN/SMX-K400BN/SMX-K400SN/SMX-K400LN Video signal NTSC Picture compression format H.264/AVC Format Audio compression format AAC (Advanced Audio Coding) TV Super Fine (about 5.0Mbps), TV Fine (about 4.0Mbps), TV Normal (about 3.0Mbps), Recording resolution Web Fine (about 4.0Mbps), Web Normal (about 3.0Mbps)
Page 141 SAMSUNG LIMITEDWARRANTY SAMSUNG Electronics America Inc. (SEA), warrants that this product is free from defective material and workmanship. SEA further warrants that if product fails to operate properly within the specified warranty period and the failure is due to improper workmanship or defective material, SEA will repair or replace the product at it’s option.
Page 142 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center Samsung Electronics America, inc. 1-800-SAMSUNG (726-7864) www.samsung.com/us RoHScompliant Our product complies with “The Restriction Of the use of certain Hazardous Substances in electrical and electronic equipment”, and we do not use the 6 hazardous materials- Cadmium(Cd), Lead (Pb), Mercury (Hg), Hexavalent Chromium (Cr +6), Poly Brominated Biphenyls (PBBs), Poly Brominated Diphenyl Ethers(PBDEs)- in our products.

This manual is also suitable for:

Smx-k400sn Smx-k400bn Smx-k44bn Smx-k44ln Smx-k44sn Smx-k40bn ... Show all

Samsung SMX-K400LN User Manual

11 What's Included with Your Camcorder

15 Attaching the Grip Belt

36 Selecting the Storage Media (SMX-K44/K45 Only)

Recording Videos

Changing the Playback Mode

51 Changing the Menu Settings

69 Menu Items

Quick Links

user manual

Related Manuals for Samsung SMX-K400LN

Summary of Contents for Samsung SMX-K400LN

This manual is also suitable for:

Table of Contents
