COLOR CCD CAMERA
INSTRUCTION MANUAL
SDC-311
SDC-241
SAMSUNG CCD CAMERA
SERIES
SERIES
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Samsung SDC-241 SERIES
Summary of Contents for Samsung SDC-241 SERIES
-
Page 1: Color Ccd Camera
SALES NETWORK ·SAMSUNG OPTO-ELECTRONICS AMERICA INC. ·SAMSUNG TECHWIN CO., LTD 40 SEAVIEW DIRVE, SECAUCUS N.J OPTICS & DIGITAL IMAGING DIV. 07094, U.S.A. 145-3, SANGDAEWON 1-DONG, JUNGWON-GU, SUNGNAM, KYUNGKI-DO, KOREA TEL : (201) 902-0347 462-121 FAX : (201) 902-9342 TEL : 82 -031-740 - 8121~41 FAX: 82 -031-740 - 8145 www.samsungcctv.com... - Page 2 Thank you for purchasing a SAMSUNG CCD CAMERA. Before operating the camera, confirm the camera model and proper input power voltage. In order that you can understand this manual thoroughly, we'll introduce our model description. SDC-311 Series (410,000 Pixels) •NTSC models •...
-
Page 3: Table Of Contents
Features Electronic Iris Automatic Backlight Compensation Electronic iris shutter is automatically The backlight compensation technology controlled at the speed of allows the camera to find the best picture conditions in any environment 1/60~1/100,000sec(NTSC Models), / and automatically gives a necessary light 1/50~1/100,000sec(PAL Models). -
Page 4: Precautions
Precautions Do not install the camera in extreme Do not install or use the camera in an temperature conditions. environment where the humidity is high. Do use the camera under conditions where It can cause the image quality to be poor. temperatures are within -10°... -
Page 5: Getting To Know Your Camera
Getting to Know Your Camera Front Focal Length Adjusting Knob. Used to adjust Back focal length. Tripod Mounting Bracket Screw Hole. Used to fix Tripod mounting bracket on the top of the camera. Auto Iris Lens Connector. Used to connect Auto iris lens plug. Back Focus Lock Screw. -
Page 6: Instruction Manual
Back AC type Power LED The LED turned on when power is supplied. V. PHASE Used to adjust vertical phase Linelock mode from 0~270 Menu Setup Switch Used to choose the desired menu on or off, select the menu. Power ground. Power Input Terminal It involved power input. -
Page 7: Connection
Connection Lens Lens is not supplied with this camera. Purchase a lens suitable for your environment. This camera accepts auto iris lens, both C- and CS-mount lens. •If the lens is stained with fingerprint or something, the image quality NOTE might be poor. -
Page 8: Installing C/Cs-Mount Lens
Installing C/CS-Mount lens Before mounting a lens, please check whether it is a C-mount or CS-mount lens. The back focus has set for CS-mount lens at the factory. If the mount is changed to the C-mount lens, it may need to be re-adjusted. -
Page 9: Connecting To Monitor
Connecting to Monitor Connect the VIDEO Out jack to the monitor VIDEO In jack. CCD Camera • As a connecting method varies according to instruments, refer to the manual supplied with the instrument. • Connect the cable after power is turned off. •... -
Page 10: Menu Setup
Menu Setup Use the six Setup Menu buttons on the rear of the camera. Menu Setup Switch ① Electonic Shutter speed Control BLC ATW VIDEO ② Flickerless ③ Backlight Compensation ④ Auto White Balance ⑤ LENS Selection ⑥ Sync Mode OFF AWC DC Function of Menu Setup Switch ①... -
Page 11: Troubleshooting
Troubleshooting If you have trouble operating your camera, refer to the following. If the guidelines do not enable you to solve the problem, contact an authorized technician. Problem Solution • Check that the power cord and line connection between the camera and monitor are made properly. -
Page 12: Color Ccd Camera
Weight (Without (Without (Without Lens) Lens) Lens) Accessory Iris jack, Instruction Manual Design and specifications are subject to change without notice. COLOR CCD CAMERA SDC-241 Series SDC-311PA SDC-311PH Item AC 24V~ AC230V~ Power Source 50Hz 50Hz 6.5W 6.5W Power Consumption...
