Samsung SCL 610 Owner's Instruction Book

Video camcorder 8mm color lcd
Hide thumbs Also See for SCL 610:
Table of Contents

Advertisement

Quick Links

ENGLISH

Video Camcorder

8mm
COLOR LCD
SCL610/L630/L650
Hi
SCL610/L630/L650
Owner's Instruction Book
Before operating the unit, please read
this instruction book thoroughly, and retain it for
future reference.
ELECTRONICS
US

Advertisement

Table of Contents
loading

Related Manuals for Samsung SCL 610

Summary of Contents for Samsung SCL 610

  • Page 1: Video Camcorder

    ENGLISH Video Camcorder COLOR LCD SCL610/L630/L650 SCL610/L630/L650 Owner’s Instruction Book Before operating the unit, please read this instruction book thoroughly, and retain it for future reference. ELECTRONICS...

  • Page 2: Table Of Contents

    ENGLISH Contents Notices and Safety Instructions Getting to Know Your Camcorder Features...12 Descriptions Front View/Side View/Rear View ...13, 14, 15 OSD (On Screen Display) ...16 Accessories Supplied with the Camcorder...18 Remote Control...19 Self Timer Recording ...19 Preparing Adjusting the Hand Strap and Shoulder Strap ...20 Lithium Battery Installation ...21...
  • Page 3 Setting the Speaker ON/OFF ...59 DSE in PLAYER mode ...59 Multi Playback (Using the PAL60 System) ...60 Maintenance Cleaning and Taking care of the Camcorder ...61 Cleaning the Viewfinder ...61 Cleaning the LCD Panel ...61 Cleaning the Video Heads ...61 Storing the Camcorder...61...

  • Page 4: Notices And Safety Instructions

    Notices regarding rotation of LCD screen Please rotate the LCD screen carefully as illustrated. Unintended rotation may cause damage to the inside of the hinge that connects the LCD screen to the Camcorder. 1) LCD screen closed. 2) Standard recording by using the LCD screen.
  • Page 5 When you take the camcorder from cool temperature inside to hot temperature outside during the summer. 2) If the “DEW” protection feature is activated, leave the camcorder in a dry, warm room with the cassette compartment opened and the battery removed.
  • Page 6 To preserve battery power, keep your camcorder turned off when you are not operating it. When your camcorder is in CAMERA mode, if it is left in STANDBY for more than 5 minutes without operation, it will automatically turn off to protect against unexpected battery discharge.
  • Page 7 Do not use a wet type cassette cleaner. It may damage the video heads. (see page 61) 5 minutes off timer in STANDBY mode To protect against tape and head-drum wear, your camcorder will automatically turn off if it is left in STANDBY mode without operation for more than 5 minutes.

  • Page 8: Safety Instructions

    8. ACCESSORIES: Do not place this CAMCORDER on an unstable cart, stand, tripod, bracket or table. The CAMCORDER may fall, causing serious injury to a child or adult, and serious damage to the unit.
  • Page 9 CAMCORDER and to protect it from overheating. These openings must not be blocked or covered. Never place your CAMCORDER on a bed, sofa, rug, or other similar surface: on or near a radiator or heat register.
  • Page 10 When the power-supply cord or plug is damaged. b. If any liquid has been spilled onto, or objects have fallen into the CAMCORDER. c. If the CAMCORDER has been exposed to rain or water. d. If the CAMCORDER does not operate normally...
  • Page 11 ENGLISH Notices and Safety Instructions NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

  • Page 12: Getting To Know Your Camcorder

    This mode enables even the beginner to easily make a recording. (see page 37) Multi PLAYBACK (PAL60) PAL60 is a special output signal format with which a tape recorded on this camcorder (NTSC format) can be viewed on a PAL TV.

  • Page 13: Front View/Side View/Rear View

    Getting to Know Your Camcorder Front View 3. PLAY/STILL (LIGHT) 2. EDIT (REW) 6. TAPE EJECT 13. VIDEO LIGHT 1. LENS 9. Remote Sensor 8. MIC 1. Lens (see page 67) 2. EDIT (REW) EDIT works in STANDBY mode. (see page 28) REW works in PLAYER mode.
  • Page 14 ENGLISH Getting to Know Your Camcorder Side View 24. BLC 23. FADE 20. SPEAKER 22. LCD Open 14. MENU ON/OFF (see page 30) MENU ON/OFF works in CAMERA and PLAYER mode. 15. ENTER (MF) (see page 30) ENTER works in MENU mode.
  • Page 15 30. Hand Strap (see page 20) 31. POWER Switch (see page 22) - CAMERA : Select to record. - OFF : Select to turn off the camcorder. - PLAYER : Select to playback. 32. START/STOP (see page 28) START/STOP works in CAMERA mode.

  • Page 16: Osd (On Screen Display)

    ENGLISH Getting to Know Your Camcorder OSD (On Screen Display) You can turn the OSD on/off by setting the Display menu on/off. The TITLE, DATE/TIME, EASY and CUSTOM functions can be operated even after the OSD is turned off. The OSD is displayed in the viewfinder and the LCD monitor.
  • Page 17 Indicates the recorded title you have set. It is superimposed on the scene. Self diagnosis (see page 63) (TAPE, TAPE END) Checks the operation of the Camcorder. m. DSE (Digital Special Effect) (see page 44) Indicates the DSE mode is activated.

  • Page 18: Accessories Supplied With The Camcorder

    ENGLISH Getting to Know Your Camcorder Accessories Supplied with Camcorder Make sure that the following basic accessories are supplied with your camcorder. Basic Accessories 1. AC Power Adapter. (see page 22) 2. AC cord. (see page 22) 3. Battery Pack. (see page 23) 4.

  • Page 19: Remote Control

    Getting to Know Your Camcorder Remote Control (SCL650 only) Description of Buttons 1. Start/Stop (see page 27) 2. Self Timer 3. Still (see page 58) 4. WIDE (see page 34) 5. TELE (see page 34) 6. Display (see page 16)

  • Page 20: Preparing

    It is very important to adjust the hand strap for better recording. The hand strap enables you to: - Hold the camcorder in a stable, comfortable position. - Press the Zoom and the red Record button without having to change the position of your hand.

  • Page 21: Lithium Battery Installation

    The lithium battery maintains the clock function, title and preset contents of the memory; even if the battery pack or AC power adapter is removed. The lithium battery for the camcorder lasts about 8~10 months under normal operation from the time of installation.

  • Page 22: Connecting The Power Source

    The LCD monitor is turned on automatically when it’s opened more than 30 degrees. Note: If the adapter is used next to a TV or the camcorder, it may cause the TV or camcorder to emit noise. Move the adapter away from the TV, camcorder or the antenna cable.

  • Page 23: To Use The Battery Pack

    On for a second and off for a second: Indicates there is an error. Reset the battery pack and DC cable. 5. If recharging is completed, separate the camcorder, AC power adapter, and battery pack. Even if the power is turned off, battery will be discharged.

  • Page 24: Using The Battery Pack

    ENGLISH Preparing Using the Battery Pack Continuous recording time table based on model and battery type. SCL610 Model Battery LCD ON, Type EVF OFF Approximately SB-L110A 90 minutes Approximately SB-L160 130 minutes Approximately SB-L320 260 minutes The continuous recording times given in the table are approximate. Actual recording time depends on usage.

  • Page 25: Battery Level Display

    25°C(77°F). As the environmental temperature and conditions may be different when you actually use the camcorder, the remaining battery time may not be the same as the approximate continuous recording times given in these instructions.

  • Page 26: Inserting And Ejecting A Cassette

    ENGLISH Preparing Inserting and Ejecting a Cassette There are several cassette types, depending on: Color system used Recording/playback time. Inserting and Ejecting a Cassette Check to see if the battery pack is in place or the AC adapter is connected. 1.

  • Page 27: Basic Recording

    Make sure the battery level indicates that there is enough remaining power for recording. (see page 25) We recommend that beginners, who are using the camcorder for the first time, switch the EASY mode on. (see page 37) a. To start recording, press the red START/STOP button.
  • Page 28 LCD. When a cassette is loaded and the camcorder is left in STANDBY mode for over 5 minutes without being used, it will turn off automatically. To use it again, push the red START/STOP button or set the power switch to OFF and then back to CAMERA.

  • Page 29: Hints For Stable Image Recording

    (refer to figure) Recording with the LCD monitor 1. Hold the camcorder firmly using the hand strap. (see page 20) 2. Place your right elbow against your side. 3. Place your left hand under or next to the LCD to support and adjust it.

  • Page 30: Adjusting The Lcd

    Basic Recording Adjusting the LCD Your camcorder is equipped with a 2.5 inch color Liquid Crystal Display (LCD) screen, which allows you to view recording or playback directly. Depending on the conditions in which you are using the camcorder (indoors or outdoors for example),...

  • Page 31: Adjusting Focus Of The Viewfinder

    Basic Recording 9. Turn the UP/DOWN dial to adjust the LCD color setting. 10. Press ENTER. For further adjustment, repeat steps 7, 8, 9. 11. Press the MENU ON/OFF button to end the setting. Notes: If you don't press a button within 30 seconds, the setting will disappear. The MENU ON/OFF function will not operate in EASY or CUSTOM mode.

  • Page 32: Playing Back A Tape On The Lcd

    You can see the video you recorded on the LCD. To stop the PLAY operation, press the Note: You can also monitor the picture on a TV screen, after connecting the camcorder to a TV or VCR. (see page 56) (STOP) button. (STOP) button.

  • Page 33: Adjusting The Lcd During Play

    When you use the LCD monitor while playing back, you can hear sound from the Speaker. Volume of the Speaker is controlled by the UP/DOWN dial tab on the camcorder. If you close the LCD monitor, the LCD monitor and Speaker are turned off.

  • Page 34: Advanced Recording

    ENGLISH Advanced Recording Zooming In and Out Zoom works in CAMERA mode only. Zooming is a recording technique that lets you change the size of the subject in the picture. For more professional looking recordings, do not use the zoom function too often. You can also choose from two zoom speeds to suit different needs : Gradual zoom (9~12 seconds from TELE/WIDE to WIDE/TELE) High-Speed zoom (3~6 seconds from TELE/WIDE to WIDE/TELE)

  • Page 35: Digital Zoom

    Advanced Recording Digital Zoom Digital Zoom works in CAMERA mode only. Zooms more than 22x are performed digitally. The picture quality deteriorates as you go towards the “T” side. We recommend that you use the DIS (SCL630/L650) feature with the DIGITAL ZOOM for picture stability.
  • Page 36 ENGLISH Advanced Recording Setting the DIGITAL ZOOM ON/OFF (SCL630/L650) The DIGITAL ZOOM feature is explained on page 35. 1. Set the power switch to CAMERA mode. (see page 22) 2. Press the MENU ON/OFF button. The MENU list will appear. 3.

  • Page 37: Easy Mode (For Beginners)

    Battery level, recording mode, counter, date/time, DIS ( ) will be displayed as the camcorder starts to run. The word “EASY” will appear on the LCD at the same time. However, the Date/Time will only be seen if it has been previously set.

  • Page 38: Custom-Creating Your Own Customized Recording Settings

    ENGLISH Advanced Recording CUSTOM-Creating your own customized recording settings You can customize the settings and save them for future use. The CUSTOM function only operates in CAMERA mode. 1. Set the power switch to CAMERA mode. 2. Press the MENU ON/OFF button, to bring up the MENU list. 3.

  • Page 39: Dis (Digital Image Stabilizer, Scl630/L650 Only)

    The DIS function works in CAMERA mode only. DIS (Digital Image Stabilizer) is a handshake compensation function that compensates for any shaking or moving of the hand holding the camcorder (within reasonable limits). It provides more stable pictures when: Recording in the Zoom In mode...

  • Page 40: Mf/Af (Manual Focus/Auto Focus)

    In the following situations, you should obtain better results by adjusting the focus manually. a. A picture containing several objects, some close to the camcorder, others further away. b. A person enveloped in fog or surrounded by snow. c. Very shiny or glossy surfaces like a car.

  • Page 41: Blc

    Advanced Recording 4. Turn the UP/DOWN dial up or down until the object is focused. 5. You will obtain a sharp picture after zooming out. 6. To return to AF(Auto Focus), press the MF button again. Note: The MF function will not operate in EASY, CUSTOM or MENU mode.

  • Page 42: Program Ae (Automatic Exposure)

    ENGLISH Advanced Recording PROGRAM AE (Automatic Exposure) The PROGRAM AE function works in the CAMERA mode only. The PROGRAM AE modes allow you to adjust shutter speeds and aperture to suit different recording conditions. They give you creative control over the depth of the field. There are 6 automatic exposure modes.
  • Page 43 Advanced Recording Setting the PROGRAM AE(Automatic Exposure) mode 1. Set the power switch to CAMERA mode. 2. Press the P.AE button, the ( 3. Press the P.AE button until the appropriate symbol is displayed. No Display : Full Auto mode. Notes: The screen status that is changed by the P.AE button will be recorded on the tape.

  • Page 44: Dse (Digital Special Effects) In Camera Mode

    ENGLISH Advanced Recording DSE (Digital Special Effects) in CAMERA mode The digital effects enable you to give a creative look to your recording by adding various special effects. Select the appropriate digital effect for the type of picture that you wish to record. There are several DSE modes.
  • Page 45 Advanced Recording Selecting and recording DSE effects 1. Set the power switch to CAMERA mode. 2. Press the DSE button, GHOST or SEPIA will be displayed. 3. Keep pressing the DSE button, until the desired mode is displayed. 4. Press the START/STOP button to start recording. 5.

  • Page 46: Setting And Recording Date/Time

    ENGLISH Advanced Recording Setting and Recording the DATE/TIME Setting and recording the date/time feature works in the CAMERA mode only. You can record the date/time on your tapes, so you will know when it was made. The date and time are recorded whenever they are displayed on the viewfinder or LCD.
  • Page 47 4. Press the START/STOP button to record the DATE/TIME on your recording. Notes: If your date and time settings are not maintained in the camcorder, it means the installed LITHIUM BATTERY is discharged. (see page 21) You cannot conceal the recorded date or time during playback.

  • Page 48: Selecting And Recording A Title

    Selecting and Recording a Title Selecting and recording a TITLE is possible in the CAMERA mode only. The TITLE feature allows you to select a preset title stored in the camcorder’s memory. You can also select the language of the titles.
  • Page 49 9. Press ENTER. The selected title will appear on the screen for 2 ~ 3 seconds and will disappear. At the same, the camcorder will return to the menu mode. Recording a Title Note: Make sure that you have selected a TITLE from the TITLE list.

  • Page 50: Fade In And Out

    ENGLISH Advanced Recording Fade In and Out The FADE function works in CAMERA mode only. You can give your films a professional look by using special effects such as fading in and out at the beginning or end of a sequence. To Start Recording 1.

  • Page 51: Pip

    Advanced Recording PIP (Picture-In-Picture, SCL630/L650 only) The PIP(Picture-In-Picture) feature works in combination with the DIGITAL ZOOM function by using a small, superimposed screen to show an image that is wider than the image being recorded. This should help you to get a more clear idea of what you are recording. The PIP function works in CAMERA mode only.

  • Page 52: Snap Shot

    At this time, be careful not to shake your camcorder because the image will be blurred. 3. After the SNAP SHOT button has been pressed, your camcorder will record the still image for 6 seconds, then automatically return to STANDBY mode.

  • Page 53: White Balance

    Advanced Recording White Balance WHITE BALANCE is a recording function that preserves the unique color of the object in any recording condition. You may select the appropriate WHITE BALANCE mode to obtain good quality color of the image. AUTO: This mode is generally used to control the WHITE BALANCE automatically. INDOOR: Controls WHITE BALANCE according to the indoor ambience.

  • Page 54: Demonstration

    ENGLISH Advanced Recording Demonstration Demonstration automatically shows you the major functions that are included with your camcorder so that you may use them more easily. The DEMO function is only available in CAMERA mode when you are not recording. The Demonstration operates repeatedly until the POWER switch is set to OFF.

  • Page 55: Lighting Techniques

    Advanced Recording Lighting Techniques When you use your camcorder, there are only two possible recording environments. You will be recording outdoors (Normal recording or through an ND(Neutral Density) filter). You will be recording indoors (Video light recommended or required). The single greatest influence on picture quality is the level of brightness, measured in lux.

  • Page 56: Playing Back A Tape

    The white plug: Audio(L) Connecting to a TV which has no Audio and Video input jack You can connect your camcorder to a TV through a VCR. Set the input selector on the VCR to LINE. The yellow plug: Video...
  • Page 57 Notes: Vibration from the built-in speaker can cause picture distortion. It is best to turn the built-in speaker off when your camcorder is connected to the TV. The system (Hi8/8mm) is selected automatically, depending on the tape format. SCL610/L630/L650 can play back both Hi8 and 8mm tapes.

  • Page 58: Various Functions In Player Mode

    Press (PLAY/STILL) button during playback. To resume playback, press Note: Your camcorder will automatically stop if it is left for more than 5 minutes in STILL mode without operation in order to prevent tape and head-drum wear. To locate a scene (picture search)

  • Page 59: Adjusting The Lcd

    Please refer to pages 44 and 45. Note: The GHOST, STROBE, NEG., MIRROR, MOSAIC, CINEMA and WIDE(16:9) effects will not operate when your camcorder is in PLAYER mode. Pressing the DSE button will scroll through the available settings. Stop at the one you require.

  • Page 60: Multi Playback (Using The Pal60 System)

    Playing back the Tape Multi Playback (using the PAL60 System) This Camcorder can convert an NTSC tape recorded in the SP mode to the “PAL60” format, allowing you to view it on a PAL TV which has Vertical sync adjustment circuitry for 60Hz.

  • Page 61: Maintenance

    2. Keep the camcorder in a ventilated, dry and warm place. 3. Do not keep the camcorder in a place where the temperature often changes, such as in a car. 4. Keep the camcorder in a stable place.

  • Page 62: Using Your Camcorder Abroad

    Before using your camcorder abroad, check the following: Power sources You can use your camcorder in any country or area that uses 100V to 240V, 50/60 Hz. Use a commercially available AC plug adapter, if necessary, depending on the power used.

  • Page 63: Troubleshooting

    camcorder.

  • Page 64: Checking

    Troubleshooting Checking If you run into any problem using the camcorder, use the following table to troubleshoot the problem. If these instructions do not allow you to solve the problem, take a note of: The model and serial number marked on the bottom of the camcorder.
  • Page 65 Explanation/Solution The contrast between the subject and the background is too great for the camcorder to operate normally. Make the back- ground bright to reduce the contrast or use the BLC function while you are recording. (see page 41) The use of VIEWFINDER is recommended when recording under sunlight.

  • Page 66: Moisture Condensation

    If the camcorder is brought directly from a cold place to a warm place, moisture may condense inside the camcorder, on the surface of the tape, or on the lens. In this condition, the tape may stick to the head drum and be damaged or the unit may not operate correctly.

  • Page 67: Specifications

    Specifications These technical specifications and design may be changed without notice. System Recording system Video signal Usable cassette Tape speed Speed mode Recording time FF or REW time Image device Optical zoom ratio Focal length: f Filter diameter Focus system Macro Min.

  • Page 68: Index

    ENGLISH Index - A - ABROAD ...62 AC POWER ADAPTER ...22 ADJUSTING ...30 AF ...40 AUDIO ...56 AUTO FOCUSING ...40 AUTO MODE...42 AUTO POWER OFF...28 - B - BATTERY ...23 BATTERY LEVEL ...25 BATTERY PACK...23 BLC...41 BRIGHTNESS ...30 - C - CAMERA ...22 CASSETTE...26 CASSETTE HOLDER...15...
  • Page 69 Index - O - OPERATION MODE...17 OSD...16 - P - PIP...51 PLAY...57 PLAYER...57 PORTRAIT MODE...42 POWER CONSUMPTION ...67 POWER REQUIREMENT ...67 POWER SWITCH...22 PROGRAM AE ...42 - R - RECHARGING ...23 REMOTE CONTROL...19 REW (REWIND) ...58 - S - SAFETY INSTRUCTIONS...4 SAND/SNOW MODE...42 SELF-30S ...19 SELF-END ...19...

  • Page 70: Warranty

    SEA will repair or replace the product at it’s option. All warranty repairs must be performed by a SEA authorized service center. The name and address of the location nearest you can be obtained by calling toll free: 1-800 SAMSUNG (1-800-726-7864). Labor 90 days carry-in...
  • Page 71 THIS CAMCORDER IS MANUFACTURED BY: ELECTRONICS SAMSUNG Electronics America Inc. 105 Challenger Road Ridgefield Park N.J 07660-0511 Tel: 1-800-SAMSUNG (1-800-726-7864) *Samsung Electronics’ Internet Home Page http://www.samsungusa.com AD68-00334B...

This manual is also suitable for:

Scl650Scl630
