- Page 1 Hotronix ® 40x50 cm O P E R A T O R ’ S M A N U A L www.stahls.eu...
- Page 2 Hotronix Air Fusion™ ® Table of Content Machine View Safety Instructions Touch Screen Guide / Connecting the System Hotronix Air Fusion™ Operating Instructions 6-17 ® Start Up / Shut Down Print Screen Passwords Preset Setup 10-11 Date & Time Setup / Display Setup Display Setup cont.
-
Page 3: Machine View
Hotronix Air Fusion™ ® Machine View Upper Safety ON/OFF Platen Connect Switch Lower Platen Circuit Breaker Touch Print & IEC Inlet Screen Hose Buttons Stand Height Adjustment Power Quick Cord Release Platen Release Base Caster Foot Pedal Stand Model Only Table Top Model Only... -
Page 4: Safety Instructions
Hotronix Air Fusion™ ® Safety Instructions Important Safety Instructions WHEN USING YOUR APPLIANCE, BASIC PRE-CAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING: Read all instructions. Use appliance only for its intended use. To reduce the risk of electric shock, do not immerse the appliance in water or other liquids. Never pull cord to disconnect from outlet, instead grasp plug and pull to disconnect. -
Page 5: Touch Screen Guide
Hotronix Air Fusion™ ® Touch Screen Guide Navigation Most screens have a Cancel or Back button to close the current screen without saving any changes and will return the user to the previous screen. (Fig.1) Some screens may present a list of items. When the list of items is larger than can be displayed on a single screen a left and/or right arrow appears on the left or right side of the screen. -
Page 6: Connecting The System
Hotronix Air Fusion™ ® Operating Instructions Connecting the System Connecting the System Connect the power cord into the IEC inlet located in the back of the Press. Connect the opposite end of the cord into a properly grounded electrical outlet with a sufficient amperage rating. (1.1) Voltage 220 Volt - A full 10 amp grounded circuit is required for 220 volt operation. - Page 7 (2.4). The system will exit the Shutdown screen and return to the Main Menu. (2.5) Once the platen has cooled below 100° F (38° C), a screen saver will display, showing the Stahls Hotronix logo and ® START button. (2.6)
-
Page 8: Print Screen
Hotronix Air Fusion™ ® Operating Instrucitons Print Screen The Print Screen is the first screen displayed after the splash screen and start up has completed. This screen provides all the printing functions. Presets Saved Presets are displayed at the top of the Print Screen. These are pre-programmed heat application settings that allow you to quickly and accurately change your print settings for specific materials. - Page 9 Hotronix Air Fusion™ ® Operating Instructions Print Screen Cont. Target Settings Cont. To change your Time Settings, press the Target Timer display located on the right side of your print screen. A pop up menu will be displayed. Press the minus or plus icons to decrease or increase the time (Press and hold to change values faster).
- Page 10 Hotronix Air Fusion™ ® Operating Instructions Print Screen cont. Tack Mode When Tack Mode is enabled, the platen is lowered as long as both print buttons are pressed and held. Touch the tack button to toggle the Tack mode. A green check mark indicates the Tack Mode is enabled.
-
Page 11: Preset Setup
Hotronix Air Fusion™ ® Operating Instructions Preset Setup After your password is entered in the setup menu, press the Preset Setup icon. (5.1). This option will allow you to edit, delete, and create new Presets. A preset can have: • 1 Preset Name •... - Page 12 Hotronix Air Fusion™ ® Operating Instructions To Create a New Preset cont. Note: A DELETE button will appear after saving if you do not wish to save. (5.8) Press the BACK button until you return to the Print Screen. The message “Saving Settings! Please wait...”...
-
Page 13: Display Setup
Hotronix Air Fusion™ ® Operating Instructions Date & Time Setup The Date and Time Setup feature allows you to program the Month, Day, Year, Hour and Minute (displayed in the lower right corner of the Print Screen). To set the Date and Time, press the Date &... - Page 14 Hotronix Air Fusion™ ® Operating Instructions Display Setup cont. Press the Pressure field (psi or bar) to toggle between psi and bar. (7.2) Press the SAVE button to save your changes. (7.3) Select the BACK button to return to the Setup menu. (7.4) Auto On and Off Setup The system can turn On or Off automatically when configured.
-
Page 15: Password Setup
Hotronix Air Fusion™ ® Operating Instructions Auto On and Off Setup cont. Select the SAVE button to save the settings. (8.6) Note: Selecting another day of the week or exiting the Auto On and Off Setup screen without saving will result in loss of changes. -
Page 16: Language Setup
Hotronix Air Fusion™ ® Operating Instructions Language Setup („Manager Level“ Only) When logged in at a “Manager Level”, the display Language may be changed in the Setup menu. Choose from eight languages: English, Deutsch, Espanol, Francais, Italiano, Japanese, Pyccko, and Chinese. In the Setup Menu, Select the Language Button. - Page 17 Hotronix Air Fusion™ ® Operating Instructions System Setup cont. („Manager Level“ only) Fan Status Select the On/Off status display to toggle the cooling fan to the desired state On or Off. This is useful for testing the operation of the cooling fan. (11,2) Power Save Status With the Power Save Status turned on, the system will auto- matically shut down after 4 hours of innactivity to save power.
- Page 18 Hotronix Air Fusion™ ® Operating Instructions Prepare to Print To begin Printing/Pressing, start by verifying that you have the proper settings selected in the Print Screen: • Do you have the correct preset selected? Note: You may also manually adjust your desired Time, Tempera- ture and Pressure settings (refer to Target Settings on pg 8-9).
-
Page 19: Parts Replacement List
Hotronix Air Fusion™ ® Parts Replacement List Item # Part Name Part # Qty. Control Housing 1-2197 Switch On/Off Lighted 1-2087 Switch, Quick Release 1-2270 Switch, Print - Blue 1-2271 Touch Screen Controller 1-2266 Control Housing Overlay 1-2198 Power Cord 2-1013-1 Upper Casting 3-1341... - Page 20 Hotronix Air Fusion™ ® Parts Location Guide...
- Page 21 Hotronix Air Fusion™ ® Parts Location Guide...
-
Page 22: Electrical Schematic
Hotronix Air Fusion™ ® Electrical Schematic Control Board Out to Left Print Switch Out to Right Print Switch Triac Out to Air Regulator White Black J4 Mate-N-Lock 9 Pin Power Connector Power ON/OFF Switch White Out to Quick Release Black Heater Wire Proximity Switch Heater Wire... - Page 23 STAHLS’ Europe GmbH will have the logo/brand of STAHLS’ Hotronix clearly marked upon them. Contact: STAHLS’ Europe GmbH, Dieselstraße 62, 66763 Dillingen, Germany Telefon: +49 (0) 68 31/97 33-0, Fax: +49 (0) 68 31/97 33 45, www.stahls.de, info@stahls.de...
-
Page 24: Terms Of Guarantee
Any exchanged parts will be the property of STAHLS’ Europe GmbH. No charge will be made for any labour or components for any claim under the warranty. STAHLS’ Europe GmbH operates a “bring in”...
