OWNER'S INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D'UTILISATION
MANUAL DE INSTRUÇÕES
ISTRUZIONI PER L'USO
AW127JE/B
AW126JE/B
AW147JB
AW146JB
AW12A6(A7)JD
AW12A6(A7)JA
WC12ZR
Window-type Room Air Conditioner
( Cool )
Acondicionador de aire doméstico sistema de tipo ventana
( Refrigeración )
Climatiseur de type Fenêtre
( Refroidissement )
O ar Condicionado de Window-Type
( Refrigeração )
Condizionatore d'aria per ambienti da finestra
( Raffreddamento )
E S F P I
DB68-30875B(3)
Advertisement
Table of Contents
Related Manuals for Samsung AW126JE/B
Summary of Contents for Samsung AW126JE/B
- Page 1 OWNER’S INSTRUCTIONS MANUAL DE INSTRUCCIONES MANUEL D’UTILISATION MANUAL DE INSTRUÇÕES ISTRUZIONI PER L’USO AW127JE/B AW126JE/B AW147JB AW146JB AW12A6(A7)JD AW12A6(A7)JA WC12ZR Window-type Room Air Conditioner ( Cool ) Acondicionador de aire doméstico sistema de tipo ventana ( Refrigeración ) Climatiseur de type Fenêtre...
-
Page 2: Safety Precautions
The following safety precautions must be taken when installing and using your air conditioner. The air conditioner must be plugged into its own specific power source, which must be installed in compliance with national wiring, earthing and safety regulations. Depending on national regulations and your specific installation, you may need to install: A circuit breaker For further information on electrical requirements, contact a professional electrician. -
Page 3: Table Of Contents
Switching the Unit Off Automatically (Off Timer) ... 11 Cancelling the Off Timer ... 11 ECOMMENDATIONS Operating Recommendation ... 12 Temperature and Humidity Ranges ... 12 Cleaning Your Air Conditioner ... 13 Solving Common Problems ... 14 Installing a Filter ... 15 Technical Specifications ... 15 ... 16... -
Page 4: Air Conditioning Unit - Main Parts, Buttons And Display
Air Conditioning Unit - Main Parts, Buttons and Display The design and shape are subject to change according to the model. Inner air flow blades (right/left orientation) Outer air flow blades (up/down orientation) Air inlet (inside) Air filter (The air filter is located inside) Remote control sensor Operating mode indicators ON/OFF &... -
Page 5: Remote Control Buttons
Remote Control - Buttons Timer setting buttons Operating mode selection (FAN, COOL) buttons Temperature adjustment ON/OFF Button buttons Fan speed adjustment Air flow blade swing button buttons... -
Page 6: Getting Started
Getting Started You have just purchased a window-type room air conditioner and it has been installed by your installation specialist. Your Owner’s Instructions contain much valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit’s features. -
Page 7: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries You must insert or replace the remote control batteries when: You purchase the air conditioner The remote control does not work correctly Use two LR03 (R03) 1.5 V batteries. Do not use old batteries or different kinds of batteries together. -
Page 8: Cooling Your Room
The air conditioner starts up in the mode selected when the unit was last used. The unit beeps twice. The air conditioner is fitted with a protection mechanism to prevent the unit from being damaged when it is started immediately after being:... -
Page 9: Airing Your Room
Result: The operating mode indicator (COOL or FAN) on the unit comes on. The air conditioner starts up in the mode selected when the unit was last used. The unit beeps twice. If the FAN indicator is not lit up on the unit:... -
Page 10: Adjusting The Air Flow Direction Horizontally
Depending on the position of the unit in your room, you can adjust the orientation of the inner air flow blades on the right-hand side of the unit, thus increasing the efficiency of the air conditioner. Press the button on the remote control. -
Page 11: Switching The Unit Off Automatically (Off Timer)
Switching the Unit Off Automatically (Off Timer) You can set the timer to switch the air conditioner off automatically at a given time. Example: You wish to switch the unit off two hours after you have gone to bed. If necessary, press the (On/Off) button. -
Page 12: Operating Recommendation
Here is a recommendation that you should follow when using your air conditioner. Topic Power failure Temperature and Humidity Ranges The following table indicates the temperature and humidity ranges within which the air conditioner can be used. Mode Indoor Temperature Cooling 21°C to 32°C approx. -
Page 13: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner To get the best possible use out of your air conditioner, you must clean it regularly by two weeks to remove the dust on the air filter. Before cleaning your air conditioner, ensure that it is switched off and unplugged from the wall socket. -
Page 14: Solving Common Problems
Odours are permeated in the room during air conditioning Explanation/Solution Check that the circuit breaker used for the air conditioner has not been triggered. Check that the power cable is plugged into a wall socket and the socket is switched on, if necessary. -
Page 15: Installing A Filter
Installing a Filter The air conditioner can be fitted with an Electrostatic filter to remove minute dust particles. The service life of the filter is approximately three months depending on the time during which the air conditioner is used. Remove the vinyl packing from the filter. -
Page 16: Method Of Installation
If it is weak, reinforcement work should be performed separately. It is advisable to install the air conditioner in the north or west side to prevent the effect of direct sunlight. When installing it in the south or east side due to unavoidable circumstances, it is advisable to install the sunshade to prevent the direct sunlight. - Page 17 In the case of an area where the drain pan can not be directly installed on the rear side of the unit after installing the air conditioner. Example: High storage Open the front grille ; refer to page 13.
