OWNER'S
INSTRUCTIONS
AW05NCM7
AW06NCM7
Window-type Room Air Conditioner (Cooling)
E S
DB98-6609A
DB98-26609A.indd
21
2006-10-12
10:19:15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AW05NCM7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Samsung AW05NCM7

  • Page 1 OWNER'S INSTRUCTIONS AW05NCM7 AW06NCM7 Window-type Room Air Conditioner (Cooling) DB98-6609A DB98-26609A.indd 2006-10-12 10:19:15...
  • Page 2: Safety Precautions

     Do not place any obstacles in front of the unit. Do not spray liquid of any kind into the indoor unit. Should this happen, switch off  the breaker used for your air conditioner and contact your installation specialist.
  • Page 3: Table Of Contents

    OPERATING YOUR AIR CONDITIONER Cooling Your Room ...  Ventilating Your Room ...  Switching the Air Conditioner Off ...  Adjusting the Air Flow Direction Horizontally ...  RECOMMENDATIONS FOR USE Power Failure ...  Temperature and Humidity Ranges ... ...
  • Page 4: Description Of Each Component

    Power Control selector Fan Mode selector DB98-26609A.indd CAUTION If the Reset button of the power plug operates, the air conditioner starts cooling operation after 2~3 minutes. Air outlet Air inlet (Outside) Air filter (Inside) Power plug (The type of the power plug may differ, depending on the local power supply).
  • Page 5: Getting Started

    Owner's Instructions. Your Owner's Instructions contain much valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit's features. The illustrations in the step-by-step procedures use four different symbols: ...
  • Page 6: Cooling Your Room

    Cooling temperature  Fan speed when Cooling  To switch the unit on, simply press the Power Control selector to the "On" position. Result: The air conditioner starts operating. Turn the Thermostat dial and set it to " 1 ~ 10 ".
  • Page 7: Switching The Air Conditioner Off

    Depending on the position of the unit in your room, you can adjust the orientation of the inner air flow blades on the unit. Adjust the air flow blades to the desired position by pushing them side to side. DB98-26609A.indd...
  • Page 8: Power Failure

    Lower temperatures Higher humidity levels DB98-26609A.indd If a power failure occurs, the air conditioner is switched off. When the power comes back on, the air conditioner will start up automatically. Indoor Temperature Outdoor Temperature 70°F to 90°F approx. 70°F to 110°F approx.
  • Page 9: Cleaning Your Air Conditioner

    Remove all dust on the air filter with a vacuum cleaner or brush. When you have finished, insert the air filter back into its original position. Wipe the surface of the unit with a neutral detergent and then wipe it again with a dry cloth.
  • Page 10: Solving Common Problems

     -When the number on the THERMOSTAT dial is too high, the room temperature may be too warm. Check to see whether there is an open window or other leakage of cool  air to the outside. - Close the window and fill the gap.
  • Page 11: Technical Specifications

    Technical Specifications Design and specifications are subject to change without notice. Model Power Supply AW05NCM7 5V ~ , 60 Hz AW06NCM7 DB98-26609A.indd 2006-10-12 10:19:05...
  • Page 12: Installation

    INSTALLATION MANUAL Window-Type room air conditioner DB98-26609A.indd 2006-10-12 10:19:06...
  • Page 13  the air conditioner after reading this supplement. The weight and size of the unit may make it too difficult for you to install by yourself.  If you feel you can install the air conditioner, this guide will assist you towards a safe installation.
  • Page 14: Preparation For Installation

    1 Carefully remove the unit from the packing case, lay it on the floor and check that all accessories (as indicated on page 16) are enclosed. 2 Check the cabinet and front grille of the unit for any defects such as scratches.
  • Page 15 Install the air conditioner in a window where there will be enough  clearance around the cabinet to allow ample circulation of air through the unit.  All supporting parts should be secured to firm wood, masonry, or metal. Width Models AW05NCM7 55.9cm to 91.4cm...
  • Page 16 DB98-26609A.indd Type B(Qty-9) Type C(Qty-2) Remove the backing from the top support channel seal strip and attach it to the bottom of the top support channel. Install the top support channel with three Type B screws provided. The screw holes are of larger gauge on the channel and smaller on the cabinet.
  • Page 17: Attach The Seal Strip To The Window

    Place the air conditioner cabinet into the window with the top support channel positioned just in front of the bottom sash. Center the cabinet side to side in the window, then pull the window down until it rests on the air conditioner, just behind the mounting channel front flange on top of the cabinet.
  • Page 18 Check for air leaks and seal. 10 Plug in the power cord on the air conditioner. Turn the air conditioner on and operate it in Cool mode and check for unusual vibrations.
  • Page 19 If you need to remove the front grille for replacement, follw the steps below. Open the front grille by pulling the tabs on both sides of the grille. Then lift it up slightly to open the front grille completely. Remove the screw that holds the grille in place.
  • Page 20: Limited Warranty To Original Purchaser

    One (1) Year Parts and Labor, Five (5) Years Parts Warranty for Compressor This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. Warranty repairs must be performed by SAMSUNG's authorized service center. To receive warranty service, the original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center.
