SERVO 260
FUSE
6A/250V
CAUTION
;
REPLACE WITH
THE SAME TYPE FUSE AS
INDICATED. UTILISER UN
~AC INPUT
FUSIBLE DE RECHANGE DE
115V/60Hz, 490W
MEME TYPE.
USE CLASS 2 WIRING MINIMUM LOAD IMPEDANCE 4
+RIGHT
GROUND
LEFT+
The Servo 260 power amplifier is designed for
fixed installations, recording and live performance use.
Easily installed, this compact, 2-space rack-mount stereo
power amplifier delivers 130 watts per channel into a 4
ohm load, over a bandwidth of 20 Hz to 50 kHz. The
260 features high-current output power transistors with
a bipolar design and servo circuitry that continuously
keeps DC output during idling at or near 0 volts. It also
features balanced 1/4" Tip-Ring-Sleeve inputs as well as
push-spring terminal outputs, front-panel clip, idle and
protection lights and thermal and overcurrent protec-
tion circuitry. The Servo 260 is convection cooled for
silent operation, eliminating both fan noise and the
need for filter maintenance. Housed in a rugged steel
chassis, the Servo 260 uses high-quality component to
ensure safe, reliable performance in all applications.
Contact:
Samson Technologies Corp., P.O. Box 9031, Syosset, NY 11791-9031 • Phone: (516) 364-2244 • Fax: (516) 364-3888 • www.samsontech.com
POWER
A M P L I F I E R
CLIP
SAMSON
STUDIO AMPLIFIER 120 WATT STEREO
IDLE
MAX
SERVO 260 STUDIO AMPLIFIER
CAUTION
!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
HEATSINK MAY BE HOT!
DO NOT BLOCK AIRFLOW
OR OVERHEATING MAY
OCCUR.
S/N
LEFT
RIGHT
CLIP
PROTECTION
IDLE
POWER
• Rack-mount stereo power amplifier (2-space).
• 130 watts per channel into 4 ohms (stereo).
• 20 Hz to 50 kHz frequency response.
• Balanced 1/4 TRS and unbalanced RCA inputs and push-
spring terminal outputs.
• 1/4 and push-spring terminal outputs.
• Turn-on muting to prevent speaker "thumps. "
• Servo protection circuitry continuously keeps DC output
during idling at or near 0 V (thus keeping idle speakers at
their 0 point).
• Protection circuitry against overheating and
overcurrent.
• High-current output power transistors.
• Unique bipolar circuit design.
• Front-panel clip, idle and protection lights.
• Independent left- and right-channel input controls with
41-position detents.
• Convection cooled (No Fan).
• All-steel chassis with new black matte titanium finish and
anodized aluminum heat sink.
MAX
SAMSON
TO PREVENT SHOCK DO NOT
OPEN. NO USER SERVICABLE
PARTS INSIDE. REFER SERVICING
T O Q U A L I F I E D S E R V I C E
PERSONNEL. TO PREVENT FIRE
OR SHOCK HAZARD DO NOT
EXPOSE TO RAIN OR MOISTURE.
R
L
(UNBALANCED 10K /0dBM)
RIGHT
LEFT
INPUTS
(BALANCED 10K /0dBM)
