INSTALLATION INSTRUCTIONS
O
i
riginal
nstructiOns
c
g
e
D
Ommercial
as Or
lectric
ryer
m
mDe20PDagW, mDe20PnagW, mDe20mnagW, mDe20csagW,
ODels
mDg20PDagW, mDg20PnagW, mDg20mnagW, anD mDg20csagW
INSTRUCTIONS D'INSTALLATION
i
'
nstructiOns D
Origine
s
-l
À
É
èche
inge
gaz Ou
lectrique À usage cOmmercial
m
mDe20PDagW, mDe20PnagW, mDe20mnagW, mDe20csagW,
ODèles
mDg20PDagW, mDg20PnagW, mDg20mnagW, anD mDg20csagW
INSTRUCCIONES DE INSTALACIÓN
i
nstrucciOnes Originales
s
ecaDOra a gas O elÉctrica cOmercial
m
mDe20PDagW, mDe20PnagW, mDe20mnagW, mDe20csagW,
ODelOs
mDg20PDagW, mDg20PnagW, mDg20mnagW, anD mDg20csagW0
ISTRUZIONI D'INSTALLAZIONE
i
struziOni Originali
a
sciugatrice a gas O elettrica cOmmerciale
m
mDe20PDagW, mDe20PnagW, mDe20mnagW, mDe20csagW,
ODelli
mDg20PDagW, mDg20PnagW, mDg20mnagW, anD mDg20csagW
www.maytagcommerciallaundry.com
W10868681A
Advertisement
Table of Contents
Related Manuals for Maytag MDE20PNAGW
Summary of Contents for Maytag MDE20PNAGW
- Page 1 INSTALLATION INSTRUCTIONS riginal nstructiOns Ommercial as Or lectric ryer mDe20PDagW, mDe20PnagW, mDe20mnagW, mDe20csagW, ODels mDg20PDagW, mDg20PnagW, mDg20mnagW, anD mDg20csagW INSTRUCTIONS D’INSTALLATION ’ nstructiOns D Origine À É èche inge gaz Ou lectrique À usage cOmmercial mDe20PDagW, mDe20PnagW, mDe20mnagW, mDe20csagW, ODèles mDg20PDagW, mDg20PnagW, mDg20mnagW, anD mDg20csagW INSTRUCCIONES DE INSTALACIÓN...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE DES MATIÈRES DRYER SAFETY ................3 SÉCURITÉ DU SECHE-LINGE ........... 28 FOR THE OWNER POUR LE PROPRIÉTAIRE MAINTENANCE INSTRUCTIONS ..........6 INSTRUCTIONS D’ENTRETIEN ..........31 IF YOU NEED ASSISTANCE ............6 SI VOUS AVEZ BESOIN D'ASSISTANCE ......31 FOR WHIRLPOOL AUTHORIZED SERVICE PERSON POUR LE PERSONNEL D’ENTRETIEN AUTORISÉ... -
Page 3: Dryer Safety
DRYER SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... - Page 4 DRYER SAFETY It is recommended that the owner post, in a prominent location, instructions for the customer’s use in the event the customer ■ smells gas. This information should be obtained from your gas supplier. Post the following warning in a prominent location. ■...
- Page 5 DRYER SAFETY IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the dryer, follow basic precautions, including the following: Read all instructions before using the dryer. The appliance is intended, but not limited, to be used in ■...
-
Page 6: If You Need Assistance
IF YOU NEED ASSISTANCE If you need help, contact the dealer from whom you purchased the appliance, or a Maytag designated service company. When calling, please know the purchase date and the complete model and serial number of your appliance. This information will help us to better respond to your request. -
Page 7: Tools & Parts
TOOLS & PARTS Tools Needed: 203 mm (8") 203 mm (8") or 254 mm (10") Flat-Blade Screwdriver Phillips Screwdriver or 254 mm (10") Adjustable Wrench Pipe Wrench that opens to 25 mm ( 1") Torx T-20 Security 25 mm (1") Hex-Head 8 mm ( 5⁄16") Socket Wrench Pliers (that open to †... -
Page 8: Dimensions/Clearances
DIMENSIONS/CLEARANCES Dimensions Side View Back View 743 mm 686 mm ") (27") 660 mm (26") Electric 210 mm 343 mm ") ") 914 mm 1042 mm 273 mm (36") (41") ") (electric models) 38 mm 953 mm ") ") 102 mm 889 mm (gas models) (4"... -
Page 9: Dryer Installation Requirements
DRYER INSTALLATION REQUIREMENTS (Australia and New Zealand – for full details of installation requirements refer to AS/NZS 5601.1) Location Requirements Recessed Area and Closet Installation Instructions This dryer may be installed in a recessed area or closet. For recessed area and closet installations, minimum clearances can be found on the warning label on the rear of the dryer or in “Dimensions/Clearances.”... -
Page 10: Installing Leveling Legs And Coin Box
INSTALLING LEVELING LEGS AND COIN BOX The console houses the electronic control board. The board is The meter case houses the factory-installed accumulator timer factory set for a dry time of 30 minutes. Consult the tech sheet with actuating arm or service switch. found inside the dryer toe panel to reset dry time and for other The service door lock and key and coin box lock and key options. -
Page 11: Leveling
LEVELING Leveling your dryer properly reduces excess noise and vibration. 2. Grip dryer from top and rock back and forth, making sure all four legs are firmly on floor. Repeat, rocking dryer from side to side. If dryer rocks, go to Step 3 and adjust leveling legs. 1. -
Page 12: Electric Dryer Installation Requirements
ELECTRIC DRYER INSTALLATION REQUIREMENTS Electrical Requirements Electric Shock Hazard IMPORTANT: Observe all governing codes and ordinances. This is 3-wire appliance which must be earthed. This dryer is supplied without an electric cord and plug. It Do not earth to a gas pipe. must be connected by a Whirlpool authorized service person Failure to follow these instructions could result in to a single-phase electricity supply at the voltage shown... -
Page 13: Gas Dryer Installation Requirements
GAS DRYER INSTALLATION REQUIREMENTS Electrical Requirements EARTHING INSTRUCTIONS IMPORTANT: Observe all governing codes and ordinances. You will need a grounded electrical outlet located within 610 mm (2 feet) of either side of the dryer. This dryer is supplied/fitted with an electrical supply cord and plug. - Page 14 GAS DRYER INSTALLATION REQUIREMENTS Gas Supply Supply line requirements: Provide a rigid gas supply line to the dryer location. It should be minimum 12.5 mm (1/2") ID. When acceptable to the gas supplier and local codes, 10 mm (3/8") ID rigid supply line may be used for lengths under 6.1 m (20').
- Page 15 DRYER VENTING REQUIREMENTS Elbows: 45° elbows provide better airflow than 90° elbows. ■ Good Better Clamps: Use clamps to seal all joints. ■ Exhaust vent must not be connected or secured with screws ■ WARNING: To reduce the risk of fire, this dryer MUST BE or other fastening devices that extend into interior of duct EXHAUSTED OUTDOORS.
- Page 16 DRYER VENTING REQUIREMENTS Vent Hoods 102 mm (4") Diameter Exhaust Hoods Exhaust hood must be at least 305 mm (12") from the ground or any object that may be in the path of the exhaust (such as flowers, rocks, bushes, or snow). Box Hood Louvered Hood Angled Hood...
- Page 17 DRYER VENTING REQUIREMENTS If an Exhaust Hood Cannot be Used Multiple Dryer Venting The outside end of main vent should have a sweep elbow A main vent can be used for venting a group of dryers. The directed downward. main vent should be sized to remove 5663 l/min. (200 CFM) of air per dryer.
- Page 18 TECHNICAL SPECIFICATIONS – GAS DRYER 220–240V~50Hz 1ph 3A max. IP24 Clothes capacity: 9.0 kg max. Sound pressure level, Lpa: 58 dBA (uncertainty, Kpa: +/-10 dBA) Total mass: 68 kg max. Factory set for NATURAL GAS: Injector size: 2.2 mm Heat input gross: 5.9 kW Country: CH, CZ, CY, ES, GB, GR, CY, CZ, DK, EE, FI, GR, HU,...
-
Page 19: Complete Installation
COMPLETE INSTALLATION 6. Check dryer operation. Close dryer door. Set the cycle. 1. Check the electrical requirements. Be sure that you have Operating time will accumulate per number of coins. the correct electrical supply and the recommended earthing method. See “Electrical Requirements.” Using a full heat cycle (not the air cycle), let the dryer run for at least five minutes. -
Page 20: Reversing Dryer Door Swing
REVERSING DRYER DOOR SWING (OPTIONAL) You can change your door swing from a right-side opening 7. Be certain to keep cardboard spacer centered between doors. Reattach outer door panel to inner door panel so to left-side opening, if desired. handle is on the side where hinges were just removed. Remove the Door Assembly 1. - Page 21 ELECTRONIC CONTROL SETUP INSTRUCTIONS (PD & PN MODELS ONLY) Accumulator Pricing IMPORTANT If the price is set to one coin 1, then accumulator pricing Electrostatic Discharge (ESD) is in effect. Cycle time can be purchased one coin at a time up to the maximum time of 99 minutes.
- Page 22 ELECTRONIC CONTROL SETUP INSTRUCTIONS (PD & PN MODELS ONLY) Control Set-up Procedures Set-Up Codes IMPORTANT: Read all instructions before operating. The NORMAL button will advance you from code to code. ■ The fabric setting buttons along with the digital display are The HEAVY DUTY button will change the code value.
- Page 23 ELECTRONIC CONTROL SETUP INSTRUCTIONS (PD & PN MODELS ONLY) OPTIONS 3.XX – 9.XX TO USE IF SPECIAL PRICING Code Explanation IS SELECTED Code Explanation 1. 00 MONEY COUNTER OPTION This option is either NOT SELECTED “OFF” or 3.06 SPECIAL CYCLE PRICE SELECTED “ON.”...
- Page 24 ELECTRONIC CONTROL SETUP INSTRUCTIONS (PD & PN MODELS ONLY) Code Explanation Code Explanation 7. 00 SPECIAL PRICE START HOUR b. 05 VALUE OF COIN 1 NOTE: Uses military time or 24 hr. clock. b. 05 This represents the value of coin 1 in number of nickels: 05 = $0.25.
- Page 25 ELECTRONIC CONTROL SETUP INSTRUCTIONS (PD & PN MODELS ONLY) END of SET-UP PROCEDURES Code Explanation EXIT FROM SET-UP MODE PAYMENT MODE (COIN/DEBIT OPTION) J. Cd Single-Load Models: Reinstall access door. J. Cd Both coin and debit selected. Press the DELICATES DIAGNOSTIC GUIDE button 3 consecutive times to change this selection.
- Page 26 DRYER DISPOSAL MODEL NOMENCLATURE: – Maytag Gas – Coin Slide A – Series Revision – Maytag Electric – Timer Non-Pay G – Global – Model Type Number – Coin Drop W – White – Electronic Non-Pay...
- Page 27 DISCLAIMER OF REPRESENTATIONS OUTSIDE OF WARRANTY Maytag makes no representations about the quality, durability, or need for service or repair of this major appliance other than the representations contained in this Warranty. If you want a longer or more comprehensive warranty than the limited warranty that comes with this major appliance, you should ask your retailer about buying an extended warranty.
