4.3.3.2

Incoming cable connection units

Cable entry options
System
LX.01 to LX.02
LX.03 to LX.05
LX.06 to LX.07
Cable feeder units
Phase sequence of the busbar package for LX connection
1)
Note
Single-core cable entries
In the case of single-core cable entries, always specify the type suffix "Base plate
aluminium" LX-BPAL.
Note
Incoming cable connection units on request
Incoming cable connection units are only available on request for the following systems:
● Double systems LX.08.. to LX.10..
● Systems with conductor configurations of the key digits 30, 52, 53, 54, 61 and 62.
SIVACON 8PS - Configuring with LX system
Configuration Manual, 10/2011, A5E02194899-02
See type code 1
Max. mm
2
4 x 300
6 x 300
8 x 300
Type
1)
LX.....-KE1
LX.....-KE2
Product selection
4.3 Selection tables
Type suffix
Base plate
Aluminium
+LX-BPAL
+LX-BPAL
